Lucci decor DION 2 LIGHT Bedienungsanleitung
Installation Instructions
1 | P a g e v 1 . 1 ( 01/ 2 0 2 1 )
DION 2 LIGHT TABLE LAMP
SKU# 270432
Rated Voltage 220-240V~ 50Hz
Thank you for purchasing this quality Lucci product. To ensure correct function and safety, please read and follow all
instructions carefully before assembly, installation and use of this product. Please keep the instructions for future reference.
Warranty
•This portable luminaire is covered by a 12-month warranty valid for in-store replacement or refund only.
•The warranty period starts from the date of purchase. Please retain the proof of purchase.
•Warranty will be void if there is any damage due to improper usage or modification to the portable luminaire.
•Failure to comply with the instructions in this manual may increase the risk of damage or injury and will void the
warranty.
Installation Requirements
•Select a suitable location for this portable luminaire:
- Ensure it is on a flat and stable surface.
- This portable luminaire is suitable for indoor use only.
- Do not place flammable material near or over the portable luminaire.
- Ensure the portable luminaire is not installed in direct line of an air vent/system.
- If the portable luminaire is placed in an area prone to moisture, ensure that the area is well ventilated, and an
appropriately rated exhaust fan is used if required. Damage or corrosion caused by moisture is not a product
fault, and as such is not covered under warranty.
•Do not exceed the maximum wattage rating. Max. 30W for SES/E14 globe and Max. 5W LED for G9 lamp.
Frosted globes are recommended, otherwise shadowing will occur.
•Take care not to pull any electrical wires during unpacking as this may damage the connection.
•Lay out all the components on a smooth surface and make sure no components are missing before assembling.
If parts are missing, return the complete product to the place of purchase for inspection or replacement.
•Check whether the luminaire has been damaged during transport. Do not operate/install any product which appears
damaged in any way. Return the complete product to the place of purchase for inspection, repair or replacement.
•Do not plug into the mains power socket-outlet before or during assembly. Only do so after the portable luminaire is
fully assembled with the globe installed and is ready to use for the first time.
Installation Instructions
2 | P a g e v 1 . 1 ( 01/ 2 0 2 1 )
Installation Directions
1. Remove all packaging material from the portable luminaire and the lamp shade.
2. Carefully remove the body (E), by loosening the lamp holder ring (C) and spacer (D) from the lamp holder (G).
3. Install a LED lamp (H - not included) into the internal G9 lamp holder (I). Do not exceed the maximum wattage rating.
Frosted globes are recommended, otherwise shadowing may occur.
NOTE: G9 LED lamp must be used with this luminaire.
4. Carefully install the body (E) onto the base (J).
NOTE: Ensure the cord is routed through the notch (F) on the body (E). Ensure the base (E) does not squash
or damage the cord.
5. Install the spacer (D) onto the top of the base (E), followed by the shade (A) and secure with the lamp holder ring (C).
6. Install a SES/E14 globe (B - not included) into the external SES/E14 lamp holder (G). Do not exceed the maximum
rated wattage. Frosted globes are recommended, otherwise shadowing will occur.
7. Select a suitable location for the portable luminaire. See the installation requirements above.
8. Insert the plug (L) into the mains power socket outlet and ensure it is fully plugged in.
9. Turn the power on at the mains power socket outlet.
10. Use the cord line switch (K) to turn the portable lamp on/off.
Installation Instructions
3 | P a g e v 1 . 1 ( 01/ 2 0 2 1 )
Safety Tips
•Always ensure the power is OFF and the portable luminaire has cooled down before performing any maintenance,
cleaning, changing the globe or making any adjustment to the portable luminaire.
•The external flexible cable or cord of this luminaire cannot be replaced; if the cable or cord is damaged, the luminaire
shall be destroyed.
•Young children should be supervised to ensure that they do not play with the portable luminaire.
•Handle the portable luminaire and shade with care to avoid any damage or breakage.
•Select a suitable location away from liquids and hazards.
•To clean, wipe with a soft damp cloth. Do NOT soak or immerse the product in water or other liquids.
•Ensure that the fitting does not come in contact with corrosive chemicals/solvents or abrasive cleaners etc.
Specifications
SKU #
270432
Rated Voltage
220-240V~ 50Hz
Rated Wattage
& Lamp Holder
35W Max.
30W Max. SES/E14 globe – External lamp holder
5W Max. G9 LED lamp – Internal lamp holder
(Frosted globes are recommended, otherwise shadowing will occur)
Weight
3.7kg
Dimensions
H:385mm Dia:300mm
