EtherFast

10/100+56K

Modem

PC Card

EtherFast Series

User Guide

is a registered trademark of Linksys. Microsoft, Windows, and the

Windows logo are registered trademarks of Microsoft Corporation.

All other trademarks and brand names are the property of their

respective proprietors.

LIMITED WARRANTY

Linksys guarantees that every EtherFast 10/100 + 56K Modem PC

Card is free from physical defects in material and workmanship

under normal use for five (5) years from the date of purchase. If

the product proves defective during this five year warranty period,

call Linksys Customer Support in order to obtain a Return

Authorization number. Warranty is for repair or replacement only.

Linksys does not issue any refunds. BE SURE TO HAVEYOUR

PROOF OF PURCHASE ON HAND WHEN CALLING. RETURN

REQUESTS CANNOT BE PROCESSED WITHOUT PROOF OF

PURCHASE.When returning a product, mark the Return

Authorization number clearly on the outside of the package and

include your original proof of purchase.

IN NO EVENT SHALL LINKSYS’ LIABILITY EXCEED THE PRICE

PAID FOR THE PRODUCT FROM DIRECT, INDIRECT, SPECIAL,

INCIDENTAL, OR CONSEQUENTIAL DAMAGES RESULTING

FROM THE USE OF THE PRODUCT, ITS ACCOMPANYING

SOFTWARE, OR ITS DOCUMENTATION. Linksys makes no war-

ranty or representation, expressed, implied, or statutory, with

respect to its products or the contents or use of this documenta-

tion and all accompanying software, and specifically disclaims its

quality, performance, merchantability, or fitness for any particular

purpose. Linksys reserves the right to revise or update its prod-

ucts, software, or documentation without obligation to notify any

individual or entity. Please direct all inquiries to:

Linksys P.O. Box 18558, Irvine, CA 92623.

FCC STATEMENT

This equipment has been tested and found to comply with the lim-

its for a Class A digital device, pursuant to Part 15 of the FCC

Rules.These limits are designed to provide reasonable protection

against harmful interference in a residential installation. This

equipment generates, uses, and can radiate radio frequency ener-

gy and, if not installed and used according to the instructions, may

cause harmful interference to radio communications. However,

there is no guarantee that interference will not occur in a particular

installation. If this equipment does cause harmful interference to

radio or television reception, which is found by turning the equip-

ment off and on, the user is encouraged to try to correct the inter-

ference by one or more of the following measures:

• Reorient or relocate the receiving antenna

• Increase the separation between the equipment or device

• Connect the equipment to an outlet other than the receiver’s

• Consult a dealer or an experienced radio/TV technician for

assistance

903

Contents

Introduction 2

Hardware Setup 4

Installing the Hardware 4

About the Software 6

Choosing IRQ and I/O Values 7

Socket and Card Services 9

Driver Setup 15

Windows 98 Setup 15

Client Setup 23

File and Printer Sharing 24

Windows 95 Setup 27

Client Setup 34

File and Printer Sharing 35

Windows NT 4.0 Setup 38

Using the EtherFast PC Card 49

Communications Software 52

Testing the Card 59

AppendixTwisted-Pair Cabling 60

LEDs 61

Troubleshooting 62

Starting Over in Windows 74

Manually Installing Network

Components in Windows 76

Specifications 78

Customer Support 80

Contents

Introduction

The EtherFast 10/100 + 56K Modem PC Card will

connect your notebook computer with any 10/100 Local

Area Network and the Internet. It’s two cards in one --

the card’s unique integrated coupler is equipped with an

auto-sensing 10/100 RJ-45 port and a standard RJ-11

telephone port built right in. Just one integrated unit

means that there’s no cables or dongles to lose!

The EtherFast 10/100 + 56K Modem PC Card comes

with everything you need to get up and running fast.

Although it’s small enough to fit in your shirt pocket,

the card includes both a 56Kbps data modem and a

14.4Kbps send/receive fax built-in. Fully Plug-and-Play

compatible for a rapid installation, the EtherFast 10/100

+ 56K Modem PC Card is optimized for 32-bit operat-

ing systems like Windows 98, WIndows 95 and NT 4.0.

A complete software suite is included, with support for

most notebook computers, Internet Service Providers,

communication software packages, faxing applications,

and dial-up programs.

Hotswapping technology lets you insert or remove the

EtherFast 10/100 + 56K Modem PC Card while your

computer is on, and a convenient low power consump-

tion rate helps to preserve your notebook PC’s battery

life.

With its professional-grade features, coupler-free

design, free software upgrades, and free, technical sup-

port, the EtherFast 10/100 + 56K Modem PC Card is

guaranteed to help you stay connected for years to

come.

Introduction

Some of the EtherFast 10/100 + 56K Modem PC

Card’s features include:

• Type II PCMCIA 56Kbps Data Modem with

14.4Kbps Send/Receive Fax

• Compatible with V.90 and K56Flex Standards.

• Versatile Modem Runs with Regular

Telephone Lines

• Internet-Ready --Runs with Most Internet, ISP,

and BBS Dial-Up Protocols

• Surf the Web while you Send or Receive

Email, and Network Data Simultaneously

• Backward Compatible with Older V.x

Standards, Slower Dialups, ISPs, and Modems

• Compatible with Windows 95, 98, and NT 4.0

• Fully Hotswappable--Insert or Remove Card

while Power is On

• Built to PCMCIA 2.1 Specifications

• Low 80mW Auto-Sleep Mode Helps Preserve

Notebook Battery Life

• Digital Line and Lightning Protection Protect

Your PC from Surges

• Free Technical Support and Software Upgrades

• 5-Year Limited Warranty

Package Contents

Before starting the installation, make sure you

received all of the following items. If any items are

missing or damaged, see your nearest Linksys dealer

for replacement parts.

• EtherFast 10/100 + 56K Modem PC Card

• Program Disk

• User Guide and Registration Card

• RJ-45 Network Cable

• RJ-11 Standard Telephone Cable

Introduction

Hardware Setup

The one-piece EtherFast 10/100 + 56K Modem PC

Card consists of both a PCMCIA-style PC Card and an

integrated cable coupler. It is different from most PC

cards that have a snap-on pigtail coupler, or “dongle”.

The integrated design means that you can take your PC

Card anywhere and you never have to worry about los-

ing or breaking your coupler.

The PC Card has two cable ports -- one for RJ-45

10/100 network connections, and one RJ-11 port for

connecting the LANmodem to a telephone line for dial-

up Internet access.

Installing the Hardware

Follow the directions below to install the 10/100 + 56K

Modem PC Card unit.

1. Turn off your PC and any devices attached to it.Your

computer may support hot swapping, which allows

PCMCIA cards to be inserted or removed while the

PC’s power is on. If this is the case, you don't need to

turn your PC off when inserting the 10/100 + 56K

Modem PC Card. If you aren’t sure whether your PC

supports this function, always turn the computer off

before inserting or removing cards.

2. Plug a standard RJ-11 telephone cable into the

10/100 + 56K Modem PC Card’s telephone plug. Next,

connect the telephone cable into a standard telephone

wall jack.

3. Connect a RJ-45 UTP cable into the PC Card’s RJ-45

port (the larger of the two ports on the coupler). The

port will automatically sense between 10Mbps and

Hardware

100Mbps connections and it will adjust the card to

operate at the correct speed. Plug the other end of the

RJ-45 cable into a hub or switch.

Remember that 100Mbps Fast Ethernet always uses

Category 5 Twisted Pair RJ-45 cabling or better.

Cables of lesser quatity and category will not work.

Be sure that your cables are free of defects and that

they do not exceed 100 meters (328 feet) in length.

4. Locate your PC's PCMCIA slot. The slot is usually

located on the side of the PC. Slide the 10/100 + 56K

Modem PC Card into the slot with the triangle on the

face of the card facing up. Make sure that the card is

seated snugly in place. If your computer has more than

one slot, insert the 10/100 + 56K Modem PC Card into

the first slot (slots are usually numbered in sequential

order starting with 0 or 1).

After verifying that the 10/100 + 56K Modem PC Card

hardware and software are working correctly, you can

always move the card to a different slot later if needed.

The hardware setup is complete.

Hardware

About the Software

The 10/100 + 56K Modem PC Card, in addition to its

drivers, requires two different kinds of software in order

to work:

• PCMCIA card and socket services, and

• communication software

PCMCIA card and socket services are special software

drivers that allow a PCMCIA card to communicate with

your computer’s PCMCIA slot. Hopefully your comput-

er came with services pre-installed by the PC’s manu-

facturer that will allow your computer to run with a

wide range of PCMCIA cards. The 10/100 + 56K

Modem PC Card was designed as a “generic” LAN and

modem card that should run right out of the box with

most services. Popular services include SystemSoft’s

CardSoft and CardWizard, Phoenix’s PCM+, and

CardWare.

If your computer doesn't have PCMCIA services, or if

you're not sure how to get yours working, the 10/100 +

56K Modem PC Card comes with generic services you

can use to get the card up and running in your comput-

er's PCMCIA slot. In order to use the services you’ll

need to edit your computer’s startup files. You’ll find

additional instructions on using PCMCIA services in

the next chapter.

Communication software allows the 10/100 + 56K

Modem PC Card to dial out from your computer over

telephone lines, connect to on-line services, tap into the

Internet, surf the web, download files, send and receive

faxes, and much more.

There are many different ways you can obtain

communication software for the 10/100 +56K Modem

PC Card.

Software

• Use virtually any Internet, modem, and/or fax soft-

ware that may have been pre-installed on your comput-

er. Most Windows 98, 95 and NT 4.0 computers have a

built-in Internet dialer program, a modem program

called Hyperterminal, and built-in fax software, all of

which are compatible with the 10/100 + 56K Modem

PC Card. Especially if you’re going to be getting on the

Internet, we highly recommend using the software that

was pre-installed on your PC for getting connected. For

more details, consult the user guide(s) that came with

your computer and Windows.

• Buy an off-the-shelf package from the computer store.

There are plenty of Internet/modem/fax packages avail-

able at affordable prices.

• Obtain a shareware or freeware communications pack-

age from the Internet. If you already have Internet

access, you might be able to locate good communcia-

tions packages at shareware sites like http://www.share-

ware.com.

If you decide to buy or obtain a third-party communica-

tions software package, make sure that it is Hayes-com-

patible, which will ensure its ability to control the

10/100 + 56K Modem PC Card with AT commands. For

more information about Hayes and AT, see page 50.

About COM Ports, IRQs, and I/O Values

Like many peripheral devices, the 10/100 + 56K

Modem PC Card uses a COM port, I/O address, and an

IRQ in your computer when it is in use.

A COM port is a serial communications port that allows

data to be exchanged with the outside world. Most PCs

have four COM ports available for you to use.

Software

Also known as an interrupt, an IRQ is a particular slice

of your computer processor’s time. Most computers

have 13 possible interrupts for you to use, numbered 3

through 15 in sequential order. You must choose an

interrupt not already in use by another device.

An I/O base address is the input/output area of your

computer's Input/Output range that the 10/100 + 56K

Modem PC Card will use for transferring data between

the modem and the PC. The I/O value you assign to the

card must not be in use by any other devices.

In most cases, a computer’s COM Ports, IRQ numbers,

and I/O addresses are paired together to make determin-

ing the values to use easier.

Plug-and-play operating systems like Windows 95 and

98 will usually assign available COM, I/O, and IRQ val-

ues to the 10/100 + 56K Modem PC Card automatically,

making the card's installation quick and easy.

If you aren’t using Windows 95 or 98, you will need to

choose COM, IRQ, and I/O values for the 10/100 +

56K Modem PC Card to use. This can usually be

accomplished by checking your Windows Control

Panel, or if you are using MS-DOS, by running DOS’s

MSD program. If you’re not sure which COM, IRQ, or

I/O values to use, start by trying COM2. If it doesn’t

work, try COM3.

In Windows NT, you can use WINMSD to find out what

settings are assigned to the modem portion of the card.

Your COM port settings may have to be manually con-

figured.

Please note that if you are using any specialized dial-up

communications software, such as software from

America Online (AOL), you must set the EtherFast

Software

Andere Handbücher für PCMLM56 - EtherFast - 56 Kbps Network

Inhaltsverzeichnis

Andere Linksys Netzwerkkarte Handbücher

Linksys

Linksys USB200HA Bedienungsanleitung

Linksys

Linksys WGA600N - Wireless-N Gaming Adapter Bridge Bedienungsanleitung

Linksys

Linksys WUSB54GR Bedienungsanleitung

Linksys

Linksys WUSB54GR Original Betriebsanleitung

Linksys

Linksys USB100TX - EtherFast 10/100 USB Network... Bedienungsanleitung

Linksys

Linksys WUSB54GS EU Bedienungsanleitung

Linksys

Linksys LINKSYS WMP300N Bedienungsanleitung

Linksys

Linksys WPC100 - Rangeplus Wireless G Pc Card Bedienungsanleitung

Linksys

Linksys CGV2W Bedienungsanleitung

Linksys

Linksys WCF11 - Wireless CompactFlash Card Type II Bedienungsanleitung

Linksys

Linksys WUSB54GSC Bedienungsanleitung

Linksys

Linksys WUSBF54G Bedienungsanleitung

Linksys

Linksys EG1032 Original Betriebsanleitung

Linksys

Linksys WCF54G - Wireless-G Compact Flash Card Bedienungsanleitung

Linksys

Linksys USB200M Original Betriebsanleitung

Linksys

Linksys Instant Wireless WUSB11 Bedienungsanleitung

Linksys

Linksys WUSBF54G Bedienungsanleitung

Linksys

Linksys FENSK05 - EtherFast Network Starter Bedienungsanleitung

Linksys

Linksys HomeLink HPN100 Bedienungsanleitung

Linksys

Linksys WCF11 - Wireless CompactFlash Card Type II Bedienungsanleitung

Linksys

Linksys LNE100M Bedienungsanleitung

Linksys

Linksys WUSB54GSC Bedienungsanleitung

Linksys

Linksys USB200M Bedienungsanleitung

Linksys

Linksys Compact USB 2.0 Bedienungsanleitung

Beliebte Netzwerkkarte Handbücher anderer Marken

FirstComm

FirstComm OBiWiFi5G Bedienungsanleitung

Sun Microsystems

Sun Microsystems Interface Adapter Bedienungsanleitung

TRENDnet

TRENDnet TU2-ETG Bedienungsanleitung

YASKAWA

YASKAWA SI-EN3 Bedienungsanleitung

Paradyne

Paradyne BitStorm 2600 IP DSLAM Bedienungsanleitung

Belkin

Belkin F5D7050 Bedienungsanleitung

3Com

3Com EtherLink 3C509B Bedienungsanleitung

TRENDnet

TRENDnet TEG-PCITX Bedienungsanleitung

Cisco

Cisco MC16E Bedienungsanleitung

Delta Electronics

Delta Electronics Braking Modules VFDB Series Bedienungsanleitung

TwinMOS

TwinMOS Booming Bedienungsanleitung

Dialogic

Dialogic Media Board DM/V1200BTEPEQ Bedienungsanleitung

Buffalo

Buffalo AirStation WLI-PCM-L11GP Bedienungsanleitung

National Instruments

National Instruments NI 9234 Bedienungsanleitung

Hama

Hama 49276 Bedienungsanleitung

Compaq

Compaq Wireless LAN 100 Bedienungsanleitung

Bose

Bose PowerMatch Dante Bedienungsanleitung

TRENDnet

TRENDnet TEG-PCITXR Bedienungsanleitung
