INSTRUCTION MANUAL
S9100
IMPORTANT SAFETY INSTRUCTIONS
DANGER
When using an electric product, basic precautions should always be followed,
including the following: Read all instructions before using this product.
TO REDUCE THE RISK OF ELECTRIC SHOCK:
-Do not reach for a product attached to a power cord that has fallen into
the water. Unplug immediately.
- The power cord, charging base, and the accessories connected to it are
not for immersion or use in the shower.
- Do not use an extension cord with this product.
- Do not place or store the product while plugged in where it can fall or be
pulled into a tub or sink. Do not place or drop the product, the power cord,
or the charging base in water or other liquid while plugged in.
- Always unplug the charging base from the electrical outlet immediately
after (re)charging.
- Unplug and remove the power supply cord from this product before clean-
ing.
WARNING
TO REDUCE THE RISK OF BURNS, FIRE, ELECTRIC SHOCK, OR INJURY
TO PERSONS:
- Close supervision is required when this product is used by, on, or near
children or persons with limited physical, sensory, or mental capabilities or
invalids.
- Use this product for its intended household use, as described in this
manual. Do not use attachments not recommended by Mueller.
- Never operate this product if it has a damaged power cord, if it is not work-
ing properly, after it has been dropped or damaged, or dropped into water
while plugged in. For assistance, contact Mueller support.
- Keep the product, power cord, charging base, and any attachments away
from heated surfaces.
- Never drop or insert any object into any opening.
- Do not use the adapter in or near a power outlet that contains an electric
air freshener to prevent damage to the power cord.
- Do not operate, charge, clean, or plug in the product outdoors or operate
where aerosol (spray) products are being used or where oxygen is being
administered.
- Always attach the power cord to the charging base first, then to the power
outlet. To disconnect, remove the product from the charging base and only
then remove the power cord from the power outlet.
- Never put the product or the power cord in direct sunlight or store at a
temperature above 140°F (60°C).
- This product is for use on human hair only. Do not use the product for any
other purpose.
- Disconnect the power cord from the wall outlet, remove the Electric razor
from the charging base and turn it OFF before cleaning it in water to
prevent electric shock.
- Do not use any power cord, adaptor, or the charging base other than the
ones provided with the product.
- Terminate the usage when there is abnormality or failure. Plug in the
adaptor into a household outlet where there is no moisture and handle it
with dry hands.
- Never use the charging adapter in a moist environment such as bath-
room or shower, as electricrical shock may occur.
- Do not dismantle or replace the battery so that you can use the shaver
again- this could cause fire or an electric shock. Replace it at an autho-
rized service center.
- Disconnect the power cord when storing the shaver. Do not bend the
power cord or wrap it around the shaver or the charging base.
IMPORTANT
This shaver has a built-in rechargeable battery. Do not throw it into the
fire, apply heat, charge, use, or leave in a high-temperature environment.
WARNING
INTRODUCTION
- Do not charge the shaver when the temperature is below 0˚C (32ºF) or
above 40˚C (104ºF).
- The outer foil is very thin and can be damaged if not used correctly. Check
that the foil is not damaged before using the shaver. Do not use the shaver
if the foil is damaged as you will cut your skin.
- Do not take the housing apart as this can affect watertight construction.
- Store the shaver in a place with low humidity after use. Do not wash the
charging stand with water.
- Hold the adaptor when disconnecting it from the household outlet. If you
tug on the power cord, you may damage it.
- Do not share your shaver with other people. Doing so may result in infec-
tion or inflammation.
Thanks for purchasing the Mueller Series 9 Electric Razor S9100. Your
purchase comes with a 100% satisfaction guarantee from Mueller.
If you are not happy with the product for any reason, please contact us at
support@muellerdirect.com or at 888-632-9981 with your feedback or
questions, and we will do our best to make things right for you!
INTENDED USE
This WET/DRY shaver can be used for wet shaving with shaving cream or
dry shaving. You can use this waterproof shaver in the shower and clean it
in water.
Your WET/DRY shaver requires a little time to get used to because your skin
and beard need about a month to adjust to any new shaving method.
This symbol indicates that the product
can be used in the bath or shower.
PARTS
Protective cap
Conductive
column Charging status indicator
Travel lock indicator
Charging symbol
Cleaning indicator
Appliance socket
Charging
base
Cleaning
brush
System
outer foil
Foil frame
Inner cutter
System
outer foil
release button
System
outer foil
release button
Power switch
Trimmer
Float
switch Trimmer
button
Charging bracket
assembly
Adaptor
INDUCTIVE CHARGING
1. Connect the power cord
to the charging base, and
then plug the power plug in
any 120-240V AC outlet.
2. Place the shaver on the
charging base. During
charging, the Charging
symbol will illuminate.
When the battery is fully
charged, the Charging
status indicator shows 100.
3. Full charging takes
approximately 1 hour. When
the product is fully charged,
it has an operating time of
around 45 minutes.
4. When finished charging,
remove the shaver from the
charging base, then remove
the power plug from the
wall outlet and pull the
power cord out of the
charging base.
NOTE: Charging the shaver continuously for more than 10 hours will
reduce the battery capacity.
WARNING: Do not operate this shaver during charging.
1h
This product comes with a charging dock which delivers wireless
inductive charging.
USING THE PRODUCT
1. Remove the protective cap.
2. Switch the shaver ON by pressing the Power switch.
3. Hold the shaver at a right angle (90°) against your skin. Start shaving by
applying gentle pressure to your face. Stretch your skin with your free hand,
and move the shaver back and forth in the direction of your beard. You may
gently increase the amount of pressure as your skin becomes accustomed
to the shaver. Applying excessive pressure does not provide a closer shave.
4. To switch the shaver OFF, press the Power switch.
5. To prevent damage to the foil and the inner cutter, put back the protective
cap every time you finish using the shaver.
Wet shaving
Put a thin layer of shaving foam on your face. Shaving foam is the most
suitable among many other shaving aids (gel, soap, cream, etc.). Do not put
a thick layer of the shaving foam as it may affect shaver’s performance. If
the shaving head clogs with foam, simply rinse it under running water.
Using the trimmer
Slide the trimmer button up to open the trimmer. Place the trimmer at a
right angle (90°) to your skin and move it downward to trim sideburns.
Close the trimmer by pushing it back until it snaps into place.
USING THE TRAVEL LOCK
Independent Floating Heads
Three independently floating heads are
specially designed for clean, smooth
shaving. This powerful, comfortable
shaver glides naturally along the contours
of the face for beautiful, long-lasting
results on the skin.
To enable the floating system, push the
float switch upward to allow the cutter
head to float back and forth while shav-
ing.
The product is equipped with a travel lock function. You can use the travel
lock if you are going to store the product for a longer period or if traveling.
The travel lock prevents the product from being switched on by accident.
Activating the travel lock
- Press the ON/OFF button for 3 seconds.
- When the travel lock is activated, the
travel lock indicator will appear. After a
few seconds, the travel lock indicator will
go out.
Deactivating the travel lock
- Press the ON/OFF button for 3 seconds.
The unit will start running to indicate that
the travel lock has been deactivated.
- The product is now ready for use.
Long press
3 seconds to
activate the
travel lock
Long press
3 seconds
to unlock
3s
Cleaning the shaver
1. With the system outer foil in place, apply some hand soap onto the outer
foil.
2. Turn the shaver on and pour some water over the foil.
3. After about 10-20 seconds, turn the shaver off, remove the system outer
foil, and clean it with running water.
4. Wipe off any drops of water with a dry cloth.
WARNING: to prevent electric shock or personal injury,
always remove the shaver from the charging base and
make sure that the shaver is OFF before cleaning.
- Regular cleaning will keep your shaver in good condition, maintain the
cutting performance, and prevent odor or bacteria from developing.
- Wash the shaver with tap water. Do not use salt water or boiling water.
Also, do not use cleaning products that are designed for toilets, bath-
rooms, or kitchen appliances.
- Do not soak the shaver in water for a long period. Do not wipe any part of
the shaver with thinner, benzene, or alcohol.
- Clean the shaver’s body only with a soft cloth slightly dampened with tap
water or soapy tap water. Do not use thinner, benzine, alcohol, or other
chemicals.
10s
20s
CLEANING AND MAINTAINANCE
MAINTENANCE
Cleaning with the brush
- Clean the outer foil, shaver body, and the trimmer with the long side of the
brush.
- Clean the inner cutter with the short side of the brush.
NOTE: Do not use the short brush to clean the outer foil.
Cleaning reminder: After 30 minutes of use, you may see a tap
symbol blinking (Cleaning indicator) on your product as a remind-
er to clean it.
To maintain a good performance of the shaver, we recommend that you
replace the outer foil at least once a year, and to replace the inner cutter at
least every two years.
Replacing the system outer foil and the inner blades
IMPORTANT! Always turn the shaver OFF before replacing the outer foil
and the inner cutter.
Replacing the system outer foil
-Press the system outer foil release buttons and lift the system outer foil
upward to remove it.
-To insert the new system outer foil, press it down until it snaps into place.
