MSA SUPREMA Touch Montage- und Bedienungsanleitung

Manual Addendum

SUPREMA Touch

Fire and Gas Warning Unit

Addendum to the SUPREMA Touch manual (Rev. 02).

Order No. 10121863/02 Addendum01

2 Addendum SUPREMA Touch

Addendum to chapter 1.4 Software Status

Module

Software version

Flash resp. EPROM

ftware version

CPLD

MAO 20 3.01.02 -

Addendum to chapter 5.1 Special Conditions for Safe Use According to EC-

type examination certificate DMT 03 ATEX G 003 X

The analogue outputs of the MAO module shall not be used for safety related purposes.

Additional Modules tested according to DMT 03 ATEX G 003 X

Module

Layout Version

Meaning

MAO20 4 Analog Output Unit

Addendum to chapter 6.6 Plug-In Modules – Status LED

Figure 50 also covers the MAO20 (right figure; similar to the MAO10)

The LED D400 (red, centre of the board) on the MAO20 indicates an error of the digital to

analog conversion system when activated.

Addendum to chapter 8.1 Modules and Accessories

Order No.

Name

10102071 SUPREMA MAO20

Correction of Chapter 9.5 Descriptions of the Modules

MAO Module (Analog Output)

This module is used when analog outputs (max. 256) are installed in the system. Each MAO

module has 8 analog signal outputs for 0 ... 24 mA current loops. The assignment between

the outputs and the signal inputs can be configured.

• 0 ... 24 mA output drivers, measurement signal outputs (galvanic isolated from system)

Signal for measuring range: 4 ... 20 mA

Signal for over flow: 22 mA (Values between 20 and 22mA are still valid

measuring values, but out of range)

Signal for INHIBIT: 3.0 mA

Signal for Signal failure: 3.2 mA

Fail dependent of Free A/Free B (see chapter 10)

• Values below 3mA and above 22mA must be handled as failure

• Maximum load: 500 Ohm

• Data transmitted from the MDO module via the CAN bus A

• The System Failure Relay is activated when a processor error occurs

• Euro card with a 96-way connector

Addendum SUPREMA Touch 3

Correction of chapter 10.3 Module Configuration

Turn-on Behaviour and Failure Behaviour of the MAO Module

After turn-on, at the analog outputs a 0 mA signal is issued for 10 - 15sec.

CAN FREE Baud Rack

A B A B 4 2 1 4 2 1

Turn-on

behaviour Behaviour at

CAN-Bus

failure

1 2 3 4 5 6 7 8 9 10

In the case of alternative

assembly 10 9 8 7 6 5 4 3 2 1

All analogue

outputs at 2 mA. All analogue

outputs at 2 mA

after 2 min.

OFF OFF

All analogue

outputs at 2 mA. Last status is

kept OFF ON

All analogue

outputs at 0 mA. All analogue

outputs at 0 mA

after 2 min.

ON OFF

All analogue

outputs at 0 mA. Last status is

kept ON ON

Fig. 69 MAO Module, Configuration of turn-on behaviour and failure behaviour

Correction of chapter 10.3 Module Configuration

Section “Configuration of the MAO Module” refers to the MAO10 module!

Addendum to chapter 10.3 Module Configuration

Configuration of the MAO-20 Module

Operation Mode Selection

Switch S200 Function

1 2 3 4

ON ON ON ON Factory setting/Do not change

OFF

X X X Bootloader active

X: Any switch

FREE-A-/B settings

After turn-on, at the analog outputs a 0 mA signal is issued for 10 - 15sec.

Switch S3 Function

1 2 3 4

OFF

ON ON Function FREE-A/B by switches on the MIB module

X X OFF

OFF

Function by switch FREE-A/B on the MAO module

Turn

on behaviour

Behaviour at CAN failure

OFF

All analogue outputs at 2 mA. All analogue outputs at 2 mA

after 2 min.

OFF

ON OFF

OFF

All analogue outputs at 2 mA. Last status is kept

ON OFF

OFF

All analogue outputs at 0 mA. All analogue outputs at 0 mA

after 2 min.

ON ON OFF

OFF

All analogue outputs at 0 mA. Last status is kept

CAN-A-/B Selection

Switch S4 Function

1 2 3 4

ON ON OFF

OFF

Control of the MAO module via CAN bus A

(also for redundant applications)

4 Addendum SUPREMA Touch

S200

Fig. 1 Configuration MAO-20 Module

Attention!

The MAO module is always controlled via CAN bus A!

Correction of chapter 10.9 Connection of the Analog Outputs

Terminal No. 1 Terminal No. 2 Terminal No. 3 Terminal No. 4 Terminal No. 5

-Ia +Ia

Fig. 140 MAT/MAT TS Module Terminal Assignment, Analog Outputs

Addendum SUPREMA Touch 5

Correction of / Addendum to chapter 14.2 Module Data

Section “MAO Module: Analog Output Unit” will be replaced by the following sections:

MAO-10 Module: Analogue Output Unit

Function

- 4 ... 20 mA output driver, measurement signal outputs

- values below 3mA and above 22mA must be handled as fail

- electrically isolated outputs

- data transmission via the CAN bus

Technical Data

Operating voltage feed: 19 ... 32 VDC

Operating current: 150 mA (maximum)

Temperature range: 5 °C ... 55 °C

Humidity: 0 ... 90 % relative humidity non-condensing

Maximum load: 500 ohms

Output current range: 0 ... 24 mA

Inhibit signal: 3.0 mA

Failure signal: 3.2 mA

Measurement signal range: 4 ... 20 mA

Over range signal: 22 mA

Dimensions: 100 x 160 mm

Weight: 127 g

MAO-20 Module: Analogue Output Unit

Function

- 4 ... 20 mA output driver, measurement signal outputs

- values below 3mA and above 22mA must be handled as fail

- electrically isolated outputs

- data transmission via the CAN bus

Technical Data

Operating voltage feed: 19 ... 32 VDC

Operating current: 270 mA (maximum)

Temperature range: 5 °C ... 55 °C

Humidity: 0 ... 90 % relative humidity non-condensing

Maximum load: 500 ohms

Output current range: 0 ... 24 mA

Inhibit signal: 3.0 mA

Failure signal: 3.2 mA

Measurement signal range: 4 ... 20 mA

Over range signal: 22 mA

Dimensions: 100 x 160 mm

Weight: 80 g

EC Suprema atex 2013-10-18 eng.doc

EC Declaration of Conformity

The manufacturer or his in the community established authorized repre-sentative

MSA AUER GmbH , Thiemannstraße 1 , D-12059 Berlin

declares that the product : SUPREMA

based on the EC-Type Examination Certificate : DMT 03 ATEX G 003 X

complies with the ATEX directive 94/9/EC, Annex III. Quality Assurance Notification com-

plying with Annex IV of the ATEX Directive 94/9/EC has been issued by DEKRA EXAM in

Bochum , Notified Body number: 0158.

Standards : EN 60079-29-1 :2007-11 , EN 50104 :2010-06 ,

EN 50271:2010-06 , EN 50 402 :2005-08

The product is in conformance with the directive 2004 / 108/ EC (EMC)

EN 50270 :2006-06 Typ 2 , EN 61000 - 6 - 4 :2011-09

The product is in conformance with the directive 2006 / 95/ EC (LVD)

EN 61010-1 :2010-10

MSA AUER GmbH

Dr. Axel Schubert

Manager R&D Instruments

& Approvals INT-T Berlin , October 2013
