Rake Range 6272 & 6878

Re-Assembly Instructions

Purpose/Scope: Rake Range Re-Assembly Instructions

Page 2of 49

CLT01058

Only suitably qualified persons experienced in Mechanical

assembly and handling, should attempt to take on this task, so it’s

achieved in a safe manner.

Always wear clothing and safety equipment that is fit for the job at

hand. When conducting re-assembly or maintenance work always

support machine properly, where possible always lower the

attachmentor implement to the ground before working on the machine.

The crane or lifting device must be capable of lifting a minimum load

of 3 tonnes (3,000 kg). Only use chains or strapping that are rated for a

minimum load of 2.5 tonnes (2,500 kg) per chain or strap when using

the lift eye locationson the chassis.

Never go under a suspended machine or attempt to try and stop it if

moving erratically, death or serious injury may result. Always be

observant of people and objects around the suspended machine and do

not allow the machine to impact heavilyon the ground after suspension

or movement.

The operator manual should be used along with these instructions for

full specifications. Only competent persons who have read and fully

understood the operator’s manual are qualified to operate this machine.

Purpose/Scope: Rake Range Re-Assembly Instructions

Page 3of 49

CLT01058

Remove all plastic shrink wrap

carefully and recycle

responsibly.

Remove bogie tandems and

box of spare parts from pallet

first.

Note: PTO shafts are secured

to rear of box.

Purpose/Scope: Rake Range Re-Assembly Instructions

Page 4of 49

CLT01058

Using a suitable crane, chains

and slings, remove all heavy

items from pallet.

Purpose/Scope: Rake Range Re-Assembly Instructions

Page 5of 49

CLT01058

Carefully set aside parts for the rake as shown.

Purpose/Scope: Rake Range Re-Assembly Instructions

Page 6of 49

CLT01058

Set centre chassis with rotor

arms in clear space for

assembly.

Lift centre chassis with rotor

arms using lifting eyes as

shown.

Using a suitable second crane

and sling, lift LH side rear

chassis as shown.

Purpose/Scope: Rake Range Re-Assembly Instructions

Page 7of 49

CLT01058

Pull out loom (red) from centre chassis and route through LH side rear

chassis as shown.

Secure LH side rear chassis

with M16x50bolts, M16

contact lock washers (on both

sides) and M16 steel lock nuts

provided.

Leave bolts loose at this stage.

Using a suitable second crane

and sling, lift RH side rear

chassis as shown.

Purpose/Scope: Rake Range Re-Assembly Instructions

Page 8of 49

CLT01058

Pull out loom (green) from centre chassis and route through RH side rear

chassis as shown.

Secure RH side rear chassis

with M16x50bolts, M16

contact lock washers (on both

sides) and M16 steel lock nuts

provided.

Leave bolts loose at this stage.

Attach spare tine arm holder

bracket to the rear chassis’

and secure with M16x80 bolts,

M16 contact lock washers (on

both sides) and M16 steel lock

nuts provided.

Leave bolts loose at this stage.

Purpose/Scope: Rake Range Re-Assembly Instructions

Page 9of 49

CLT01058

Secure both rear chassis’ with

the last M16x50 bolts, M16

contact lock washers (on both

sides) and M16 steel lock nuts

provided.

Tighten all bolts fully.

Torque bolts to 240Nm.

Attach wheel chock to the LH

side rear chassis and secure

with M8x25 setscrews and M8

flat washers provided.

Purpose/Scope: Rake Range Re-Assembly Instructions

Page 10 of 49

CLT01058

Attach steering arm bracket

in-between the rear chassis’

and secure with M12x60 bolts,

bushes, M12 SKM washers

and M12 nyloc nuts provided.

Using a suitable crane and

sling, lift rear chassis’ as

shown.

3 steering rods are provided

with rake.

The longer steering rod links

from the steering rod

underneath the centre chassis

to the steering arm bracket.

The 2 smaller steering rods

link from the steering arm

bracket to the axle arms.
