Magic Chef MCBM920S Bedienungsanleitung

9.2 CU.FT. BOTTOM FREEZER REFRIGERATOR

INSTRUCTION MANUAL

Model No.: MCBM920S

To ensure proper use of this appliance and your safety, please read the

following instructions completely before operating this appliance.

Product Registration Copy

Thank you for purchasing a Magic Chef product. The first step in protecting your

new product is to complete the product registration form on our website at

www.mcappliance.com/register .The benefits of registering your product

include the following.

1. Registering your product will allow us to contact you regarding a safety

notification or product update.

2. In the event that warranty service is required, registering your product will

allow for more efficient warranty service processing.

3. In the event of an insurance loss registering your product could act as

your proof of purchase.

Once again thank you for purchasing a Magic Chef product.

TABLE OF CONTENTS

NAMES OF THE PARTS……………………………………………………… 2

SPECIFICATIONS…………………………………………………………….. 3

IMPORTANT SAFETY INSTRUCTIONS…………………………………… 4

INSTALLATION INSTRUCTION

BEFORE USING YOUR REFRIGERATOR……………………..…… 4

INSTALLING YOUR REFRIGERATOR ……………………………… 4

ELECTRICAL CONNECTION………………………………………… 5

OPERATING THE REFRIGERATOR

TEMPERATURE CONTROL………………………………………….. 6

OPERATING THE FREEZER COMPARTMENT

TEMPERATURE CONTROL………………………………………….. 6

ICE TRAY………………………………………………………………… 6

THE FREEZER COMPARTMENT……………………………………. 6

CHANGING THE LIGHT……………………………………………………….. 7

CHANGING THE REVERSIBLE DOOR ……………………………………… 7-8

CARE AND MAINTENANCE

CLEANING YOUR REFRIGERATOR………………………………… 9

VACATION TIME………………………………………………………. 9

MOVING YOUR REFRIGERATOR…………………………………… 9

ENERGY SAVING TIPS………………………………………………. 9

TROUBLESHOOTING GUIDE………………………………………………. 10-11

REFRIGERATOR WARRANTY……………………….…………………….. 12

NAMES OF THE PARTS

MODEL NO. MCBM920S

1 Interior Light 7 Freezer Shelf

2 Refrigerator Temperature Control8 Freezer Basket

3 Freezer Temperature Control 9 Refrigerator Door Racks

4 Refrigerator Shelves 10 Can Dispenser

5 Glass Crisper Cover 11 Bottle Storage Bin

6 Crisper

aWARNINGa: Never touch the interior of the Freezer Chamber or frozen foods in the

compartment with wet hands as this could result in frost bite.

SPECIFICATIONS – Model # MCBM920S

Product Description

Magic Chef Refrigerator

Model No.

MCBM920S

Capacity

9.2 Cu. Ft.

Width

Height

Depth

Unit Dimensions

( inches )

23 4/5”

59 4/5”

26 2/3”

Net Weight ( lbs)

134( lbs )

IMPORTANT SAFETY INSTRUCTIONS

aWARNINGa

To reduce the risk of fire, electrical shock,

or injury when using your refrigerator,

follow these basic precautions:

•Read all instructions before using the refrigerator.

•DANGER or WARNING: Risk of child entrapment.

•To avoid the possibility of child entrapment, please take the following precautions

before throwing out the refrigerator.

- Remove all doors from the unit.

- Leave the shelves in place so that children may not easily climb inside.

•Never allow children to operate, play with, or crawl inside the refrigerator.

•Refrigerants: All refrigeration products contain refrigerants, which under the

guidelines of federal law must be removed before disposal of product. It is the

consumer’s responsibility to comply with federal and local regulations when

disposing of this product.

•Never clean refrigerator parts with flammable fluids. The fumes can create a fire

hazard or explosion.

•Do not store or use gasoline or any other flammable vapors and liquids in the vicinity

of this or any other refrigerator. The fumes can create a fire hazard or an explosion.

-Save these instructions-

INSTALLATION INSTRUCTIONS

Before Using Your Refrigerator

•Remove the exterior and interior packing.

•Before connecting the refrigerator to the power source, let it stand upright for approximately 4

hours. This will reduce the possibility of a malfunction in the cooling system from improper handling

during transportation.

•Clean the interior surface with lukewarm water using a soft cloth. (Cleaning instruction on page 9)

Installing Your Refrigerator

•This appliance is designed to be free standing only, and should not be recessed or built-in.

•Place your refrigerator on a floor that is strong enough to support the refrigerator when it is fully

loaded.

•Allow 5 inches of space between the back and sides of the refrigerator, which allows the proper air

ventilation. Adjust the feet to keep the refrigerator level.

•Locate the refrigerator away from direct sunlight and sources of heat (stove, heater, radiator, etc.).

Direct sunlight may affect the acrylic coating and heat sources may increase electrical consumption.

Ambient temperature below 50°F (10°C) or above 85°F (29.4°C) will hinder the performance of this

appliance. This unit is not designed for use in a garage or any other outside installation.

•Avoid locating the refrigerator in moist areas.

•Plug the refrigerator into dedicated, properly installed-grounded wall outlet. Do not under any

circumstances cut or remove the third (ground) prong from the power cord. Any questions

concerning power and/or grounding should be directed toward a certified electrician or an

authorized service center. This unit is not designed to be installed in an RV or used with an

inverter.

•After plugging the appliance into a wall outlet, turn the unit on and allow the unit to cool down for

2~3 hours under before placing food in the refrigerator or freezer compartment.

Electrical Connection

This refrigerator should be properly grounded for your safety. The power cord of this refrigerator is

equipped with a three-prong plug which mates with standard three prong wall outlets to minimize the

possibility of electrical shock.

Do not, under any circumstances, cut or remove the third ground prong from the power cord supplied.

This refrigerator requires a standard 115/120 Volt A.C. ~/60Hz electrical outlet with three-prong ground.

This refrigerator is not designed to be used with an inverter.

The cord should be secured behind the refrigerator and not left exposed or dangling to prevent

accidental injury.

Never unplug the refrigerator by pulling the power cord. Always grip the plug firmly and pull straight out

from the receptacle.

Do not use an extension cord with this appliance. If the power cord is too short, have a qualified

electrician or service technician install an outlet near the appliance. Use of an extension cord can

negatively affect the performance of the unit.

If any problems with the appliance persist, please contact our Customer Service Dept. to consult with a

representative at 888 775-0202 or visit our website to request warranty service at

www.mcappliance.com.

aWARNINGa

Improper use of the grounded plug can result in the risk of electrical shock. If the power cord is

damaged, have it replaced by an authorized service center.

OPERATING THE REFRIGERATOR

Temperature Control

•Your refrigerator has a separate control for regulating the

temperature for each section independently. The temperature controls are

located at the rear of refrigerator section. (See the graphics shown

above).

•The first time you turn the unit on, adjust the temperature control knob to

“coldest” and run for at least 2 hours before putting foods inside. This will

ensure the cabinet is thoroughly chilled before food is put in. After 24 to

48 hours, adjust the temperature control to the setting that best suits your

needs.

•The range of the temperature controls are from position “ COLD” to “COLDEST ” in refrigerator

section.

•NOTE;

•If the unit is unplugged, loses power; you must wait 3 to 5 minutes before restarting the

unit. If you attempt to restart before this time delay, the refrigerator will not start.

•Large amounts of food will lower the cooling efficiency of the appliance.

•Do not place the foods on the air outlet, and leave spaces for airflow.

•If you choose to change the thermostat setting, adjust thermostat control by one increment

at a time. Allow several hours for temperature to stabilize between adjustments.

•Adjusting the temperature control in the refrigerator compartment will affect the temperature

in both the refrigerator and the freezer compartment.

OPERATING THE FREEZER COMPARTMENT

Temperature Control

•Your refrigerator has a separate control for regulating the

temperature for each section independently. The temperature controls

are located at the rear of refrigerator section. (See the graphics shown

above).

•The first time you turn the unit on, adjust the temperature control knob

to “COLDEST” and run for at least 2 hours before putting foods inside.

This will ensure the cabinet is thoroughly chilled before food is put in.

•The range of the FREEZER temperature control is from position "COLD" to "COLDEST". Adjust the

temperature control to the setting that best suits your needs.

Ice Tray

To make ice, pour cool water into ice tray and place it in the freezer for two

hours. To release ice cubes, twist the ice tray and the ice cubes will separate

from the ice tray. To shorten the time of making ice, you can set the temperature

control knob at a colder position.

Notes:

Do not store can foods or food stored in glass containers in the freezer

compartment.

The Freezer Compartment

•This compartment is designed for the long-term storage of frozen food.

•The storage life of frozen foods varies and the recommended storage time should not be exceeded.

•Place frozen food into the freezer as quickly as possible after purchase. If there are instructions on

the packet, carefully follow these instructions regarding storage times.

CHANGING THE LIGHT

Before removing the light bulb, turn off the refrigerator first and then unplug the unit from the wall outlet.

Failure to do so could result in electrical shock or personal injury.

•As shown in Figure step 1, remove the lamp cover;

•As shown in Figure step 2, use left hand to press the LED light panel to inside along the direction of

arrow B and pull out the circuit boards along the direction of “arrow C” with flat head screwdriver.

•As shown in Figure step 3, hold down of wire terminal with left hand and remove the LED lamp

circuit with right hand seizing the other wire terminal .

•Replace with LED light that is the same shape and size.

•Reinstall the LED light panel and lamp cover.

CHANGING THE REVERSIBLE DOOR

Step 1 Step 3

Step 2

Your refrigerator is built with a reversible door. You have the choice of either opening it from the left or

the right side. In order to reserve the opening direction of your door, please follow these simple

instructions:

IMPORTANT:

Before you begin, unplug refrigerator or disconnect power. Remove food and any adjustable door or

utility bins from doors.

Door and Hinge Removal

1. Unplug refrigerator or disconnect power.

2. Keep both doors closed until you are ready to lift them free from the cabinet.

NOTE: Provide additional support for the doors while the hinges are being moved. Do not

depend on the door magnets to hold the doors in place while you are working.

3. Remove the parts for the top hinge as shown in Top Hinge graphic. Lift the freezer door from

the cabinet.

4. Remove the parts for the center hinge as shown in the Center Hinge graphic. Lift the

refrigerator door free from the cabinet.

5. Remove the parts for the bottom hinge as shown in the Bottom Hinge graphic.

Door Reversal

Cabinet

1. Remove the cover of upper hinge hole from left side and move them to opposite side (see

Graphic 1).

2. Remove hole plugs from left side and move them to opposite side (see Graphic 2)

Doors

1. Remove door hinge hole plug from the top of freezer and refrigerator door (see graphic 4)

2. Remove the door stop from refrigerator door and move to the other side (see graphic 5)

3. Take out the left door stop of freezer door and screw from the accessory bag and fix it on the

handle (see graphic 3)

Note: The left door and the right door stop of the freezer door are different. They can’t replace

each other.

Door and Hinge Replacement

1. Replace the parts for the bottom hinge as shown (see Bottom Hinge graphic). Tighten screws.

Replace the refrigerator door.

NOTE: Provide additional support for the doors while the hinges are being moved. Do not

depend on the door magnets to hold the doors in place while you are working.

2. Assemble the parts for the center hinge as shown and tighten all screws (see Center Hinge

graphic). Replace the freezer door.

3. Assemble the parts for the top hinge as shown (see Top Hinge graphic). Do not tighten screws

completely.

4. Line up the doors so that the bottom of the freezer door aligns evenly with the top of the

refrigerator door. Tighten all screws.

Final Steps

1. Check all holes to make sure that hole plugs and screws are in place.

2. Plug in refrigerator or reconnect power.

3. Reset the controls (see “ temperature control” section).

4. Return all removable door parts to doors and food to product.

Inhaltsverzeichnis

Andere Magic Chef Kühlschrank Handbücher

Magic Chef

Magic Chef MCQR1500ST Bedienungsanleitung

Magic Chef

Magic Chef MCBR240W Bedienungsanleitung

Magic Chef

Magic Chef MCBR270B Bedienungsanleitung

Magic Chef

Magic Chef MCBR170B Bedienungsanleitung

Magic Chef

Magic Chef HMAR265WE Bedienungsanleitung

Magic Chef

Magic Chef HMCR440WE Bedienungsanleitung

Magic Chef

Magic Chef MCSR-6085W Bedienungsanleitung

Magic Chef

Magic Chef MCBR170S Bedienungsanleitung

Magic Chef

Magic Chef HMBR265WE1 Bedienungsanleitung

Magic Chef

Magic Chef MCBR350W2 Bedienungsanleitung

Magic Chef

Magic Chef HMAR33WE Bedienungsanleitung

Magic Chef

Magic Chef MCBR350B2 Bedienungsanleitung

Magic Chef

Magic Chef MCBR510W Bedienungsanleitung

Magic Chef

Magic Chef HMBR265WE Bedienungsanleitung

Magic Chef

Magic Chef CRD22AY-3A Bedienungsanleitung

Magic Chef

Magic Chef MCBR170BMD Bedienungsanleitung

Magic Chef

Magic Chef MCBR1010S Bedienungsanleitung

Magic Chef

Magic Chef RB17CA-1A Bedienungsanleitung

Magic Chef

Magic Chef MCBR160B2 Bedienungsanleitung

Magic Chef

Magic Chef MCR32CHW Bedienungsanleitung

Magic Chef

Magic Chef CTB1821VRW01 Bedienungsanleitung

Magic Chef

Magic Chef HVDR1040W Bedienungsanleitung

Magic Chef

Magic Chef MCBR405B Bedienungsanleitung

Magic Chef

Magic Chef MCR1010WEF Bedienungsanleitung

Beliebte Kühlschrank Handbücher anderer Marken

Bonnet Neve

Bonnet Neve SKYVIEW PLUS Bedienungsanleitung

Zanussi Electrolux

Zanussi Electrolux ZERB 8441 Bedienungsanleitung

Sharp

Sharp SJ-BA31IEXW2-EU Bedienungsanleitung

CORBERO

CORBERO CC2300MCW Bedienungsanleitung

KitchenAid

KitchenAid 2205264 Bedienungsanleitung

Stengel

Stengel KU 1101 A++ Bedienungsanleitung

NEFF

NEFF KI181 Series Bedienungsanleitung

Hoshizaki

Hoshizaki Reach-In Bedienungsanleitung

Amana

Amana ASD2524VES00 Bedienungsanleitung

BOMANN

BOMANN KGC 213 Bedienungsanleitung

Danby

Danby DAR044A1SLDD Montageanleitung

Samsung

Samsung RF323TE Bedienungsanleitung

Beko

Beko CSA31022 Bedienungsanleitung

IKEA

IKEA FROSTIG C 185 E Bedienungsanleitung

Electrolux

Electrolux ER 6821 D Bedienungsanleitung

True

True TS-28 Bedienungsanleitung

Frigidaire

Frigidaire FSC23R5DW9 Bedienungsanleitung

Beko

Beko LSP4579W Bedienungsanleitung
