Mustang MPF-L65UA Bedienungsanleitung

Best in Class Flat Wall Mounting Solution

lPost-installation leveling

lClick in place display placement without use of tools

lOptional securing screws locks release latch for additional security

lUniversal design

lVESA compatible

lLow-prole, holds display close to wall for a clean look

lOpen wall plate allows easy access for wiring

lLateral shift for perfect placement

lPre-sorted hardware pack for easy installation to wood studs or concrete

surfaces included

SKU Display Size Max VESA Depth Max Load

MPF-L65UA 32” - 75” 600x400mm 1.4” 200lb

Built-in Kickstand

Kickstand holds display away from wall for

easy cord installation.

Universal Design

Fits any hole pattern up to 660x502mm. Max

VESA hole pattern 600x500mm.

Mounting Hardware

Complete set of display mounting hardware,

labeled for ease of use and ready to go.

Pre-Installed Securing Screws

Easy hook and secure installation and

pre-assembled securing screws makes

installation fast and easy.

Lateral Adjustment

Lateral adjustment functionality for positioning

display in the right spot on the wall.

www.mustangav.com

info@mustangav.com

MPF-L65UA Flat Wall Mount With Post-Install Leveling

Universal mount For 32-75” displays

Adjustable at wall mount with Universal hole pattern (660x502mm) to t a wide

selection of displays. Makes a secure installation quick and easy. Post-installation

leveling feature allows for perfect display positioning even when ceiling is not

perfectly level. Click in place display placement requires no tools to secure the

display on the wall. Pre-installed securing screws are included and may be optionally

engaged for additional theft deterrent. Open wall plate design and kickstand feature

provides easy access to wiring.

TV size range 32” - 75”

Orientation Varies with display

Weight capacity 200lbs (91kg)

Max mounting pattern 660x502mm

Depth 1.4” (35.6mm)

Lateral adjustment Varies with display

Construction High-grade cold rolled steel

Model Number MPF-L65UA

Color Black

Warranty Limited lifetime

Product Weight 4.4lb (2kg)

Attribute Value

Universal at wall mount with post-install leveling

MPF-L65UA Flat Wall Mount

™

TITLE:

DWG.N.O.

F55A

Crimson AV LLC.

www.crimsonav.com

Scale=1:1

Maximum load rating: 200 lbs

www.mustangav.com

info@mustangav.com

Mustang AV

www.mustangav.com
