Mitsubishi Electric MELSEC-QD75MH1 Bedienungsanleitung

MELSEC-Q

QD75MH Positioning Module

User's Manual (Details)

-QD75MH1

-QD75MH2

-QD75MH4

A - 1

SAFETY PRECAUTIONS

(Please read these instructions before using this equipment.)

Before using this product, please read this manual and the relevant manuals introduced in this manual

carefully and pay full attention to safety to handle the product correctly.

Refer to the Users manual of the QCPU module to use for a description of the PLC system safety

precautions.

In this manual, the safety instructions are ranked as "DANGER" and "CAUTION".

DANGER

Indicates that incorrect handling may cause hazardous

conditions, resulting in death or severe injury.

CAUTION

Indicates that incorrect handling may cause hazardous

conditions, resulting in medium or slight personal injury or

physical damage.

Depending on circumstances, procedures indicated by CAUTION may also be linked to serious

results.

In any case, it is important to follow the directions for usage.

Please save this manual to make it accessible when required and always forward it to the end user.

A - 2

For Safe Operations

1. Prevention of electric shocks

DANGER

Never open the front case or terminal covers while the power is ON or the unit is running, as this

may lead to electric shocks.

Never run the unit with the front case or terminal cover removed. The high voltage terminal and

charged sections will be exposed and may lead to electric shocks.

Never open the front case or terminal cover at times other than wiring work or periodic

inspections even if the power is OFF. The insides of the module and servo amplifier are charged

and may lead to electric shocks.

Completely turn off the externally supplied power used in the system before mounting or removing

the module, performing wiring work, or inspections. Failing to do so may lead to electric shocks.

When performing wiring work or inspections, turn the power OFF, wait at least ten minutes, and

then check the voltage with a tester, etc. Failing to do so may lead to electric shocks.

Be sure to ground the module, servo amplifier and servomotor (Ground resistance : 100 or

less). Do not ground commonly with other devices.

The wiring work and inspections must be done by a qualified technician.

Wire the units after installing the module, servo amplifier and servomotor. Failing to do so may

lead to electric shocks or damage.

Never operate the switches with wet hands, as this may lead to electric shocks.

Do not damage, apply excessive stress, place heavy things on or sandwich the cables, as this

may lead to electric shocks.

Do not touch the module, servo amplifier, servomotor connector or terminal blocks while the

power is ON, as this may lead to electric shocks.

Do not touch the built-in power supply, built-in grounding or signal wires of the module and servo

amplifier, as this may lead to electric shocks.

2. For fire prevention

CAUTION

Install the module, servo amplifier, servomotor and regenerative resistor on incombustible.

Installing them directly or close to combustibles will lead to fire.

If a fault occurs in the module or servo amplifier, shut the power OFF at the servo amplifier's

power source. If a large current continues to flow, fire may occur.

When using a regenerative resistor, shut the power OFF with an error signal. The regenerative

resistor may abnormally overheat due to a fault in the regenerative transistor, etc., and may lead

to fire.

Always take heat measures such as flame proofing for the inside of the control panel where the

servo amplifier or regenerative resistor is installed and for the wires used. Failing to do so may

lead to fire.

Do not damage, apply excessive stress, place heavy things on or sandwich the cables, as this

may lead to fire.

A - 3

3. For injury prevention

CAUTION

Do not apply a voltage other than that specified in the instruction manual on any terminal.

Doing so may lead to destruction or damage.

Do not mistake the terminal connections, as this may lead to destruction or damage.

Do not mistake the polarity ( + / - ), as this may lead to destruction or damage.

Do not touch the heat radiating fins of module or servo amplifier, regenerative resistor and

servomotor, etc., while the power is ON and for a short time after the power is turned OFF. In this

timing, these parts become very hot and may lead to burns.

Always turn the power OFF before touching the servomotor shaft or coupled machines, as these

parts may lead to injuries.

Do not go near the machine during test operations or during operations such as teaching.

Doing so may lead to injuries.

4. Various precautions

Strictly observe the following precautions. Mistaken handling of the unit may lead to faults,

injuries or electric shocks.

(1) System structure

CAUTION

Always install a leakage breaker on the module and servo amplifier power source.

If installation of an electromagnetic contactor for power shut off during an error, etc., is specified in

the instruction manual for the servo amplifier, etc., always install the electromagnetic contactor.

Install the emergency stop circuit externally so that the operation can be stopped immediately and

the power shut off.

Use the module, servo amplifier, servomotor and regenerative resistor with the correct

combinations listed in the instruction manual. Other combinations may lead to fire or faults.

Use the CPU module, base unit and positioning module with the correct combinations listed in the

instruction manual. Other combinations may lead to faults.

If safety standards (ex., robot safety rules, etc.,) apply to the system using the module, servo

amplifier and servomotor, make sure that the safety standards are satisfied.

Construct a safety circuit externally of the module or servo amplifier if the abnormal operation of

the module or servo amplifier differ from the safety directive operation in the system.

In systems where coasting of the servomotor will be a problem during the forced stop, emergency

stop, servo OFF or power supply OFF, use dynamic brakes.

Make sure that the system considers the coasting amount even when using dynamic brakes.

In systems where perpendicular shaft dropping may be a problem during the forced stop,

emergency stop, servo OFF or power supply OFF, use both dynamic brakes and electromagnetic

brakes.

The dynamic brakes must be used only on errors that cause the forced stop, emergency stop, or

servo OFF. These brakes must not be used for normal braking.

The brakes (electromagnetic brakes) assembled into the servomotor are for holding applications,

and must not be used for normal braking.

A - 4

CAUTION

The system must have a mechanical allowance so that the machine itself can stop even if the

stroke limits switch is passed through at the max. speed.

Use wires and cables that have a wire diameter, heat resistance and bending resistance

compatible with the system.

Use wires and cables within the length of the range described in the instruction manual.

The ratings and characteristics of the parts (other than module, servo amplifier and servomotor)

used in a system must be compatible with the module, servo amplifier and servomotor.

Install a cover on the shaft so that the rotary parts of the servomotor are not touched during

operation.

There may be some cases where holding by the electromagnetic brakes is not possible due to the

life or mechanical structure (when the ball screw and servomotor are connected with a timing belt,

etc.). Install a stopping device to ensure safety on the machine side.

(2) Parameter settings and programming

CAUTION

Set the parameter values to those that are compatible with the module, servo amplifier,

servomotor and regenerative resistor model and the system application. The protective functions

may not function if the settings are incorrect.

The regenerative resistor model and capacity parameters must be set to values that conform to

the operation mode, servo amplifier and servo power supply module. The protective functions

may not function if the settings are incorrect.

Set the mechanical brake output and dynamic brake output validity parameters to values that are

compatible with the system application. The protective functions may not function if the settings

are incorrect.

Set the stroke limit input validity parameter to a value that is compatible with the system

application. The protective functions may not function if the setting is incorrect.

Set the servomotor encoder type (increment, absolute position type, etc.) parameter to a value

that is compatible with the system application. The protective functions may not function if the

setting is incorrect.

Set the servomotor capacity and type (standard, low-inertia, flat, etc.) parameter to values that

are compatible with the system application. The protective functions may not function if the

settings are incorrect.

Set the servo amplifier capacity and type parameters to values that are compatible with the

system application. The protective functions may not function if the settings are incorrect.

Use the program commands for the program with the conditions specified in the instruction

manual.

Set the sequence function program capacity setting, device capacity, latch validity range, I/O

assignment setting, and validity of continuous operation during error detection to values that are

compatible with the system application. The protective functions may not function if the settings

are incorrect.

A - 5

CAUTION

Some devices used in the program have fixed applications, so use these with the conditions

specified in the instruction manual.

The input devices and data registers assigned to the link will hold the data previous to when

communication is terminated by an error, etc. Thus, an error correspondence interlock program

specified in the instruction manual must be used.

Use the interlock program specified in the intelligent function module's instruction manual for the

program corresponding to the intelligent function module.

(3) Transportation and installation

CAUTION

Transport the product with the correct method according to the mass.

Use the servomotor suspension bolts only for the transportation of the servomotor. Do not

transport the servomotor with machine installed on it.

Do not stack products past the limit.

When transporting the module or servo amplifier, never hold the connected wires or cables.

When transporting the servomotor, never hold the cables, shaft or detector.

When transporting the module or servo amplifier, never hold the front case as it may fall off.

When transporting, installing or removing the module or servo amplifier, never hold the edges.

Install the unit according to the instruction manual in a place where the mass can be withstood.

Do not get on or place heavy objects on the product.

Always observe the installation direction.

Keep the designated clearance between the module or servo amplifier and control panel inner

surface or the module and servo amplifier, module or servo amplifier and other devices.

Do not install or operate modules, servo amplifiers or servomotors that are damaged or that have

missing parts.

Do not block the intake/outtake ports of the servo amplifier and servomotor with cooling fan.

Do not allow conductive matter such as screw or cutting chips or combustible matter such as oil

enter the module, servo amplifier or servomotor.

The module, servo amplifier and servomotor are precision machines, so do not drop or apply

strong impacts on them.

Securely fix the module, servo amplifier and servomotor to the machine according to the

instruction manual. If the fixing is insufficient, these may come off during operation.

Always install the servomotor with reduction gears in the designated direction. Failing to do so

may lead to oil leaks.

A - 6

CAUTION

Store and use the unit in the following environmental conditions.

Conditions

Environment

Module/Servo amplifier Servomotor

Ambient

temperature According to each instruction manual. 0°C to +40°C (With no freezing)

(32°F to +104°F)

Ambient humidity According to each instruction manual. 80% RH or less

(With no dew condensation)

Storage

temperature According to each instruction manual. -20°C to +65°C

(-4°F to +149°F)

Atmosphere Indoors (where not subject to direct sunlight).

No corrosive gases, flammable gases, oil mist or dust must exist

Altitude 1000m (3280.84ft.) or less above sea level

Vibration According to each instruction manual

When coupling with the servomotor shaft end, do not apply impact such as by hitting with a

hammer. Doing so may lead to detector damage.

Do not apply a load larger than the tolerable load onto the servomotor shaft. Doing so may lead

to shaft breakage.

When not using the module for a long time, disconnect the power line from the module or servo

amplifier.

Place the module and servo amplifier in static electricity preventing vinyl bags and store.

When storing for a long time, please contact with our sales representative.

Also, execute a trial operation.

Make sure that the connectors for the servo amplifier and peripheral devices have been securely

installed until a click is heard.

Not doing so could lead to a poor connection, resulting in erroneous input and output.

(4) Wiring

CAUTION

Correctly and securely wire the wires. Reconfirm the connections for mistakes and the terminal

screws for tightness after wiring. Failing to do so may lead to run away of the servomotor.

After wiring, install the protective covers such as the terminal covers to the original positions.

Do not install a phase advancing capacitor, surge absorber or radio noise filter (option FR-BIF) on

the output side of the servo amplifier.

Correctly connect the output side (terminal U, V, W). Incorrect connections will lead the

servomotor to operate abnormally.

Do not connect a commercial power supply to the servomotor, as this may lead to trouble.

A - 7

CAUTION

Do not mistake the direction of the surge absorbing diode installed on the DC relay for the control

signal output of brake signals, etc. Incorrect installation may lead to signals not being output

when trouble occurs or the protective functions not functioning.

DICOM

Control output

signal

DOCOM

Servo amplifier 24VDC

Control output

signal

DICOM

DOCOM

Servo amplifier

24VDC

For the sink output interface For the source output interface

Do not connect or disconnect the connection cables between each unit, the encoder cable or

PLC expansion cable while the power is ON.

Securely tighten the cable connector fixing screws and fixing mechanisms. Insufficient fixing may

lead to the cables combing off during operation.

Do not bundle the power line or cables.

Use applicable solderless terminals and tighten them with the specified torque.

If any solderless spade terminal is used, it may be disconnected when the terminal screw comes

loose, resulting in failure.

(5) Trial operation and adjustment

CAUTION

Confirm and adjust the program and each parameter before operation. Unpredictable

movements may occur depending on the machine.

Extreme adjustments and changes may lead to unstable operation, so never make them.

When using the absolute position system function, on starting up, and when the module or

absolute value motor has been replaced, always perform a home position return.

Before starting test operation, set the parameter speed limit value to the slowest value, and make

sure that operation can be stopped immediately if a hazardous state occurs.

A - 8

(6) Usage methods

CAUTION

Immediately turn OFF the power if smoke, abnormal sounds or odors are emitted from the

module, servo amplifier or servomotor.

Always execute a test operation before starting actual operations after the program or parameters

have been changed or after maintenance and inspection.

Do not attempt to disassemble and repair the units excluding a qualified technician whom our

company recognized.

Do not make any modifications to the unit.

Keep the effect or electromagnetic obstacles to a minimum by installing a noise filter or by using

wire shields, etc.

Electromagnetic obstacles may affect the electronic devices used near the module or servo

amplifier.

When using the CE Mark-compliant equipment design, refer to the "EMC Installation Guidelines"

(data number IB(NA)-67339) and refer to the corresponding EMC guideline information for the

servo amplifiers and other equipment.

Note that when the reference axis speed is designated for interpolation operation, the speed of

the partner axis (2nd axis, 3rd axis and 4th axis) may be larger than the set speed (larger than

the speed limit value).

Use the units with the following conditions.

Item Conditions

Input power According to each instruction manual.

Input frequency According to each instruction manual.

Tolerable momentary power failure According to each instruction manual.

A - 9

(7) Corrective actions for errors

CAUTION

If an error occurs in the self diagnosis of the module or servo amplifier, confirm the check details

according to the instruction manual, and restore the operation.

If a dangerous state is predicted in case of a power failure or product failure, use a servomotor

with electromagnetic brakes or install a brake mechanism externally.

Use a double circuit construction so that the electromagnetic brake operation circuit can be

operated by emergency stop signals set externally.

Electro-

magnetic

brakes

Servomotor

24VDC

RA1 EMG

Shut off with servo ON signal OFF,

alarm, electromagnetic brake signal.

Shut off with the

emergency stop

signal(EMG).

If an error occurs, remove the cause, secure the safety and then resume operation after alarm

release.

The unit may suddenly resume operation after a power failure is restored, so do not go near the

machine. (Design the machine so that personal safety can be ensured even if the machine

restarts suddenly.)

(8) Maintenance, inspection and part replacement

CAUTION

Perform the daily and periodic inspections according to the instruction manual.

Perform maintenance and inspection after backing up the program and parameters for the

module and servo amplifier.

Do not place fingers or hands in the clearance when opening or closing any opening.

Periodically replace consumable parts such as batteries according to the instruction manual.

Do not touch the lead sections such as ICs or the connector contacts.

Before touching the module, always touch grounded metal, etc. to discharge static electricity from

human body. Failure to do so may cause the module to fail or malfunction.

Do not directly touch the module's conductive parts and electronic components.

Touching them could cause an operation failure or give damage to the module.

Do not place the module or servo amplifier on metal that may cause a power leakage or wood,

plastic or vinyl that may cause static electricity buildup.

Do not perform a megger test (insulation resistance measurement) during inspection.

When replacing the module or servo amplifier, always set the new module settings correctly.

When the module or absolute value motor has been replaced, carry out a home position return

operation using one of the following methods, otherwise position displacement could occur.

1) After writing the servo data to the positioning module using programming software, switch on

the power again, then perform a home position return operation.

Dieses Handbuch passt für folgende Modelle

Inhaltsverzeichnis

Andere Mitsubishi Electric Controller Handbücher

Mitsubishi Electric

Mitsubishi Electric MELSEC Q Series Bedienungsanleitung

Mitsubishi Electric

Mitsubishi Electric Melsec-F FX2NC Series Bedienungsanleitung

Mitsubishi Electric

Mitsubishi Electric FX3UC-4AD Bedienungsanleitung

Mitsubishi Electric

Mitsubishi Electric MELSEC FX3U-485ADP-MB Bedienungsanleitung

Mitsubishi Electric

Mitsubishi Electric MELSERVO MR-J5-G-N1 Series Bedienungsanleitung

Mitsubishi Electric

Mitsubishi Electric CR750-D Series Bedienungsanleitung

Mitsubishi Electric

Mitsubishi Electric MELSEC iQ-R Series Bedienungsanleitung

Mitsubishi Electric

Mitsubishi Electric MELSEC iQ-R16MTCPU Betriebsanleitung

Mitsubishi Electric

Mitsubishi Electric MELSEC-L Bedienungsanleitung

Mitsubishi Electric

Mitsubishi Electric RD77MS2 Bedienungsanleitung

Mitsubishi Electric

Mitsubishi Electric MELSEC iQ-R Series Bedienungsanleitung

Mitsubishi Electric

Mitsubishi Electric MELSEC iQ-F Series Bedienungsanleitung

Mitsubishi Electric

Mitsubishi Electric AL2-4EX-A2 Bedienungsanleitung

Mitsubishi Electric

Mitsubishi Electric MEHITS CH Bedienungsanleitung

Mitsubishi Electric

Mitsubishi Electric MELSERVO MR-JET-G-N1 Bedienungsanleitung

Mitsubishi Electric

Mitsubishi Electric MELSEC iQ-F Series Bedienungsanleitung

Mitsubishi Electric

Mitsubishi Electric MELSEC iQ-R Series Bedienungsanleitung

Mitsubishi Electric

Mitsubishi Electric MELSEC iQ-F Series Bedienungsanleitung

Mitsubishi Electric

Mitsubishi Electric PAC-YG66 DCA-J Service-Handbuch

Mitsubishi Electric

Mitsubishi Electric FX3U-2HC Bedienungsanleitung

Mitsubishi Electric

Mitsubishi Electric MELSEC L series Bedienungsanleitung

Mitsubishi Electric

Mitsubishi Electric MELSEC FX3U-485ADP Bedienungsanleitung

Mitsubishi Electric

Mitsubishi Electric MELSEC iQ-R Series Stücklistenhandbuch

Mitsubishi Electric

Mitsubishi Electric MELSERVO J5 Series Bedienungsanleitung

Beliebte Controller Handbücher anderer Marken

Digiplex

Digiplex DGP-848 Betriebsanleitung

YASKAWA

YASKAWA SGM series Bedienungsanleitung

Sinope

Sinope Calypso RM3500ZB Bedienungsanleitung

Isimet

Isimet DLA Series Style 2 Installationshandbuch

LSIS

LSIS sv-ip5a Bedienungsanleitung

Rockwell Automation

Rockwell Automation 1769-L31 Bedienungsanleitung

Airflow

Airflow Uno hab Bedienungsanleitung

ABB

ABB ACS580-01 drives Bedienungsanleitung

Panasonic

Panasonic GM1 Series Bedienungsanleitung

Emerson

Emerson SW93 Bedienungsanleitung

AutoAqua

AutoAqua Smart ATO micro SATO-120P Bedienungsanleitung

Panasonic

Panasonic FP? Positioning Unit RTEX Bedienungsanleitung

Samson

Samson Type 5824 Service-Handbuch

Alpha IP

Alpha IP MIOB 21001 Bedienungsanleitung

Siemens

Siemens OpenAir GMA 1 Series Bedienungsanleitung

Surecom

Surecom SR-629 Bedienungsanleitung

Fishman

Fishman TriplePlay Bedienungsanleitung

Regulus

Regulus SRS1 T Bedienungsanleitung
