Megasat HD 601 Bedienungsanleitung

user manual

HD 601

Contents

Safety instructions ............................................................................................ 03

1. Referenz

1.1 Genareal Features .................................................................................... 04

1.2 Delivery............................................................................................................ 04

2. Names and key assignment

2.1 Front view ...................................................................................................... 05

2.2 Rear view ........................................................................................................ 05

2.3 Remote Control.......................................................................................... 06

3. Connecting the set-top box and a hard disk

3.1 Connecting the set-top box............................................................... 07

4. Main Menu

4.1 Installation ..................................................................................................... 08

4.2 Channel edit................................................................................................. 14

4.3 Settings............................................................................................................ 17

4.4 Time settings................................................................................................ 19

4.5 Advanced....................................................................................................... 21

4.6 Receiver Informations............................................................................. 22

5. Additional Information

5.1 Troubleshooting......................................................................................... 23

5.2 Speciﬁcations............................................................................................... 24

5.3 Informations ................................................................................................. 25

ENGLISH

Safety instructions

Please read the manual thoroughly before operating the equipment. In case of incorrect

or improper handling, the warranty becomes void.

Power supply: Before start please check the correct operation voltage of the

power point. The operating voltage of this device is AC 100 ~

240V, 50/60Hz.

Overload: Do not overload a wall outlet, extension cord or adapter, neither

use damaged power cord or touch it with wet hand as this may

result in electric shock.

Liquid: The device shall not be exposed to dripping or splashing water,

and that no objects ﬁlled with liquids, such as base, shall be

placed on the apparatus.

Ventilation: Keep the slots on top of the receiver uncover to allow suﬃcient

airﬂow to the unit. Do not put the receiver on soft furnishings or

carpets. Do not expose the receiver to direct light or do not

place it near a heater or in humid conditions. Do not stack other

electronic equipments on top of the receiver.

Risk of ssuocation: Do not let children play with ﬁlms or other packaging

components, there is a risk of suﬀocation.

Cleaning: Plug out the receiver from the wall outlet before cleaning. Clean

the receiver by a soft cloth or mild solution of washing-up liquid

(no solvents).

Connection: Disconnect the receiver from the mains when you connect it to

satellite LNB or disconnect it from LNB. Failure would possibly

cause damage to the LNB.

Location: Put the receiver indoor in order to avoid lightening, raining or

sunlight.

Uncover: Do not remove the cover, to reduce the risk of electric shock.

Contact qualiﬁed and licensed service personnel to repair the

receiver, or contact your dealer.

ENGLISH

1.1 General Features

1.2 Delivery

1. Referenz

• DVB-S/DVB-S2 Satellite Compliant (MPEG-II / MPEG-IV / H.264)

• DiSEqC 1.0, 1.1, (USALS) compatible

• 4-digit display

• Support SCPC & MCPC receivable from C / Ku-band satellite LNB

• Universal, Single, Single S & C band wideband LNBs

• Sensitive Tuner

• PAL / NTSC conversion

• Variable aspect ratio (4:3, 16:9) with Pan Vector or Letter Box

• Output resolution: 576p & 576i, 720p, 1080i & 1080p

• To improve HDMI with Upscalefunktion to picture quality

• 8 favorite lists

• Parental Control function

• 5 types of sorting function for channels

• Screen display with full color resolution

• Teletext and subtitle support (OSD)

• 7 days EPG (Electronic Program Guide) for On-Screen Program Information

• Multilingual menu

• Multichannel order

• USB 2.0 (Mediaplayer)

• Megasat HD 601

• Remote control

• Batteries

• User manual

04 ENGLISH

2.1 Front view

2. Names and key assignment

05ENGLISH

2.2 Rear view

ScartHDMI

Digital Audio

(S/PDIF)

Power switchLNB Input

Standby button

Diplay

USB

2. Names and key assignment

2.3 Remote control

ENGLISH

Zone 1

POWER Turn on/oﬀ the unit (Standby)

MUTE Muting the sound

TV/R Switches between TV and radio reception

DISPLAY Switching between diﬀerent display formats

MODE Change the TV resolution

TIME Timer Einstellungen

F1 Function key (optional)

Numeric keys (0~9) Program Change / Enter numbers

FAV Displays the Favorites list (if favorites available)

RECALL Switches between the last and current program

MENU To access the main menu

EXIT Exits the current menu step by step

INFO Displays information of the current program

EPG Displays the EPG (Electronic Program Guide)

Zone 2

pqSwitches TV/radio programs (up/down)

tuAdjust the volume

VOL +/- Adjust the volume

CH +/- Switches TV/radio programs (up/down)

OK Conﬁrm the current selection / Open the program list

TXT Displays the teletext of the respective program

SUB Displaying subtitles (if available)

OPT Option button

PAGE p/qScroll page by page

USB Display menus of the USB if a USB device is connected

FIND Quick search of individual programs

SLEEP Activate Oﬀ-Timer (15, 30, 45, 60, 90, 120min.)

Zone 3

AUDIO Selection or change the audio track

PAUSE Pauses the current TV picture (freeze picture)

ZOOM Zoom function of the current program

SAT Displays the stored satellite list

tt / uu Fast forward / reverse

uStart

nStop

tt / uu

Chapter forward / backward

Pause

lStart recording (optional)

07ENGLISH

3. Connecting the set-top box

3.1 Connecting the set-top box

HDMI cable

Scart cable (optional)

1. Connect the coaxial cable to the LNB.

(You can connect an LNB directly to the LNB IN,

or more LNBs through a DiSEqC switch or multiswitch.

2. Connect the HDMI or Scart cable with your TV.

3. Make sure that on your TV is selected corresponding

to the input channel (for example, HDMI 1).

08 ENGLISH

4. Main Menu

After connecting the receiver to other required equipment, turn on the set-top box

Use the tubutton to select your sub-

ject and press OK to conﬁrm your selec-

tion and enter that sub menu, press EXIT

button you can return to the previous

menu.

Satellite

Press the OK button to enter the list of

preset satellites. Use the pq buttons to

select a satellite, with the tubuttons you

can at select the symbol of the bottom of

the screen for editing and to the respective

satellite edit.

4.1 Installation

Note:

The default password for

the menu access is: 0000

Press the MENU button to enter the

menu.

The main menu consists of:

• Installation

• Channel edit

• Settings

• Time settings

• Advanced

• Information

1. Antenna settings

Press OK to Enter Dish setup, here you can make Satellite Scan, Satellite Edit, TP Search,

TP Edit and other related Functions.

09ENGLISH

4. Main Menu

Add satellite:

Add satellite by using the Red key. Here

you can input new Satellite angle, Satellite

Direction (east, west), Band (ku,c). OK to

conﬁrm the setting and this new satellite

will be added to the end of the Satellite

list.

Move satellite:

Select the satellite and press the OK but-

ton. You can now enter to move the po-

sition of the satellite in a desired position.

Delete satellite:

You can delete the user’s satellite. Select

the satellite that you want to delete from

the satellite list. You will be asked to con-

ﬁrm whether delete the satellite or not. If

you press ok key, all the channels in the

selected satellite and transponder will be

deleted, and the selected satellite will di-

sappear.

Rename satellite:

Select the satellite then press green but-

ton. You can change the satellite’s name,

angle, direction and band. Input the cha-

racters which you want to edit using the

browser.

10 ENGLISH

Transponder

Press the OK button to enter the list of pre-

set transponders. Use the pq buttons to

select a transponder, with the tubut-

tons you can at select the symbol of the

bottom of the screen for editing and to the

respective transponder. The processing is

performed in the same manner as the pro-

cessing of the satellite.

LNB Typ

Here you need to check the LNB typ according to your antenna, set the correct fre-

quency or deﬁne yourself. The default setting (Universal) is true in most cases.

LNB Power

Here you need to check the LNB power according to your antenna, set the correct

frequency or deﬁne yourself. The default setting (13V/18V) is true in most cases.

4. Main Menu

Unicable System:

Under the menu item LNB type, you can make the settings for single-cable (unicable).

The set-top box is programmable for diﬀerent unicable systems. Depending on the sys-

tem can be connected to a system of up to 8 set-to boxes.

Megasat, Kathrein, Technisat and identical devices use the following frequencies:

IF Channel: 1=1284; 2=1400; 3=1516; 4=1632; 5=1748; 6=1864; 7=1980; 8=2096

Inverto and identical systems use the following frequencies:

IF Channel: 1=1076; 2=1178; 3=1280; 4=1382; 5=1484; 6=1586; 7=1688; 8=1790

Under IF Channel You can select up to 8 diﬀerent frequencies, while each IF channel is

automatically assigned a frequency. Note that each frequency may be present only once

in your system. The frequencies depend on your cable system and must not be changed

arbitrarily. For systems that does not match the pre-programmed frequencies which can

under these Adjust the main point frequency.

Note:

Basically, one uses the

lowest frequency for the

longest cable path to the

set-top box.
