SRM150 COMPACT ACTIVE
PA SYSTEM
FEATURES:
■Extremely portable powered loudspeaker system
■Built-in Mackie mixer with superior sound quality with:
•3-channelmixerwith3-bandactiveEQ
•Twohigh-headroomMackiemic/linepreampswith
48V phantom power
•Instrument-readyinput(noDIrequired)
•
Dedicatedstereochannelforkeyboards,CD,MP3,etc.
•Combo“linein”forlinkingoraddinginputs
•XLR“thru”withmic/lineswitchforlinkingmore
SRM150sordirectsendtomainPA
■ 150WPeakofhighoutput,ClassDpower
■ 5.25"premiumquality,full-rangeneodymiumdriver
■ Frequencyresponse:100Hzto17.5kHz
■ 120dBmaximumSPLpeak@1meter
■ Completesystemprotectionwithbuilt-inlimiter
■Built-in carry handle on top
■ Integralaluminumheatsink
■ Micstandintegrationsystemforusewithstandand
boom
■ Tough,impactresistantpolypropyleneenclosure
■ Lightweightforultimateportability(7.6lb/3.4kg)
SRM150
The SRM150 combines Mackie’s proven mixer and SRM
Series Active loudspeaker technologies to create a powerful,
great-sounding 3-channel PA system that is ultra-compact,
versatile and expandable. The Mackie SRM150 Compact
Active PA System is ideal for a wide variety of applications
ranging from boardroom A/V to live musical performance in
coffee houses, piano bars, or rehearsals, just to name a few.
The built-in Mackie mixer provides two mic/line channels
that accept XLR or ¼-inch connectors, with switchable 48V
phantom power on the mic inputs. Channel 1 can also
accept an instrument input directly from a guitar or bass
with the press of a switch. A third stereo channel can be
used for playing back MP3s, CDs, or tapes. A 3-band EQ is
included to adjust the tone and minimize feedback, and a
Thru connector provides a line-level output for connecting to
a mixer or another powered loudspeaker.
The 5.25-inch full-range weather-resistant neodymium driver
was specified by EAW to handle the 150 available watts
delivered by the internal Class D amp. The SRM150 can
deliver 120 dB SPL @ 1 meter, which is incredible for its
size.
The cabinet is constructed of high-pressure injected
polypropylene. An insert is provided on the bottom of the
cabinet for mounting on a mic stand, using the included mic
stand adapter. In addition, a threaded insert is provided on
the top of the cabinet for mounting a microphone, using the
included mic boom extender.
APPLICATIONS
Small club/band PA systems, boardrooms,
A/V presentations, classrooms, personal monitor for
practice or performance, PA system expansion and many,
many more.
2/4 PAGES
SRM150 COMPACT ACTIVE
PA SYSTEM
SRM150 SPECIFICATIONS
Acoustic Performance
Frequency Response (–3 dB) 100 Hz - 17.5 kHz
Frequency Range (–10 dB) 60 Hz - 22 kHz
Max SPL long-term 110 dB @ 1 m
Max SPL peak 120 dB @ 1 m
Mixer Section
Frequency Response (–3 dB)
(Mic Input to Line Out, Gain at 0 dB) 5 Hz - 40 kHz (+0, –1 dB)
Input Impedance
Mic 3 k balanced
Hi-Z 20 k balanced
Instrument 1 M
Line 10 k balanced
Stereo 10 k balanced
Maximum Voltage Gain
Mic Input 1/2 51 dB
Stereo Input 9 dB
Maximum Input Level
Mic –28 dBu, gain at +50 dB
+15 dBu, gain at +6 dB
Line –8 dBu, gain at +30 dB
+35 dBu, gain at –15 dB
Stereo +20 dBu, gain at 0 dB
3-Band Equalization
High ±15 dB @ 12 kHz
Mid ±15 dB @ 2.5 kHz
Low ±15 dB @ 100 Hz
Thru Out Mic Level Pad –30 dB
Common Mode Rejection Ratio (CMRR)
(1 kHz, gain at unity) 55 dB
Noise
(20 Hz to 20 kHz BW, 150 source impedance)
Equivalent Input Noise (EIN) –129 dBu
Residual Output Noise (Line out, channel and master levels off)
–85 dBu
Power Amplier
Rated Power 100 watts
Maximum Power 150 watts peak
Rated THD < 0.05%
Cooling Convection Extrusion
Design Class D
Transducer
Diameter 5.25 in / 134 mm
Voice Coil Diameter 1.0 in / 25.4 mm
Magnet Material Neodymium
Line Input Power
Universal Power Supply 100 VAC - 240 VAC, 50 - 60 Hz, 35 VAC
AC Connector 3-pin IEC 250 VAC
Safety Features
Overload Protection Limiter
Thermal Protection Amplifier shutdown, auto-reset
Construction Features
Material Polypropylene
Finish Grey, textured finish
Handles One on top
Grille Perforated metal with weather-resistant coating
Display LEDs Power ON, and Phantom Power ON
Operating Temperature 0˚ - 40˚C
32˚ - 104˚F
Physical Properties (packaged product)
Height 10.3 in / 262 mm
Width 12.0 in / 305 mm
Depth 7.5 in / 191 mm
Shipping Weight 10 lb / 4.5 kg
Physical Properties (product)
Height 8.0 in / 203 mm
Width 11.2 in / 284 mm
Depth 6.8 in / 173 mm
Net Weight 7.6 lb / 3.4 kg
Mounting Methods
Mic stand mountable with the supplied adapter via the built-in
socket on the bottom of the cabinet
Ordering Information
SRM150 5.25" Compact Active PA System, US P/N 2033796-00
SRM150 5.25" Compact Active PA System, EU P/N 2033796-01
SRM150 5.25” Compact Active PA System, CN P/N 2033796-05
3/4 PAGES
HIGH
12kHz
MID
2.5kHz
LOW
100Hz
MA XMI N
U
+15-15
U
+15-15
U
+15-15
MA XMI NMA XMI N
SRM150
COMPACT ACTIVE PA SYSTEM
MAXOFF
LEVEL
EQ
MIC/LINE MIC/LINE
123
L
R
PHANTOM POWER
MAIN
INSTRUMENT (CH 1)
48V
HIGH
MID
LOW
LEVEL
E Q
M I C / L I N E M I C / L I N E
123
P H A N T O M P O W E R
M A I N
I N S T R U M E N T ( C H 1 )
4 8 V
203
[8.0]
173
[6.8]
173
[6.8]
284
[11.2]
284
[11.2]
NOTES:
1. WEIGHT APPROX. 3.4 kg [7.6 lb]
2. SHIPPING WEIGHT APPROX. 4.5 kg [10 lb]
SRM150
">2C0E4A4B?>=B4
=^a\P[XiTSc^S1B?;
5aT`dT]Rh7i
¸
¸!
¸"
¸#
¸$
! :!:
THRU
POWER
FUSE
MAIN IN
LINE
MIC
3
A
M
P
SRM150
SRM150 COMPACT ACTIVE
PA SYSTEM
SRM150 FREQUENCY RESPONSE SRM150 FRONT PANEL
SRM150 DIMENSIONS SRM150 REAR PANEL
4/4 PAGES
Part No. SW0762 Rev. C 08/10
HIGH
MID
LOW
LEVEL
EQ
MIC/LIN E MIC/LINE
123
PHANTOM P OWER
MAIN
INSTRUM ENT (CH 1)
48V
SRM150
Po wer
Cord
Boom Extender
(Included)
Mic Stand
Adapter
(Included)
Electric Guitar
Vocal Mic
MP3 Player
Channel 2
Channel 3
Channel 1
Mic
Line
Gain
2
3
1+
-
+
-
Phantom
48V
Main Level Power Amplifier
Mic
Line
Gain
2
3
1+
-
Gain
Instrument
Line
Hi-Z
Main In
2
3
1+
-
Mic (–30 dB)
Line
3-Band EQ
LO
100 2.5K 12K
HIMID
2
3
1THRU
Limiter Loudspeake
r
SRM150 COMPACT ACTIVE
PA SYSTEM
Since we are always striving to make our products better by
incorporating new and improved materials, components, and
manufacturing methods, we reserve the right to change these
specications at any time without notice. “Mackie” and the “Running
Man” gure are registered trademarks of LOUD Technologies Inc.
All other brand names mentioned are trademarks or registered
trademarks of their respective holders, and are hereby acknowledged.
©2010 LOUD Technologies Inc. All Rights Reserved.
Electronic les for this product are available at:
www.mackie.com
Specification Sheet SRM150_SS.PDF
Owner’s Manual SRM150_OM.PDF
SRM150 STAND MOUNT
www.mackie.com
16220 Wood-Red Road NE
Woodinville, WA 98072 USA
800-898-3211, Fax 425-487-4337, [email protected]
SRM150 BLOCK DIAGRAM
