CAUTION : The laser used in the CD-R/RW drive can damage your eyes.

Do not attempt to open the cover.

To reduce the risk of electric shock, do not remove cover (or back).

No user-serviceable parts inside.

Refer servicing to qualified service personnel.

Use of controls or performance of procedures other than those specified

herein may result in hazardous radiation exposure.

WARNING : To reduce the risk of fire or electric shock, do not expose this appliance to

rain or moisture

Industry Canada requirement

This class B digital apparatus meets all requirements of the Canadian Interference-Causing

Equipment Regulations.

Cet appareil numérique de la classe B respecte toutes les exigences du Règlement sur le

matériel brouilleur du Canada.

FCC COMPLIANCE STATEMENT

Note : This equipment has been tested and found to comply with the limits for a Class B

digital device, pursuant to Part 15 of the FCC Rules.

These limits are designed to provide reasonable protection against harmful

interference in a residential installation. This equipment generates, uses, and can

radiate radio frequency energy and, if not installed and used in accordance with the

instructions, may cause harmful interference to radio communications.

However, there is no guarantee that interference will not occur in a particular installation.

If this equipment does cause harmful interference to radio or television reception,

which can be determined by turning the equipment off and on, the user is encouraged

to try to correct the interference by one or more of the following measures:

- Reorient or relocate the receiving antenna.

- Increase the separation between the equipment and receiver.

- Connect the equipment into an outlet on a circuit different from that to which the

receiver is connected.

- Consult the dealer or an Authorized Service Center for help.

• FCC WARNING

Changes or modifications not expressly approved by the party responsible for compliance

could void the user’s authority to operate the equipment.

• This CD-R/RW Drive is for use only with UL listed personal computers that have installa-

tion instructions detailing user-installation of card cage accessory.

English

This product is manufactured to comply with the radio interference requirements of

EEC DIRECTIVE 89/336/EEC, 93/68/EEC and 73/23/EEC.

CAUTION - INVISIBLE LASER RADIATION WHEN OPEN AVOID EXPOSURE TO BEAM.

VARNING-OSYNLIG LASERSTRÄLNING NÄR DENNA DEL ÄR ÖPPNAD STRÄLEN ÄR

FARLIG.

CLASS 1 LASER PRODUCT

KLASSE 1 LASER PRODUKT

LUOKAN 1 LASER LAITE

KLASS 1 LASER APPARAT

This unit uses CD-ROM discs with the following mark

When you use this unit as a CD player, use compact

discs with the following mark

This unit uses CD-R discs with the following mark.

This unit uses CD-RW discs with the following mark.

This unit uses High Speed CD-RW discs with the following mark.

WARNING: Only CD-RW drivers bearing the logo Compact Disc ReWritable High Speed can

write or erase High Speed CD-RW media.

High Speed CD-RW Media may be recognized by the same Compact Disc ReWritable High

Speed logo on the disc label or packaging material, or by the fact that it lists recording speeds of

4X to 10X, or Up to 10X

Attempted writes to High Speed CD-RW media using CD-RW drives NOT bearing the logo

Compact Disc ReWritable High Speed may result in data loss.

Recordable

ReWritable

High Speed

DirectCDTM v2.5b(s)

Introduction

Installation

Operation

Appendix

Contents

Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2

Important Precautions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3

System Environment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

Location and Function of Controls . . . . . . . . . . . . . . . . . . . 5

Installing the Drive . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

Device Drivers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

How to Use the Discs . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

Troubleshooting. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13

Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14

■PC DOS is a trademark of IBM Inc.

■MS-DOS, Windows, and Windows®95 are trademarks registered in

the United States and other countries by the Microsoft Corporation.

■The company names and product names written in this manual are

trademarks or registered trademarks of the respective companies.

DirectCDTM v2.5b(s) Introduction

Thank you for

purchasing this

CD- / W

Drive.

Package Items

Features

•Enhanced-IDE (ATAPI) interface.

•Power tray loading and ejection of disc. (The disc can also be

ejected manually.)

•The recorded CD-RW media can be played in a DVD player or a

multiread CD-ROM Player, maintaining future compatibility

•Supports Windows 95/98/2000/ME/XP & NT 4.0.

•Automatic buffer underrun error prevention technology-Super Link

•48X max Writing (CD-R), 16X Rewriting (CD-RW), and 48X max

reading(CD-ROM)*.

* Writing speed depends on capabilities of discs.

For high speed write/rewrite, you should use media labelled High

Speed Writable/ReWritable discs.

CAV technology & Optimun Write Speed control

This drive is equipped with CAV technology, so the CD-R write speed can

change in the range of 22X - 48X max according to the type of the disc.

In this optimum write control system, the drive automatically selects the

best recording speed for the inserted media.

Item Quantity

- Internal CD-R/RW Drive 1

- CD Recording Software 1

- E-IDE (ATAPI) cable 1

- Audio Cable 1

- Mounting Screws 4

- Manual for CD-R/RW Drive 1

- Manual for CD Recording Software 1

DirectCDTM v2.5b(s) Introduction

Precautions

Installation

Operation

Important Precautions

Follow these precautions when handling the drive or discs.

•Please take notice that the manufacturer of this equipment does not

offer any warranty against data loss due to inappropriate installation

or handling or direct or indirect damages.

•Please take notice that the manufacturer will bear no responsibility for

direct or indirect damages caused by the use of this product or its

malfunction.

•Please take notice that the manufacturer will bear no responsibility for

damage to data caused by this product.

•Please backup (copy) all important data as protection against data

loss.

•Avoid placing the drive in a location subject to:

- high humidity

- high temperature

- excessive dust

- mechanical vibration

- direct sunlight

We recommend using the drive in a horizontal or vertical position.

Do not install the drive at an angle.

•Don’t move the drive suddenly from a cold place to a warm one

or raise the room temperature suddenly. Condensation may occur,

causing abnormal operation.

•Make sure to remove the disc before moving the drive.

The disc may be damaged, causing data loss.

•Be careful to prevent foreign objects, such as liquids or metal, from

entering the drive. In case a foreign object enters the drive, please

consult the dealer where the drive was purchased.

•Don’t interrupt the electric power while the drive is operating.

•When connecting two IDE devices to the Primary or Secondary

connectors, make sure that the two devices are not configured as

both Master, or both Slave. If they are both set the same, Windows

may fail to run or recognize the drives.

•The total length of the IDE cable should be no more than 18 inches

(about 45 cm).

DirectCDTM v2.5b(s) Introduction

Computer

Software

System Environment

This unit can be operated in the system environment explained here.

❏ Occasionally the CD-R and CD-RW discs written by the CD-R/RW

drive cannot be read by other CD drives*.

These unreadable discs may need to be read using the CD-R/RW

drive on that did the original writing.

* The disc written using the CD-R/RW drive might not be readable by CD-ROM

drives other than Multi-read compatible (UDF compatible) CD-ROM drives.

Multiread compatible (UDF compatible) CD-ROM drives are:

1. CD-ROM drives that can read low reflectance.

2. CD-ROM drives that support Packet Write.

Install the supplied CD Recording Software before using this unit.

350MHz (or faster) Pentium (for high speed,

500MHz or faster recommended)

650MB or more free space.

(The free space needed for writing depends on

the quantity of data.)

Enhanced-IDE interface (as Primary Slave,

Secondary Master or Slave)

5.25-inch half-height bay required

+5V/+12V power socket required

Windows 95/98/2000/ME/XP, Windows NT

Workstation Ver.4.0 or later

CD-R : LG, Ricoh, Mitsubishi Chemical, Taiyo

Yuden, Fuji Film, CMC, Acer or Fusion discs are

recommended. (For 48X: CMC, SKC, Ritek,

Mitsubishi Chemical, Fuji Film, Ricoh)

CD-RW : Ricoh, Mitsubishi chemical, TDK,

Fuji

Film

, Sony discs are recommended.

System

requirements

Hard disk

Interface

Drive bay

Power

Software Required OS

CD-R, CD-RW discs

CPU

Memory Windows 95/98/ME : 64MB or greater.

Windows NT Workstation Ver. 4.0: 64MB or

greater (128MB or over recommended)

Windows 2000/XP: 128MB or greater(256MB or

over recommended)

DirectCDTM v2.5b(s) Introduction

Front Panel

ear Panel

Location and Function o Controls

READ

WRITE

12 43

1. Headphone Jack

2. Volume Control

3. Emergency Eject Hole

4. Stop/Eject Button

5. Disc Tray

6. Drive activity indicators

Two colored LEDs are used to indicate

the operation of CD-R/RW Drive.

(1) Read

The orange LED is displayed when

the spindle motor begins the spin-up

operation: accessing data, reading

data, playing Audio, and opening

or closing the tray.

(2) Write

The green LED is used during disc

writing sessions.

DIGITAL

AUDIO

ANALOG

AUDIO INTERFACEPOWER

401+5GND+12

CSM

SLA

R G L

1 2 3 4 5

1. Digital Audio Output Connector

2. Analog Audio Output Connector

3. Jumper Connector

This jumper determines whether the drive is configured as a master or slave.

Changing the master-slave configuration takes effect after power-on reset.

4. IDE Interface Connector

Connect to the IDE (Integrated Device Electronics) Interface using a 40-pin flat IDE

cable.

NOTE : Do not connect or disconnect the cable when the power is on, as this could

cause a short circuit and damage the system. Always turn the power OFF when

connecting or disconnecting the cable.

5. Power Connector

DirectCDTM v2.5b(s) Installation

Before

Installation

emoving the

Computer

Cover

Mounting the

Drive

Installing the Drive

Before installing the drive, please note the following points.

■You will need the following:

•A screw driver of a suitable size to fit the securing screws

for the drive unit.

•The manual for the computer, so you can find the mounting

positions for the IDE controller cable.

■Turn off all peripheral appliances of the computer and the computer

itself, and disconnect their power cords from the wall sockets.

■

Discharge any static electricity on your person by touching the

computer covers, etc.

Make sure all peripheral devices of the computer and the computer itself

are turned off, and then remove the cover. Refer to the manual for the

computer for details about removing the cover.

NOTE : There may be sharp edges inside the computer so take care to

avoid injury.

1. Remove the 51/4″ drive bay panel from the computer. Refer to the

manual for the computer for details.

2. Insert the drive unit into the bay. Do not apply excessive pressure to

the cables inside the computer.

3. Secure the drive with the screws provided. If there is not enough

space behind the drive, connect the IDE and other cables before

securing the drive.

NOTE : This is a general installation guide. If your PC hardware appears

different, please consult your hardware manual for installing peripheral

devices.

READ

WRITE

READ

WRITE

DirectCDTM v2.5b(s) Installation

Jumper Setup

Before installation, set the jumper on the jumper connector on the rear

panel.

The drive can be connected as the Master or Slave on an EIDE (ATAPI)

interface. When several (up to four) EIDE devices are connected, each

must be set in a unique way. Specific knowledge of hardware and

software is necessary to install the drive.

NOTE : If two peripheral devices with the same settings are both con-

nected to the Primary or to the Secondary EIDE bus, the host computer

may fail to run or may malfunction. Careful attention is necessary.

DIGITAL

AUDIO

ANALOG

AUDIOINTERFACEPOWER

401+5GND+12

CSM

SLA

RGL

R G L C S M

S L A 39

ANALOG

AUDIO

CS: Cable Select (CSEL)

SL: Slave

MA: Master

NOTE : Only one jumper should be installed on the jumper connector.

If more than one jumper is installed, the drive may malfunction or be

damaged.

Master/Slave setting is determined by jumper installation on the Jumper

Connector. The following table shows the possible jumper settings.

If you use CSEL setting, the MASTER/SLAVE setting will be made

automatically, depending on the hardware configuration.

For details refer to the manual of your computer.

Name Function

Drive set as Master

Drive set as Slave

Drive mode set by CSEL on the

host IDE interface

(Master)

(Slave)

(Cable Select)

Andere Handbücher für GCE-8480B

Dieses Handbuch passt für folgende Modelle

Inhaltsverzeichnis

Andere LG CD/CDR-Laufwerk Handbücher

LG CRD-8520B Bedienungsanleitung

LG CRD-8240B Bedienungsanleitung

LG CRD-8360B Bedienungsanleitung

LG CH12LS28 Bedienungsanleitung

LG CED-8080B - - CD-RW Drive Bedienungsanleitung

LG GCE-8320B Bedienungsanleitung

LG CRD-8522B Bedienungsanleitung

LG GCE-8523B Bedienungsanleitung

LG CRD-8480B Bedienungsanleitung

LG GCR-8521B Bedienungsanleitung

LG CRD-8241B Bedienungsanleitung

LG GCE-8480B Bedienungsanleitung

LG DRD-8120B Bedienungsanleitung

LG GCE-8320B Bedienungsanleitung

LG CRD-8322B Bedienungsanleitung

LG GCR-8523B Bedienungsanleitung

LG CED-8120B - - CD-RW Drive Bedienungsanleitung

LG CRD-8402B Bedienungsanleitung

LG GCR-8523B Bedienungsanleitung

LG CRD-8161B Bedienungsanleitung

LG GCC-4241N Bedienungsanleitung

LG GCC-4480B Bedienungsanleitung

LG GCE-8160B Bedienungsanleitung

LG BP06LU10 Bedienungsanleitung

Beliebte CD/CDR-Laufwerk Handbücher anderer Marken

Philips

Philips CDD3610 Bedienungsanleitung

QPS

QPS Que!Fire Bedienungsanleitung

Plextor

Plextor 12X-3 Leitfaden

Samsung

Samsung SN-324B Bedienungsanleitung

Teac

Teac CD-211E Bedienungsanleitung

SmartDisk

SmartDisk Firewire CD-R/W Bedienungsanleitung

Axis

Axis CD-ROM SERVER Bedienungsanleitung

Memorex

Memorex 32023234 - 52x32x52x External USB2.0 CD... Montageanleitung

Yamaha

Yamaha CD Recordable/Rewritable Drive CRW3200 Bedienungsanleitung

Sony

Sony CRX230AE Bedienungsanleitung

Sony

Sony CRX - 160E Bedienungsanleitung

Panasonic

Panasonic KX-LD742 Bedienungsanleitung

Pioneer

Pioneer BDR-S13U-X Bedienungsanleitung

Panasonic

Panasonic LK-MC606BP Bedienungsanleitung

Panasonic

Panasonic CF-VCW Series Bedienungsanleitung

Conner

Conner CFP2107 Series Bedienungsanleitung

Sony

Sony CRX-1611 Bedienungsanleitung

Plextor

Plextor 12-20C Leitfaden
