Owner’s

Manual

Double-Drawer

Built-In Refrigerator

ZIDI240

ZIDS240

Introduction

Your new Monogram double-drawer refrigerator makes an eloquent statement of style,

convenience and kitchen planning flexibility. Whether you chose it for its purity of design

or the assiduous attention to detail, you will find that your Monogram double-drawer

refrigerator’s superior blend of form and function will delight you for years to come.

The information on the following pages will help you operate and maintain your

double-drawer refrigerator properly.

If you have any other questions, visit our Website at: www.monogram.com

Consumer Information

Double-Drawer Refrigerator

Contents

Built-In Dimensions . . . . . . . . . . . . .12, 13

Care and Cleaning . . . . . . . . . . . . . .11, 12

Consumer Services . . . . . . . . . . . . . . . .19

Controls and Features . . . . . . . . . . . .8–10

Installation . . . . . . . . . . . . . . . . . . . .14, 15

Model and Serial Numbers . . . . . . . . . . .2

Problem Solver . . . . . . . . . . . . . . . . .16–18

Repair Service . . . . . . . . . . . . . . . . . .3, 19

Safety Instructions . . . . . . . . . . . . . . . .4–7

Warranty . . . . . . . . . . . . . . . . .Back Cover

Before

using your

double-drawer

refrigerator

Read this manual carefully. It is intended

to help you operate and maintain your

new double-drawer refrigerator properly.

Keep it handy for answers to your

questions.

If you don’t understand something or

need more help, there is a list of toll-free

consumer service numbers included in

the back section of this manual.

Visit our Website at: www.monogram.com

Write

down the

model &

serial

numbers

You will find them on a label on the

ceiling inside the double-drawer

refrigerator.

Please write these numbers here:

Model Number

Serial Number

Use these numbers in any correspondence

or service calls concerning your double-

drawer refrigerator.

Consumer Information

Double-Drawer Refrigerator

If you received

a damaged

appliance

The warranty does not cover damage

caused after delivery. Immediately contact the dealer (or

builder) that sold you the double-drawer

refrigerator.

Remove

packaging

Before using, be sure all packing materials

and tape have been removed.

To assure no damage is done to the finish

of the product, the safest way to remove

the adhesive left from packaging tape on

new appliances is an application of

household liquid detergent. Apply with

a soft cloth and allow to soak. Wipe dry

and then apply an appliance polish to

thoroughly clean and protect the surface.

If you need

service

To obtain service, see the Consumer

Services page in the back of this manual.

We are proud of our service and want you

to be pleased. If for some reason you are

not happy with the service you receive,

here are steps to follow for further help.

For customers in the USA:

FIRST, contact the people who serviced

your appliance. Explain why you are not

pleased. In most cases, this will solve the

problem.

NEXT, if you are still not pleased, write

all the details—including your phone

number—to:

Manager, Customer Relations

GE Appliances

Appliance Park

Louisville, KY 40225

For customers in Canada:

FIRST, contact the people who serviced

your appliance. Explain why you are not

pleased. In most cases, this will solve the

problem.

NEXT, if you are still not pleased, write

all the details—including your phone

number to:

Manager, Consumer Relations

Camco Inc.

1 Factory Lane, Suite 310

Moncton, N.B. E1C 9M3

After

installation

is completed

• Promptly inspect your new Monogram

double-drawer refrigerator. If it has been

damaged, contact the Installer or Dealer

immediately.

• This double-drawer refrigerator must

be properly leveled to ensure correct

drawer alignment and drawer closure.

Contact the Installer if the unit is not

level.

• The unit should be centered in the

opening. The front face of the drawer

will be flush with adjacent cabinetry.

Contact the installer if clearance is not

correct.

• Test the drawer. Carefully open and close

the drawer. The drawer should not rub

or catch on adjacent cabinetry. Notify

the installer if the drawer makes contact

with cabinetry.

Please Contact the Installer or Dealer if

you experience any of these problems.

Your custom panel (ZIDI240 model only)

double-drawer refrigerator is shipped with

two toekicks, a stainless steel and a black

toekick. For shipping purposes, one of

the toekicks will be secured to the back of

the unit, and the second will be installed

on the unit. Keep the unused toekick

and other unused or removed parts for

possible future use.

Save time

& money

Before you request service, check the

Problem Solver in the back of this guide. It lists causes of minor operating problems

that you can correct yourself.

IMPORTANT SAFETY INSTRUCTIONS

READ AND SAVE THESE INSTRUCTIONS

wWARNING: When using

this appliance, always exercise basic safety

precautions, including the following:

•Double-drawer refrigerators are

designed to be built-in only. They cannot

be used free-standing.

•Use this appliance only for its intended

purpose as described in this Owner’s

Manual.

•This double-drawer refrigerator must be

properly installed in accordance with the

Installation Instructions before it is used.

•Do not allow children to climb, stand

or hang on the shelves in the double-

drawer refrigerator. They could damage

the double-drawer refrigerator and

seriously injure themselves.

•Do not store or use gasoline or other

flammable vapors and liquids in the

vicinity of this or any other appliance.

•Keep fingers out of the “pinch point”

areas: clearances between the drawer

and between the drawer and cabinet are

necessarily small. Be careful closing the

drawer when children are in the area.

•Unplug your double-drawer refrigerator

before cleaning or making repairs.

NOTE: We strongly recommend that any

servicing be performed by a qualified

individual.

wDANGER: RISK OF CHILD ENTRAPMENT

Child entrapment and suffocation

are not problems of the past. Junked or

abandoned refrigeration products are

still dangerous…even if they will sit for

“just a few days.” If you are getting rid of

your old appliance, please follow these

instructions to help prevent accidents.

Before You Throw Away Your Old

Refrigeration Product:

• Take off the doors.

• Leave the shelves in place so that

children may not easily climb inside.

REFRIGERANTS

All refrigeration products contain

refrigerants, which under federal law must

be removed prior to product disposal.

If you are getting rid of an old refrigeration

product, check with the company handling

the disposal about what to do.

IMPORTANTES INSTRUCTIONS DE SÉCURITÉ

LIRE ET CONSERVER CES INSTRUCTIONS

wAVERTISSEMENT :

Lorsque vous utilisez l’appareil, observez

toujours certaines précautions de base,

notamment :

•Les réfrigérateurs à deux tiroirs sont

conçus pour être encastrés uniquement.

Ils ne peuvent pas être séparés.

• N’utilisez l’appareil que pour son usage

prévu, comme décrit dans le présent

manuel.

• Installez le réfrigérateur à deux tiroirs

conformément aux directives

d’installation avant de l’utiliser.

• Ne laissez pas les enfants grimper,

s’asseoir, se tenir debout ni se pendre

aux clayettes du réfrigérateur à deux

tiroirs. Ils pourraient endommager le

réfrigérateur à deux tiroirs et se blesser

gravement.

• N’entreposez et n’utilisez pas d’essence

ou autres vapeurs et liquides

inflammables à proximité de cet appareil

ou de tout autre appareil électroménager.

• Éloignez les doigts des parties du

réfrigérateur où l’on peut facilement

se pincer : les espaces entre les tiroirs

et entre les tiroirs et les placards sont

toujours étroits. Soyez prudent lorsque

vous fermez les tiroirs de l’appareil en

présence des enfants.

• Débranchez votre réfrigérateur à deux

tiroirs avant de le nettoyer et de le

réparer.

REMARQUE : Nous vous recommandons

vivement de confier toute réparation à

un technicien qualifié.

wDANGER : RISQUES POUR LES ENFANTS

Les enfants pris au piège ou morts

d’asphyxie sont toujours d’actualité.

Les appareils de réfrigération abandonés

sont toujours aussi dangereux, même si

on n’attend que “quelque jours” pour

s’en débarasser. Si vous ne gardez pas

votre ancien appareil, veuillez suivre

les directives ci-dessous afin de prévenir

les accidents.

Avant de vous débarasser de votre vieux

appareil de réfrigération :

• Démontez les portes.

• Laissez les clayettes en place afin

d’empêcher les enfants de grimper à

l’intérieur.

RÉFRIGÉRANTS

Tous les appareils de réfrigération

contiennent des refrigerants qui,

conformément aux lois fédérales, doivent

être enlevés avant toute élimination de

l’appareil.

Si vous vous débarrassez de vieux appareils

de réfrigération, vérifiez, auprès de la

société qui s’occupe de leur élimination,

ce que vous devez faire.

SAVE THESE INSTRUCTIONS

IMPORTANT SAFETY INSTRUCTIONS

HOW TO CONNECT ELECTRICITY

Do not, under any circumstances, cut or

remove the third (ground) prong from

the power cord. For personal safety, this

appliance must be properly grounded.

The power cord of this appliance is

equipped with a 3-prong (grounding)

plug which mates with a standard 3-prong

(grounding) wall outlet to minimize the

possibility of electric shock hazard from

this appliance.

Have the wall outlet and circuit checked

by a qualified electrician to make sure

the outlet is properly grounded.

Where a standard 2-prong wall outlet

is encountered, it is your personal

responsibility and obligation to have

it replaced with a properly grounded

3-prong wall outlet.

Use of a GFI (Ground Fault Interrupter)

is not recommended for the double-

drawer refrigerator.

The appliance should always be plugged

into its own individual electrical outlet

which has a voltage rating that matches

the rating plate. This provides the best

performance and also prevents overloading

house wiring circuits which could cause a

fire hazard from overheated wires.

DO NOT USE AN

ADAPTER PLUG TO

CONNECT THE

DOUBLE-DRAWER

REFRIGERATOR TO

A 2-PRONG OUTLET.

DO NOT USE AN

EXTENSION CORD

WITH THIS APPLIANCE.

Never unplug an appliance by pulling on

the power cord. Always grip the plug firmly

and pull straight out from the outlet.

Repair or replace immediately all power

cords that have become frayed or

otherwise damaged. Do not use a cord

that shows cracks or abrasion damage

along its length or at either end.

When moving the appliance, be careful

not to roll over or damage the power cord.

CONSERVEZ CES DIRECTIVES

IMPORTANTES INSTRUCTIONS DE SÉCURITÉ

RACCORDEMENT ÉLECTRIQUE

Ne coupez ni retirez en aucun cas la

troisième broche (mise à la terre) de la

fiche du cordon d’alimentation. Pour

votre sécurité, cet appareil doit être

correctement mis à la terre.

Le cordon d’alimentation de cet appareil

est muni d’une fiche à 3 broches (mise à

la terre) qui se branche dans une prise

mural ordinaire à 3 alvéoles (mise à la

terre) pour réduire au minimum les

risques du chocs électriques.

Faites examiner la prise de courant et le

circuit par un électricien qualifié pour

vous assurer que la prise est correctement

mise à la terre.

Si la prise murale est du type standard

à 2 alvéoles, il vous incombe de la faire

remplacer par une prise à 3 alvéoles

correctement mise à la terre.

L’utilisation d’un disjoncteur de fuite

à la terre est recommandée pour le

réfrigérateur à deux tiroirs.

L’appareil doit toujours être branché

dans sa propre prise de courant, dont la

tension nominale est identique à celle

indiquée sur la plaque signalétique.

Cette précaution est recommandée pour

garantir un rendement optimum et éviter

une surcharge des circuits électriques de

la résidence, ce qui pourrait créer un

risque d’incendie par surschauffe des fils.

N’UTILISEZ JAMAIS

UNE PRISE À

ADAPTATEUR POUR

LE RÉFRIGÉRATEUR À

DEUX TIROIRS À UNE

PRISE BIPOLAIRE.

N’UTILISEZ JAMAIS DE

RALLONGE AVEC CET

APPAREIL.

Ne débranchez jamais l’appareil en tirant

le cordon d’alimentation. Saisissez

fermement la fiche du cordon et tirez

droit pour la retirer de la prise.

Réparez ou remplacez immédiatement

tout cordon effiloché ou endommagé.

N’utilisez pas un cordon fendillé ou

présentant des signes d’usure.

Lorsque vous déplacez l’appareil, faites

attention de ne pas la faire rouler sur le

cordon d’alimentation afin de ne pas

l’endommager.

Controls and Features

Double-Drawer Refrigerator

Unit

ON/OFF

This pad stops cooling in the double-

drawer refrigerator, turns off the

temperature controls and removes

power to the light circuit.

Press this pad for a minimum of 3 seconds

to turn the double-drawer refrigerator

on or off or unplug the unit for long

vacations or absences, or when cleaning

the unit or changing the light bulb.

Temperature

control

The temperature display shows the

actual temperature of the double-drawer

refrigerator. The actual temperature may

vary slightly from the set temperature

based on factors such as drawer opening,

amount of food and room temperature.

To change the temperature setting, press

the WARMER or COLDER pads until you

reach the desired set temperature. After

5 seconds, the display will return to the

actual temperature.

Allow 12–24 hours for the double-drawer

refrigerator to reach the temperature you

have set.

Temperature Settings

Minimum: 34°F (1.1°C)

Maximum: 45°F (7.2°C)

Interior fan

The interior fan located in the rear wall

of the double-drawer refrigerator and is

designed to run continuously to help

maintain the proper cooling temperature.

The interior fan will only turn off when

the drawer is opened.

Controls and Features

Double-Drawer Refrigerator

Snugger

The snugger attached to the glass divider

helps prevent tipping, spilling or sliding

of small items when the top drawer is

opened. Lift the lock down lever near the

top of the snugger then move it to fit your

needs. Press the lever down to lock the

snugger in place.

The snugger is dishwasher safe,

top rack only.

Glass

divider

The top drawer has a moveable, tempered

glass divider for separating and organizing

foods. The divider can be placed in one of

two locations.

To remove the divider, lift up until divider

clears the rear and front retaining slots.

To replace the divider, slide into one of

the divider locations.

The glass divider is dishwasher safe,

top rack only.

Divider locations

Glass divider

Lever

Snugger

Assembly

instructions

To remove:

1. Lift the glass divider assembly out of

the drawer by grasping the glass divider

and snugger where the lever is located.

Sit the assembly on a sturdy surface.

2. Lift the lever.

3. Slide the snugger off the glass divider.

4. Remove the lever from the snugger by

lifting the lever up and sliding it down

and out of the assembly.

NOTE: The glass divider, snugger and

lever can be cleaned on the top rack of

a dishwasher.

To replace or relocate:

1. Reassemble lever into snugger by

sliding the lever up into place.

2. Slide glass divider into the snugger.

The lever must be installed before

sliding the divider into the snugger.

3. Put the glass divider assembly in the

desired divider location in the top

drawer.

Lever

Snugger

Glass

divider

Lever

Locked

Unlocked

(1)

(2)

Controls and Features

Double-Drawer Refrigerator

Food

storage

pan

The bottom drawer offers a pan for

storage of smaller items. The pan slides

easily to allow storage of and access to

larger items in the drawer below.

The pan can be removed allowing you

to carry food to the countertop for

preparation or to allow storage space

for large food items.

The food storage pan is dishwasher safe,

top rack only.

Shelf

The top drawer features a shelf that can

fold down for storage of smaller containers,

or fold up for storage of larger items on

the drawer bottom.

To fold up the shelf, lift to the right until

it rests in place against the right side.

The shelf is dishwasher safe, top rack only.

Drawer

lights

The brilliant full-width LED lighting

in either drawer illuminates when the

drawer is opened.

Shelf

Sliding

pan

Andere Handbücher für ZIDI240

Dieses Handbuch passt für folgende Modelle

Inhaltsverzeichnis

Andere Monogram Kühlschrank Handbücher

Monogram

Monogram ZDOD240NSS Bedienungsanleitung

Monogram

Monogram ZFGP21HZJSS Bedienungsanleitung

Monogram

Monogram ZIPS360NHSS Bedienungsanleitung

Monogram

Monogram ZIDI240HII Bedienungsanleitung

Monogram

Monogram Monogram ZISW36DRC Bedienungsanleitung

Monogram

Monogram ZIS360N Leitfaden

Monogram

Monogram ZIS42 Bedienungsanleitung

Monogram

Monogram Bottom-Freezer Built-In Bedienungsanleitung

Monogram

Monogram Monogram ZFSB25DSS Bedienungsanleitung

Monogram

Monogram ZPB480D Bedienungsanleitung

Monogram

Monogram ZFSB23DRDSS Bedienungsanleitung

Monogram

Monogram ZSGS420D Bedienungsanleitung

Monogram

Monogram ZSAB1 Bedienungsanleitung

Monogram

Monogram ZICS360NHLH Bedienungsanleitung

Monogram

Monogram ZIFS36NMBLH Bedienungsanleitung

Monogram

Monogram 36 Ceramic Cooktop Bedienungsanleitung

Monogram

Monogram 36 Ceramic Cooktop Bedienungsanleitung

Monogram

Monogram Monogram ZIBI240PII Bedienungsanleitung

Monogram

Monogram ZIFS360NHH Bedienungsanleitung

Monogram

Monogram ZWE23PSHSS Bedienungsanleitung

Monogram

Monogram ZIBI240HII Bedienungsanleitung

Monogram

Monogram ZWE23E series Bedienungsanleitung

Monogram

Monogram ZIRS36NM Bedienungsanleitung

Monogram

Monogram ZDOG240 Bedienungsanleitung

Beliebte Kühlschrank Handbücher anderer Marken

Bonnet Neve

Bonnet Neve SKYVIEW PLUS Bedienungsanleitung

Zanussi Electrolux

Zanussi Electrolux ZERB 8441 Bedienungsanleitung

Sharp

Sharp SJ-BA31IEXW2-EU Bedienungsanleitung

CORBERO

CORBERO CC2300MCW Bedienungsanleitung

KitchenAid

KitchenAid 2205264 Bedienungsanleitung

Stengel

Stengel KU 1101 A++ Bedienungsanleitung

NEFF

NEFF KI181 Series Bedienungsanleitung

Hoshizaki

Hoshizaki Reach-In Bedienungsanleitung

Amana

Amana ASD2524VES00 Bedienungsanleitung

BOMANN

BOMANN KGC 213 Bedienungsanleitung

Danby

Danby DAR044A1SLDD Montageanleitung

Samsung

Samsung RF323TE Bedienungsanleitung

Beko

Beko CSA31022 Bedienungsanleitung

IKEA

IKEA FROSTIG C 185 E Bedienungsanleitung

Electrolux

Electrolux ER 6821 D Bedienungsanleitung

True

True TS-28 Bedienungsanleitung

Frigidaire

Frigidaire FSC23R5DW9 Bedienungsanleitung

Beko

Beko LSP4579W Bedienungsanleitung
