Levoit LV-H128 Bedienungsanleitung

Desktop True HEPA Air Puriﬁer

Model: LV-H128

Questions or Concerns?

Please contact us Mon–Fri, 9:00 am–5:00 pm PST/PDT

at [email protected] or at (888) 726-8520.

USER MANUAL

Table of Contents

Package Contents

Speciﬁcations

Safety Information

Getting to Know Your Air Puriﬁer

Getting Started

Using Your Air Puriﬁer

Care & Maintenance

Troubleshooting

Warranty Information

Customer Support

Package Contents

1 x Desktop True HEPA Air Puriﬁer

2 x True HEPA Combination Filters

(Pre-Installed)

1 x Aroma Pad

1 x AC Power Adapter

1 x User Manual

Speciﬁcations

Rated Power 6W

Eective Range ≤ 161 ft² / 15 m²

Operating

Conditions

Temperature:

14°–104°F / -10°–40°C

Humidity: ≤ 85% RH

Noise Level 24–36dB

Dimensions 6.7 x 6.7 x 10.4 in /

17 x 17 x 26.5 cm

Weight 3.3 lb / 1.5 kg

Power Adapter Input: 100–240V~

50/60Hz, 0.2A

Output: 12V⎓ 600mA

GETTING TO KNOW YOUR AIR PURIFIER

A. Fan Speed Indicators

B. Control Button

C. Indicator Ring

D. Air Outlet

E. Housing

F. AC Power Adapter Input

G. True HEPA Combination Filters

H. Filter Cover Lock

I. Anti-Skid Pads

J. Filter Cover

Note: The Indicator Ring lights up white when the air puriﬁer is turned on, and lights up red to

remind you to check your ﬁlters (see Check Filter Indicator Light, page 8).

K. Air Inlets

L. AC Power Adapter

M. Aroma Box

N. Aroma Pad Cap

O. Aroma Pad

About the Filters

A. Fine Preliminary Filter (Pre-Filter)

•Captures large particles such as

dust, lint, ﬁbers, hair, and pet fur.

•Maximizes the life of the True

HEPA Filter by protecting it.

B. True HEPA Filter (H13 HEPA Class)

•Removes at least 99.97% of

airborne particles as small as 0.3

micrometers (µm) in diameter.

•Traps ﬁne partiles such as dust

mites,pet dander,mold spores

and pollen.

Note：Levoit air puriﬁers reduce

airborne particles 0.3 microns or

larger and make no claims to

help reduce COVID-19 viruses.

C. Activated Carbon Filter

•Physically adsorbs smoke, odors,

and fumes.

Your Levoit Desktop True HEPA Air Puriﬁer

uses 2 ﬁlters, both of which use a 3-stage

air ﬁltration system to purify air.

G E TTING S TA R TED

1. Flip over the air puriﬁer. Twist the cover

of the air puriﬁer. [Figure 1.1]

2. Take out the ﬁlters and remove the

ﬁlters from their plastic packaging.

[Figure 1.2]

Figure 1.1

Figure 1.2

GETTING TO KNOW YOUR AIR

C B A

3. Place the ﬁlters back into the air puriﬁer.

The Pre-Filter must be facing outward

and the Activated Carbon Filter must

be facing inward for both ﬁlters. Make

sure the pull tabs are visible and facing

inward. [Figure 1.3]

4. Replace the ﬁlter cover. Twist the cover

lock counter-clockwise to secure the

cover.

5. Place your air puriﬁer on a ﬂat, stable

surface with the air outlet facing up.

Leave 15 in / 38 cm of clearance on all

sides of the air puriﬁer.

6. Connect the AC power adapter to the

air puriﬁer. Plug into an outlet.

Figure 1.3

USING YOUR AIR

PURIFIER

1. Press the Control Button to turn on the

air puriﬁer. The fan will start on “SLEEP”.

2. Optionally, press the Control Button

repeatedly to change fan speed

(“SLEEP”, “LOW”, and “HIGH”), and to

turn the air puriﬁer o.

WARNING: Make sure the air outlet and the

air inlets are not blocked. This may cause

the air puriﬁer to overheat and stop working.

Note:

• Sleep Mode uses the lowest

possible fan speed for a quiet

environment.

• In Sleep Mode, the display lights

will automatically turn o after 5

seconds. Press the Control Button

again to turn the display lights back

on for 5 seconds.

Note:

• “HIGH” is the loudest fan speed, but

cleans air the quickest.

• For best results, or to address

a speciﬁc air quality issue such

as smoke, run the air puriﬁer on

“HIGH” for 15–20 minutes before

using a lower speed.

• To eectively clean air, keep

windows and doors closed while

the air puriﬁer is on.

GETTING STARTED (CONT.)

Pull tabs facing inward

Air Puriﬁer Placement

Clean Air Delivery Rate

Adding Essential Oils

Humidity

For highest eciency of air puriﬁcation,

make sure that airﬂow isn’t obstructed. To

allow air to circulate freely in and out of the

air puriﬁer, there should ideally be

15 in / 38 cm of clearance on all sides of

the air puriﬁer. Avoid placing too near a

corner or too close to a wall. Keep away

from curtains and anything that might block

airﬂow.

This air puriﬁer has a Clean Air Delivery

Rate of 70 cubic meters per hour.

Clean Air Delivery Rate (CADR) measures

the eciency of an air puriﬁer by indicating

the volume of clean air that an air puriﬁer

produces. This is based on the removal

of dust, pollen, and smoke, which are the

3 most common indoor air pollutants. The

higher the CADR, the more particles the air

puriﬁer will remove and the larger the area it

can clean. The rating is measured at the air

puriﬁer’s highest speed.

Moisture may damage the ﬁlters. This air

puriﬁer should be used in an area with a

humidity level below 85% RH. If you use the

air puriﬁer in excessively humid areas, the

surface of the ﬁlters will become moldy.

Note: Water or moisture will allow mold

to grow. To solve a mold problem, get

rid of the source of the moisture and

clean up the mold. Air puriﬁers cannot

solve an existing mold problem, only

remove airborne mold spores and

reduce odors.

Note: Do not mix essential oil blends.

Clean the aroma pad before using a

new essential oil blend (see Cleaning

the Aroma Pad, page 9).

Note: Essential oils are not included.

Essential Oils

Do not add essential oils to the ﬁlters or the

fan. The ﬁlters will be damaged by the oil

and will eventually release an unpleasant

smell. Only add essential oils to the aroma

box at the top of the air puriﬁer.

USING YOUR AIR PURIFIER (CONT.)

1. Remove the aroma box cap.

2. Add 2–3 drops of the essential oil to the

aroma pad.

3. Replace the cap.

CARE & MAINTENANCE

Cleaning the Air Puriﬁer

Note:

• For best performance, clean every

1–2 months.

• WARNING: Do not disassemble the

air puriﬁer, such as by removing any

screws. Only remove the ﬁlter cover

and replace ﬁlters as directed.

• Do not clean with detergents or

soap, as this may cause damage

or discolouration. Do not clean with

abrasive chemicals or ﬂammable

cleaning agents.

1. Unplug before cleaning.

2. Wipe the outside of the air puriﬁer with

a soft, dry cloth. If necessary, also wipe

with a damp cloth, then immediately dry.

3. Vacuum the inside of the air puriﬁer

using a vacuum hose with a crevice

attachment. [Figure 2.1]

Cleaning the Filters

The Pre-Filters should be cleaned about

once a month to increase the eciency

and extend the life of your ﬁlters. Clean

the outside of the Pre-Filter using a soft

brush or a vacuum hose with a soft brush

attachment to remove hair, dust, and large

particles. Do not clean any part of the ﬁlters

with water or other liquids.

Filter When to

Clean

When to

Replace

Pre-Filters Every 2–4

weeks

6–8 months

True HEPA

& Activated

Carbon

Filters

Do not

clean

Figure 2.1

Check Filter Indicator Light

The Control Button will light up red as a

reminder to check the ﬁlters. Depending

on how often you use the air puriﬁer, the

indicator should turn on within 6–8 months.

You may not need to replace your ﬁlters

yet, but you should check them when the

Control Button lights up red.

CARE & MAINTENANCE (CONT.)

Resetting the Check Filter

Indicator

Cleaning the Aroma Pad

Replacing the Aroma Pad

Reset the indicator light when:

A. The Control Button lights up red.

1. Replace the ﬁlters (see Replacing

the Filters, page 10).

2. With the air puriﬁer plugged in and

the fan turned o, press and hold the

Control Button for 3 seconds.

3. The red light will turn o when

successfully reset.

B. The ﬁlters were changed before the

Control Button lit up red.

3. With the air puriﬁer plugged in and

the fan turned o, press and hold the

Control Button for 3 seconds. This

will turn on the red indicator light.

4. Press and hold the Control Button

again for 3 seconds.

5. The red light will turn o when

successfully reset.

For eective aromatherapy, the aroma pad

should always be cleaned before using

a new essential oil blend. Do not mix

essential oil blends.

To clean:

1. Remove the aroma box cap.

2. Remove the aroma pad and rinse

under warm, running water.

3. Dry with a clean cloth and place it

back into the aroma box.

If the aroma pad becomes deformed or

damaged after repeated washing, it may

need to be replaced. Replacement aroma

pads can be purchased at levoit.com/shop.

Note: You cannot reset the indicator

light if the fan is on at any speed.

Note: Do not pour liquid cleaners or

detergents into the aroma pad or box.

When Should I Replace the

Filters?

You should replace your ﬁlters every 6–8

months. You may need to change your

ﬁlters sooner or later depending on how

often you use your air puriﬁer. Using your

air puriﬁer in an environment with relatively

high pollution may mean you will need to

change the ﬁlters more often, even if the

red indicator light is o.

You may need to replace your ﬁlters if you

notice:

• Increased noise when the air puriﬁer

is on

• Decreased airﬂow

• Unusual odors

• Visibly clogged ﬁlters

CARE & MAINTENANCE (CONT.)

Replacing the Filters

1. Unplug the air puriﬁer. Flip the air puriﬁer

over and remove the ﬁlter cover (see

Getting Started, page 5).

2. Remove the old ﬁlters.

3. Clean out any remaining dust or hair

inside the air puriﬁer using a vacuum

hose with a crevice attachment. Do

not use water or liquids to clean the air

puriﬁer.

4. Unwrap the new ﬁlters and place them

into the air puriﬁer (see Getting Started,

page 5).

5. Replace the cover. Plug in the air puriﬁer.

6. Reset the Check Filter Indicator light

(see Resetting the Check Filter Indicator

Light, page 9).

If not using the air puriﬁer for an extended

period of time, wrap the ﬁlters in plastic

packaging and store in a dry place to avoid

moisture damage.

Storage

Note: To maintain the performance of

your air puriﬁer, only use ocial Levoit

ﬁlters. To buy replacement ﬁlters, visit

Levoit’s online store. Go to levoit.com

for more information.

Problem Possible Solution

Air puriﬁer will not turn

on or respond to button

controls.

Plug in the air puriﬁer.

Plug the air puriﬁer into a dierent outlet.

Disconnect the AC power adapter from the air puriﬁer and

reconnect it.

Check to see if the AC power adapter is damaged. If so, stop using

the air puriﬁer and contact Customer Support (see page 14).

The air puriﬁer may be malfunctioning. Contact Customer Support

(see page 14).

Airﬂow is signiﬁcantly

reduced.

Make sure the ﬁlters are removed from their packaging and

properly in place (see Getting Started, page 5).

Press the Control Button to increase fan speed.

Leave at least 15 in / 38 cm of clearance on all sides of the air

puriﬁer.

The Pre-Filters may be clogged by large particles, such as hair

or lint, blocking airﬂow. Clean the Pre-Filters (see Cleaning the

Filters, page 8).

Replace the ﬁlters (see Replacing the Filters, page 10).

Air puriﬁer makes an

unusual noise while the

fan is on.

Make sure the ﬁlters are properly in place with plastic packaging

removed (see Getting Started, page 5).

Make sure the air puriﬁer is operating on a hard, ﬂat, level surface.

Replace the ﬁlters (see Replacing the Filters, page 10).

The air puriﬁer may be damaged, or a foreign object may be inside.

Stop using the air puriﬁer and contact Customer Support (see

page 14). Do not try to repair the air puriﬁer.

Poor air puriﬁcation

quality.

Press the Control Button to increase fan speed.

Make sure no objects are blocking the sides or top of the air

puriﬁer (the outlet or inlets).

Make sure the ﬁlters are removed from its packaging and properly

in place (see Getting Started, page 5).

Close doors and windows while using the air puriﬁer.

Make sure the room is smaller than 161 ft² / 15 m². The air puriﬁer

may not be as eective in larger rooms.

Replace the ﬁlters (see Replacing the Filters, page 10).

TROUBLESHOOTING

Andere Handbücher für LV-H128

Inhaltsverzeichnis

Andere Levoit Luftreiniger Handbücher

Levoit

Levoit Vital 100 Bedienungsanleitung

Levoit

Levoit LV-H132 Bedienungsanleitung

Levoit

Levoit Smart True HEPA Core 300S Series Bedienungsanleitung

Levoit

Levoit True HEPA Core 300-RAC Bedienungsanleitung

Levoit

Levoit VeSync Core 600S Series Bedienungsanleitung

Levoit

Levoit LV-H133 Bedienungsanleitung

Levoit

Levoit LV-H128 Bedienungsanleitung

Levoit

Levoit Classic 300S Bedienungsanleitung

Levoit

Levoit LV-H132 Bedienungsanleitung

Levoit

Levoit LV-H135-RWH Bedienungsanleitung

Levoit

Levoit LV-PUR131S Bedienungsanleitung

Levoit

Levoit LV-H134 Bedienungsanleitung

Levoit

Levoit LV-PUR131S Bedienungsanleitung

Levoit

Levoit VeSync Core Pro 400S Bedienungsanleitung

Levoit

Levoit Vista 200 Bedienungsanleitung

Levoit

Levoit LV-H132 Bedienungsanleitung

Levoit

Levoit LAP-V201S-AEUR Bedienungsanleitung

Levoit

Levoit Core 300 Bedienungsanleitung

Levoit

Levoit LV-H128 Bedienungsanleitung

Levoit

Levoit Vital 100S Bedienungsanleitung

Levoit

Levoit Core 400S Series Bedienungsanleitung

Levoit

Levoit HERA LAP-C302S-WUSB Bedienungsanleitung

Levoit

Levoit Classic 300S Bedienungsanleitung

Levoit

Levoit Tower Pro LV-H134 Bedienungsanleitung

Beliebte Luftreiniger Handbücher anderer Marken

IKEA

IKEA UPPÅTVIND Bedienungsanleitung

Nash

Nash AP-1 PureSmart Bedienungsanleitung

LG PH-U450 Series Bedienungsanleitung

DeLonghi

DeLonghi DDSX 220WFA Bedienungsanleitung

Mitsubishi Electric

Mitsubishi Electric MA-E85R-E Bedienungsanleitung

Sharp

Sharp FU-40SE Bedienungsanleitung

Philips

Philips AC2721 Bedienungsanleitung

Hitachi

Hitachi EP-A3000 Bedienungsanleitung

TruSens

TruSens Z-2000 Bedienungsanleitung

Motorola

Motorola MBP87SN Bedienungsanleitung

Beko

Beko ATP 7100I Bedienungsanleitung

Carrier

Carrier INFINITY 1620 Bedienungsanleitung

AtmosAir

AtmosAir P2002 Bedienungsanleitung

Winix

Winix NK300 Bedienungsanleitung

Friedrich

Friedrich C-90A Bedienungs- und Montageanleitung

Surgically Clean Air

Surgically Clean Air JADE2.0 Bedienungsanleitung

Base aire

Base aire 555 Pro Bedienungsanleitung

Champion

Champion CP25 Bedienungsanleitung
