Masimo Radius PPG Handbuch

Apply Sensor

Pair Radius PPG

Setup Instructions

GET TO KNOW YOUR SYSTEM

see back for sensor application

Sensor

Worn on your wrist and ﬁngertip,

the sensor collects your data.

Snapped into the wrist portion

of the sensor, the chip sends your

data to the Masimo SafetyNet App.

Chip

Masimo SafetyNet displays Oxygen Saturation,

Pulse Rate, Respiration Rate and other data from

Radius PPG. It also allows data updates to your

care provider.

Masimo SafetyNet App

Radius PPG

Accept Masimo SafetyNet

Invitation

See instructions on the back

showing how to apply the sensor

to your wrist and ﬁnger

and insert the chip.

The invite will come to your email.

After you accept, download the

Masimo SafetyNet App and follow

setup instructions.

page 1 of 2

Getting Started

Masimo SafetyNet™

Warning: Do not self-diagnose or self-medicate on the basis of the

measurements. Always consult your doctor.

Under Masimo SafetyNet App

Settings, enter the Add Device

menu, and follow instructions

for pairing the Radius PPG to

your phone.

For more info go to:

masimo.com/masimo-safetynet

301295/10689B-0320

Masimo Safetynet | Build 1.0.0.0

To Purchase, Visit Avobus.com or call 1-800-674-3655

2.1 Sensor Set Up

How to Apply your Sensor

2.2 Apply Finger Sensor

2.3 Insert Chip

3. Place sensor on wrist as shown and

carefully thread the tip of the strap

through the open red loop

4. Wrap the loose end of the strap

around your wrist and press

1. Remove sensor from pouch 2. Peel off yellow label

to activate battery

Listen for

click to secure.

Look for light

to conﬁrm

connection.

1. Insert the chip into the open

compartment on the sensor

2. Press down on the chip to secure

page 2 of 2

Place black

square ( )

on ﬁnger pad

1. Remove part of release liner

and place star ( ) on top

of ﬁngernail of ring ﬁnger

2. Wrap halfway around ﬁnger. Make

sure the star and square are lined

up directly across from each other

4. Remove release liner

and continue to

wrap remainder

around ﬁnger

3. Squeeze top and

bottom of wrap

to secure

5. Adjust cable to

comfortable length

To Purchase, Visit Avobus.com or call 1-800-674-3655
