Luxul XAP-310 Bedienungsanleitung

Simply Connected

Quick Install Guide

XAP-310

Standard Power Wireless 300N

Low Proﬁ le Access Point

Use the XAP-310 to:

Deliver Cost-effective Multi-AP

Wi-Fi Coverage

Create a Secure Guest Network

Improve Data Rates with Multi-Stream

Wireless 802.11n Technology

Optimize VoIP, Streaming Media and

Other Demanding Applications

Simplify Wi-Fi Installation while

Minimizing Setup Time and Costs

Minimize Unsightly Cables and Equipment

Quick Install Guide

XAP-310

14203 Minuteman Drive, Suite 201, Draper, UT 84020-1685 | luxul.com | 801-822-5450

LUX-QIG-XAP-310 029150954

Quick Install Guide

Model Number: XAP-310

Wireless 300N Low Proﬁle Access Point

FCC ID: W59XAP310

IC: 8584A-XAP310

No part of this publication may be modiﬁed or adapted in any way, for any

purposes without permission in writing from Luxul. The material in this manual

is subject to change without notice. Luxul reserves the right to make changes to

any product to improve reliability, function, or design. No license is granted, either

expressly or by implication or otherwise under any Luxul intellectual property rights.

An implied license only exists for equipment, circuits and subsystems contained in

this or any Luxul product.

DOCUMENT CONVENTIONS

These graphical alerts are used in this document to indicate notable situations:

NOTE: Tips, hints, or special requirements that you should take note of.

CAUTION: Care is required. Disregarding a caution can result in data

loss or equipment malfunction.

WARNING!: Indicates a condition or procedure that could result in

personal injury or equipment damage.

FCC COMPLIANCE

This device complies with Part 15 of the FCC Rules. Operation is subject to the

following two conditions: (1) this device may not cause harmful interference, and

(2) this device must accept any interference received, including interference that

may cause undesired operation.

CONTACT LUXUL

Sales

P: 801-822-5450

E: [email protected]

Technical Support

P: 801-822-5450

E: [email protected]

Simply Connected

Other trademarks and registered trademarks are the property of their respective owners

PACKAGE CONTENTS

The following items should be included in the box:

One: XAP-310 Wireless AP

One: Mounting Bracket and Hardware

One: PoE Injector and Power Cord

One: Ethernet Cables

One: Quick Install Guide

NOTE: If any of the listed items are missing or damaged, please contact

the reseller from whom you purchased for return/replacement.

HARDWARE DESCRIPTION

XAP-310 LED

XAP-310 front LED

XAP-310 LED Indicators

Name Status Function

Power On The XAP-310 is powered and working properly.

Off The XAP-310 is not receiving power or the LED has been

turned off in the AP’s software interface.

Blinking The XAP-310 is booting up.

XAP-310 Rear Ports

XAP-310 Rear Ethernet port

Quick Install Guide

XAP-310

14203 Minuteman Drive, Suite 201, Draper, UT 84020-1685 | luxul.com | 801-822-5450

LUX-QIG-XAP-310 029150954

PoE Injector LED Indicators

Name Status Function

PWR On Power is connected to the injector

Off Injector is not receiving power

PREPARING FOR INSTALLATION

System and Power Requirements

Computer with supported Web browser. Minimum supported web browser

versions include: I.E. 9.0, Firefox 7, Safari 5.0, Chrome 14 and up. The Web browser

is used to conﬁ gure the XAP-310.

The POE injector power supply requires AC100V ~ 240V, 50Hz ~ 60Hz.

XAP-310 INSTALLATION

Access Point Placement

The XAP-310 access point is designed for simple and efﬁ cient installation and

setup. It can be mounted on the ceiling, wall or placed on a desktop or other ﬂ at

surface. Because the signal generated by the XAP-310 is omnidirectional, the unit

should be mounted on a ceiling or wall directly in the center of the desired cover-

age area.

XAP-310 Coverage Pattern

Ceiling and Wall Mounting

The XAP-310 comes with a square mounting bracket to mount it to the wall or

ceiling. Use the Mounting Pattern (Page 6-7) for mounting bracket alignment.

Simply Connected

Other trademarks and registered trademarks are the property of their respective owners

XAP-310 mounted on a ceiling XAP-310 mounted on a wall

Desktop Installation

Place on any ﬂ at surface

XAP-310 on a desktop or ﬂ at surface

Connecting the Ethernet Cable

With the XAP-310 properly mounted, you can now plug the Ethernet Cable into the

RJ-45 connector.

NOTE: Category-5, super Category-5 or Category-6 unshielded twisted

pair (CAT5/CAT5e/CAT6 UTP) cables can be used. For best

results, it is recommended that Category-6 shielded twisted pair

be used to ensure stable data transmission at highest data rates.

Connecting to the Power Source

The XAP-310 is PoE ready and supports 802.3af PoE. A PoE injector is included with

the device. To apply power, simply connect the opposite end of the Ethernet

cable to which the access point is already connected to the provided PoE injector

or other PoE switch or injector. An Ethernet cable length of up to 300 feet can be

used. DO NOT yet apply power to the PoE injector or switch.

MOUNTING PATTERN

Quick Install Guide

XAP-310

14203 Minuteman Drive, Suite 201, Draper, UT 84020-1685 | luxul.com | 801-822-5450

LUX-QIG-XAP-310 029150954

PoE Injector Setup

Data In: Connect an Ethernet cable from your router or switch

to the Data In port of the included PoE Injector

Data & PWR Out: Connect an Ethernet cable from the Data & PWR Out

port of the included PoE Injector to the PoE Port of the XAP-310

AC Power: Connect the included AC Cord to the Power Input of the Included

Injector ﬁrst and then to the AC outlet.

NOTE: The XAP-310 is not a router and will need to be connected to a

network with a router in order to deliver Internet access.

Power

Source

POE

Injector

From your

Router or Switch

XAP-310

DATA IN

DATA &

PWR OUT

The PoE Injector combines power and data to the XAP-310

CAUTION: Because the XAP-310 is a High-Powered access point it is

normal for it to be warm to the touch

NOTE: The XAP-310 is designed to work with any 802.3af power

source.

NOTE: The XAP-310 can also be powered by direct AC power. Contact

Luxul to purchase an AC Power Adapter.

Simply Connected

Other trademarks and registered trademarks are the property of their respective owners

CONFIGURATION

Default IP Address

The XAP-310 is not equipped with an internal DHCP server. If connected to a Luxul

Router, conﬁguration will be automatic. Otherwise, the IP address of the computer

for login and conﬁguration will need to be manually conﬁgured. The table below

lists the default parameters of the XAP-310.

Parameter: Default Value

Default IP address: 192.168.0.10

Default user name: admin

Default password: admin

The Luxul XAP-310 default IP addresss is 192.168.0.10. If the IP address of your router is

not set to the 192.168.0.X network, a temporary static IP address must be set on the

computer being used for conﬁguration. To do so, set the IP address of the com-

puter to the 192.168.0.X range and then use the default IP address of your XAP-310

as the Gateway/Router. Once conﬁgured, set the computer IP conﬁguration back

to “Obtain Automatically/DHCP.”

NOTE: Go to http://luxul.com/how-to-videos for videos about

changing the IP address of your Operating System.

Connect a Client Device

Connecting a Wireless Client Device: Connect the client device to the XAP-310

default wireless network Luxul310. Wireless network will run in Open Security

mode. A passphrase is not required until Wireless Security is conﬁgured.

Connecting an Ethernet Device: Use Ethernet cable to connect your computer

or device to one of the XAP-310 LAN ports.

1. Open a Web browser, and enter 192.168.0.10. The access point login screen

will appear.

2. Enter the user name and password (default user name and default password

are both set as “admin”), and then click “OK” to login to the access point

conﬁguration interface.

Quick Install Guide

XAP-310

14203 Minuteman Drive, Suite 201, Draper, UT 84020-1685 | luxul.com | 801-822-5450

LUX-QIG-XAP-310 029150954

ADVANCED SETTINGS

For advanced settings information go to luxul.com

WARNINGS AND SAFETY INFORMATION

Verify that the electrical circuits have appropriate grounding and overload protection.

Attach only approved power cords to the device.

Verify there is adequate ventilation around the device, and that ambient temperatures meet

equipment operation speciﬁcations.

The XAP-310 is designed for indoor use only. DO NOT place this outdoors.

DO NOT install in or near hot or humid places, such as a kitchen or bathroom. Take care to

minimize exposure to excessive heat or moisture.

Small parts and plastic bags used for packaging may be harmful to small children. KEEP All

ACCESSORIES OUT OF THE REACH OF CHILDREN!

The XAP-310 may become hot when in use for extended time periods. This is normal and is not a

malfunction. DO NOT install where it will be exposed to paper, cloth or other ﬂammable materials.

REGULATORY COMPLIANCE

The device complies with internationally recognized standards covering human exposure to elec-

tromagnetic ﬁelds from radio devices. This equipment also complies with FCC radiation exposure

set forth for an uncontrolled environment. In order to avoid the possibility of exceeding the FCC

radio frequency exposure limits, human proximity to the antenna shall not be less than 20 cm (8

inches) during normal operation.

Unauthorized antennas, modiﬁcations, or attachments could cause damage and may violate regula-

tory approvals. Any changes or modiﬁcations not expressly approved by the party responsible for

compliance could void the authority to operate the equipment.

The equipment version marketed in the U.S. is restricted to usage of channels 1-11 only.

Health and Safety Recommendations

Warnings for the use of Wireless Devices: Please observe all warning notices with regard to the

usage of wireless devices

Potentially Hazardous Atmospheres: You are reminded of the need to observe restrictions on the

use of radio devices in fuel depots, chemical plants etc. and areas where the air contains chemicals

or particles (such as grain, dust, or metal powders).

Safety in Hospitals: Wireless devices transmit radio frequency energy and may affect medical

electrical equipment. When installed adjacent to other equipment, it is advised to verify that the

adjacent equipment is not adversely affected.

RF Exposure Guidelines

Safety Information: The device complies with internationally recognized standards covering

human exposure to electromagnetic ﬁelds from radio devices.
