Weld meters — digital ammeter

and presettable voltmeter allow

monitoring of welding output for

each welder.

Multi-arc welding is here! One

dependable engine and two high-

performance arcs allow operators

to work independent of each other.

It’s a one-of-a-kind, go-anywhere

engine drive.

Miller Du-Op®Engine-Driven

Welder/Generator

Issued May 2008 • Index No. ED/10.9

Thermal overload protection

prevents machine damage if the

duty cycle is exceeded or airflow

is blocked.

Two 14-pin remote controls can

be used for precise adjustment

of amperage or voltage along

with contactor.

Increase profits with this multi-arc

machine by completing even your

most demanding jobs in half the

time compared to conventional

engine-driven welders. With two

arcs in one engine drive, fewer

machines are required for a job.

Double the amperage output

with a switch that parallels both

outputs to a single side. This

provides a safe and easy way to

run large electrodes, stud weld,

or carbon-arc gouge.

5,500 watts of AC generator

power independent of welding

output. Two 120 V, 20 A GFCI

duplex receptacles. Two 230 V,

20 A duplex receptacles.

Hot Start™provides positive stick

electrode starts to make it easy

to start all types of electrodes.

The Power of Blue®

Welder/generator is warranted by Miller for 3 years, parts and labor.

Engine is warranted by Deutz for 2 years.

Miller Electric Mfg. Co.

An Illinois Tool Works Company

1635 West Spencer Street

Appleton, WI 54914 USA

Web Site

www.MillerWelds.com

International Headquarters

Phone: 920-735-4505

USA FAX: 920-735-4134

Canadian FAX: 920-735-4169

International FAX: 920-735-4125

Heavy Industrial Applications

Pipe Welding

Structural

Processes

Stick (SMAW)

MIG (GMAW)

Flux Cored (FCAW)

DC TIG (GTAW)

Air Carbon Arc (CAC-A)

Single Weld Mode:

3/8 in (9.5 mm) Carbons

Dual Weld Mode:

1/4 in (6.4 mm) Carbons

Output Range

Single Weld Mode: (Right side) CC/DC 30 – 600 A

Dual Weld Mode: (Both sides) CC/DC 15 – 300 A

CV/DC 10 – 32 A

Weld Output Rated at 104°F (40°C)

Single Weld Mode: 550 A at 30 VDC, 40% Duty Cycle

Dual Weld Mode: 275 A at 31 VDC, 40% Duty Cycle

Generator Output Rated at 104°F (40°C)

5,500 Watts Peak — 4,000 Watts Continuous

Weight Net: 2115 lb (959 kg) Ship: 2150 lb (975 kg)

Arc control (DIG) allows the arc

characteristics to be changed for

specific applications and electrodes.

Smooth running 7018 or stiffer,

more penetrating 6010 electrodes.

100

150

200

250

300

0 5 10 15 20 25 30

10 15 20 3025 40 50 60 80 100

AC AMPERES IN 240V MODE

AC VOLTS

100

150

125

WELD AMPERES

100% DUTY CYCLE

100

150

400

300

250

200

500

600

1000

800

0102030405060

AC AMPERES IN 120V MODE

0 50 100 150 200 250 300 350 400 450 500 550 600

DC WELD AMPERES AT 40% DUTY CYCLE

0.25

0.50

0.75

1.00

1.25

1.50

1.75

2.00

0.40

0.21

0.62

0.83

1.25

1.04

1.46

1.70

1.98

0.95

2.84

3.78

5.67

4.73

6.62

7.57

U.S. GAL./HR.

IMP. GAL./HR.

LITERS/HR.

SINGLE

DUAL

Welding

Mode

Single

Dual

Weld Output Rated

at 104˚ F (40˚ C)

550 A at 30 VDC,

40% Duty Cycle

275 A at 31 VDC,

40% Duty Cycle

Weld

Output

Range

30 – 600 A

15 – 300 A

10 – 32 V

Weld

Stations

Available

(Right side)

1 or 2

(Both sides)

Weld

Output

CC/DC

CV/DC

Max. Open-

Circuit

Voltage

*Additional 176 lb (80 kg) when fuel tank is full.

Engine Brand

Deutz, F3L-914

Features

Tier IV: EPA-certified, direct-injected, air-

cooled engine. Right-side service access with

service intervals of 500 hours for oil and

filters.

Type

Three-cylinder,

industrial, air-

cooled, diesel

Weld

Speed

1800 RPM

Idle: N/A

49.3

Fuel

Capacity

25 gal

(95 L)

Oil

Capacity

9 qt

(8.5 L)

Automatic Engine

Shutdown

High oil

temperature

Low oil pressure

Coolant

Capacity

Air

Engine (Subject to change without notice.)

Front Panel Side Panels

Control Panel

Performance Data

Weight

Without Fuel*

Net: 2005 lb

(909 kg)

Ship: 2032 lb

(922 kg)

Dimensions

H: 47-5/8 in

(1210 mm)

W: 31-1/4 in

(794 mm)

D: 60-1/2 in

(1537 mm)

Generator Output Rated

at 104˚ F (40˚ C)

Peak: 5500 watts

Continuous: 4000 watts,

34/17 A, 120/240 VAC,

while welding

Sound Levels at

Rated Output,

7 m (23 ft)

83 dB (108 Lwa)

Specifications (Subject to change without notice.)

1. 120 VAC, 20 A GFCI Duplex Receptacle and Circuit Breakers

2. 240 VAC, 20 A Duplex Receptacle and Circuit Breakers

3. Battery Charging Warning Light

4. Engine Hour Meter

5. Engine Start Button

6. Manual Stop Control

7. Ether Starting Aid Switch (Optional)

8. Separate/Parallel Switch

1. Process Selector Switch

2. Arc Force (DIG) Control

3. Hot Start Switch

4. Ammeter

5. Voltmeter

6. Amperage/Voltage Control

7. High Temperature

Shutdown Light

8. Remote Amperage/Voltage

Control Switch

9. Output (Contactor) Switch

10. Negative Weld Output Terminal

11. CC Weld Output Terminal

12. CV Weld Output Terminal

FUEL CONSUMPTIONAUXILIARY POWER

DUTY CYCLE

Genuine Miller Options and Accessories

Stick (SMAW) Welding

No. 2/0 Stick Welding Accessory Kits

#173 851

50 ft (15 m) No. 2/0 electrode cable with

electrode holder and 50 ft (15 m) No. 2/0

work cable with work clamp. 350 A at

100% duty cycle.

#043 952

100 ft (30.5 m) No. 2/0 electrode cable with

electrode holder and 50 ft (15 m) No. 2/0

work cable with work clamp. 300 A at

100% duty cycle.

Wire Feeders

SuitCase™X-TREME™ 8VS Wire Feeder

#300 093

SuitCase™X-TREME™ 12VS Wire Feeder

#195 500

Lightweight, portable, voltage-sensing wire

feeder for .045/.052 flux core and .035/.045

hard wire. Includes secondary contactor and

gas valve. Requires gun and drive roll kit.

See Lit. Index M/6.41.

MIG (GMAW) Guns

Miller produces a complete line of

dependable MIG guns. Check literature

for complete details. See Lit. Index Nos.

M/10.0 and M/13.4.

Remote Controls

RHC-14 Hand Control #129 340

Miniature hand control for remote current

and contactor control. Dimensions: 4 x 4 x

3-1/4 in (102 x 102 x 82 mm). Includes

20 ft (6 m) cord and 14-pin plug.

Extension Cords for 14-Pin Remote Controls

#122 973 25 ft (7.6 m)

#122 974 50 ft (15.2 m)

#122 975 75 ft (22.9 m)

HWY-224 Trailer #043 805

A 2650 lb (1202 kg) capacity highway

trailer. Welded steel tubing frame, heavy-

duty axle with roller bearing hubs and

leaf-spring suspension. The HWY-224

comes with jack stand, 2 in (50 mm)

ball hitch, fenders and lights.

Note: Trailer is shipped unassembled.

OFR-224 Trailer #043 802

A 2650 lb (1202 kg) capacity off road

trailer. Welded steel tubing frame, heavy-

duty axle with roller bearing hubs and leaf

spring suspension. The OFR-224 comes

with jack stand and 2 in (50 mm) ball hitch.

Note: Trailer is shipped unassembled.

Lunette Eye 2-1/2 in (64 mm) #043 824

For use with both 224 trailers.

Cable Tree #043 826

Provides an area to conveniently wrap weld

cables and extension cords. Works on all

224 and 430 trailers.

HWY-430 Tandem Axle Trailer #043 806

Smooth riding with 3750 lb (1701 kg)

capacity. Includes: adjustable hitch for

level operation, a hand operated parking

brake, a self-actuating hydraulic brake

system and a break-away device to lock

brakes if the trailer comes loose. It also

includes jack stand, fenders and lights.

(Hitch must be ordered separately.)

Note: Some assembly required.

Ball Hitch 2 in (50 mm) #043 864

For use with the 430 trailer.

Lunette Eye 3 in (76 mm) #043 863

For use with the 430 trailer.

4 West Four-Wheel Steerable Off-Road

Trailer #042 801

A heavy-duty 2570 lb (1166 kg) capacity

trailer designed for use in mines, quarries,

and other rough terrain. Has narrow 22 ft

(6.7 m) turning radius. Includes 3 in lunette

eye, universal hitch and safety chains.

Note: Trailer is shipped unassembled.

See page 4 for specifications on each trailer.

Trailers and Hitches

Litho in USA

Distributed by:

Equipment and Factory Options Stock No. Description Qty. Price

Miller Du-Op™Base Model #907 317

International Model #907 317-01-1 Dry Battery

#907 317-02-1 Dry Battery, Polarity Switches

Wire Feeders

Suitcase X-TREME™8VS Wire Feeder #300 093 Includes contactor and gas valve. See Lit. Index No. M/6.41

Suitcase X-TREME™12VS Wire Feeder #195 500 Includes contactor and gas valve. See Lit. Index No. M/6.41

MIG Guns and Consumables See Lit. Index No. M/10.0 and M/13.4

Stick Accessories

Welding Leads #173 851 2/0, 350 A, 100% duty cycle, 50 ft (15 m) stinger, 50 ft (15 m) work clamp

#043 952 2/0, 300 A, 100% duty cycle, 100 ft (30.5 m) stinger, 50 ft (15 m) work clamp

Remote Controls

RHC-14 #129 340 Hand control

Extension Cords #122 973 25 ft (7.6 m), 14-pin remote controls

#122 974 50 ft (15.2 m), 14-pin remote controls

#122 975 75 ft (22.9 m), 14-pin remote controls

Trailers and Hitches

HWY-224 Trailer #043 805 Trailer with lights, fenders and 2 in ball hitch

OFR-224 Trailer #043 802 Trailer with 2 in ball hitch

Lunette Eye, 2-1/2 in #043 824 Replaces the 2 in ball hitch on the HWY-224 or OFR-224

Cable Tree #043 826 Trailer mounted cable holder for HWY-224, OFR-224 or HWY-430

HWY-430 Trailer #043 806 Hitch required

Ball Hitch, 2 in #043 864 For HWY-430 only

Lunette Eye, 3 in #043 863 For HWY-430 only

4-West Trailer #042 801 Four-wheel steerable implement trailer

Date: Total Quoted Price:

Ordering Information

Trailer Specifications (Subject to change without notice.)

Net

Payload

2650 lb

(1202 kg)

3750 lb

(1701 kg)

2570 lb

(1166 kg)

Gross Vehicle

Weight Rating

2960 lb

(1343 kg)

4280 lb

(1941 kg)

3000 lb

(1361 kg)

Gross Axle

Weight Rating

3500 lb

(1588 kg)

2200 lb/axle

(998 kg/axle)

2000 lb/axle

(907 kg/axle)

Model

HWY-224

OFR-224

HWY-430

4 West

Height

of Bed

18-1/2 in

(470 mm)

19-1/4 in

(489 mm)

21-1/4 in

(540 mm)

Road

Clearance

7-1/2 in

(191 mm)

8-1/2 in

(216 mm)

8 in

(203 mm)

Net

Weight

355 lb

(161 kg)

530 lb

(240 kg)

430 lb

(1950 kg)

Track (Center

to center of

tires)

52 in

(1321 mm)

52 in

(1321 mm)

55-1/4 in

(1403 mm)

Standard Tires

(Standard rating

or P-size rating)

B78-13C

B78-13B

B78-13

Dimensions

Length: 122-1/2 in (3112 mm)

Width: HWY– 61 in (1549 mm)*

OFR–58-1/2 in (1486 mm)

Length: 156-1/2 in (3975 mm)

Width: 61 in (1549 mm)*

Length: 91 in (2311 mm)**

Width: 61-1/4 in (1556 mm)

Width at outside of fenders.

Does not include tongue.

Dieses Handbuch passt für folgende Modelle

Inhaltsverzeichnis

Andere Miller Electric Schweißsystem Handbücher

Miller Electric

Miller Electric SuitCase X-TREME 8VS WCC Bedienungsanleitung

Miller Electric

Miller Electric Maxstar 150 STL Bedienungsanleitung

Miller Electric

Miller Electric D-74S Bedienungsanleitung

Miller Electric

Miller Electric Digi-Meter RMS (AC-DC) Bedienungsanleitung

Miller Electric

Miller Electric MARK VIII-2 Bedienungsanleitung

Miller Electric

Miller Electric XMT 350 CC/CV Bedienungsanleitung

Miller Electric

Miller Electric Two Fifty AC Bedienungsanleitung

Miller Electric

Miller Electric S-62 Bedienungsanleitung

Miller Electric

Miller Electric GB-10 Bedienungsanleitung

Miller Electric

Miller Electric Dynasty Bedienungsanleitung

Miller Electric

Miller Electric 057 607 Bedienungsanleitung

Miller Electric

Miller Electric APT-1000 Bedienungsanleitung

Miller Electric

Miller Electric Voltage Interface Control Bedienungsanleitung

Miller Electric

Miller Electric Syncrowave 500 Bedienungsanleitung

Miller Electric

Miller Electric SW3 Bedienungsanleitung

Miller Electric

Miller Electric AUTO ARC AATC-150 Bedienungsanleitung

Miller Electric

Miller Electric MP-75E Bedienungsanleitung

Miller Electric

Miller Electric SYNCRON 300 Bedienungsanleitung

Miller Electric

Miller Electric SWLR-115 Bedienungsanleitung

Miller Electric

Miller Electric MILLERMATIC 30B CONTROL/FEEDER Bedienungsanleitung

Miller Electric

Miller Electric SSW-2020 ATT Bedienungsanleitung

Miller Electric

Miller Electric CP-302 Bedienungsanleitung

Miller Electric

Miller Electric Subarc DC 1250 Bedienungsanleitung

Miller Electric

Miller Electric SuitCase X-TREME 8VS Bedienungsanleitung

Beliebte Schweißsystem Handbücher anderer Marken

Berner

Berner PLASMACUT 54 Bedienungsanleitung

Pro Spot

Pro Spot PR-155 Bedienungsanleitung

Forney

Forney 210 Bedienungsanleitung

Thermal Arc

Thermal Arc 400S Bedienungsanleitung

Lincoln Electric

Lincoln Electric HANDYMIG 170I Bedienungsanleitung

GYS

GYS PROTIG 201 AC/DC Bedienungsanleitung

TAFA

TAFA 30*8B35 Bedienungsanleitung

Lincoln Electric

Lincoln Electric INVERTEC V350-PRO CE Bedienungsanleitung

ESAB

ESAB Buddy Arc 145 Bedienungsanleitung

CIGWELD

CIGWELD 636804 Kurzanleitung

Red-D-Arc

Red-D-Arc DC-400 Bedienungsanleitung

Hobart Welding Products

Hobart Welding Products Spool Gun DP 3035-10 Bedienungsanleitung

Elettro

Elettro HI-MIG 3000 SYNERGIC Bedienungsanleitung

WIA

WIA Weldmatic 270 CP132-2 Bedienungsanleitung

Sonics

Sonics H520T Bedienungsanleitung

Miller

Miller Big Blue 400D Bedienungsanleitung

NewArc

NewArc RT2000 Kurzanleitung

Hypertherm

Hypertherm powermax1000 Bedienungsanleitung
