LOOQS MB202 Bedienungsanleitung

LOOQS

MeeBox NAS MB202

User Guide

User Guide MeeBox

MeeBox and LOOQS are trademarks of RRC bv. Other trademarks are the property of their

resp. owners. Specifications subject to change without notice.

This equipment has been tested and found to comply with the limits for a Class B digital

device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide

reasonable protection against harmful interference in a residential installation. This

equipment generates, uses and can radiate radio frequency energy and, if not installed

and used in accordance with the instructions, may cause harmful interference to radio

communications. However, there is no guarantee that interference will not occur in a

particular installation. If this equipment does cause harmful interference to radio or

television reception, which can be determined by turning the equipment off and on, the

user is encouraged to try to correct the interference by one or more of the following

measures:

Reorient or relocate the receiving antenna.

Increase the separation between the equipment and receiver.

Connect the equipment into an outlet on a circuit different from that to which the

receiver is connected.

Consult the dealer or an experienced radio/TV technician for help.

iii

User Guide MeeBox

Table of Contents

Part 1 - About Your MeeBox ...................................................................................6

Safety Precautions................................................................................................................7

Specifications.........................................................................................................................8

What’s in the Box ..................................................................................................................9

Product Exterior ...................................................................................................................10

Front .............................................................................................................................................. 10

Rear............................................................................................................................................... 11

Note for Macintosh users ..................................................................................................12

Part 2 - Setting Up Your MeeBox ..........................................................................13

Connecting and turning on your MeeBox...................................................................14

Performing initial setup ......................................................................................................15

Using the Setup Wizard (Windows only) .............................................................................. 15

Using the browser-based admin interface (all operating systems)............................. 16

Adding user accounts.......................................................................................................18

Part 3 - Using Your MeeBox...................................................................................19

Using your MeeBox as a UPnP media server...............................................................20

Copying files into the media folder...................................................................................... 20

Managing the media server .................................................................................................. 21

Understanding scan options .................................................................................................. 22

Enabling/disabling the media server................................................................................... 23

Using your MeeBox as an iTunes server ........................................................................25

Enabling the iTunes server....................................................................................................... 25

Copying music to your MeeBox ............................................................................................ 25

Using your MeeBox as a network storage device.....................................................26

Accessing a share in Windows .............................................................................................. 27

Accessing a share in Mac OS X or Linux ............................................................................. 27

Mapping a share to a drive letter (Windows only) .......................................................... 28

Accessing a second internal hard drive............................................................................. 28

Using external storage devices.......................................................................................29

Using a USB drive ....................................................................................................................... 29

Using a USB memory card reader......................................................................................... 29

Page 4

User Guide MeeBox NAS

Sharing a USB printer..........................................................................................................31

Adding a shared printer to your computer ....................................................................... 31

Printing to a shared printer ..................................................................................................... 34

Managing users, groups, and shared folders .............................................................35

Why create user accounts, groups, or additional shared folders? ............................. 35

Creating, modifying, and deleting user accounts .......................................................... 36

Creating, modifying, and deleting groups ........................................................................ 37

Creating, modifying, and deleting shared folders .......................................................... 37

Using the BitTorrent client..................................................................................................39

Working with torrents ................................................................................................................ 39

Using the web photo gallery application....................................................................41

Using other preinstalled web applications ..................................................................42

Part 4 - Advanced Topics......................................................................................44

Accessing your MeeBox remotely .................................................................................45

Setting up port forwarding on your router.......................................................................... 45

Using the web file browser ...................................................................................................... 46

Accessing files on your MeeBox remotely using FTP........................................................ 46

Accessing files on your MeeBox remotely using Secure FTP ......................................... 48

Setting up a website ..........................................................................................................50

Uploading website files to the server ................................................................................... 50

Editing web server configuration files .................................................................................. 51

Adding a second internal hard drive ...........................................................................52

Installing the second hard drive............................................................................................ 52

Verifying and formatting the second hard drive ............................................................. 53

Creating a RAID array.............................................................................................................. 54

Managing storage devices .............................................................................................56

Viewing storage reports .......................................................................................................... 56

Using the disk utility ................................................................................................................... 56

Managing a RAID array........................................................................................................... 57

Updating your MeeBox’s software.................................................................................59

Accessing your MeeBox’s command line interface.................................................61

Executing commands with elevated privileges ............................................................... 62

Page 5

User Guide MeeBox NAS

Product Registration...........................................................................................................63

Warranty................................................................................................................................64

Copyright ..............................................................................................................................67

Licensing................................................................................................................................68

About Your MeeBox

Congratulations on acquiring your MeeBox NAS, the most

versatile media server in the world.

Before you begin using your new MeeBox, please read the

following pages to familiarize yourself with important facts

about the product.

Part 1

Page 7

User Guide MeeBox NAS

Safety Precautions

Please read these safety instructions and precautions carefully before using your MeeBox.

Use a grounded electrical outlet.

Place the server where there is good ventilation. There should be at least three

inches of clearance on all four sides.

Do not place the server where it could be exposed to high temperature or direct

sunlight.

Do not put wet or heavy objects on top of the server.

Do not install or leave the server, its power cable, or LAN cables in areas of heavy

foot traffic.

Do not install the server in areas of high humidity (bathrooms and areas exposed to

rain or splashing water).

Keep the server out of reach of infants and young children.

Use only good quality cables.

Place the server on a level and stable surface.

Page 8

User Guide MeeBox NAS

Specifications

Product name:

LOOQS MeeBox NAS MB202

Storage:

One or two 3.5" SATA hard disk drives

Processor:

300-MHz ARM9 32-bit RISC CPU w/ 24KB L1 cache

Memory:

128 MB DDR SDRAM / 16 MB Flash ROM

Network interface:

Gigabit Ethernet

Expansion ports:

2 x USB 2.0 (support drives, printers, memory card readers)

External drive

support:

FAT32, NTFS, XFS, ext2, ext3

Internet services:

HTTP, WebDAV, FTP, SFTP, Telnet, SSH, POP, SMTP, Samba,

OpenVPN

Dimensions:

40mm x 435mm x 210mm HWD

Weight:

2.5kg (lbs) with 1 HDD

Power:

Adapter input: 90–200V AC, 50/60 Hz

Adapter output: 12V DC, 3A

Max power consumption: 24W

Certifications:

FCC Class B, CE, MIC Class B

Operating

temperatures:

0°–40° C (32°–104° F)

Page 9

User Guide MeeBox NAS

What’s in the Box

MeeBox media server

AC adapter

power cord

Ethernet cable

Mounting screws for second internal drive (except two-drive models)

Setup CD

User Guide

Quick Start Guide

Page 10

User Guide MeeBox NAS

Product Exterior

Front

Power Button

Press to turn your MeeBox on. Press and hold for at least

one second to turn your MeeBox off.

HDD Activity Indicator

Blinks when the internal hard drive is being accessed.

USB Status Indicator

Lights up when a USB device is attached.

Network Status Indicator

Blinks when there is network activity.
