Maytag MTF1842EEQ - 18 cu. Ft. Refrigerator Benutzerhandbuch

3" (7.5 cm)

2" (5.08 cm)

1/2" (1.25 cm)

2" (5.08 cm)

Top Mount Refrigerator

PRODUCT MODEL NUMBERS PRODUCT DIMENSIONS

LOCATION REQUIREMENTS

MTF1842EE

MTF1954EE

MTB1954EE

MTB2254EE

MTF2142EE

Electrical: A 115 Volt, 60 Hz., AC only 15- or

20-amp fused, grounded electrical supply is

required. It is recommended that a separate

circuit serving only your refrigerator be provided.

Use an outlet that cannot be turned off by a

switch. Do not use an extension cord.

Water: Connect the ice maker to a cold water

supply with water pressure between 30 and 120

psi (207 and 827 kPa).

If a reverse osmosis water filtration system is

connected to your cold water supply, the water

pressure to the system needs to be a minimum

of 40 to 60 psi (276 to 414 kPa).

Because Whirlpool Corporation policy includes a continuous commitment to improve

our products, we reserve the right to change materials and specifications without notice.

Dimensions are for planning purposes only. For complete details, see Installation

Instructions packed with product. Specifications subject to change without notice.

Ref. W10131413B

07-15-08

To ensure proper ventilation for your refrigerator, allow for a 1/2" (1.25 cm) space

on each side and the top. If your refrigerator has an ice maker, make sure you leave

some extra space at the back for the water line connections.

When installing your refrigerator next to a fixed wall, leave 2" (5.08 cm) minimum

on the hinge side (some models require more) to allow for the door to swing open.

NOTE: Do not install the refrigerator near an oven, radiator, or other heat source,

nor in a location where the temperature will fall below 55°F (13°C).

includes

rollers

extended 3/4"

includes

rollers

extended 3/4"

overall to

back of coils

EEC

Model Size Overall Depth A Cab.Width B Door Width C Cab.Height D Overall Height E

18 cu. ft. 29-3/8" 29-1/2" 29-3/4" 65-1/2" 66-1/4"

(74.6 cm) (74.9 cm) (75.6 cm) (166.4 cm) (168.3 cm)

19 cu. ft. 31-1/2" 29-1/2" 30-1/8" 65-1/2" 66-1/2"

(80.0 cm) (74.9 cm) (76.5 cm) (166.4 cm) (168.9 cm)

21 cu. ft. 29-3/8" 32-1/2" 32-3/4" 65-1/2" 66-1/4"

(74.6 cm) (82.5 cm) (83.2 cm) (166.4 cm) (168.3 cm)

22 cu. ft. 31-1/2" 32-1/2" 33-1/8" 65-1/2" 66-1/2"

(80.0 cm) (82.5 cm) (84.1 cm) (166.4 cm) (168.9 cm)
