Munters EM50 Bedienungsanleitung
Assembly manual
EM50
Air extraction fan
EM50
Spare part list + Assembling guideline
Ag/MIT/IGB-2208-09/14 rev 1.6
© Munters AB, 2018
2
EM50
Assembly manual
Original instructions
Revision 1.6
This document is destined for the user of the apparatus: it may not be reproduced in whole or in part, committed
to computer memory as a file or delivered to third parties without the prior authorisation of the assembler of the
system.
Munters Italy S.p.A. reserves the right to effect modifications to the apparatus in accordance with technical and
legal developments and to make alterations to specifications, quantities, etc.,for production or other reasons,
subsequent to publication.
© Munters AB, 2018
3
chapter page
1. SPARE PART LIST 4
EM50 exploded view 4
Motor exploded view 11
2. ASSEMBLING TOOLS 13
3. ASSEMBLING GUIDELINE 15
Housing assembling 15
Centrifugal system and pulley to propeller assembling 17
Shutter blades assembling 19
Safety meshes assembling 21
CE kit assembling 22
Pyramidal shape mesh assembling 23
Index
All the components and spare parts MUST be storaged in dry and clean
environment.
WARNING
!
© Munters AB, 2018
4
Spare part list 1.
© Munters AB, 2018
5
Ref. Picture Description Q.ty
GROUP1: BODY
1.1 SAFETY MESHES 670X1,338 23X89 GALV. 2
1.2 CENTRAL SUPPORT GALV. 1
1.3 COVER PLATE GALV. 2
1.4 SIDE PANEL 515X1,367X0.8 GALV 2
1.5 TOP PANEL 549X1,457X1 GALV. 1
1.6 VENTURI 1,425X1,425 GALV. 1
1.7 BOTTOM PANEL 549X1,457X1 GALV. 1
1.8 PVC TIE-ROD 2
Spare part listChapter1
© Munters AB, 2018
6
1.9 RIGHT SIDE SHUTTER BEARING ASSEMBLY 9
1.10 RIGHT SIDE SHUTTER BEARING ASSEMBLY WITH SPRING 1
1.11 SHUTTER BLADE GALV. 9
1.12 CENTRAL SHUTTER BLADE GALV. 1
1.13 LEFT SIDE SHUTTER BEARING ASSEMBLY 9
1.14 LEFT SIDE SHUTTER BEARING ASSEMBLY WITH SPRING 1
1.15 EUROEMME STICKER 24.6X180 2
1.16 WARNING STICKER A-1997 35X210 1
1.17 WARNING STICKER B-1997 70X105 1
Spare part listChapter1
© Munters AB, 2018
7
1.18 PRODUCT LABEL G-1998 95X115 1
1.19 NO HIGH PRESSURE STICKER 42X118 2
GROUP2: PULLEY
2.1 CENTRAL PULLEY 1
2.2 HUB 1
GROUP3: BELT
3.1 V-BELT 88-2270 1
GROUP4: MOTOR
SEE MOTOR TABLE (p.10)
GROUP5: PROPELLER
5.1 PROPELLER STAINLESS STEEL/PRECOATED/GALV. 1
Spare part listChapter1
© Munters AB, 2018
8
GROUP6: CENTRIFUGAL SYSTEM
6.1 COMPLETE CENTRIFUGAL SYSTEM SINGLE/MULTI SPEED 1
GROUP7: BOLTS&NUTS
7.1 POP RIVET D6.4X8
Purpose: for housing and Venturi assembling
20
7.2
THREADED BUSH D8X17.5 M8 LONG
Purpose: to insert on the housing
THREADED BUSH D8X12.5 M8 SHORT
Purpose: to insert on the top panel
8
2
7.3
HEXAGON SCREW M8X16 UNI 5739
PLAIN WASHER D8X32 DIN 126
Purpose: to fix motor to the top panel
2
2
7.4
HEXAGON SOCKET SCREW M10X30 UNI 5923
OVAL PLATE 170X40X8
TOOTHED WASHER D10.5X18 UNI 5589
TICK HEXAGON NUT M10X10 UNI 5587
Purpose: to fix the propeller central support to the housing
4
2
4
4
7.5
HEXAGON SCREW M6X30 UNI 5739
FLANGED HEX NUT M6 DIN 6923
Purpose: to fix the central pulley to the hub
4
4
7.6
HEXAGON SCREW M8X25 UNI 5739
TOOTHED WASHER D8.4X15 UNI 6798
TICK HEXAGON NUT M8X8 UNI 5587
Purpose: to fix the propeller to the hub
4
4
4
7.7
HEXAGON SOCKET HEAD CAP SCREW M8X55 UNI 5931
TOOTHED WASHER D8.4X15 UNI 6798
PLAIN WASHER D8.4X17 UNI 659
TICK HEXAGON NUT M8X8 UNI 5587
Purpose: to fix the centfugal system to the propeller
2
2
2
2
Spare part listChapter1
© Munters AB, 2018
9
7.8 WATERPROOF DISTANCE PIECE
Purpose: to distance the hub from the propeller central support.
1
7.9
HEXAGON SCREW M6X16 UNI 5739
CENTRAL SHUTTER BLADE FORK
HEXAGON NUT M6X5 UNI 5588
Purpose: to fix the central shutter blade fork to the central shutter
blade.
2
1
2
7.10
THIN HEXAGON NUT M25X10 UNI 5589
CUP COVER NUT
Purpose: to fix the hub to the propeller central support.
1
1
7.11
SPRING HOOK
Purpose: to fix the two springs of central shutter blade to the side
panel.
2
7.12 KNURLED AXLE D6X33
Purpose: to fix the tie-rod to the central shutter blade fork.
1
7.13
SELF TAPPING SCREW 6.3X19
PLAIN WASHER D6.7X24 UNI 659
Purpose: for cover plate and wire meshes assembling.
15
1
7.14PLASTIC CLIP MESHES
Purpose: to fix the safety meshes to the housing.
4
7.15
RUBBER GROMMET
Purpose: to protect the electric cable on the side panel in
correspondence with the motor slot.
1
Spare part listChapter1
© Munters AB, 2018
10
GROUP8: OPTIONAL KITS
PLASTIC CE PROTECTION KIT
8.1 PLASTIC SAFETY PROTECTION FOR CENTRAL PULLEY 1
8.2 PLASTIC SAFETY PROTECTION FOR BELT 2
8.3 PLASTIC SAFETY PROTECTION FOR MOTOR PULLEY AND FIXING
CLIP 1
8.4 SELF TAPPING HEX SCREW D6.3X19 1
PYRAMIDAL SAFETY MESH KIT
8.5 PYRAMIDAL SAFETY MESH 1
8.6
SELF TAPPING HEX SCREW D6.3X19
METAL CLIPS
Purpose: to fix the pyramidal safety mesh to the housing.
6
6
Spare part listChapter1
