Installation and Operating Instructions

Model: MW1012P

Fully Electronic Automatic

Washing Machine

Please

read

these

instructions

carefully

before

attempting

install

use

this

appliance.

It is advisable to keep these instructions in a safe place for future reference.

(Model shown for indicative purposes only)

www.montpellier-appliances.com

CONTENTS:

Section 1: Safety Instructions

-Correct Usage

-General Warnings

-Safety Warnings

7/8

Section 2: Installation

-Removing Transit Bolts

-Adjusting the Feet

-Electrical Connection

-Water Inlet Hose Connection

-Water Discharge Connection

Section 3:

Technical

Specifications

Section 4: Control Panel

-Control Panel

-Detergent Drawer

-Program Knob

15/17

Section 5:

Washing

your Laundry

-Preliminary Preparation of Laundry

-Putting Laundry in the Machine

-Adding Detergent to the Machine

-Operating your Machine

-Auxiliary Functions

-Child Lock

-Cancelling a Program

-Finishing a Program

18/19

22/23/24

Section 6: Maintenance and Cleaning

-Water Inlet Filters

-Pump Filters

-Detergent Draw

Section 7:

Troubleshooting

29/30/31

Section 8: Fault Codes

Section 9: Program

Table

33/34

Section 10: Service Help Line

Section 11: WEEE Directive

Introduction

Thank you for choosing this

appliance. It has been

designed to give years of trouble-free use provided it is installed and

maintained correctly.

Please

read

these

instructions

carefully

before

installing

using

your

appliance. It is advisable to keep your purchase and installation receipts

with these instructions in a safe place for future reference. Included is

some important safety information in addition to guidelines and

recommendations that will enable you to take full advantage of all the

functions available.

This

quality

appliance

has

been

tested

and

certified

meet

all

applicable

UK electrical and safety standards.

This

appliance

must

installed

and

connected

accordance

with

current regulations by a qualified electrician.

After unpacking the appliance ensure that there is no visible damage. If the

appliance has been damaged during transit, do not use it, contact your

retailer immediately.

Your 2 year Manufacturer's guarantee

THIS DOES NOT AFFECT YOUR STATUTORY RIGHTS

Your new montpellier appliance carries a free guarantee which protects you against the cost of

repairs during the first 24 months from date of purchase provided that:

Any claim is accompanied by evidence of the model reference, model serial number and proof

of purchase, such as a Sales Receipt, showing that the appliance was purchased within

the 24 months prior to the date of claim.

What is not covered under the Guaran

tee

•Any appliance not correctly installed and operated in accordance with the

manufacturer's instructions.

•Any appliance that is used for anything other than domestic purposes.

•Any defect caused by accident, misuse, unauthorized modification or inexpert repair.

•Cost of Call

out where a fault cannot be found with the appliance.

•Cost of Call

out for work covering routine maintenance, such as, but not

exclusively, cleaning of filters or defrosting.

•Cost of Call

out for work required to correct the alignment of doors following

door reversal procedures carried out by you.

•Use of the appliance by anyone other than the Householder.

•Use in any commercial environment.

•Consumable items, such as, but not exclusively, fuses in plugs, bulbs and

breakable items which require routine replacement.

•Repair costs incurred that have not been authorised by Repairtech.

•Repairs carried out by a non-approved Repairtech engineer.

YOUR GUARANTEE IS VALID ONLY IN THE UK.

To Register your Appliance simply complete the card in your appliance pack

and return it with a stamp affixed or Alternatively you can Register online at

www.repairtechuk.com

SERVICE HELPLINE

Should your appliance develop a fault, please call

the Repairtech Service Helpline on:

01527

888133

Please remember to have all your product details

available, including the serial number, before registering

a fault.

Your service call cannot progress without this information.

Description

the

Appliance

Transit Bolt

Water Inlet Valve

Discharging Hose

Power Cable

Transit Bolt

BEFORE

OPERATING

YOUR

WASHING

MACHINE

YOU MUST

REMOVE THE TRANSIT BOLTS. FAILURE TO DO SO MAY DAMAGE

THE MACHINE AND WILL INVALIDATE YOUR GUARANTEE.

Section 1. Safety

Advice

1.1 Correct Usage

Read the user instruction manual.

Your

machine is designed to be used

domestically.

Commercial

use will cause your warranty to be invalid.

Keep pets away from your machine.

Please check the packaging of your machine is in good order before

installation, and the

outer surface of the machine after the package is opened. Do not operate damaged

machines.

Have your machine installed only by a qualified person.

Any interference to your machine

by anyone other than a qualified person will invalidate your

warranty.

The appliance in not intended for use by people (including children) with reduced

physical, sensory or mental capabilities, or lack of experience and knowledge unless they

have been given supervision or instruction concerning use of the appliance by a person

responsible for their safety. Children should be supervised to ensure that they do not play

with the appliance.

Use your machine only for laundry that has been specified as suitable for washing by the

manufacturer.

Before operating the washing machine, remove the 4 transit

bolts and rubber spacers from the back of the machine. If the bolts

are not removed, it will cause heavy vibration, noise and product

malfunction (invalidating the guarantee).

Your

machine is not covered under warranty for faults caused by any kind of external

factors (pesticides, fire, etc.).

Please do not throw away this user manual: keep it for future reference as it

contains full operating instructions as well as the serial number of your machine.

You will need this should you wish to book a service call.

Note: Specifications may vary depending on the product purchased.

1.2 General

Warnings

The ambient temperature for your

machine’s

ideal operation is 15

25ºC.

Frozen hoses can tear and explode. In regions where temperature is below zero, ambient

temperature might endanger the safe operation of the electronic circuit board.

Please ensure that the clothes put into your machine do not contain

any foreign objects

(nails, needles, coins, lighters, matches, clips, etc.) in pockets. These objects can

damage your machine.

It is recommended that the first washing operation is carried out on a

90º Cotton program but without laundry and using ½ the dose of

detergent in the 2nd compartment of the detergent drawer.

- If a detergent or softener is exposed to air for any time, residue may be caused, be sure

only put your detergent or softener

in the detergent drawer at the beginning of every wash.

It is advised that you unplug

your machine and close the water inlet tap if you do not intend

to use the machine for a prolonged period of time. Also, leaving the door of your appliance

open will prevent the formation of bad odours due to humidity.

Some water might be left in your machine after factory trials and tests conducted due to

Quality Control procedures.

This is normal and will not damage your machine.

Remember the packaging materials of your machine may be dangerous for children. Keep

the packaging materials in a place where children cannot reach them and dispose of them

appropriately.

Keep any small parts

away from the reach of children and babies.

Use Pre

wash programs only for very dirty

laundry.

Never open the detergent compartment when the appliance is running.

- In case of any breakdown, unplug the appliance first and then turn the

water inlet off. Do not attempt repair by yourself, always contact the

authorised service agent help line.

The amount of laundry you put in your washing machine should not

exceed the maximum amount indicated.

Never force the door to open when the machine is running.

Do not wash clothes covered in flour or other powders in your machine as

it will cause

damage.

Please adhere to detergent/fabric conditioner manufacturer’s advice

regarding the use of fabric conditioner or similar products.

Set up your machine in a place where its door can be completely opened.

- Set up your machine in a position where it can be fully ventilated and

has constant air circulation.

1.3 Safety

Warnings

You

must take note of these warnings, as this can protect you,

your family and the product.

DANGER OF GETTING BURNT!

Do not touch the discharge hose or water during the discharge process

as the appliance can reach high temperatures during operation.

RISK DUE

ELECTRICAL

CURRENT!



Do not use multi

sockets on an extension lead.



Do not plug in damaged plugs.



Never pull the cable when unplugging

always grip the plug itself.



Do not plug

in or remove the

plug with wet hands.



Never touch the machine with wet hands or feet.

If the mains cable becomes damaged it must be replaced by an

authorised electrician or service agent.

DANGER OF FIRE!



Do not keep flammable liquids near your

machine.



The sulphur content of paint removers might cause corrosion. For this

reason, never use paint

removing materials in your machine.



Never use products that contain solvent material in your machine.



Remove all objects from

the pockets of your laundry (needles,

paperclips, lighters, matches, etc.) before placing it in your machine.

1.3 Safety

Warnings

(continued)

FALL

AND

INJURY

HAZARD!

Do not climb on your machine.

The top lid of your machine may

break and you might get injured.

idy

the

hose,

cable

and

packaging

your

machine

during

installation, to avoid tripping or falling over.

Do not

turn your machine upside down or on its side.

Do not lift your machine by holding it from extruding parts

(detergent

drawer,

door).

These parts might break and cause

you to get injured.

There’s

the risk of tripping and injury if the materials like hoses

and cables are not properly stored after your machine is installed.

Machine must be carried by 2 people.

CHILD SAFETY!

Do not leave children unattended near the machine. Children

might lock themselves inside.

Door glass and surface may get hot while your machine operates.

And as a result of this, touching the machine might damage the

skin, especially that of children.

Keep

packaging material away from children.

Danger may occur if detergent or cleaning materials are

consumed, and eyes or the skin might be irritated if contact is

made. Keep the cleaning materials away from the reach of

children.

Section 2. Installation

2.1 Removing transit bolts

Before operating the washing machine,

remove the 4 transit bolts and rubber

spacers from the back of the machine.

If the bolts are not removed, it will

cause heavy vibration, noise and

product malfunction, (invalidating the

guarantee).

Loosen the transit bolts by rotating

counter-clockwise using an appropriate

wrench.

The transit bolts are removed by

pulling out.

Fit the plastic transit bolt caps (in the

accessories bag) into the holes left by the

removal of the transit bolts.

The transit bolts should be stored to be

used in case of future transportation.

NOTE:

You

must remove the

transit bolts of your machine

before first use. Faults occurring

to the machine if operated with

transit bolts fitted will be out of

scope of warranty.

Inhaltsverzeichnis

Andere montpellier Waschmaschine Handbücher

montpellier

montpellier MW6105W Bedienungsanleitung

montpellier

montpellier MWD8514W Bedienungsanleitung

montpellier

montpellier MW1045W Bedienungsanleitung

montpellier

montpellier MW8014 Bedienungsanleitung

montpellier

montpellier MW8410P Bedienungsanleitung

montpellier

montpellier MW7145 Bedienungsanleitung

montpellier

montpellier MW6201P Bedienungsanleitung

montpellier

montpellier MIWM84-1 Bedienungsanleitung

montpellier

montpellier MWM1014BLW Bedienungsanleitung

montpellier

montpellier MW9140P Bedienungsanleitung

montpellier

montpellier MIWM65 Bedienungsanleitung

montpellier

montpellier MWM71400W Bedienungsanleitung

montpellier

montpellier MWM61200W Bedienungsanleitung

montpellier

montpellier MW7141W Bedienungsanleitung

montpellier

montpellier MWM814BLK Bedienungsanleitung

montpellier

montpellier MW8140P Bedienungsanleitung

montpellier

montpellier MWM712W Bedienungsanleitung

montpellier

montpellier MTL6120W Bedienungsanleitung

montpellier

montpellier MWM1214W Bedienungsanleitung

montpellier

montpellier MWBI8014 Bedienungsanleitung

montpellier

montpellier MWM6120W Bedienungsanleitung

montpellier

montpellier MW5101W Bedienungsanleitung

montpellier

montpellier MW7120P Bedienungsanleitung

montpellier

montpellier MWM612W Bedienungsanleitung

Beliebte Waschmaschine Handbücher anderer Marken

Tricity Bendix

Tricity Bendix AW 1000 W Produkthandbuch

Panasonic

Panasonic NA-F60L5WRB Bedienungsanleitung

GE WSLP1500 Handbuch

Electrolux

Electrolux EWF1284EDW Bedienungsanleitung

Bosch

Bosch WAN2829BSN Bedienungsanleitung

LG TV2516DV3B Bedienungsanleitung

LG TH2517DSAV Bedienungsanleitung

VESTEL

VESTEL CMH-XL 7510 TE Bedienungsanleitung

AEG

AEG 74335 Bedienungsanleitung

Johnson

Johnson JWF721A Bedienungsanleitung

Beko

Beko WTE7604XLW0 Bedienungsanleitung

Danby

Danby DTT100A1WDB Montageanleitung

Amica

Amica WA 14 Ex Bedienungsanleitung

Daewoo

Daewoo DWD-F1222 Bedienungsanleitung

Bosch

Bosch WAS28461AU Bedienungsanleitung

Miele

Miele PW 6080 Vario Bedienungsanleitung

Finlux

Finlux FLX108CF220 Bedienungsanleitung

Whirlpool

Whirlpool 3LBR5132AN0 Bedienungsanleitung

montpellier MW1012P Bedienungsanleitung

Beliebte Waschmaschine Handbücher anderer Marken
