Multitech MTCBA-E Bedienungsanleitung

MultiModemEDGE

Wireless Modem

MTCBA-E

Quick Start Guide

2 Multi-Tech Systems, Inc. Quick Start Guide

Quick Start

MultiModemWireless EDGE Modem

MTCBA-E

82010743L, Revision D

This publication may not be reproduced, in whole or in part, without prior

expressed written permission from Multi-Tech Systems, Inc. All rights

reserved.

Multi-Tech Systems, Inc. makes no representations or warranty with respect to

the contents hereof and specifically disclaims any implied warranties of

merchantability or fitness for any particular purpose.

Furthermore, Multi-Tech Systems, Inc. reserves the right to revise this

publication and to make changes from time to time in the content hereof

without obligation of Multi-Tech Systems, Inc. to notify any person or

organization of such revisions or changes. Check Multi-Tech’s Web site for

current versions of our product documentation.

Record of Revisions

Revision Date Description

B 01/27/06 Add the fused DC power cable information.

C 06/13/06 Moved the AT Command section to the User

Guide. Changed the format to a booklet.

D 06/22/06 Changed location of Activation Notices. Added

note about current document on Web site.

Trademarks

Trademarks and registered trademarks of Multi-Tech Systems, Inc. include

MultiModem, the Multi-Tech logo, and Multi-Tech. All products or technologies

are the trademarks or registered trademarks of their respective holders.

Technical Support

Country By Email By Phone

France: [email protected] +(33) 1-64 61 09 81

India: support@multitechindia.com +91 (124) 2340780

Europe, Asia, Africa: [email protected] +(44) 118 959 7774

U.S., Canada. all others: [email protected] (800) 972-2439 or

+763-717-5863

World Headquarters

Multi-Tech Systems, Inc.

2205 Woodale Drive

Mounds View, Minnesota 55112

(763) 785-3500 or (800) 328-9717

Fax 763-785-9874

Internet Address: http://www.multitech.com

MultiModem EDGE Wireless Modem

Multi-Tech Systems, Inc. Quick Start Guide 3

Introduction

The purpose of this guide is to show you how to set up your

MultiModem EDGE wireless modem. For information on operating

and configuring your modem see the User Guide, which is available

on the MultiModem CD and the Multi-Tech Web site.

See the Multi-Tech Web site for the lastest version of user

documentation.

General Safety

The modem is designed for and intended to be used in fixed and

mobile applications. “Fixed” means that the device is physically

secured at one location and is not able to be easily moved to

another location. In a “Mobile” application, the device may be moved

regularly from one location to another.

Caution: Maintain a separation distance of at least 20 cm (8 inches)

between the transmitter’s antenna and the body of the user or

nearby persons. The modem is not designed for, nor intended to be,

used in applications within 20 cm (8 inches) of the body of the user.

RF Interference Issues

Avoid possible radio frequency (RF) interference by carefully

following the safety guidelines below.

•Switch OFF the MultiModem when in an aircraft. The use of

cellular telephones in aircraft is illegal. It may endanger the

operation of the aircraft and/or disrupt the cellular network.

Failure to observe this instruction may lead to suspension or

denial of cellular services to the offender, legal action, or both.

•Switch OFF the MultiModem in the vicinity of gasoline or diesel-

fuel pumps or before filling a vehicle with fuel.

•Switch OFF the MultiModem in hospitals and any other place

where medical equipment may be in use.

•Respect restrictions on the use of radio equipment in fuel

depots, chemical plants, or in areas of blasting operations.

MultiModem EDGE Wireless Modem

4 Multi-Tech Systems, Inc. Quick Start Guide

•There may be a hazard associated with the operation of your

MultiModem in the vicinity of inadequately protected personal

medical devices such as hearing aids and pacemakers.

Consult the manufacturers of the medical device to determine if

it is adequately protected.

•Operation of the MultiModem in the vicinity of other electronic

equipment may cause interference if the equipment is

inadequately protected. Observe any warning signs and

manufacturers’ recommendations.

Vehicle Safety

•Do not use your MultiModem while driving.

•Respect national regulations on the use of cellular telephones

in vehicles. Road safety always comes first.

•If incorrectly installed in a vehicle, the operation of MultiModem

telephone could interfere with the correct functioning of vehicle

electronics. To avoid such problems, be sure that the

installation has been performed by qualified personnel.

Verification of the protection of vehicle electronics should be

part of the installation.

•The use of an alert device to operate a vehicle’s lights or horn

on public roads is not permitted.

Package Contents

Single Package (one unit) Bundled Package (multiple units)

1 modem

1 mounting bracket

1 fused DC power cable

1 Quick Start Guide

1 MultiModem CD

Note: You must supply:

Screws for the bracket

An antenna

Each individual package in the

bundle includes the following:

1 modem

1 mounting bracket

1 RS232 cable (15-to-9 pin)

1 antenna

1 power supply

4 rubber feet

1Quick Start Guide

1 MultiModem CD

Note: You must supply screws for

the bracket.

Note: Your wireless provider will supply the SIM card.

MultiModem EDGE Wireless Modem

Multi-Tech Systems, Inc. Quick Start Guide 5

Activate Your Wireless Account

Multi-Tech – A Certified National Activation Agent

Multi-Tech Systems, Inc. is a certified national activation agent for

Cingular and Sprint wireless. For more information about

available data plans and to purchase and activate a wireless data

account, contact Multi-Tech at 888-288-5470.

Pre-Configured Multi-Tech Products

Each Multi-Tech wireless product has been pre-configured to

operate on a wireless network.

Activate Your Wireless Account

Please see the wireless account Activation Notices located on the

MultiModem CD. Choose the one for your wireless network

provider and follow the directions to activate your account.

Phone Numbers for the Wireless Modem

Every wireless modem will have its own unique phone number.

The phone number may simply be given to you by your wireless

service provider or it may be on the SIM card or both. Wireless

provider implementations may vary.

Inserting SIM Card into Holder

The wireless modem requires a SIM card (Subscriber Identity

Module) to operate on a GSM/GPRS or EDGE network. To install

the SIM card:

1. Using your fingernail or a small screwdriver, pry off the SIM

cover.

2. Insert the SIM card into the SIM card slot. The following graphic

illustrates the correct SIM card orientation.

Wireless Service Provider

will give you a SIM card.

Insert SIM card.

Replace cover.

3. Verify that the SIM card fits properly. Then replace the cover.

MultiModem EDGE Wireless Modem

6 Multi-Tech Systems, Inc. Quick Start Guide

Hook up the Antenna, Serial Cable, and Power

•Antenna. Connect a suitable antenna to the SMA connector

(see the User Guide for antenna/RF specifications).

•Serial Cable. Connect one end of the serial cable to the

modem and the other end to a PC.

•Power. Plug the power supply into the wireless MultiModem.

For standard transformer power supply:

∗Connect the AC cord and its transform block.

∗Connect the AC cord plug into the main power outlet.

Note: Units shipped with the universal AC power supply are

not suited for installation in hazardous locations.

For optional direct-DC powering:

∗Connect the fused DC power cable into the power source

on a vehicle or machine in which you are mounting the

MultiModem. Be sure the GNS connection is correct.

∗Connect the red wire to the + positive and the black wire

to the - negative.

MultiModem EDGE Wireless Modem

Multi-Tech Systems, Inc. Quick Start Guide 7

Note

For automotive applications, you can use permanent “+” or

key-switched “+” according to the type of application.

Connect the power supply to its source (for example, in a

mobile situation, to the vehicle’s DC fuse/terminal block).

Warning

Do not connect your wireless modem directly to a

vehicle’s battery for your power source. Doing so

may cause power spikes. If you wish to use the

battery as a power source, add a filtering device to

the DC input.

Optional – Attach the Modem to Flat Surface

The MultiModem is mounted against a flat surface with the mounting

bracket and two mounting screws. Drill the mounting holes at the

desired mounting location. The mounting holes must be separated

by 125mm (4 -15/16 inches) center-to-center. Slide the mounting

brackets into slot on the back side of the MultiModem chassis.

Attach the MultiModem to the surface with two mounting screws.

MultiModem EDGE Wireless Modem

Modem Driver Installation

Compatibility: The wireless modem is compatible with Windows

2000/2003+, Windows XP, and Linux.

Windows: To load the MultiModem wireless modem’s Windows

driver onto your PC, select the Control Panel’s Phone and Modem

Options option. During this installation, you will be required to

browse the MultiModem CD to load the modem’s INF file. This file is

located at the root directory on the MultiModem CD. See the User

Guide for information that will detail each step for loading the driver.

Linux: Linux does not require a driver for serial modems.

AT Commands

AT commands can be used to operate, configure, and query your

modem. An AT Command Reference Guide to the EDGE

commands is included on the MultiModem CD and on the Multi-Tech

Web site.

For examples of how to use some common operating, configuring,

and querying commands, see the User Guide.

Internet Access

See the User Guide for Internet access directions.

Using Mobile PhoneTools

Mobile PhoneTools is a communication software program included

on your MultiModem CD. You can install this program onto your PC

and use it for making Internet connections, voice calls, SMS

messaging, and email. This program allows you to use your wireless

modem hooked up to your PC as if it were a cell phone.

82010743L

Andere Handbücher für MTCBA-E

Dieses Handbuch passt für folgende Modelle

Inhaltsverzeichnis

Andere Multitech Modem Handbücher

Multitech

Multitech MultiModem MTCBA-G-U-F4 Bedienungsanleitung

Multitech

Multitech Multimodem RJ-45 Bedienungsanleitung

Multitech

Multitech QuickCarrier USB-D MTD-H5 Bedienungsanleitung

Multitech

Multitech MultiModem V.90/K56FLEX MT5600ZDX Bedienungsanleitung

Multitech

Multitech QuickCarrier USB-D Bedienungsanleitung

Multitech

Multitech Dragonfly MTQ-LNA7 Bedienungsanleitung

Multitech

Multitech MultiModem MT5634ZBA-V-V92 Bedienungsanleitung

Multitech

Multitech MultiModem MT5634ZPX-PCI-U-NV Bedienungsanleitung

Multitech

Multitech MTD-H5 Bedienungsanleitung

Multitech

Multitech MultiModem MT2834ZDX Series Bedienungsanleitung

Multitech

Multitech MTSMC-E Bedienungsanleitung

Multitech

Multitech GPRS Bedienungsanleitung

Multitech

Multitech MTD-H5 Bedienungsanleitung

Multitech

Multitech MultiModem MT9234ZPX-PCIE Bedienungsanleitung

Multitech

Multitech CC1600 Series Bedienungsanleitung

Multitech

Multitech MultiMobile MT128ZLX-NT Bedienungsanleitung

Multitech

Multitech MultiModem MT5634ZPW-PCI Bedienungsanleitung

Multitech

Multitech 5634 Series Bedienungsanleitung

Multitech

Multitech MultiModem MTCBA-G-UF1 Bedienungsanleitung

Multitech

Multitech MultiModem MT2834ZDX Series Bedienungsanleitung

Multitech

Multitech MultiModem MT5600ZDXV Bedienungsanleitung

Multitech

Multitech MultiModem MTCBA-C Bedienungsanleitung

Multitech

Multitech MultiModem ZPX Bedienungsanleitung

Multitech

Multitech MultiModem iCell Bedienungsanleitung

Beliebte Modem Handbücher anderer Marken

Davicom

Davicom DM562AP Bedienungsanleitung

EpiValley

EpiValley TATA indicom SXC-1080 Bedienungsanleitung

Zte

Zte WiMAX Bedienungsanleitung

Intelimax

Intelimax MA-2060 Bedienungsanleitung

SMC Networks

SMC Networks D3CM1604V Gebrauchs- und Pflegehandbuch

Telstra

Telstra Wi-Fi 4G Advanced Pro X Bedienungsanleitung

Thrane&Thrane

Thrane&Thrane imarsat EXPLORER 300 Bedienungsanleitung

Samsung

Samsung AceLink SAM-335A Bedienungsanleitung

Enfora

Enfora Enabler-G Kurzanleitung zur Einrichtung

iRZ

iRZ ATM2-232 Bedienungsanleitung

Zhone

Zhone 6310 Bedienungsanleitung

Paradyne

Paradyne Hotwire 7976 Bedienungsanleitung

US Robotics

US Robotics 3453C Bedienungsanleitung

MaxTech

MaxTech Plug & Play Internal Voice/FAX/Data/SVD... Bedienungsanleitung

Zte

Zte MF823 Bedienungsanleitung

Four-Faith

Four-Faith F1403 Bedienungsanleitung

Sierra Wireless

Sierra Wireless AIRLINK MP595W Bedienungsanleitung

Gemtek

Gemtek WiMAX WIXFBR-103 Bedienungsanleitung
