INSTALLATION INSTRUCTIONS AND PARTS LIST

APPLICATION: MODEL 401529 W2W GRIP STEP BRACKETS ON:

2015+ FORD F150 PICKUPS

NO DRILL APPLICATION

1. READ INSTRUCTIONS COMPLETELY AND CHECK TO MAKE SURE THAT ALL REQUIRED PARTS

(LISTED ON SERVICE PARTS LIST) ARE ON HAND BEFORE STARTING THE INSTALLATION.

2. ON THE LEFT SIDE OF THE VEHICLE INSTALL TWO 1.5” ISOLATOR WASHERS (ITEM #3), THE STEP

MOUNTING BRACKET (ITEM #2) AND TWO M8-1.25 FLANGE NUTS (ITEM #4) OVER THE FACTORY

PROVIDED STUDS ON THE INSIDE OF THE ROCKER PANEL AS SHOWN.

3. REPEAT STEP 2 FOR THE REAR BRACKET.

4. CHECK THAT THE FRONT AND REAR BRACKETS ARE LEVEL AND TIGHTEN ALL FLANGE NUTS.

NOTE: IF INSTALLING ON A REGULAR CAB PICKUP SKIP TO STEP #10.

5. REMOVE THE CENTER BODY MOUNT BOLT AND INSTALL THE CENTER INBOARD MOUNTING

BRACKET (ITEM #10) AS SHOWN IN FIGURE 1.

6. USING THREE 3/8”-18 X 1.0” HEX BOLTS (ITEM #5) THREE 3/8” FLAT WASHERS (ITEM #6) AND

THREE 3/8”-18 FLANGE NUTS (ITEM #7) ATTACH THE OUTBOARD BRACKET (ITEM #11) TO THE

INBOARD BRACKET (ITEM #10). ADJUST THE HEIGHT TO MATCH YOUR STEP BOARD AND

TIGHTEN BOLTS.

7. ASEMBLE THE LOAD REACTION STUDS AND HARDWARE (ITEMS #6-9) AS FOLLOWS.

7.1. ON THE SHORT THREADED END OF THE LOAD REATION STUD (ITEM #9), INSTALL A 3/8”

FLANGE NUT (ITEM #7) BACKWARDS ONTO THE BOTTOM OF THE THREAD. THEN INSTALL A

3/8” FLAT WASHER (ITEM #6) AND RUBBER CUSHION WASHER (ITEM #8) TIGHT UP AGAINST

THE FLANGE NUT. (THE END OF THE STUD MUST BE RECESSED IN THE RUBBER WASHER

APPOX. 3/16”)

7.2. ON THE LONG THREADED END OF THE STUD, INSTALL A 3/8” FLANGE NUT (ITEM #7)

BACKWARDS TO NEAR THE BOTTOM OF THE THREADS.

8. CHECK THAT THE CENTER BRACKET IS PERPENDICULAR TO THE BODY OF THE VEHICLE AND

TIGHTEN THE BODY MOUNT BOLT PER THE MANUFACTURES SPECIFICATIONS.

9. INSTALL THE LOAD REACTION STUD INTO THE CENTER INBOARD BRACKET (ITEM #10) AS

SHOWN IN FIGURE 1 AND ADJUST THE INBOARD NUT SO THAT THE RUBBER CUSHION WASHER

IS SNUG UP AGAINST THE FRAME OF THE VEHICLE. INSTALL A 3/8” FLANGE NUT (ITEM #7) ON

THE OUTBOARD SIDE OF THE STUD AND TIGHTEN TO 19 LB-FT.

10. REMOVE THE CABLE GUIDE BRACKET FROM THE LEAF SPRING SHACKLE. NOTE: THIS IS ONLY

NECESSARY ON THE LEFT (DRIVERS) SIDE OF THE VEHICLE. THE CABLE GUIDE BRACKET

WILL NO LONGER BE NEEDED AND MAY BE REMOVED.

11. REMOVE THE NUT ON THE SPRING SHACKLE BOLT AND INSTALL THE REAR INBORAD BRACKET

(ITEM #12) AS SHOWN IN FIGURE 2. MAKE SURE THE INBOARD BRACKET IS VERTICAL AND

TIGHTEN TO 80 LB-FT.

552830 SHEET 1 OF 3 16FEB15

12. USING TWO 5/16-18 X 1” BOLTS (ITEM #17) TWO 5/16 FLAT WASHER (ITEM #16) AND TWO 5/16-18

FLANGE NUTS (ITEM #18) INSTALL THE OUTBOARD BRACKET (ITEM #14) AS SHOWN IN FIGURE 2.

NOTE: LEAVE THIS BRACKET LOOSE AT THIS TIME.

13. ATTACH THE STEP BOARD TO THE MOUNTING BRACKETS AS DESCRIBED IN THE INSTRUCTION

SHEET INCLUDED WITH YOUR STEP BOARD ASSEMBLY.

14. ADJUST THE REAR OUTBOARD BRACKET FOR YOUR STEP ASSEMBLY AND TIGHTEN THE BOLTS

SECURING THE OUTBOARD BRACKET TO THE INBOARD BRACKET.

15. USING A 5/16-18 X 1” BOLT (ITEM #17) A 5/16 FLAT WASHER (ITEM #16) AND A 5/16-18 FLANGE

NUT (ITEM #18) INSTALL THE REAR CLAMP BRACKET (ITEM #15) OVER THE CABLES FROM STEP

10 ON TO THE REAR INBOARD BRACKET.

16. REPEAT STEPS 2 – 15 FOR THE RIGHT SIDE OF THE VEHICLE.

SERVICE PARTS LIST

ITEM PART NO. QTY DESCRIPTION

1 1 STEP ASSY, GRIP STEP

2 552845 4 BRACKET-MTG, GRIP STEP, 401521

3 108442 8 WASHER – NYLON, .36” X 1.5” X .032” BLACK

4 105859 8 NUT- FLANGE, M8-1.25, ZP

5 100040 6 BOLT-HEX HD, 3/8”-16 X 1.00”, ZP

6 100062 8 WASHER-FLAT, 3/8”, ZP

7 106995 12 NUT-FLANGE, 3/8”-16, ZP

8 102592 2 WASHER-RUBBER, .354 X 1.0 X .75

9 104673 2 STUD-DBL END, 3/8”-16 X 5”

10 552843 2 BRKT-MTG, CTR, INBOARD, 401529

11 552844 2 BRKT-MTG, CTR, OUTBOARD, 401529

12 552832 1 BRKT-MTG, REAR, W2W, INBOARD, LH, 401592

13 552833 1 BRKT-MTG, REAR, W2W, INBOARD, RH, 401529

14 552125 2 BRKT-MTG, REAR, W2W, OUTBOARD, 401529

15 552754 1 BRKT-CLAMP, W2W, 401529/571529

16 106998 5 WASHER-FLAT, .375X.875X.083, BZP

17 106997 5 SCR-HEX, 5/16-18 X 1.0”, BZP

18 106996 5 NUT-FLANGE, 5/16-18, BZP

552830 SHEET 2 OF 3 16FEB15
