2. INSTALLING COVER (Continued)
G. Swing pivot links out from clips and
attach anchors.
Pivot link attached
to anchor
H. With anchor’s post toward cover, test
placement on top of cab in fl at area between
ribs, then mark location. Repeat for opposite
side.
IMPORTA NT: Ensure 1 to 1-1/2” space
between cover and closest point on cab.
NOTE: Improper placement of anchors will
require ordering replacements. Flat area on
top of cab
Ensure 1 to
1-1/2” space
Anchor’s post
I. Release pivot link from anchor and secure in
clip on each side.
!CAUTION: Air and surface temperatures
must be above 60° F for proper adhesion.
J. Clean marked locations with alcohol pad.
K. Shake primer and squeeze at black dot to
start liquid fl ow, then prime marked locations.
Clean
marked
locations
!CAUTION: Strong magnetic pull may
cause improper placement.
L. Peel adhesive liner from anchors and
adhere to marked locations. Apply pressure
for 10 seconds, then close cover.
NOTE: After installation, cover should remain
in closed position for at least 48 hours.
During this time period, anchors bond to cab
and cover typically conforms to truck box.
Anchor
