milliard Changing Table Bedienungsanleitung
Changing Table
Congratulations on the purchase of your Changing Table!
PRECAUTION:
Always read and follow instructions before use | Always use the unit according to the
manufacturers guidelines | Only use the unit in a manner as intended by manufacturer.
Our team of dedicated customer care professionals are ready to help you with
any questions or concerns you may have.
For immediate attention, call Monday-Thursday 9:00am-5:00pm & Friday
9:00am-1:00pm.
Or you can leave us a voice message or email, and we guarantee you will hear
back from us within one business day.
Phone: 866-686-4891
Email: [email protected]
Did your Changing Table come with any damaged or missing parts?
WE’RE HERE TO HELPWE’RE HERE TO HELP
WARNING: THIS PRODUCT IS TO BE ASSEMBLED BY AN
ADULT. IN ITS UNASSEMBLED STATE THIS PRODUCT CONTAINS
POTENTIALLY HAZARDOUS SHARP POINTS, SHARP EDGES, AND
SMALL PARTS. KEEP OUT OF REACH OF CHILDREN.
!
MAINTENANCE:
To keep the unit clean, periodically dust and wipe it with a damp cloth. For more
extensive cleaning, use a mild wood cleanser and a soft cloth.
FALL HAZARD: CHILDREN HAVE SUFFERED SERIOUS INJURIES AFTER
FALLING FROM CHANGING TABLES. FALLS CAN HAPPEN QUICKLY.
• STAY IN ARM’S REACH OF YOUR CHILD.
• ALWAYS SECURE THIS PRODUCT TO THE SUPPORT FRAME, SEE
INSTRUCTIONS IN STEPS 33 AND 34.
SUFFOCATION HAZARD: BABIES HAVE SUFFOCATED WHILE SLEEPING
IN CHANGING AREAS. CHANGING AREAS ARE NOT DESIGNED FOR
SAFE SLEEPING.
• NEVER ALLOW BABY TO SLEEP IN CHANGING AREA.
WARNING
!
Shelves x2
8
Back Right Leg
1
Front Left Leg
3
Front Right Leg
2
Back Left Leg
4
CHANGING TABLE PARTS
Drawer Shelf
9
Right Side Panel
5
Left Side Panel
6
Back Top Panel
7
Front Strip
10
11
Changer Bottom Panel
21
12
Drawer Right Side
13
Drawer Front Panel
17
Drawer Left Side
15
Changer Bottom Support
20
Drawer Back Side
Changer Sides Panels x2
18
Drawer Bottom Support
16
Changer Front Panel
19
Changer Back Panel
22
Dresser Top Drawer Bottom Panel
14
HARDWARE PARTS
AB C
Cam Locks x26 Cam Screw x26 Dresser Side
Rail x2
D
Drawer Rail x2
F
Slotted Barrel
Nut x28
G
Bolt x12
H
Long Bolt x12
E
x12
K L
IJ
x2 Drawer Knobs x2
x8 Dowel Pins x8
Q
Non Slip Tape x6
R
White Bolt x4
S
Hex Key x1
MN
Long Screw x1 Short Screw x1
P
O
L Bracket x1
Wall Anchor x1
Attach the cam screws to the legs and .
Insert the cam locks into the holes on the right side panel
and left side panel .
ASSEMBLY INSTRUCTIONS
STEP 1
B
A
1
5
6
3
24
STEP 2
1
3
5
6
2
4
B
A
x8
x8
• Attach the front and back right legs with the right side
panel by turning the cam lock clockwise 90 degrees.
• Attach the front and back left legs with the left side
panel by turning the cam lock clockwise 90 degrees.
STEP 3
1
3
5
6
2
4
• Attach dresser rail to right side panel using screws.
• Attach dresser rail to left side panel using screws.
STEP 4
C
C 6
5 E
E
CE
x2 x6
1 32 4
5
5
6
6
• Insert slotted barrel nuts into the holes on the back top
panel .
• Attach the drawer shelf with the back top panel using
bolts .
Attach the selves with the back and
front and left legs using slotted
barrel nuts and long bolts .
STEP 5
F
G
7
9
8
7
STEP 6
3
F H
4
9
8
8
7
F
F
H
G
x2
x4
x4
x2
STEP 8
STEP 7
STEP 9
Attach cam screws to back
left leg .
• Attach drawer shelf to the left legs using long bolts .
• Secure the back top panel by turning the cam locks
clockwise 90 degrees.
• Insert cam locks into the holes
on the back top panel .
• Insert slotted barrel nut into the
holes on the drawer shelf .
4
4
7
H3
A
A
7
F
9
9
B
9
9
7
7
F
A
A
B
4
H
x2
x2
x2
x2
x2
Attach the cam screws to the back right leg .
Insert cam locks into the holes
on the back panel .
Attach the back right leg to the back top panel by turning the
cam locks clockwise 90 degrees.
STEP 10
STEP 12
B
A
A
1
1
7
7
STEP 11
1
1
Bx2
7
9
Ax2
7
