Marey Aquamatic Bedienungsanleitung

Congratulations!

You'vejustpurchasedanewAquamatictanklesswaterheaterandwillsoonbeginto

enjoythebenefitsof“goingtankless.”

Takethe timeto thoroughly read andunderstand this safetyand installation manual

in its entirety before you attempt to install your new Aquamatic tankless water

heater,asitcontainsimportantsafetytipsandinstructions.

Pleasecarefullyread allinstructionsand warnings.Should youhaveany questions,

pleasevisitwww.marey.comforinstallationvideosandFAQ.

Pleasekeepthismanualforfuturereference.

INSTALLING YOUR SHOWER HEATER

INSTALLING YOUR SHOWER HEATER - AQUAMATIC

AQUAMATIC TECHNICAL SPECIFICATIONS

CUSTOMER SERVICE

OTHER PRODUCTS

0504

1a 1b

WE ALSO RECOMMEND YOU TO BUY THE

SINGLE FUNCTION SHOWER HEAD

MAREY BRAND

MANERA CORRECTA

CORRECT WAY MANERA INCORRECTA

WRONG WAY

AGUA CALIENTE / HOT WATER AGUA FRÍA / COLD WATER

1.Wrapwithteflon:

a)Bothendsofa½"straightnipple(notincluded);

b)Thethreadsontheheateroutput.

2.Screwoneendofthenippleintothebackoftheheater.

3.Screwtheheaterontothepipe, holdingtheheatercover firmly.Tightentheheater

withanadjustablewrench.

4.Screwontheshowerhead.

EXTREMELY IMPORTANT!! DO NOT CONNECTPOWER BEFORE ALLOWING

WATER TO FLOW THROUGH THE SHOWER HEATER FOR 10 SECONDS OR

LONGER. DAMAGE MAY OCCUR TO THE UNIT WHICH COULD INVALIDATE

THEWARRANTY.

Turnfaucetonandallowthewaterrunfor10seconds,thenattachtheshowerhead.

Note:OnlyusetheshowerheadincludedwiththisMarey®Heater.

Damage may occur if a replacement head is installed and this could also void your

warranty.

5.Plugtheheatertoareceptacle*6feetawayfromtheshowerarea.

*30ampelectriccircuitforexclusiveuseoftheheater.DONOTUSE

EXTENSIONS.

CONGRATULATIONSINSTALLATIONISNOWCOMPLETE!

Oncethefaucetisturnedon,hotwaterwillcomeoutinstantly.

AQUAMATIC: SET THE TEMPERATURE BY REGULATING THE FLOW OF

WATERAND/ORBYUSINGTHETEMPERATURESWITCHATTHESIDEOFTHE

UNIT.

I-LOW(Summer)

II-HIGH(Winter)

AQUAMATIC SANTON

POWERPAK PORTABLE POWER GAS

MINI MAREY

06 07

Please visit our website to get to know more about other Marey products.

Temperature increases listed are based on use of the water heater under optimal

conditions with an incoming water temperature of 48ºF. Variable factors such as

incorrect or imperfect installation or warmer incoming water temperature may yield

different results.

Delbrey Street, 211

San Juan, Puerto Rico

00912

www.marey.com

Voltage 110V

Voltage x Amperage = Power 110Vx23,5A=2.6kW

Width x Height x Depth 5" x 7.5" x 3.5"

TECHNICAL SPECIFICATIONS AQUAMATIC

Min./Max. GPM 0.85 - 1.5 GPM

Temperature Control HI & LOW Switch

& Water Pressure

Temperature Increase 110V = 10ºF - 23ºF

4 lbs

220V = 10ºF - 30ºF

220Vx16A=3.5kW

220V

Weight

0.85 - 1.5 GPM

HI & LOW Switch

& Water Pressure

5" x 7.5" x 3.5"

4 lbs

POWER

AQUA110

GPM

0.85

1.0

27º

15º

36º

21º

TEMP. INCREASE

PER GPM POWER

1.25

1.5

11º

9º

14º

12º

POWER

AQUA220

GPM

0.85

1.0

45º

25º

60º

34º

TEMP. INCREASE

PER GPM POWER

1.25

1.5

17º

15º

24º

20º

At Marey, we pride ourselves on the excellence of our

customerserviceandsupportteam.

Please feel free to contact us if you have any questions

about our products, warranty service, or if you need

assistance installing a unit. We also strive for continuous

improvement, so we welcome your comments, feedback

andsuggestions.
