The following features are programmable for each individual channel. A description of each
feature is included. For programming each feature see the relevant page number in the
PROGRAMMING section of this manual.
Feature Description Page
Adding New Remotes Allows additional Code Hopping Remote Controls to be
learnt into the system
i.e. Use this for learning in additional remote controls.
4
Latched – activating the channel activates the output,
activating the channel again deactivates the output.
e.g. If a light was connected to the output, pressing the
button once would turn the light on, pressing the button
again would turn the light off.
Latched or Pulsed
Output
(Note: The Default
Factory Setting For Each
Channel is a 1 Second
Pulsed Output) Pulsed Output – Activating the channel will activate the
output for only 1 second.
e.g. If a light was connected to the output, pressing the
button would turn the light on for 1 second, the light will
then turn off.
5
Normally Open – output switches to closed when the
channel is activated.
Normally Open or
Normally Closed
Outputs Normally Closed – output switches to open when the
channel is activated.
i.e. Use on channel 4 when a normally closed circuit is
required. Channels 1, 2, and 3 have connections for both
normally open and normally closed outputs.
5
Timed Output Output will activate only for a programmed time when the
channel is activated.
e.g. If a light was connected to the output, pressing the
button would turn the light on for the programmed time,
the light will then turn off.
6
Momentary Output
Enable Output is activated while button on remote control is held
down and deactivates when button is released.
e.g. If a light was connected to the output, while pressing
the button the light would be on, releasing the button will
turn the light off.
7
Adding Wireless
Detectors Allows Wireless Detectors to be learnt into the system to
trigger one of the output channels.
i.e. Use this for learning in wireless detectors
8
Reed Mode Enable Output is activated on open and deactivated on close of
wireless reed switch.
i.e. Use when using wireless reed switches.
9
Low Battery output
from Wireless
Detector
Output is activated when a wireless detector learnt into any
channel transmits a low battery signal.
i.e. When the battery in the wireless detector goes low, the
output will activate.
9
