DC VOLTAGE INPUT MODULE

(8 points, non-isolated) MODEL R3-SV8N

INSTRUCTION MANUAL

BEFORE USE ....

Thank you for choosing M-System. Before use, please check

contents of the package you received as outlined below.

If you have any problems or questions with the product,

please contact M-System’s Sales Ofﬁce or representatives.

■ PACKAGE INCLUDES:

DC voltage input module ............................................. (1)

■ MODEL NO.

Conﬁrm Model No. marking on the product to be exactly

what you ordered.

■ INSTRUCTION MANUAL

This manual describes necessary points of caution when

you use this product, including installation, connection and

basic maintenance procedures.

POINTS OF CAUTION

■ CONFORMITY WITH EC DIRECTIVES

• The equipment must be mounted inside the instrument

panel of a metal enclosure.

• The actual installation environments such as panel con-

ﬁgurations, connected devices and connected wires may

affect the protection level of this unit when it is integrated

in a panel system. The user may have to review the CE

requirements in regard to the whole system and employ

additional protective measures to ensure CE conformity.

■ HOT INSERTION/REMOVAL OF MODULES

Removing or replacing modules does not affect other mod-

ules on the same backplane. It is possible to replace them

without removing the power supply. However, replacing

multiple modules at once may greatly change line voltage

levels. We recommend that you replace them one by one.

■ ENVIRONMENT

• Indoor use

• When heavy dust or metal particles are present in the air,

install the unit inside proper housing with sufﬁcient ven-

tilation.

• Do not install the unit where it is subjected to continuous

vibration. Do not subject the unit to physical impact.

• Environmental temperature must be within -10 to +55°C

(14 to 131°F) with relative humidity within 30 to 90% RH

in order to ensure adequate life span and operation.

■ WIRING

• Do not install cables (power supply, input and output)

close to noise sources (relay drive cable, high frequency

line, etc.).

• Do not bind these cables together with those in which

noises are present. Do not install them in the same duct.

■ UNUSED INPUT CHANNELS

Set the unused channels to -10 – +10V range. Otherwise, set

them as “Unused” with PC Conﬁgurator software: R3CON.

Unused channels left open with other settings are equal to

the input lower than -15%, which sets a data abnormality at

the PLC or the host device.

■ AND ....

The unit is designed to function as soon as power is sup-

plied, however, a warm up for 10 minutes is required for sat-

isfying complete performance described in the data sheet.

INSTALLATION

Use the Installation Base (model: R3-BSx).

R3-SV8N

P. 2 / 3EM-8403 Rev.2

■ STATUS INDICATOR LED

RUN indicator: Bi-color (red/green) LED;

Red when the bus A operates normally;

Green when the bus B operates normally;

Amber when both buses operate normally.

ERR indicator: Bi-color (red/green) LED;

Red with the input circuit abnormality (AD

converter response failure);

Green in normal operating conditions.

■ SIDE DIP SW

• Input Range: SW1, SW2 (selectable per 4 channels)

INPUT 1 through INPUT 4 (SW1)

RANGEINPUT 5 through INPUT 8 (SW2)

1 2 3 4

OFF OFF OFF OFF -10 – +10V (*)

ON OFF OFF OFF -5 – +5V

ON ON OFF OFF 0 – 10V

OFF OFF ON OFF 0 – 5V

ON OFF ON OFF 1 – 5V

• Conversion Rate: SW3

SW CONVERSION RATE

100 ms (*)50 ms 20 ms 10 ms

SW3-1 OFF ON OFF ON

SW3-2 OFF OFF ON ON

(*)Factory setting

SW1SW2

SW3

■FRONT VIEW ■SIDE VIEW

ERR LED

RUN LED

Conv.

Rate Range

Input 1-4 (SW1)

Input 5-8 (SW2)

Functions

COMPONENT IDENTIFICATION

R3-SV8N

P. 3 / 3EM-8403 Rev.2

WIRING INSTRUCTIONS

■ SOLDERLESS TERMINAL mm (inch)

Refer to the drawing below for recommended ring tongue

terminal size. Spade tongue type is also applicable. Solder-

less terminals with insulation sleeve do not ﬁt. Applicable

wire size: 0.3 – 0.5 mm2

3.2 (.13) dia.

4 min.

(.16)

12 (.47) max.

6 max.

(.24)

3 (.12) max.

130 (5.12)

27.5 (1.08) 109 (4.29) POSITIONING

GUIDE

TERMINAL

COVER

20–M3

SCREW

6.2

(.24)

INTERNAL POWER

BUS A

BUS B*

*For dual redundant communication.

BUS CONNECTOR

INPUT 1

INPUT 2

INPUT 3

INPUT 4

INPUT 5

INPUT 6

INPUT 7

INPUT 8

COM

■ DIMENSIONS mm (inch)

■ CONNECTION DIAGRAM

TERMINAL CONNECTIONS

Connect the unit as in the diagram below.
