Lexmark X748dte Bedienungsanleitung

Power Saver –Reduces the power state of the printer after printing –adjustable from

1-240 minutes

Scheduled Warm-up using MarkVision –Conserves energy by scheduling power

saver to engage during specified days and times during the week

Instant Warm-Up fuser –Saves energy

Eco-Mode –Conserves energy and paper through three optional settings:

Energy Saving Mode: Operator panel backlight and advance paper start are

disabled, the fuser is not continually heated, and the scanner lamps are only

activated when a scan job is started

Paper Saving Mode: Device defaults to duplex printing and the print log features

are turned off

Energy + Paper Saving Mode: Energy and paper saving settings are activated

Quiet Mode –Reduces noise emission by adjusting print speed, disabling advanced

paper start, disabling or minimizing beeps (key press, alarms, etc.), and adjusting fan

speed (Quiet mode may be combined with Eco-Mode)

Multi-Page Printing –Prints multiple page images on one page

Duplex –Prints on both sides of a page

Recycled Paper –Supports the use of recycled content media

Print and Hold –Holds print jobs until released by the user at the printer interface by

entering a pin number (Hard drive option needed)

Badge Reader Authentication –Holds print jobs until released by the user at the

printer interface by swiping an identification badge (Hard drive option and integration

services required through SPR)

Fax Redirect –Conserves paper by digitalizing faxes and redirecting to email or file

rather than printing (Hard drive option required)

Distribute Information Electronically –Conserves paper by routing scanned

documents to e-mail, network folders, USB thumb drives, FTP, and LDSS

destinations (Additional options may be required)

Toner Darkness Control –Adjusts the print darkness to conserve toner

Color Saver –Conserves toner by printing images and graphics lighter

High Yield Toner Cartridges –More toner per cartridge reduces the energy and

materials used per printed page

Lexmark X748de, X748dte

Color Multifunction Laser Printers

Design for Environment

This Lexmark product offers the following resource conserving

features:

Conscientious Material

Selection

Energy Saving

Paper Saving

Toner Saving

Waste Minimizing

(Non paper waste)

Chemical Emissions

Printer emissions testing is performed in accordance with the “Test method

for the determination of emissions from hardcopy devices with respect to

awarding the environmental label for office devices with printing function

according to RAL-UZ 122, “ BAM April 2006.

Emitted

Substance

Product Measurement

(Monochrome)

Maximum according

to Guideline (Mono)

Ozone (mg/h)

<0.06

1.5

Styrene (mg/h)

0.14

1.0

Benzene (mg/h)

<0.03

<0.05

Dust (mg/h)

<0.7

4.0

TVOC (mg/h)

0.74

Emitted

Substance

Product Measurement

(Color)

Maximum according

to Guideline (Color)

Ozone (mg/h)

<0.06

Styrene (mg/h)

0.4

1.8

Benzene (mg/h)

<0.03

<0.05

Dust (mg/h)

<0.7

4.0

TVOC (mg/h)

6.8

*Note: The print test is performed using genuine Lexmark supplies. Emissions may

vary if using non-Lexmark supplies.

Product Restricted Materials

The reduction of materials harmful to persons or the environment is a

significant part of Lexmark's commitment to continuously improving the

environmental design of all our products and services. Lexmark has

developed a multi-layered due diligence process to ensure that all

materials going into Lexmark products are safe and compliant with global

regulations regarding hazardous substances.

This product is compliant with the requirements of the European Union's

Directive 2002/95/EC on the Restriction of the Use of Certain Hazardous

Substances in Electrical and Electronic Equipment (RoHS).

This product is compliant with the requirements of the European Union’s

Registration, Evaluation, Authorization and Restriction of Chemicals

(REACH) regulation.

This product and its packaging are labeled as required by China’s

“Management Methods for Controlling Pollution by Electronic Information

Products.”

The product does not contain:

Cadmium

Hexavalent chromium

Polybrominated biphenyls

Polybrominated diphenyl ethers

Mercury

Asbestos

Short chain chlorinated paraffins

Polychlorinated phenols

Polychlorinated terphenyls

Ozone depleting chemicals (Chlorofluorocarbons (CFCs), halons, HCFCs,

HBFCs, 1,1,1-trichlorethane, carbon tetrachloride, methyl bromide)

Halogenated flame retardants in cover sets

Voluntary Environmental Certifications

This product conforms to the following voluntary

environmental program criteria:

US EPA ENERGY STAR V 1.2

BLUE ANGEL (RAL-UZ 122) (Valid until December 2012)

Recyclable Design

Mechanical plastic parts over 100g consist of one or more easily

separable materials.

Use of non-separable connections between different materials, such

as gluing or welding, has been avoided.

Product Description:

Measurements provided are for a non-

packaged product.

X748de

Weight 40.40 kg | 89.07 lbs (without cartridge)

Width 546 mm | 21.50 in

Depth 622 mm | 24.49 in

Height 787 mm | 30.98 in

X748dte

Weight 44.7 kg | 98.55 lbs (without cartridge)

Width 546 mm | 21.50 in

Depth 622 mm | 24.49 in

Height 909 mm | 35.79 in

Due to printer weight this printer requires at least three

people to lift it safely. For additional information consult

the setup guide.

Operational Data

Speed (Letter –ppm) Up to: 35 Speed (A4 - ppm) Up to: 33

Power

Printing Duplex

435 W

Printing Simplex

560 W

Ready

55 W

Sleep

11 W

Hibernate

0.5 W

Off

0 W

Typical Electricity Consumption Test

(TEC)

4.525 kwh/week

Typical Electricity Consumption Test

Eco-Mode (TEC)

3.061 kwh/week

Acoustic

Noise

Printing Simplex (mono / color)

56 dBA / 57 dBA

Printing Duplex (mono / color)

56 dBA / 57 dBA

Printing* Quiet Mode (mono / color)

49 dBA / 49 dBA

Idle

34 dBA

*Note: These measurements are subject to change

* Note: Simplex

This product contains the following in limited quantities as allowed

by regulations:

Lead (use is limited to small amounts for specific applications)

Battery Usage

This product is compliant with the 2006/66/EC Battery Directive.

The battery contained within this product does not contain cadmium,

mercury, or lead.

Battery Type: Lithium Manganese Dioxide coin cell

Weight: ~ 0.23 g

Customer removable: No

Packaging

Packaging Materials

Wood 6.505 kg

Corrugated 5.260 kg

Polyethylene Foam 2.411 kg

Paperboard 0.295 kg

High Density Polyethylene (HDPE) 0.233 kg

Polypropylene 0.065 kg

Please check the availability of municipal recycling programs in

your area that will accept these packaging materials.

Plastic packaging materials are marked according to DIN 6120, ISO

11469 or ISO 1043.

Plastic packaging is free from halogen and ozone depleting

materials.

In order to comply with the local packaging take-back requirements

in Europe, Lexmark is a member of a packaging recovery scheme.

The “Green Dot” symbol is printed on Lexmark packaging when

applicable.

End-of-Life Management/Recycling

Lexmark offers customers an environmentally responsible choice for

disposal of end-of-life printers- the Lexmark Equipment Collection

Program. Through this program, customers may return any end-of-life

Lexmark branded products, and Lexmark will recycle the equipment for

free.

Lexmark also offers customers an environmentally responsible choice

for disposal of used toner cartridges- the Lexmark Cartridge Collection

Program. The Lexmark Cartridge Collection Program diverts millions of

Lexmark cartridges from landfills annually by making it both easy and

free for Lexmark customers to return used print cartridges to Lexmark for

reuse or recycling. One hundred percent of the empty cartridges

returned to Lexmark are either reused or demanufactured for recycling.

Boxes used to return the cartridges are also recycled.

Visit www.lexmark.com/recycle for information specific to the recycling

program offered in your geography.

Lexmark fully complies with the European Union’s Waste Electrical and

Electronic Equipment (WEEE) Directive.

Product Safety

Material Safety Data Sheets are available for Lexmark Printer supplies

at: http://www.lexmark.com

Additional safety information about this product is in the User’s

Reference and at: http://www.lexmark.com

Longevity and upgrading

Standard

Standard Warranty 1 year

Extended Warranty Optional

Spare parts and service is available for a minimum of 5 years.

Information about upgrades is available online at

http://www.lexmark.com

Company Information

Lexmark International, Inc. (NYSE:

LXK) makes it easier for businesses to

move information between the digital

and paper worlds. Since our inception

in 1991 as a spin-off of IBM, Lexmark

has become a leading developer,

manufacturer and supplier of printing

and imaging solutions for offices and

homes. Lexmark’s products include

laser printers, inkjet printers,

multifunction devices and associated

supplies, services and solutions.

Lexmark Corporate Social

Responsibility (CSR) activities are

fundamentally guided by the Lexmark

vision and values –the cornerstone of

the corporate character we have built

at Lexmark. Lexmark is committed to

acting as a socially responsible

company in our global community. This

means that we will fully comply with the

laws, rules and regulations of the

countries in which we operate. It also

means that we will go further by

continually evaluating our business

practices using the principle of

sustainability.

PRODUCT ENVIRONMENTAL FEATURES

Lexmark X748de, X748dte Color Multifunction Laser Printers

Compatible with

Recycled Paper

Multifunction

Device

Anywhere

Scan to

Destination

Multi-

Page

Printing

Capability

Toner

Darkness

Control

Eco-Mode

Power Saver

Mode

Quiet Mode

Recyclable

Design

Return Program Print Cartridges

High Yield Cartridges

Free and Easy Cartridge Recycling

with the Lexmark Cartridge

Collection Program

Duplex

Capability

Andere Handbücher für X748dte

Dieses Handbuch passt für folgende Modelle

Andere Lexmark Multifunktionsdrucker Handbücher

Lexmark

Lexmark S600 Bedienungsanleitung

Lexmark

Lexmark X466DTE Bedienungsanleitung

Lexmark

Lexmark X 2600 Bedienungsanleitung

Lexmark

Lexmark CX510 series Bedienungsanleitung

Lexmark

Lexmark X543DN Bedienungsanleitung

Lexmark

Lexmark 19Z0201 - X 862dte 4 B/W Laser Bedienungsanleitung

Lexmark

Lexmark 201 Bedienungsanleitung

Lexmark

Lexmark CX431 Bedienungsanleitung

Lexmark

Lexmark X925 Bedienungsanleitung

Lexmark

Lexmark X422 Produktinformationsblatt

Lexmark

Lexmark 13B0503 - X 364dw B/W Laser Bedienungsanleitung

Lexmark

Lexmark C544N/DN/DW/DTN Bedienungsanleitung

Lexmark

Lexmark XC2132 Konfigurationshandbuch

Lexmark

Lexmark X820E Bedienungsanleitung

Lexmark

Lexmark X860 Bedienungsanleitung

Lexmark

Lexmark Pro710 series Bedienungsanleitung

Lexmark

Lexmark X1100 Series Bedienungsanleitung

Lexmark

Lexmark CX510de Bedienungsanleitung

Lexmark

Lexmark Interpret S415 Bedienungsanleitung

Lexmark

Lexmark S515 Bedienungsanleitung

Lexmark

Lexmark CX310 series Bedienungsanleitung

Lexmark

Lexmark X543DN Bedienungsanleitung

Lexmark

Lexmark MX510 Series Bedienungsanleitung

Lexmark

Lexmark X264dn Bedienungsanleitung

Beliebte Multifunktionsdrucker Handbücher anderer Marken

Triumph Adler

Triumph Adler DC 2016 Handbuch

Epson

Epson WorkForce WF-2510 Benutzerhandbuch

Epson

Epson Stylus Scan 2000 Installations- und Betriebshandbuch

Epson

Epson PictureMate Snap PM 240 Bedienungsanleitung

Konica Minolta

Konica Minolta bizhub C35 Bedienungsanleitung

Brother

Brother MFC-J430w Bedienungsanleitung

Konica Minolta

Konica Minolta BIZHUB 558 Bedienungsanleitung

Brother

Brother MFC-9760 Bedienungsanleitung

Sharp

Sharp MX-2310U Leitfaden

Aficio

Aficio 200 Bedienungsanleitung

Canon

Canon ImageCLASS 2300 Handbuch

Ricoh

Ricoh Pro C900 Bedienungsanleitung

Brother

Brother Business Smart MFC-J4510dw Bedienungsanleitung

Epson

Epson Stylus CX8400 Series Bedienungsanleitung

Oce

Oce VarioLink 5022 Bedienungsanleitung

Copystar

Copystar CS 4551ci Bedienungsanleitung

Konica Minolta

Konica Minolta Magicolor 4650EN Bedienungsanleitung

Brother

Brother MFC-9840CDW Bedienungsanleitung
