OWNER’S MANUAL
Electric Fan
Model: AMS150-CJ
READ AND SAVE THESE INSTRUCTIONS
Attention: Pictures in the IM are for reference only.
IMPORTANT SAFETY INSTRUCTIONS
Read Rules for Safe Operation and Instructions Carefully.
Caution
WARNING
1
1. If the supply cord is damaged, it must be replaced by
manufacturer or its service agent or a similarly qualified
person in order to avoid a hazard.
2. To protect against the risk of electrical shock, do not immerse
the unit, cord or plug in water or other liquid.
3. This appliance is not intended for use by persons (including
children) with reduced physical, sensory or mental capabilities, or
lack of experience and knowledge, unless they have been given
supervision or instruction concerning use of the appliance by a
person responsible for their safety. Children should be
supervised to ensure that they do not play with the appliance.
4. When the appliance is not in use and before cleaning, unplug
the appliance from the outlet.
5. Correct Disposal of this product
This marking indicates that this product should not be
disposed with other household wastes throughout the EU. To
prevent possible harm to the environment or human health
from uncontrolled waste disposal, recycle it responsibly to
promote the sustainable reuse of material resources. To
return your used device, please use the return and collection
systems or contact the retailer where the product was
purchased. They can take this product for environmental safe
recycling.The packaging material is recyclable. Dispose of
the packaging in an environmentally friendly manner and
make it available for the recyclable material
collection-service.
2
1. Never insert fingers, pencils, or any other object through the
grille when fan is running.
2. Disconnect fan when moving from one location to another.
3. Be sure fan is on a stable surface when operating to avoid
overturning.
4. DO NOT use fan in window, rain may create electrical hazard.
5. Indoor use only.
RULES FOR SAFE OPERATION
IMPORTANT SAFETY INSTRUCTIONS
WARNING
6. Keep electrical appliances out of reach from Children or infirm
persons. Do not let them use the appliances without
supervision.
7.
Indoor and household use only.
8. When the fan was assembled, the rotor blade guard shall not
be taken off anymore.
- Prior cleaning unplug the fan.
- The rotor guard shall not be dissembled/opened to clean the
rotor blades.
- Wipe the fan enclosure and rotor blade guard with a slightly
damp cloth.
PRODUCT INTRODUCTION
Pictures in the manual are for reference only, and real objects within the
packaging box will prevail in the end.
Note:
Parts name
1
2
3
4
5
6
78 89 910 10
NO. Description NO. Description
1 Operation panel
2Display panel
3Air outlet
4
5
7
Ambient light of belt
8
Base
Power cord plug
Air inlet grille
9 Pre-filter
10 HEPA filter
6Power line
3
Remote Controller ×1 Manual × 1 HEPA Filter ×2
4
PRODUCT INTRODUCTION
Parts list
INSTALLATION INSTRUCTIONS
Installation steps
Remove the protective
film of the filter.
3
Take out the pre-filter
Press the raised part on both
sides to pull it outwards, and
take out the pre-filter.
21 Remove the air inlet grille.
Buckle
Install the HEPA filter4
It is recommended to clean the filter once every two weeks and replace it once
every six months (the cleaning and replacement cycle can be adjusted according
to the use environment).
INSTALLATION INSTRUCTIONS
Installation steps
Install the pre-filter
5
Align the slot position at the
bottom, and buckle up the upper
U-shaped buckle.
Install the air inlet grille
Align the upper two buckles
and press them tightly, then
press the two sides at lower
part, slowly and gently buckle
the air inlet grille.
6
Buckling
position
Plug power supply7
5
INSTRUCTIONS
Control area Display area
Button Function Description
“- 、+”
Startup/Standby.
Set wind speed/timing.
Multi-angle oscillating switch of 30°,60°, 120° and 0°.
In the startup mode, press this button for cyclic switch between normal wind
(12 gears, indicator light is on) /sleep wind (3 gears, indicator light is
on)/baby wind (2 gears, indicator light is on).
Timed shutdown is achieved in the startup state, and reserved startup is
achieved in the standby state;
After clicking , set the timing time by pressing "+, -" (the display screen
shows 0-1-2- … -12-0h in a cycled manner), and when the timing time is 0h, it
indicates cancellation of timing/reservation.
Start up or shut down the mode of the wind changing with the temperature.
In the mode of wind changing with the temperature, the indicator light is on,
and the wind force can be automatically adjusted according to the change of
environmental temperature.
Short press to turn on/off the net ion sterilization module.
Long press for 3 seconds to reset the filter.
Ambient light function, turn on/off the Ambient light.
6
INSTRUCTIONS
Additional Features and Maintenance
Forced shutdown
Intelligent memory
There is no operation during the running of the fan, after 12 hours of contin-
uous operation, the fan will be forced to shut down automatically.
When the fan is turned off or powered off, it will run in the state before
turning off or power off when the power is powered on again (the timing
function is not memorized).
Screen-off function
In case of no operation for 60 seconds during normal operation, the indicator
light on the body will be automatically off, but the fan will continue to oper-
ate. Press the ON/OFF button to turn off the fan when the screen is off, and
press the other button to restore display.
Automatic reset of oscillating function upon shutdown
Upon shutdown, the oscillating function is automatically reset.
Remote control button description
7
Note:
The remote control should be normally used within 5 meters of the front of the product and 30
degrees of the deviation angle.
The battery contains many heavy metals, acids and bases, etc., which may threaten human's
health; Waste batteries should be recycled separately.
Start up or shut down
oscillating and air blowing
Startup/Standby
Switch the wind type
Start up /shut down the mode of
the wind changing with the
temperature
Set the timed shutdown/
reserved startup
Press “+, -” to set the wind
speed or timing time
AAA Battery, 1.5 V
Battery
Use manganese or alkaline batteries of type "AAA".
DO not use rechargeable batteries.
INSTRUCTIONS
Remote control button description
Filter replacement
8
Filter model: FQ150CJ-2
(including 2 sets)
12 When the indicator light for replacement
of filter is on, the prompt that reminds you
of filter replacement will appear. If it is not
replaced in time, the prompt will appear
during each startup.
4 Long press the net ion button for 3 seconds
to turn off the indicator light for filter
replacement.
Replace a new filter
3
PRODUCT PARAMETER
AMS150-CJ
Model
50Hz
Rated frequency
33W
Rated power
220-240V~
Rated voltage
≤61dB
Noise
INSTRUCTIONS
Pre-Filter cleaning
Unplug the power cord1
Remove the dust with vacuum
cleaner
3Install the machine in reverse
order and plug power supply
4
Take out the filter2
9
