Magic Chef MCBR240W1 Bedienungsanleitung

PLEASE READ THIS MANUAL CAREFULLY BEFORE USING YOUR

REFRIGERATOR AND KEEP IT FOR FUTURE REFERENCE.

Model MCBR240W1 / MCBR240B1 / MCBR240S1 / MCBR240C

2.4 Cu. Ft.

Compact Refrigerator

User's Manual

Product Registration

Thank you for purchasing a Magic Chef®product. The ﬁrst step to protect your new product is to complete the product registration on our website:

www.mcappliance.com/register. The beneﬁts of registering your product include the following:

1. Registering your product will allow us to contact you regarding a safety notiﬁcation or product update.

2. Registering your product will allow for more efﬁcient warranty service processing when warranty service is required.

3. Registering your product could act as your proof of purchase in the event of insurance loss.

Once again, thank you for purchasing a Magic Chef® product.

IMPORTANT SAFETY INSTRUCTIONS

To reduce the risk of fire, electrical shock, or injury

follow these basic precautions when using your

refrigerator.

10)

11)

12)

13)

WARNING----Keep ventilation openings, in the appliance enclosure or in the built-in

structure, clear of obstruction.

WARNING----Do not use mechanical devices or other means to accelerate the defrosting

process, other than those recommended by the manufacturer.

WARNING----Do not damage the refrigerant tubing to increase the risk of a leak when

handle, move and use of refrigerator.

WARNING----Do not use electrical appliances inside the food storage compartments of

the appliances, unless they are of the type recommended by the manufacturer.

WARNING----DANGER: Never allow children to play with, operate, or crawl inside the

refrigerator. Risk of child entrapment. Before you throw away your old refrigerator or

freezer:

• Take off the doors

• Leave the shelves in place so that children may not easily climb inside.

The appliance has to be unplugged before carrying out user maintenance on the appli-

ance.

This appliance can be used by children age 8 years and above and persons with reduced

physical sensory or mental capabilities or lack of experience and knowledge if they have

been given supervision or instruction concerning use of the appliance in a safe way and

understand the hazards involved. Children should not play with the appliance. Cleaning

and maintenance should not be made by children without supervision.

If the component part is damaged, it must be replaced by the manufacturer, its service

agent or similar qualiﬁed persons in order to avoid a hazard.

Please abandon the refrigerator according to local regulations as the unit contains ﬂam

mable blowing gas and refrigerant.

Follow local regulations regarding disposal of the appliance due to ﬂammable refrigerant

and blowing gas. All refrigeration products contain refrigerants, which under the guidelines

of federal law must be removed before disposal. It is the consumer's responsibility to

comply with federal and local regulations when disposing of this product.

This appliance is intended to be used in household and similar environments; such as:

• stakitchen areas in shops, oces and other working environments;

• farm houses and by clients in hotels, motels and other residential type environments;

• bed and breakfast type environments;

• catering and similar non-retail applications.

Do not store or use gasoline or any inﬂammable liquors and liquids inside or in the vicinity

of refrigerator.

Do not use an extension cord with this appliance. If the power cord is too short, have a

qualiﬁed electrician install an outlet near the appliance. Use of an extension can

negatively aect the unit”s performance.

IT IS HAZARDOUS FOR ANYONE OTHER THAN AUTHORIZED

SERVICE PERSONNEL TO CARRY OUT SERVICES OR REPAIRS

INVOLVING THE REMOVAL OF COVERS.

TO AVOID THE RISK OF AN ELECTRICAL SHOCK DO NOT

ATTEMPT REPAIRS YOURSELF.

TABLE OF CONTENTS

NAMES OF THE PARTS……………………………………………………… 2

SPECIFICATIONS…………………………………………………………….. 3

IMPORTANT SAFETY INSTRUCTIONS…………………………………… 4

INSTALLATION INSTRUCTION

BEFORE USING YOUR REFRIGERATOR……………………..…… 4

INSTALLING YOUR REFRIGERATOR ……………………………… 4

ELECTRICAL CONNECTION………………………………………… 5

OPERATING YOUR REFRIGERATOR

TEMPERATURE CONTROL………………………………………….. 6

MAKING THE ICE CUBES….………………………………….……… 6

HOW TO DEFROST………………..………………………………….. 7

ASSEMBLING LEGS…………………………………………………… 7

DOOR REVERSAL INSTRUCTION ………………………………………….. 8

CARE AND MAINTENANCE

CLEANING YOUR REFRIGERATOR………………………………… 10

VACATION TIME………………………………………………………. 10

MOVING YOUR REFRIGERATOR…………………………………… 10

ENERGY SAVING TIPS………………………………………………. 10

TROUBLESHOOTING GUIDE………………………………………………. 11

REFRIGERATOR WARRANTY……………………….……………………… 12

1. Small door 2. Pan, drain 3. Steel wire shelf

4. Leveler, leg 5.Thermostat 6. Wire steel bar

Refrigerating chamber

The is suitable for storage of a variety of fruits, vegetables, beverages and

other food consumped in the short term.

Cooking foods shall not be put in the refrigerating chamber until cooled to room temperature.

Foods are recommended to be sealed up before putting into the refrigerator.

The glass shelves can be adjusted up or down for a reasonable amount of storage space and easy use.

Refrigerating Chamber

NAMES OF THE PARTS

WARNING : Never touch the interior of the Freezer Chamber or frozen foods in the

compartment with wet hands as this could result in frost bite.

SPECIFICATIONS – Model # MCBR240W1.B1.S1.C

Product Description Magic Chef 2.4 cu.ft. Refrigerator

Model No. MCBR240W1.B1.S1.C

Capacity 2.4 Cu. Ft.

Width Height Depth

Unit Dimensions

( inches ) 17.5” 20.1”24.8”

Net Weight ( lbs) 39.7 ( lbs )

IMPORTANT SAFETY INSTRUCTIONS

aWARNINGa

To reduce the risk of fire, electrical shock,

or injury when using your refrigerator,

follow these basic precautions:

•Read all instructions before using the refrigerator.

•DANGER or WARNING: Risk of child entrapment.

•To avoid the possibility of child entrapment, please take the following precautions

before throwing out the refrigerator.

- Remove all doors from the unit.

- Leave the shelves in place so that children may not easily climb inside.

•Never allow children to operate, play with, or crawl inside the refrigerator.

•Never clean refrigerator parts with flammable fluids. The fumes can create a fire

hazard or explosion.

•Do not store or use gasoline or any other flammable vapors and liquids in the vicinity

of this or any other refrigerator. The fumes can create a fire hazard or an explosion.

-Save these instructions-

INSTALLATION INSTRUCTIONS

Before Using Your Refrigerator

•Remove the exterior and interior packing.

•Before connecting the refrigerator to the power source, let it stand upright for approximately 4 hours.

This will reduce the possibility of a malfunction in the cooling system from improper handling during

transportation.

•Clean the interior surface with lukewarm water using a soft cloth. (Cleaning instruction on page 9)

Installing Your Refrigerator

•This appliance is designed to be free standing only, and should not be recessed or built-in.

•Place your refrigerator on a floor that is strong enough to support the refrigerator when it is fully

loaded.

•Allow 5 inches of space between the back and sides of the refrigerator, which allows the proper air

ventilation. Adjust the feet to keep the refrigerator level.

•Locate the refrigerator away from direct sunlight and sources of heat (stove, heater, radiator, etc.).

Direct sunlight may affect the acrylic coating and heat sources may increase electrical consumption.

Ambient temperature below 50°F or above 85°F will hinder the performance of this appliance. This

unit is not designed for use in a garage or any other outside installation.

•Avoid locating the refrigerator in moist areas.

•Plug the refrigerator into dedicated, properly installed-grounded wall outlet. Do not under any

circumstances cut or remove the third (ground) prong from the power cord. Any questions concerning

power and/or grounding should be directed toward a certified electrician or an authorized service

center. This unit is not designed to be installed in an RV or used with an inverter.

•After plugging the appliance into a wall outlet, turn the unit on and allow the unit to cool down for 2~3

hours under before placing food in the refrigerator or freezer compartment.

Electrical Connection

This refrigerator should be properly grounded for your safety. The power cord of this refrigerator is

equipped with a three-prong plug which mates with standard three prong wall outlets to minimize the

possibility of electrical shock.

Do not, under any circumstances, cut or remove the third ground prong from the power cord supplied.

This refrigerator requires a standard 115V~ / 60Hz electrical outlet with three-prong ground.

This refrigerator is not designed to be used with an inverter.

The cord should be secured behind the refrigerator and not left exposed or dangling to prevent accidental

injury.

Never unplug the refrigerator by pulling the power cord. Always grip the plug firmly and pull straight out

from the receptacle.

Do not use an extension cord with this appliance. If the power cord is too short, have a qualified

electrician or service technician install an outlet near the appliance. Use of an extension cord can

negatively affect the performance of the unit.

If any problems with the appliance persist, please contact our Customer Service Dept. to consult with a

representative at 888 775-0202 or visit our website to request warranty service at

www.mcappliance.com.

WARNING

Improper use of the grounded plug can result in the risk of electrical shock. If the power cord is

damaged, have it replaced by an authorized service center.

DANGER – Risk Of Fire Or Explosion. Flammable Refrigerant Used. To Be Repaired Only By

Trained Service Personnel. Do Not Puncture Refrigerant Tubing

CAUTION – Risk Of Fire Or Explosion. Flammable Refrigerant Used. Consult Repair

Manual/Owner’s Guide Before Attempting To Service This Product. All Safety Precautions Must

be Followed

CAUTION – Risk Of Fire Or Explosion. Dispose Of Property In Accordance With Federal Or

Local Regulations. Flammable Refrigerant Used

CAUTION – Risk Of Fire Or Explosion Due To Puncture Of Refrigerant Tubing; Follow Handling

Instructions Carefully. Flammable Refrigerant Used

MED

MIN

MAX

OFF

OPERATING YOUR REFRIGERATOR

Making the Ice Cubes

Take out the ice cube tray and fill the tray to 80% capacity with drinkable water. Put the ice cube tray

back into the freezer compartment and close the door.

•Turn the temperature control knob to “MAX”.

•Wait for approximately two to five hours.

•Twist the ice cube tray and release the ice cubes.

•Reset the temperature control knob to the normal recommended setting. (“MED”)

Temperature Control

•

•The range of the refrigerator temperature control is from position "MIN" the warmest to "MAX" the coldest.

Adjust the temperature control to the setting that best suits your needs. The setting of “MED” should be

appropriate for home or office refrigerator use.

•To turn off the refrigerator, please turn the temperature control knob to “OFF”. Please note that turning

the temperature control knob to “OFF” position stops the cooling cycle, but does not disconnect the

power supply to the refrigerator

•NOTE

•If the unit is unplugged, loses power; you must wait 3 to 5 minutes before restarting the unit.

If you attempt to restart before this time delay, the refrigerator will not start.

•Large amounts of food will lower the cooling efficiency of the appliance.

•Do not place the foods on the air outlet, and leave spaces for airflow.

•If you choose to change the thermostat setting, adjust thermostat control by one increment at

a time. Allow several hours for temperature to stabilize between adjustments.

Your refrigerator has one control for regulating the temperature. The temperature control is

located on the top left hand corner of the refrigerator compartment

The first time you turn the unit on, adjust the temperature control knob to “MAX” and run for at least 2

hours before putting foods inside. This will ensure the cabinet is thoroughly chilled before food is put

in.

How to Defrost

Your refrigerator has two leveling legs which are located in the front bottom corners of your

refrigerator. After properly placing your refrigerator in its final position, you can level your refrigerator.

Leveling legs can be adjusted by turning them clockwise to raise your refrigerator or by turning them

counterclockwise to lower your refrigerator. The refrigerator door will close easier when the leveling

legs are extended.

Assembling Legs

Defrost whenever frost on the wall of the freezer compartment becomes 1/8" thick. Never us a sharp or

metallic instrument to remove frost as it may damage the cooling coils. (A punctured cooling coil will

cause serious damage to the product and will void the warranty). We recommend using a plastic scraper.

To defrost, remove foods and ice cube tray from the freezer compartment. Make sure the drip tray is in

place and unplug the unit. Defrosting usually takes a few hours. To defrost faster, keep the door open and

place a bowl of warm water in the refrigerator. After defrosting, empty water from the drip tray and wash

the drip tray in warm water.

Dieses Handbuch passt für folgende Modelle

Inhaltsverzeichnis

Sprachen:

Andere Magic Chef Kühlschrank Handbücher

Magic Chef

Magic Chef MCBR170BF Bedienungsanleitung

Magic Chef

Magic Chef HMAR33WE Bedienungsanleitung

Magic Chef

Magic Chef MCBM920W Bedienungsanleitung

Magic Chef

Magic Chef MCBR270B Bedienungsanleitung

Magic Chef

Magic Chef MCBR170W Bedienungsanleitung

Magic Chef

Magic Chef HMAR265WE Bedienungsanleitung

Magic Chef

Magic Chef MCBR265BEF Bedienungsanleitung

Magic Chef

Magic Chef HVDR1040W Bedienungsanleitung

Magic Chef

Magic Chef MCBR170BMD Bedienungsanleitung

Magic Chef

Magic Chef MCBR160B2 Bedienungsanleitung

Magic Chef

Magic Chef MCBR350B2 Bedienungsanleitung

Magic Chef

Magic Chef HMBR350WE Bedienungsanleitung

Magic Chef

Magic Chef MCBR170B Bedienungsanleitung

Magic Chef

Magic Chef MCBM920S Bedienungsanleitung

Magic Chef

Magic Chef CRD22AY-3A Bedienungsanleitung

Magic Chef

Magic Chef HMCR320RE Bedienungsanleitung

Magic Chef

Magic Chef MCBR170B Bedienungsanleitung

Magic Chef

Magic Chef CTB1821VRW01 Bedienungsanleitung

Magic Chef

Magic Chef MCAR240B Bedienungsanleitung

Magic Chef

Magic Chef MCBR415S Bedienungsanleitung

Magic Chef

Magic Chef MCR16CHW Bedienungsanleitung

Magic Chef

Magic Chef MCKC490B Bedienungsanleitung

Magic Chef

Magic Chef HMBR445WE Bedienungsanleitung

Magic Chef

Magic Chef HMAR45HCWE Bedienungsanleitung

Beliebte Kühlschrank Handbücher anderer Marken

Bonnet Neve

Bonnet Neve SKYVIEW PLUS Bedienungsanleitung

Zanussi Electrolux

Zanussi Electrolux ZERB 8441 Bedienungsanleitung

Sharp

Sharp SJ-BA31IEXW2-EU Bedienungsanleitung

CORBERO

CORBERO CC2300MCW Bedienungsanleitung

KitchenAid

KitchenAid 2205264 Bedienungsanleitung

Stengel

Stengel KU 1101 A++ Bedienungsanleitung

NEFF

NEFF KI181 Series Bedienungsanleitung

Hoshizaki

Hoshizaki Reach-In Bedienungsanleitung

Amana

Amana ASD2524VES00 Bedienungsanleitung

BOMANN

BOMANN KGC 213 Bedienungsanleitung

Danby

Danby DAR044A1SLDD Montageanleitung

Samsung

Samsung RF323TE Bedienungsanleitung

Beko

Beko CSA31022 Bedienungsanleitung

IKEA

IKEA FROSTIG C 185 E Bedienungsanleitung

Electrolux

Electrolux ER 6821 D Bedienungsanleitung

True

True TS-28 Bedienungsanleitung

Frigidaire

Frigidaire FSC23R5DW9 Bedienungsanleitung

Beko

Beko LSP4579W Bedienungsanleitung
