PLEASE READ THIS MANUAL CAREFULLY BEFORE USING YOUR

REFRIGERATOR AND KEEP IT FOR FUTURE REFERENCE.

MCR16CHW /MCR16CHB /MCR16CHR /MCR16CHM

Speciﬁcations are subject to change without prior

notice for purpose of product improvement.

1.6 Cu. Ft.

Compact All Refrigerator

User's Manual

Product Registration

Thank you for purchasing a Magic Chef® product. The ﬁrst step to protect your new product is to complete the product registration on our website:

www.mcappliance.com/register. The beneﬁts of registering your product include the following:

1. Registering your product will allow us to contact you regarding a safety notiﬁcation or product update.

2. Registering your product will allow for more efﬁcient warranty service processing when warranty service is required.

3. Registering your product could act as your proof of purchase in the event of insurance loss.

Once again, thank you for purchasing a Magic Chef®product.

IMPORTANT SAFETY INSTRUCTIONS

To reduce the risk of fire, electrical shock, or injury

follow these basic precautions when using your

refrigerator.

• Leave the shelves in place so that children may not easily climb inside.

10)

11)

12)

13)

WARNING----Keep ventilation openings, in the appliance enclosure or in the built-in

structure, clear of obstruction.

WARNING----Do not use mechanical devices or other means to accelerate the defrosting

process, other than those recommended by the manufacturer.

WARNING----Do not damage the refrigerant tubing to increase the risk of a leak when

handle, move and use of refrigerator.

WARNING----Do not use electrical appliances inside the food storage compartments of

the appliances, unless they are of the type recommended by the manufacturer.

WARNING----DANGER: Never allow children to play with, operate, or crawl inside the

refrigerator. Risk of child entrapment. Before you throw away your old refrigerator:

• Take off the doors.

The appliance has to be unplugged before carrying out user maintenance on the appli-

ance.

This appliance can be used by children age 8 years and above and persons with reduced

physical sensory or mental capabilities or lack of experience and knowledge if they have

been given supervision or instruction concerning use of the appliance in a safe way and

understand the hazards involved. Children should not play with the appliance. Cleaning

and maintenance should not be made by children without supervision.

If the component part is damaged, it must be replaced by the manufacturer, its service

agent or similar qualiﬁed persons in order to avoid a hazard.

Please abandon the refrigerator according to local regulations as the unit contains ﬂam

mable blowing gas and refrigerant.

Follow local regulations regarding disposal of the appliance due to ﬂammable refrigerant

and blowing gas. All refrigeration products contain refrigerants, which under the guidelines

of federal law must be removed before disposal. It is the consumer's responsibility to

comply with federal and local regulations when disposing of this product.

This appliance is intended to be used in household and similar environments; such as:

• sta kitchen areas in shops, o ces and other working environments;

• farm houses and by clients in hotels, motels and other residential type environments;

• bed and breakfast type environments;

• catering and similar non-retail applications.

Do not store or use gasoline or any inﬂammable liquors and liquids inside or in the vicinity

of refrigerator.

Do not use an extension cord with this appliance. If the power cord is too short, have a

qualiﬁed electrician install an outlet near the appliance. Use of an extension can

negatively a ect the unit”s performance.

IT IS HAZARDOUS FOR ANYONE OTHER THAN AUTHORIZED

SERVICE PERSONNEL TO CARRY OUT SERVICES OR REPAIRS

INVOLVING THE REMOVAL OF COVERS.

TO AVOID THE RISK OF AN ELECTRICAL SHOCK DO NOT

ATTEMPT REPAIRS YOURSELF.

TABLE OF CONTENTS

NAMES OF THE PARTS……………………………………………………… 2

SPECIFICATIONS…………………………………………………………….. 3

INSTALLATION INSTRUCTION

BEFORE USING YOUR REFRIGERATOR……………………..…… 4

INSTALLING YOUR REFRIGERATOR ……………………………… 4

HANDLE INSTALL INSTRUCTION ….....…………………………… 4

ELECTRICALCONNECTION………………………………………… 5

OPERATING YOUR REFRIGERATOR

TEMPERATURE CONTROL………………………………………….. 6

CARE AND MAINTENANCE

CLEANING YOUR REFRIGERATOR………………………………… 7

CHANGING THE INNER LIGHT……………………………………… 7

VACATIONTIME………………………………………………………. 7

MOVING YOUR REFRIGERATOR…………………………………… 7

ENERGY SAVING TIPS………………………………………………. 7

TROUBLESHOOTING GUIDE………………………………………………. 8

REFRIGERATOR WARRANTY……………………….……………………… 9

LEVELING LEGS…………………………......………………………… 6

NAMES OF THE PARTS

（1）Removable Glass Shelf

（2）Adjustable Front Leveling Legs

（3）Small Transparent Plastic Shelf

（4）Big Transparent Plastic Shelf

（5）Temperature control box

（6）Temperature control knob

（7）Hinge

SPECIFICATIONS – Model # MCR16CHW.CHB.CHR.CHM

Product Description Magic Chef Refrigerator

Model No. MCR16CHW.CHB.CHR.CHM

Capacity 1.6 Cu. Ft.

Width Height Depth

Unit Dimensions

( inches ) 17.5” 18.6”19.3”

Net Weight ( lbs) 29.5 ( lbs )

INSTALLATION INSTRUCTIONS

Before Using Your Refrigerator

•Remove the exterior and interior packing.

•Before connecting the refrigerator to the power source, let it stand upright for approximately 4 hours.

This will reduce the possibility of a malfunction in the cooling systemfromimproper handling during

transportation.

•Clean the interior surface with lukewarmwater using a soft cloth. (Cleaning instruction on page 7)

Installing Your Refrigerator

•This appliance is designed to be free standing only, and should not be recessed or built-in.

•Place your refrigerator on a floor that is strong enough to support the refrigerator when it is fully

loaded.

•Allow 5 inches of space between the back and sides of the refrigerator, which allows the proper air

ventilation. Adjust the feet to keep the refrigerator level.

•Locate the refrigerator away fromdirect sunlight and sources of heat (stove, heater, radiator, etc.).

Direct sunlight may affect the acrylic coating and heat sources may increase electrical consumption.

Ambient temperature below 50°F or above 85°F will hinder the performance of this appliance. This

unit is not designed for use in a garage or any other outside installation.

•Avoid locating the refrigerator in moist areas.

•Plug the refrigerator into dedicated, properly installed-grounded wall outlet. Do not under any

circumstances cut or remove the third (ground) prong fromthe power cord. Any questions concerning

power and/or grounding should be directed toward a certified electrician or an authorized service

center. This unit is not designed to be installed in an RV or used with an inverter.

•After plugging the appliance into a wall outlet, turn the unit on and allow the unit to cool down for 2~3

hours under before placing food in the refrigerat .ro

Handle Install Instruction

Please note that the Handle parts are inseparable once joined. Please ensure that the handle

base is screwed firmly on the door before joining the actual handle part onto its base.

1. Take out the handle from the unit and remove the package.

2. Push the handle horizontally until it clicks in.

3. Push and pull the handle to make sure that it is installed completely.

Electrical Connection

This refrigerator should be properly grounded for your safety. The power cord of this refrigerator is

equipped with a three-prong plug which mates with standard three prong wall outlets to minimize the

possibility of electrical shock.

Do not, under any circumstances, cut or remove the third ground prong fromthe power cord supplied.

This refrigerator requires a standard 115V~ / 60Hz electrical outlet with three-prong ground.

This refrigerator is not designed to be used with an inverter.

The cord should be secured behind the refrigerator and not left exposed or dangling to prevent accidental

injury.

Never unplug the refrigerator by pulling the power cord. Always grip the plug firmly and pull straight out

fromthe receptacle.

Do not use an extension cord with this appliance. If the power cord is too short, have a qualified

electrician or service technician install an outlet near the appliance. Use of an extension cord can

negatively affect the performance of the unit.

If any problems with the appliance persist, please contact our Customer Service Dept. to consult with a

representative at 888 775-0202 or visit our website to request warranty service at

www.mcappliance.com.

WARNING

Improper use of the grounded plug can result in the risk of electrical shock. If the power cord is

damaged, have it replaced by an authorized service center.

DANGER – Risk Of Fire Or Explosion. Flammable Refrigerant Used. To Be Repaired Only By

Trained Service Personnel. Do Not Puncture Refrigerant Tubing

CAUTION – Risk Of Fire Or Explosion. Flammable Refrigerant Used. Consult Repair

Manual/Owner’s Guide Before Attempting To Service This Product. All Safety Precautions Must

be Followed

CAUTION – Risk Of Fire Or Explosion. Dispose Of Property In Accordance With Federal Or

Local Regulations. Flammable Refrigerant Used

CAUTION – Risk Of Fire Or Explosion Due To Puncture Of Refrigerant Tubing; Follow Handling

Instructions Carefully. Flammable Refrigerant Used

OPERATING YOUR REFRIGERATOR

Temperature Control

•

•The range of the refrigerator temperature control is from position "COOL" the warmest to "COLDEST" the

coldest. Adjust the temperature control to the setting that best suits your needs. The setting of “COLD”

should be appropriate for home or office refrigerator use.

•To turn off the refrigerator, please turn the temperature control knob to “OFF”. Please note that turning

the temperature control knob to “OFF” position stops the cooling cycle, but does not disconnect the

power supply to the refrigerator.

•NOTE

•If the unit is unplugged, loses power; you must wait 3 to 5 minutes before restarting the unit.

If you attempt to restart before this time delay, the refrigerator will not start.

•Large amounts of food will lower the cooling efficiency of the appliance.

•Do not place the foods on the air outlet, and leave spaces for airflow.

•If you choose to change the thermostat setting, adjust thermostat control by one increment at

a time. Allow several hours for temperature to stabilize between adjustments.

Your refrigerator has one control for regulating the temperature.The temperature control is located on

the top right hand corner of the refrigerator compartment.

The first time you turn the unit on, adjust the temperature control knob to “COLDEST” and run for at least

2 hours before putting foods inside. This will ensure the cabinet is thoroughly chilled before food is put

in.

OFF

COLD

COOL

COLDEST

•Your refrigerator has two leveling legs which are located in the front bottomcorners of your

refrigerator. After properly placing your refrigerator in its final position, you can level your refrigerator.

•Leveling legs can be adjusted by turning them clockwise to raise your refrigerator or by turning them

counterclockwise to lower your refrigerator. The refrigerator door will close easier when the leveling

legs are extended.

Leveling Legs

CARE AND MAINTENANCE

Cleaning Your Refrigerator

•Upon

•

Before removing the inner light, turn off the appliance first and then unplug the unit from the wall outlet.

Failure to do so could result in electrical shock or personal injury.

Using a screwdriver, remove the two screws from the clear plastic cover.

Tilt the panel towards the front of the appliance and unscrew the LED board from the white plastic spacer.

Gently unclip the power cable from the red socket insert on the LED board.

Insert the power cable into the red socket insert on the replacement LED board.

Position within the black plastic spacer.

Reassemble the LED board, spacer and cover together using the two screws.

Reposition the panel and carefully enclose the cord within the LED housing.

Reattach the clear plastic panel using two screws.

installation of your new appliance, it is recommended that it be cleaned thoroughly.

•Turn off the refrigerator first and then unplug the unit fromthe wall outlet.

•Remove all food content.

•Wash the inside with a damp warmcloth soaked in lukewarmwater and baking soda solution. The

solution should be about 2 tablespoons of baking soda to a quart of water.

•Be sure to keep the doorgasket (seal) clean to keep the unit running efficiently.

•The outside of the refrigerator should be cleaned with mild detergent and warmwater.

•Dry the interiorand exterior with a soft cloth.

Vacation Time

Important: The replacement of LED lamp can only be performed by an authorized technician.

•Turn off the refrigerator first and then unplug the unit fromthe wall outlet.

•Remove all the food.

•Clean the refrigerator.

•Leave the lid open slightly to avoid possible formation of condensation, mold, or odors.

•Use extreme caution in the case of children. The unit should not be accessible to child’s play.

•Short vacations: Leave the refrigerator operating during vacations of less than threeweeks.

•Long vacations: If the appliance will not be used for severalmonths, remove all food and unplug the

power cord. Clean and dry the interior thoroughly. To prevent odor and mold growth, leave the door

open slightly: blocking it open if necessary or have the door removed.

Moving Your Refrigerator

•Turn off the refrigerator first and thenunplug the unit fromthe wall outlet.

•Remove all the food.

•Securely tape down all loose items inside your refrigerator.

•Tape the doors shut.

•Be sure the refrigerator stays in the upright position during transportation.

Energy Saving Tips

•The refrigerator should be located in the coolest area of the room, away fromheat producing

appliances or heating ducts, and out of the direct sunlight.

•Let hot foods cool to roomtemperature before placing in the refrigerator. Overloading the refrigerator

forces the compressor to run longer.

•Be sure to wrap foods properly, and wipe containers dry before placing themin the refrigerator. This

cuts down on frost build-up inside the refrigerator.

•Organize and label food to reduce door openings and extended searches. Remove as many items as

needed at one time,and close the door as soon as possible.

Changing the Inner Light

Dieses Handbuch passt für folgende Modelle

Inhaltsverzeichnis

Sprachen:

Andere Magic Chef Kühlschrank Handbücher

Magic Chef

Magic Chef MCBR170W Bedienungsanleitung

Magic Chef

Magic Chef MCDR450WEF Bedienungsanleitung

Magic Chef

Magic Chef MCBR445W1F Bedienungsanleitung

Magic Chef

Magic Chef MCBR240W Bedienungsanleitung

Magic Chef

Magic Chef HMBR265WE1 Bedienungsanleitung

Magic Chef

Magic Chef MCBR350B2 Bedienungsanleitung

Magic Chef

Magic Chef MCBR980W Bedienungsanleitung

Magic Chef

Magic Chef AON-2703 Bedienungsanleitung

Magic Chef

Magic Chef MCBR170B Bedienungsanleitung

Magic Chef

Magic Chef HMCR320RE Bedienungsanleitung

Magic Chef

Magic Chef MCBR1000B Betriebsanleitung

Magic Chef

Magic Chef MCBR460S Bedienungsanleitung

Magic Chef

Magic Chef HVDR430WE Bedienungsanleitung

Magic Chef

Magic Chef MCBR170B Bedienungsanleitung

Magic Chef

Magic Chef MCBR170B Bedienungsanleitung

Magic Chef

Magic Chef MCBR270B Bedienungsanleitung

Magic Chef

Magic Chef HMBR350WE1 Bedienungsanleitung

Magic Chef

Magic Chef MCBM920W1 Bedienungsanleitung

Magic Chef

Magic Chef HMBR445WE Bedienungsanleitung

Magic Chef

Magic Chef MCBR360HB Bedienungsanleitung

Magic Chef

Magic Chef MCBR405B Bedienungsanleitung

Magic Chef

Magic Chef HMAR45HCWE Bedienungsanleitung

Magic Chef

Magic Chef HMR330WE Bedienungsanleitung

Magic Chef

Magic Chef MCBR402S Bedienungsanleitung

Beliebte Kühlschrank Handbücher anderer Marken

Bonnet Neve

Bonnet Neve SKYVIEW PLUS Bedienungsanleitung

Zanussi Electrolux

Zanussi Electrolux ZERB 8441 Bedienungsanleitung

Sharp

Sharp SJ-BA31IEXW2-EU Bedienungsanleitung

CORBERO

CORBERO CC2300MCW Bedienungsanleitung

KitchenAid

KitchenAid 2205264 Bedienungsanleitung

Stengel

Stengel KU 1101 A++ Bedienungsanleitung

NEFF

NEFF KI181 Series Bedienungsanleitung

Hoshizaki

Hoshizaki Reach-In Bedienungsanleitung

Amana

Amana ASD2524VES00 Bedienungsanleitung

BOMANN

BOMANN KGC 213 Bedienungsanleitung

Danby

Danby DAR044A1SLDD Montageanleitung

Samsung

Samsung RF323TE Bedienungsanleitung

Beko

Beko CSA31022 Bedienungsanleitung

IKEA

IKEA FROSTIG C 185 E Bedienungsanleitung

Electrolux

Electrolux ER 6821 D Bedienungsanleitung

True

True TS-28 Bedienungsanleitung

Frigidaire

Frigidaire FSC23R5DW9 Bedienungsanleitung

Beko

Beko LSP4579W Bedienungsanleitung
