Microtek C997SD Bedienungsanleitung

•

Ｃ９９７ＳＤ　Ｅｎｇｌｉｓｈ．ｐ６５ 03-3-26, 13:391

The Federal Communications Commission warns that changes or

modifications of the unit not expressly approved by the party responsible

for compliance could void the user’s authority to operate the equipment.

CE mark for Class B ITE (Following European standard EN55022/1998;

EN61000-3-2/1995;EN61000-3-3/1995,EN55024/1998,EN60950/

1992+A1+A2+A3+A4+A11)

Radio Frequency Interference Statement

Warning:

This is a Class B product. In a domestic environment, this product may

cause radio interference in which case the user may be required to take

adequate measures.

Canadian Doc Notice

For Class B Computing Devices

This digital apparatus does not exceed the Class B limits for radio noise

emissions from digital apparatus as set out in the Radio Interference

Regulation of the Canadian Department of Communications.

“Le présent appareil numérique n’èmet pas de bruits radioélectriques

dépassant les limites applicables aux appareils numériques de la class

B prescrites dans le Règlement sur le brouillage radioélectrique édicté

par le ministère des Communications du Canada”

Ｃ９９７ＳＤ　Ｅｎｇｌｉｓｈ．ｐ６５ 03-3-26, 13:392

Table of Contents

Your New LCD Monitor

Unpacking

Identifying Components

Hot Keys for Quick Adjustment of Monitor Settings

Adjusting the Viewing Angle

Connecting AC Power

Connecting Video

Connecting the Stereo Speakers

Power Management System

The LCD Monitor’s Display Controls

Adjusting the Monitor’s Display

LCD Monitor Specifications

SupportedTiming

TroubleshootingProcedures

Ｃ９９７ＳＤ　Ｅｎｇｌｉｓｈ．ｐ６５ 03-3-26, 13:393

The LCD Monitor

Your New LCD Monitor!

Your LCD Monitor has been designed to be versatile, ergonomic and

user-friendly. The LCD Monitor is capable of displaying most standards,

from 640 x 400 VGA to 1280 x 1024 SXGA. The digital controls located

on the front panel allows the user to easily adjust the Monitor’s display

parameters, and the LCD Monitor’s small footprint allows you more

room in your workspace for other peripherals. Lightweight and compact,

the LCD Monitor is the perfect solution for users on the go. You can

use the LCD Monitor for everything from making business presentations

to playing computer games. The two stereo speakers allow you to

further expand your computer’s multimedia capabilities by connecting

your computer’s Audio out port to the LCD Monitor’s Audio in port. The

Monitor also has a wall-mountable stand for added convenience.

The architecture of the LCD Monitor incorporates an LCD panel that

produces a clear display with low radiation emission. And with its low

power consumption, the LCD Monitor helps you reduce your power bill.

Unpacking

Before you unpack your LCD Monitor, prepare a suitable workspace for

your LCD Monitor and computer. You need a stable, level and clean

surface near a wall outlet. Even though the LCD Monitor uses very little

power, you should put it in a location which allows sufficient airflow to

ensure that the LCD Monitor and your computer do not overheat. Set up

your LCD Monitor so that the panel is not facing a window where sun-

light often comes in. The glare caused by sunlight reflecting off of the

LCD Monitor’s screen will make it difficult to use the Monitor for viewing.

Ｃ９９７ＳＤ　Ｅｎｇｌｉｓｈ．ｐ６５ 03-3-26, 13:394

Note:

Using a computer for an extended period of time with a poor

workstation set-up and incorrect working habits can cause health

problems. The science of ergonomics studies the relationship between

health and a suitable working environment. There is a section on

ergonomics at the end of this chapter. For more information on

ergonomics, contact your nearest computer bookstore, or local library.

The Internet also has information on this and other subjects.

After unpacking your LCD Monitor; make sure the following items are

included in the box and are in good condition:

•LCD Monitor

•Monitor-to-PC Analog signal cable (15-pin)

•Monitor-to-PC Digital signal cable (24-pin)

•Mini stereo audio cable

•AC Adapter

•Power cord

•User’s manual

If you find that any of these items are missing or appear damaged,

contact your dealer immediately. Do not throw away the packing mate-

rial or shipping carton in case you need to ship or store the LCD Moni-

tor in the future.

Identifying Components

This LCD Monitor has been designed to provide easy access to

all controls and peripheral ports. The illustrations below will help

you in identifying the LCD Monitor’s controls and ports.

Ｃ９９７ＳＤ　Ｅｎｇｌｉｓｈ．ｐ６５ 03-3-26, 13:395

The LCD Monitor — Front View

Figure 1-1: The LCD Monitor Panel and Controls

1. LCD Screen

The LCD Monitor Screen is a 19” TFT 1280 x 1024 SXGA screen.

2. Function Control Buttons /OSD Menu Button

The 1st button allows you to display the OSD (On-Screen Display)

Menu and to select the function group. The 2nd button allows you

to select one of the control functions within each function group.

3. Adjustment Control Buttons

These two buttons allow you to adjust the selected control function

to accommodate your specific working environment. Press the

upper button (+) to increase the setting of the selected control

function and press the lower (-) button to decrease the setting of

the selected control function.

4. Power-On Indicator

This LED indicator lights up when the power is on. The LED

indicator will blink when the LCD Monitor is in power-saving mode.

Ｃ９９７ＳＤ　Ｅｎｇｌｉｓｈ．ｐ６５ 03-3-26, 13:396

5. Power Button

Press this button to turn the Monitor on/off.

6. Monitor Stand

The Monitor Stand supports the LCD Panel. Loop the VGA signal

cable through the hole on the Monitor Stand.

7. Stereo Speakers

You can connect your PC’s Audio out port to the LCD Monitor’s

Audio in port and listen to your PC’s audio output with these

speakers.

Hot Keys for Quick Adjustment of Monitor Settings

1.”Auto-adjust” hot key:

Press the 2nd function button to apply monitor

settings automatically. A small “AUTO ADJUST”

OSD is also displayed.

2.” Adjust-volume” hot key:

Press the 1st adjustment control button to adjust the

audio volume directly.

Figure 1-2: Hot Keys

Ｃ９９７ＳＤ　Ｅｎｇｌｉｓｈ．ｐ６５ 03-3-26, 13:397

3.” Contrast-adjust” hot key:

Press the 2nd adjustment control button to adjust

the contrast of the display directly.

** To close the OSD windows, press the power button once.

The LCD Monitor — Rear View

Figure 1-3: LCD Monitor’s Rear Ports

1. DC Power Jack for AC adaptor

Connect the AC adapter cable to this jack.

2. Audio Line-in

Connect your PC’s line-out to this jack to listen the PC’s audio on

the LCD monitor’s stereo speakers. (You can also connect your

CD-ROM’s line-out to this jack.)

3. VGA Cable Connector

This 15-pin D-Sub VGA connector is used to connect to your PC’s

VGA card.

4. Digital VGA Cable Connect

This 24-pin DVI connector is used to connect to your PC’s Graphic

card if it is equipped a DVI connector.

Ｃ９９７ＳＤ　Ｅｎｇｌｉｓｈ．ｐ６５ 03-3-26, 13:408

Adjustsing the Viewing Angle

Your LCD Monitor is designed to allow you to adjust it to a comfortable

viewing angle. The LCD Monitor’s vertical angle setting range is from -5°

to 20°. Please see

Figure 1-3

Figure 1-4: Angle Settings

•When positioning the equipment, make sure that the

main ports and sockets are easily accessible.

•Do not place your LCD Monitor close to a heat source.

•Do not place the LCD Monitor in direct sunlight or near a

window. Moisture and direct sunlight exposure can

seriously damage the LCD Monitor.
