MicroNet EtherFast SP624EA Bedienungsanleitung

Quick Installation Guide

EtherFast 10/100M Switch

Model No.: SP624EA

Website http://www.micronet.info

Introduction

Micronet SP624EA provides powerful, high-performance Ethernet

switch, with all ports capable of 10 and 100Mbps auto-negotiation

operation.

Store-and-forward switching mode promises the low latency plus

eliminates all the network errors, including runt and CRC error

packets. To work under full-duplex mode, transmission and

reception of the frames can occur simultaneously without causing

collisions as well as double the network bandwidth.

The switch is plug-n-play without any software to configure and also

fully compliant with all kinds of network protocols. Moreover, the

diagnostic LEDs on the front-panel can provide the operating status

of individual port and whole system.

Package Contents

Before you start installing the device, verify the following items are in

the package:

yOne SP624EA Ethernet Switch

yQuick Installation Guide

yOne power cord

yWall-Mount accessories

Features

yComplies with 10Base-T/100Base-TX specifications of the

IEEE802.3/802.3u standard

ySupport Auto-Negotiation function to automatically select optimal

speed (10/100Mbps) and mode (Full/Half Duplex)

y8K MAC address table

y320 Kbyte memory buffer

ySupport auto uplink, no more cross-over cable

yForward and filter packets at non-blocking, full wire speed

y100 - 240V AC, universal internal power supply

Physical Description

SP624EA front panel view

SP624EA rear panel view

Please refer to the following table for LED definition

LED Status Operation

Steady Green Power is on

Power Off Power is off

Steady Green A valid link is established

Off No link is established

LINK/ACT

Blinking Green Transmitting or receiving data

Installation

Micronet SP624EA Switches do not require software configuration.

Users can immediately use any of the features of this product simply

by attaching the cables and turning on the power.

Connect each station to the switch by twisted-pair cable. Plug one

RJ-45 connector into a RJ-45 port of the switch, and plug the other

RJ-45 connector into the station’s network adapter. Power on the

switch and then system is ready.

In making a switch interconnection, you could use any port to

connect another switch with straight or crossover cable. As all the

ports support auto-uplink (MDI / MDI-X) function, using a straight

cable to make a switch-to-switch connection is allowed.

For cable selection, refer to the following table：

Network Speed Cable Type Max. Length

10Mbps Cat. 3, 4, 5 UTP/STP 100 meters

100Mbps Cat. 5 UTP/STP 100 meters

Note: To prevent costly equipment damage and downtime, please

consider installing a surge suppression device or a UPS

(Un-interrupted Power Supply).

Specifications

Standard IEEE802.3, IEEE802.3u

IEEE802.3x : Flow Control

Interface 24 * RJ-45 ports (10/100Mbps)

Cable Connections 10BASE-T: Category 3, 4, 5 UTP/STP

100BASE-TX: Category 5 UTP/STP

Network Speed 10/100Mbps & Full/Half duplex mode

auto detection

Uplink Auto Uplink (Auto MDI / MDI-X)

Switch Fabric 4.8Gbps

Memory 320 KByte

MAC Address Table 8K entries

Filtering/Forwarding

Rate 10Mbps: 14,880pps/14,880pps

100Mbps: 148,800pps/148,800pps

Emission FCC Class A, CE

Operating Temperature 0o ~ 55o C (32o ~ 131o F)

Operating Humidity 10% - 95% (Non-condensing)

Dimension & Weight 267 x 161 x 42 mm, 1.3kg

Power Supply 100 - 240V AC, 50/60 Hz

Full range internal power supply

CE Mark Warning

This equipment complies with the requirements relating to

electromagnetic compatibility, EN 55022 class A for ITE, the

essential protection requirement of Council Directive 89/336/EEC on

the approximation of the laws of the Member States relating to

electromagnetic compatibility.

Company has an on-going policy of upgrading its products and it

may be possible that information in this document is not up-to-date.

Please check with your local distributors for the latest information.

No part of this document can be copied or reproduced in any form

without written consent from the company.

Trademarks:

All trade names and trademarks are the properties of their

respective companies.

P/N: 2300-0228
