Logitech Ultrathin Keyboard Mini Bedienungsanleitung

Setup Guide

Ultrathin Keyboard Mini

Contents

English. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3

繁體中文 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

한국어 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19

English 3

Know your product

1. Protective cover

2. iPad mini holder

3. Keyboard

4. Function keys

5. Bluetooth® light

6. Status light

7. Bluetooth connect button

8. On/O switch

9. Documentation

10. Micro-USB charging cable

Setup Guide

Ultrathin Keyboard Mini

4 5 6

4English

Set up your product

1. Turn on the Keyboard:

• Bluetooth discovery starts automatically

and continues for 15 minutes. The

Bluetooth light blinks.

• If the Status light brieﬂy turns red,

charge the batteries. For more

information, see “Charge the batteries.”

2. Make sure your iPad mini’s Bluetooth feature

is on. Select Settings > Bluetooth > On.

3. Select “Ultrathin Keyboard Mini” on the iPad

mini’s Devices menu.

4. If your iPad mini requests a PIN,

enter the code using the Keyboard

and not your iPad mini’s virtual keyboard.

After the Bluetooth connection is made, the

Bluetooth light turns on, and then it turns o.

5. Place the iPad mini landscape on the

Keyboard.

English 5

Charge the keyboard battery

1. Plug one end of the micro-USB cable into the

charging port, and the other end into a USB

port on your computer.

Alternatively, you can use a 5V USB charger,

such as that provided with your iPad mini,

providing the power output rating is at least

500mA.

The status light blinks green as the battery

charges.

2. Charge the battery until the Status light turns

solid green.

Battery information:

• A fully charged battery provides about 3

months of power when the Keyboard is used

about 2 hours a day.

• Charge the battery when the Status light

brieﬂy turns red after the Keyboard turns on.

• When not in use, turn o the Keyboard to

conserve battery power.

• The Keyboard enters sleep mode if powered

on and not used. Press any key to wake.

USB

6English

Visit Product Central

There’s more information and support online

for your product. Take a moment to visit

Product Central to learn more about your

new Keyboard.

Browse online articles for setup help, usage

tips, or information about additional features.

Connect with other users in our Community

Forums to get advice, ask questions, and

share solutions.

At Product Central, you’ll ﬁnd a wide selection

of content:

• Tutorials

• Troubleshooting

• Support community

• Online documentation

• Warranty information

• Spare parts (when available)

Go to www.logitech.com/support/

ultrathinkeyboardmini

English 7

Use your product

Product features

Home

Displays the iPad mini Home screen

Fn + 1 = Lock screen

Locks or unlocks the iPad mini

screen

Fn + 2 = Siri

Siri lets you use your voice to send

messages, schedule meetings, place

phone calls, and more

Fn + 3 = Search*

Launches the iPad mini

search function

Fn + 4 = Switch language

Switches the keyboard language

Fn + 5 = Virtual keyboard

Shows/hides the virtual keyboard

Fn + 6 = Slide show*

Fn + 7 = Previous track

Fn + 8 = Play/Pause

Fn + 9 = Next track

Fn + 0 = Mute

Fn + dash = Volume down

Fn + plus = Volume up

Fn + X = Cut

Fn + C = Copy

Fn + V = Paste

Fn + Left cursor = Select left

Selects text on the left, word

by word

Fn + Right cursor = Select right

Selects text on the right, word

by word

Fn + Space bar =

Switch applications

Note: Function keys To use, press and hold the Fn key, and then press a key listed above.

* Available only for iPad mini with iOS 6 or earlier.

8English

Status light indications

Light Description

Blinking green The battery is charging.

Solid green The battery is fully charged (100%).

Red Battery power is low (less than 10%). Recharge the battery.

Bluetooth light indications

Light Description

Blinking Fast: The keyboard cover is in discovery mode, ready for pairing.

Slow: The keyboard cover is trying to reconnect to your iPad mini.

Solid Bluetooth pairing or reconnection is successful.

Storing the iPad mini for travel

1. Lift the iPad mini from the Keyboard.

2. Rotate the iPad mini, with the screen

side down, so the Home button is

on the right.

3. Place the iPad mini on to the Keyboard. A

magnetic clip holds the iPad mini in position.

English 9

Connecting to a different iPad mini

1. Make sure the Keyboard is turned on.

2. Check that your iPad mini’s Bluetooth feature

is on. Select Settings > Bluetooth > On.

3. Press the Bluetooth Connect Button.

The Keyboard is discoverable for 3 min.

4. Select “Ultrathin Keyboard Mini” on the iPad

mini’s Devices menu.

5. If your iPad mini requests a PIN,

enter the code using the Keyboard and

not your iPad mini’s virtual keyboard.

After the Bluetooth connection is made, the

Bluetooth light turns on, and then it turns o.

6. Place the new iPad mini on the Keyboard.

Troubleshooting

The Keyboard does not work

• Press any key to wake the Keyboard from

sleep mode.

• Turn the Keyboard O and then back On.

• Recharge the internal batteries.

For more information, refer to “Charge the

batteries.”

• Re-establish the Bluetooth connection

between the Keyboard and iPad mini.

• Verify that iPad mini’s Bluetooth feature is

turned on.

• Choose “Ultrathin Keyboard Mini” from

the Devices menu on your iPad mini. The

Bluetooth light turns on after the Bluetooth

connection is made.

10 English

Battery disposal at product end of life

1. Pry o top cover of keyboard

with screwdriver.

2. Detach battery from circuit board

and remove battery.

3. Dispose of your product and its battery

according to local laws.

1 2
