EtherFast®Cable/DSL Firewall Router

with 4-Port Switch/VPNEndpoint

The Linksys Instant Broadband™ EtherFast®Cable/DSL

Firewall Router with 4-Port Switch/VPN Endpoint is the

perfect solution for connecting a small group of PCs to

a high-speed broadband Internet connection or a 10/100

Ethernet backbone. The Router can be configured to limit

internal users’ Internet access based on URLs and/or time

periods—URL filtering and time filtering. For enhanced pro-

tection against intruders from the Internet, the Router fea-

tures an advanced Stateful Packet Inspection firewall.

Use the Cable/DSL Firewall Router with 4-Port Switch/VPN

Endpoint to create IPSec VPN tunnels, so you can securely

connect to the corporate server from your home office—or

any location when you’re on the road.The Router provides a

dedicated port for DMZ hosting and acts as the only exter-

nally recognized Internet gateway on your local area net-

work (LAN). With the performance and security features of

the Cable/DSL Firewall Router with 4-Port Switch/VPN

Endpoint, your network will take advantage of the Internet

while keeping its data secure.

• Protects PCs from Ping of Death,SYN Flood,LandAttacks,

IP Spoofing,and Other DoS (Denial of Service) Attacks

• Supports Up to Two IPSec Virtual Private Network (VPN)

Tunnels

• Supports URL Filtering and Time Filtering

• Blocks Java,ActiveX, and Cookies

• Easily Configurable through a Web Browser from Any

Networked PC

• Supports IPSec and PPTP Pass-Through

• Administer and Upgrade Your Router Remotely over the

Internet

• Supports Traffic and Event Logging

• Configurable as a DHCP Server on Your Network

• Administrators Can Block Specific Internal Users’ Internet

Access with Filtering

• Supports SNMP ver. 2.0 and SNMP MIB I and II

• Supports NTP (NetworkTime Protocol) for Synchronization

with Real-Time Server

• Support for PPPoE Connection

• Dedicated Port for DMZ

• NAT and Stateful Packet Inspection Firewall to

Protect Your PCs from Outside Intruders on the

Internet

• Virtual Private Network (VPN) Capabilities for

Secure Access of Remote Networks

• Supports Universal Plug-and-Play

• Dramatically Speed Up Your Network Gaming

and Multimedia Connections

• Free Technical Support—24 Hours a Day,

7 Days a Week, Toll-Free US Calls

• 1-Year Limited Warranty

Instant Broadband™EtherFast®Cable/DSL Firewall Router

with 4-Port Switch/VPN Endpoint

Model Number: BEFSX41

Connect Your Network to the Internet and

Access a Remote Network—with Security and

Peace of Mind

Features

Benefits

OOnneeSSoolluuttiioonnffoorrIInntteerrnneett

SShhaarriinngg,,VVPPNNCCaappaabbiilliittiieess,,&&

EEnnhhaanncceeddFFiirreewwaallllSSeeccuurriittyy

Instant Broadband

™

Series

diskontcomputer.com

Firma Matzner Michael

Wiener Bundesstraße 38

4061 Pasching, Austria

:: Seite 2 von 2 :: Datenblatt zum Produkt Linksys Etherfast Cable/DSL FW Router mit DC# 47186 ::

Fragen zu dem Produkt Linksys Etherfast Cable/DSL FW Router? Kein Problem - wir helfen Ihnen per eMail ([email protected]) gerne weiter!

Den aktuellen Preis und Lagerstand finden Sie online auf http://www.diskontcomputer.com/Linksys_Etherfast_Cable_DSL_FW_Router_DC_47186.html

Package Contents

Instant Broadband™

EtherFast®Cable/DSL Firewall Router

with 4-Port Switch/VPN Endpoint

• Cable/DSL Firewall Router

• OneSetupWizardCD-ROM withUserGuide

Included

• One Power Adapter

• One Fast Start Guide and Registration Card

DS-BEFSX41-041702NC JL

Linksys

17401 Armstrong Ave.

Irvine, CA 92614 USA

Sales Information (800) 546-5797

World Wide Web* http://www.linksys.com

Japan (03) 5259-5137

Philippines (632) 638-5580

Singapore 552-8998

Thailand 717-0770

United Kingdom 0870 7393939

*Visit our website for the most current contact information.

Specifications

Model Number BEFSX41

Standards IEEE 802.3, IEEE 802.3u

Protocol CSMA/CD

Ports WAN: One 10/100 RJ-45 Port

LAN: Four 10/100 RJ-45 Ports (One with

DMZ Functionality)

Cabling Type UTP Category 5 or Better

Topology Star

Speed (Mbps) WAN: 10/100 (Half Duplex)

20/200 (Full Duplex)

LAN: 10/100 (Half Duplex)

20/200 (Full Duplex)

LEDs Power, Diag, DMZ

WAN: Link/Act, Full/Col, 100

LAN: Link/Act, Full/Col, 100

Warranty 1-Year Limited

Environmental

Dimensions 7.31" x 6.16" x 1.88"

(186 mm x 154 mm x 48 mm)

Unit Weight 13.6 oz. (0.38 kg)

Power 12V DC,1000 mA

Certifications FCC Class B, CE Mark

Operating Temp. 0ºC to 40ºC (32ºF to 104ºF)

Storage Temp. -20ºC to 70ºC (-4ºF to 158ºF)

Operating Humidity 10% to 85% Non-Condensing

Storage Humidity 5% to 90% Non-Condensing
