Maxtor QUICKVIEW EXPANDER Bedienungsanleitung

Setup

1Verify the recording space available on your

Digital Video Recorder (DVR).

Write down the percentage of available space then

power down and disconnect the power cable from

your DVR.

2Connect power to a suitable wall outlet or power

strip. Do not use the auxiliary power connector

on the back of the DVR.

See reverse side for important information about attaching

the QuickView Expander drive to an electrical outlet.

The Green power light should display solid and the

orange status light should start flashing after power-

ing up the Quickview Expander drive.

3Connect the ESATAcable to the back of the

Quickview Expander drive and the DVR.

After power is reconnected and the DVR is powered

up, the orange status light should stop flashing.

Quick Start Guide

Handling Precautions

Handle your drive with care! The following precautions

can help prevent loss of data or damage to your drive:

• Do not drop, jar or bump the QuickView Expander drive.

• Do not stack your QuickView Expander drive on top of

other component cooling vent holes or block airflow to

other components.

• Do not set the drive on its side without using the vertical stand.

• Do not remove any cables or power cords without properly

powering down the set top box, as instructed in your set top

box manual.

• Do not set any liquids or drinks on the drive. Liquids will

damage the internal electronics.

• Do not open the drive’s case.

• Do not place equipment in front of or behind your drive.

Doing this will restrict airflow that helps keep the drive cool.

Included in this Kit

Rubber Feet

Power Adapter

ESATACable

Maxtor QuickView Expander Drive

Vertical Stand

Product Features

Power Light

(green) Status Light

(orange) Power

Connector

ESATA

Connector

BACKFRONT

4Check available recording space. If the Quickview

Expander was detected properly by the DVR, your

available recording space should have increased.

Adding rubber feet to your QuickView

Expander Drive

If you plan to use your drive on a flat surface, your kit

includes four rubber feet to protect your drive and the

surface it is on.

To apply the feet:

1. Make sure your QuickView Expander drive is disconnected

properly from your DVR, and the drive is turned off.

2. The feet go on the bottom of your drive. Apply feet as

illustrated on bottom of your drive.

3. Return the drive to its upright position, so it rests on the

rubber feet.

STATUS MESSAGE

1 blink Light will blink once after product is plugged in.

2 blinks The SATA cable is not connected to the set top box.

8 blinks or

continuous There is an internal error. Contact your service

provider or www.maxtor.com.

POWER MESSAGE

ON The drive is on and running.

OFF The drive is off.

Recording Space Used:

You currently have 18 recordings.

44%

Recording Space Used:

You currently have 18 recordings.

15%

Display Lights

Your QuickView Expander drive is equipped with two

display lights. Each light communicates the health and

operation of the drive.

Status light only valid when the power light is on.

QUICKVIEW EXPANDER™DRIVE

www.maxtor.com

Maxtor P/N: 20260803

Important Notice

Some Digital Video Recorders (DVR) will have auxiliary power

outlets on the back of them.

Power outlets on the back of DVR’s should not be used to

power the QuickView Expander drive. Doing so may be

detrimental to the drive and the content you are recording.

When installing your QuickView Expander drive, make sure

you plug the power cord for the drive into a wall outlet or

power strip.

Do not remove any cables or power cords from the QuickView

Expander without first disconnecting the external ESATA cable

from the DVR. Failure to disconnect the external ESATA cable

first could damage the drive or the content you are recording.

Incorrect way to connect power to

QuickView Expander drive Correct way to connect power to

QuickView Expander drive

POWER CONNECTION CAUTION

Your cable service provider must enable and

continue the connection to your Digital Video

Recorder (DVR) for the Quickview Expander

Drive to record.

Your service provider is responsible for all warranty

and support services regarding your Cable and

DVR. For additional information regarding the

operation of your DVR, please contact your cable

service provider.

The QuickView Expander drive cannot

be used with more than one DVR.

Content will only be recognized by the

DVR originally connected to the

QuickView Expander.

The QuickView Expander is not designed to

operate with a personal computer.

For additional information or troubleshooting help

with your QuickView Expander drive, please

visit www.maxtor.com

refers to one billion bytes. Maxtor and the Maxtor stylized logo are registered trade-

marks, and QuickView Expander is a trademark, of Maxtor Corporation.

ADDITIONAL CAUTIONS AND INFORMATION
