SOHO Internet Security Appliance

Model RF550VPN

User Guide

RouteFinder SOHO Internet Security Appliance

Model RF550VPN

PN S000235E Revision E

This publication may not be reproduced, in whole or in part, without prior expressed written permission

Multi-Tech Systems, Inc. makes no representations or warranties with respect to the contents hereof

and specifically disclaims any implied warranties of merchantability or fitness for any particular

purpose. Furthermore, Multi-Tech Systems, Inc. reserves the right to revise this publication and to

make changes from time to time in the content hereof without obligation of Multi-Tech Systems, Inc. to

notify any person or organization of such revisions or changes.

Revision Date Description

A 11/26/01 Initial release.

B 01/25/02 Changes to some screen captures. Formatting changes.

Renamed and modified the section entitled Configuring Your PC.

Added an Appendix to describe the SSH IPSec Client Setup.

C05/17/02 New examples. New screen captures. SSH IPSec Sentinel new

version (v.1.3). Advanced features are discussed in the User

Guide only.

D10/01/02 Changes to the Virtual Server section, Administrative Settings,

and VPN Connection. Software version 4.63.

E04/16/03 Software version 4.64.

Trademarks

The Multi-Tech logo is a trademark of Multi-Tech System, Inc. Windows is a trademark of Microsoft. All

other trademarks are owned by their respective companies.

World Headquarters

Multi-Tech Systems, Inc.

2205 Woodale Drive

Mounds View, Minnesota 55112

(763) 785-3500 or (800) 328-9717

Fax (763) 785-9874

Internet Address: http://www.multitech.com

Contents

Chapter 1 – Introduction and Description.............................................................................. 5

Key Features ...................................................................................................................... 5

RouteFinder Documentation ............................................................................................... 7

RF550VPN Front Panel ...................................................................................................... 8

RF550VPN Back Panel....................................................................................................... 9

Chapter 2 – Installation...........................................................................................................10

Safety Warnings ................................................................................................................10

System Requirements .......................................................................................................10

Unpacking Your RouteFinder.............................................................................................10

Cabling Your RouteFinder .................................................................................................11

Chapter 3 – Configuring the PC.............................................................................................12

Chapter 4 – Navigating the Screens ......................................................................................19

Chapter 5 – Configuring the RouteFinder Using a Web Browser........................................20

About the Browser Interface...............................................................................................20

Setup Wizard.....................................................................................................................22

Chapter 6 – Managing the RouteFinder Using a Web Browser............................................33

Device Information.............................................................................................................33

Device Status ....................................................................................................................34

Advanced Settings.............................................................................................................37

System Tools.....................................................................................................................47

Chapter 7 – Troubleshooting .................................................................................................54

Chapter 8 – Frequently Asked Questions .............................................................................57

Appendix A – Specifications..................................................................................................60

Appendix B – Installing TCP/IP..............................................................................................61

Appendix C – Tools for Your RF550VPN...............................................................................63

PING..................................................................................................................................63

WINIPCFG and IPCONFIG................................................................................................63

TRACERT..........................................................................................................................63

Appendix D – Warranty and Repairs .....................................................................................64

Appendix E – Regulatory Compliance Information ..............................................................66

FCC Part 15 Regulation.....................................................................................................66

EMC, Safety, and R&TTE Directive Compliance................................................................67

Other Approvals.................................................................................................................67

Appendix F – Technical Support............................................................................................68

Glossary ..................................................................................................................................70

Index ........................................................................................................................................75

Chapter 1 – Introduction and Description

Multi-Tech Systems, Inc. RF550VPN User Guide 5

Chapter 1 – Introduction and

Description

Welcome to the world of Internet security. Your Multi-Tech SOHO RouteFinder VPN Internet security

appliance, Model RF550VPN, is ideal for the small branch office or telecommuter who needs secure

access to the corporate LAN.

In addition to providing a WAN Ethernet port for DSL or cable broadband Internet access, it also offers

both client-to-LAN and

LAN-to-LAN connectivity based on the IPSec protocol. The SOHO RouteFinder supports up to 5

IPSec tunnels and provides 3DES encryption with 700K bps throughput.

The RF550VPN is a cost-effective, easy-to-manage solution that is ideal for small- to medium-sized

businesses through the use of Network Address Translation (NAT). Since NAT provides for the

sharing of a single connection, you save the cost of multiple Internet accounts. See the Glossary for

more about NAT.

Key Features

·One WAN Ethernet port connects to a DSL or cable modem for shared Internet access.

·Supports up to 5 IPSec VPN tunnels for secure LAN-to-LAN and Client-to-LAN access over the

Internet.

·3DES encryption throughput of 700K bps.

·Built-in 4-port 10/100M bps switch.

·Built-in firewall and DHCP services with Network Address Translation (NAT).

·Protects your LAN against Denial of Service (DoS) attacks.

·Internet access controls provide client and site filtering.

·Asynchronous port for automatic dial-backup.

·Network monitoring allows the network administrator to view all incoming and outgoing packets,

status of connections, and specific connection events via a Syslog server.

·Configuration and management using any Web browser.

·Works with H.323 Voice over IP products including Multi-Tech MultiVOIP gateways or Microsoft

NetMeeting.

·Provides email addresses for 10 users with one connection.

·PPPoE support.

·Supports Windows Plug and Play

·Flash memory allows easy firmware upgrades.

·IP address mapping/port forwarding.

·Two-year warranty.

Chapter 1 – Introduction and Description

Multi-Tech Systems, Inc. RF550VPN User Guide 6

·Secure VPN Connections. The SOHO RouteFinder VPN uses the IPSec industry standard

protocol, data encryption, and the Internet to provide high-performance, secure VPN connections.

·For LAN-to-LAN connectivity, the RouteFinder utilizes the IPSec protocol to provide up to 5

tunnels with strong 168-bit 3DES encryption using IKE and PSK key management. In addition, it

provides very high performance with 700K with 3 DES encryption throughput.

·For Client-to-LAN connectivity, Multi-Tech provides optional IPSec client software allowing

traveling employees and telecommuters secure access to the company’s internal network.

·Network Security Protection. Protects a network from invalid access.

·Prevention of DoS (Denial of Service) – Prevents the consequences of the Denial of Service,

such as network traffic congestion or ping of death.

·Hacker Attack Logging – Supports general hacker attack pattern monitoring and logging.

·Filtering – Prevents unauthorized packets from entering or leaving the local network.

·Connects up to 253 Users to the Internet with Broadband Speed. With the SOHO

RouteFinder VPN, up to 253 users are connected to the Internet with only one IP account.

·LAN Segmentation. For added LAN security, the RouteFinder can be used to segment the LAN

by connecting the corporate servers to one RouteFinder Ethernet port and the Internet Servers to

the other Ethernet port. This configuration puts the corporate servers behind a firewall and the

Internet servers outside the firewall. To continue to provide Internet access, connect a modem or

ISDN terminal adapter to the RouteFinder’s asynchronous port.

·Can Be Configured as a DHCP Server. The SOHO RouteFinder VPN can be configured as a

DHCP server to handle request for Internet services and route to and from the ISP. Server and

Client features include:

DHCP Server – Automatically assigns IP information to the network users.

DHCP Client – Automatically gets IP information from the ISP DHCP server.

PPPoE Client – Supports PPPoE client function to connect to the remote PPPoE server.

Idle Time – Lets you set a specified idle-time before automatically disconnecting.

Dial-on-Demand – Eliminates the need for dial-up; automatically logs to your ISP.

The RouteFinder RF550VPN

Chapter 1 – Introduction and Description

Multi-Tech Systems, Inc. RF550VPN User Guide 7

RouteFinder Documentation

The Quick Start Guide

The Quick Start Guide is a shorter version of this User Guide. It is included in printed form with your

RF550VPN. Both guides are intended to be used by systems administrators and network managers.

They provide the necessary information for a qualified person to unpack, cable, and configure the

device for proper operation.

This User Guide

The User Guide can be installed from the CD by clicking Install Manuals on the Installation screen or

downloading the file from our Web site at: http://www.multitech.com

Save or Print the User Guide

Once the User Guide is displayed on screen using Adobe Acrobat Reader, you can save the .pdf

file to your system or print a copy.

Setup Examples and Other Helpful Documents

There are five reference documents to help you setup and use your RF550VPN.

These reference guides are located on the CD that accompanies your RouteFinder and also on

the Multi-Tech Web site.

A Description of the Reference Guides:

1. Setup Examples for the RF550VPN - Document Number S000258C

The four examples show:

·A LAN-to-LAN VPN configuration between two RF550VPNs. One at Site A and one at Site

B. Both RouteFinders use static IP address at their WAN port gateways.

·A LAN-to-LAN VPN configuration between an RF550VPNs at Site A that uses a static IP

through its WAN port and an RF550VPN at Site B that uses a dynamic IP address through

its WAN port.

·A LAN-to-LAN VPN configuration between an RF550VPN at Site A that uses a static IP

address at the WAN port and an RF550VPN at Site B that uses dynamic IP addressing

through a modem connected to the serial port.

·A Client-to-LAN configuration between an RF550VPN at Site A and an SSH IPSec Client.

Each example includes a diagram, a summary chart of input values, an address table you can use

to keep track of your values, and explanations of the Web interface screens.

2. RF550VPN Using a NAT Box with an IPSec Pass-Through - Document Number S000259B

The two example show:

·AN SSH Sentinel IPSec client behind a NAT box doing IPSec Pass-Through to an

RF550VPN.

·An RF550VPN behind a NAT box doing IPSec Pass-Through to another RF550VPN.

3. RF550VPN File Sharing Across VPN - Document Number S000260B

4. Configuring IPSec Tunneling in Windows XP or 2000 and Connecting to an RF550VPN -

Document Number S000261C.

5. Advanced Settings - five examples - Document Number S000268B

Chapter 1 – Introduction and Description

Multi-Tech Systems, Inc. RF550VPN User Guide 8

RF550VPN Front Panel

Link

ACT

100

FDX

COL Data DCD

Serial WAN

Link RXD TXD PWR

1234

RF550VPN Light Panel

LEDs Description

Link ACT Lights when the LAN client is correctly connected to the Ethernet port. Blinks

when there is activity on the Ethernet port.

100/10 Lights when the LAN client is connected at 100MB.

Off when the LAN client is connected at 10MB.

FDX COL

Lights when the LAN client is connected as full duplex.

Off when the LAN client is connected as half duplex. Blinks when there are

collisions on the network.

Serial Data Blinks when the Serial async port is receiving or transmitting data.

Serial DCD Lights when the Serial async port is properly connected to a remote site.

WAN Link Lights when a successful connection to the 10BaseT WAN is established.

WAN RXD Lights when the WAN port is receiving data.

WAN TXD Lights when the WAN port is transmitting data.

PWR Lights when power is being supplied to the router.

Chapter 1 – Introduction and Description

Multi-Tech Systems, Inc. RF550VPN User Guide 9

RF550VPN Back Panel

1234

Serial Reset

WAN

5VDC

RF550VPN Back Panel

Power 5VDC The power port connects the AC power adapter.

10 BT WAN

(10Base-T) The WAN port connects the xDSL modem or cable modem.

Serial The Serial port connects a standard modem (optional).

Reset

The Reset button resets the router to factory defaults. Press and hold button

until the serial LEDs of the RF550VPN blink, and then release the reset button.

Do not press this button unless you want to clear the current data.

Ports 1 - 4 There are 4 LAN ports. You can connect network devices such as PCs, FTP

servers, printers, or anything else you want to put on your network.

Chapter 2 – Installation

Multi-Tech Systems, Inc. RF550VPN User Guide 10

Chapter 2 – Installation

Safety Warnings

1. Never install telephone wiring during a lightning storm.

2. Never install telephone jacks in a wet location unless the jack is specifically designed for wet

locations.

3. This product is to be used with UL and cUL listed computers.

4. Never touch uninsulated telephone wires or terminals unless the telephone line has been

disconnected at the network interface.

5. Avoid using a telephone during an electrical storm. There may be a remote risk of electrical

shock from lightening.

6. Do not use the telephone to report a gas leak in the vicinity of the leak.

7. To reduce the risk of fire, use only No. 26 AWG or larger Telecommunications line cord.

System Requirements

·Microsoft I.E 4.0 or later version or Netscape Navigator 4.0 or later version

·One computer with an installed 10Mbps, 100Mbps or 10/100Mbps Ethernet card

·One Modem or ISDN TA (if a dialup backup connection is needed)

·One RJ-45 xDSL/Cable Internet connection

·TCP/IP protocol installed

·UTP network Cable with a RJ-45 connection

Unpacking Your RouteFinder

The RF550VPN shipping box contains the following items:

·The RouteFinder RF550VPN

·System CD

·Power Supply

·This Quick Start Guide

If any of the items is missing or damaged, please contact Multi-Tech Systems.

Andere Handbücher für RouteFinder RF550VPN

Inhaltsverzeichnis

Andere Multitech Tor Handbücher

Multitech

Multitech MultiConnect Conduit AP MTCAP-LNA3-915 Bedienungsanleitung

Multitech

Multitech 410 Bedienungsanleitung

Multitech

Multitech OneBox Smart Building Bedienungsanleitung

Multitech

Multitech MultiVOIP 100 (MVP110 Bedienungsanleitung

Multitech

Multitech MultiConnect MT100EOCG-G2 Bedienungsanleitung

Multitech

Multitech MultiConnect Conduit MTCDT-LAP3 Montageanleitung

Multitech

Multitech MTAC-003 Montageanleitung

Multitech

Multitech MultiVOIP 800 MVP800 Bedienungsanleitung

Multitech

Multitech MultiVOIP GSM SIP-to-Cellular Gateways... Bedienungsanleitung

Multitech

Multitech Conduit AP MTCAP-L4E1 Bedienungsanleitung

Multitech

Multitech Conduit MTCDT-246L-US-EU-GB Montageanleitung

Multitech

Multitech MULTIVOIP MVP-130 Installationsanleitung

Multitech

Multitech MultiVOIP MVP120 Bedienungsanleitung

Multitech

Multitech Conduit MTCDT-L4E1 Montageanleitung

Multitech

Multitech MULTIVOIP MVP-210 Bedienungsanleitung

Multitech

Multitech MultiVOIP MVP210-SS Bedienungsanleitung

Multitech

Multitech CallFinder CF100FX2 Bedienungsanleitung

Multitech

Multitech MULTIVOIP MVP-130 Bedienungsanleitung

Multitech

Multitech MultiVOIP 400 MVP400 Bedienungsanleitung

Multitech

Multitech ProxyServer MTPSR1-202ST Bedienungsanleitung

Multitech

Multitech MultiVOIP MVP400 Bedienungsanleitung

Multitech

Multitech MultiConnect Conduit IP67 Base Station Handbuch

Multitech

Multitech MULTIVOIP MVP-130 Handbuch

Multitech

Multitech MultiVOIP MVP100GK Gatekeeper Bedienungsanleitung

Beliebte Tor Handbücher anderer Marken

LST

LST M500RFE-AS Bedienungsanleitung

Kinnex

Kinnex Media Gateway Bedienungsanleitung

2N Telekomunikace

2N Telekomunikace 2N StarGate Bedienungsanleitung

Mitsubishi Heavy Industries

Mitsubishi Heavy Industries Superlink SC-WBGW256 Bedienungsanleitung

ZyXEL Communications

ZyXEL Communications ZYWALL2 ET 2WE Bedienungsanleitung

Telsey

Telsey CPVA 500 - SIP Bedienungsanleitung

RTA

RTA 460A-NNA4 Technisches Datenblatt

Shaw

Shaw Gateway HDPVR Bedienungsanleitung

ABB

ABB VSN900 Kurzanleitung

Commander

Commander Pulse Bedienungsanleitung

2N Telekomunikace

2N Telekomunikace ATEUS EasyGate 501309E Bedienungsanleitung

NETGEAR

NETGEAR C6300BD Bedienungsanleitung

Amit

Amit CDW531AM Bedienungsanleitung

HMS

HMS Netbiter EasyConnect EC150 Bedienungsanleitung

Huawei

Huawei EchoLife HG620 Bedienungsanleitung

AT&T

AT&T U-verse 3801 Gebrauchs- und Pflegehandbuch

Logic IO

Logic IO RTCU MX2 turbo Bedienungsanleitung

Suttle

Suttle MediaMAX MXM-521 Bedienungsanleitung
