USB.006 Studio Quality USB Microphone

MXL USB.006

Congratulations on your purchase of the MXL USB.006 which uses a large gold

diaphragm capsule for added warmth. MXL microphones are the result of world-

class engineering and manufacturing capabilities. They are designed to provide you

with outstanding performance and exceptional value. While we encourage you to

review this entire manual, there are a few key points about handling this microphone

that we want you to familiarize yourself with right from the start.

The MXL USB mics are a professional quality, cardioid condenser studio

microphone designed speciﬁcally for recording. Unlike microphones designed for

live performance or lesser dynamic model microphones, this instrument requires

careful handling. Hence, you should observe the following…

ALWAYS: Handle the microphone carefully, avoiding sudden shocks such

as dropping or bumping the microphone into other objects.

ALWAYS: Maintain a distance of approximately 4 – 6 inches when speaking or

User Manual

singing into the microphone. You are encouraged to use a pop ﬁlter for

added protection of the sensitive capsule and to shield the instrument from

saliva and sudden bursts of air.

NEVER: Tap the microphone to check if it’s working. The RED LED behind the

microphone’s protective grill will tell you it’s on and that the correct side is

facing you.

NEVER: Blow into the microphone to check if it’s working. The RED LED behind the

microphone’s protective grill.

By following these few basic handling procedures, you can expect a long and trou-

ble-free relationship with your new microphone. Again, thank you for your purchase

of this outstanding MXL microphone.

A Little Background Information:

MXL condenser microphones use what is known as a cardioid pickup pattern, which

is more sensitive to sound waves arriving at the front of the microphone as opposed

to those arriving from the sides or rear. Unlike other MXL models, this microphone

beneﬁts from being a USB (Universal Serial Bus) device — meaning this is a plug

and play microphone that will interface with Windows and Macintosh comput-

ers without the need for any special drivers. As a USB device, it carries the added

beneﬁt of not requiring an external microphone preamp, as is the case with most

cardioid condenser microphones.

MXL USB.006 User Manual

We’ve already mentioned the importance of proper handling, but should you ﬁnd

yourself recording an outdoor performance, you would be well advised to use a

windscreen as protection for your microphone.

Unpack Your Microphone:

Begin by examining the contents of your MXL USB kit. You should have the

following components:

• Protective vinyl travel case

• One MXL USB.006 microphone

• A 10-foot USB 2.0 high speed cable

• A windscreen

• A desktop microphone stand plus the mounting ring

• Owners manual

• Microphone applications guide

Getting Familiar With Your Microphone:

In addition to speaking or singing into the side of the microphone with the RED LED

facing you, you should also understand the use of the three-position attenuation

switch on the microphone’s back side.

What’s an attenuation switch?

An attenuation switch reduces the signal strength in an electronic device. As the

microphone converts acoustical energy (your voice) into electrical energy (the

signal that feeds your computer), it is possible that a loud,

“boomy” voice, or a vocalist who is really “belting out those

notes” may exceed normal recording levels. In this case,

you will want to reduce the signal strength by using the

microphone’s attenuation switch.

The attenuation switch on the back side of the USB mic

provides three positions: High, Medium, and Low - identi-

ﬁed as: Hi, Med, Lo. Normally, you’ll want to keep the microphone’s attenuation

switch in the Hi position. If, however, you need to “back off” the signal to compen-

sate for a loud voice, simply move the switch to the desired setting. You may also

need to move further away from the microphone which will also reduce the level.

PLEASE NOTE: Recording is a creative process, so there are no hard and

fast rules. Experimentation is the key to best results.

Using the Supplied Desktop Microphone Stand

1. After opening the stand’s tripod leg system and placing it on the table or desk,

loosen the angle adjuster and orient the large portion of the microphone holder

so that it faces upward, or horizontal.

2. Place the base of the microphone into the microphone holder with one hand

while holding it upright with your other hand.

3. While holding the microphone upright and ﬁrmly in one hand, secure the

MXL USB.006 Setup

microphone to the desktop stand by screwing the black mounting ring into the

microphone’s base. The microphone should now sit securely in the desktop

stand.

4. At this point, attach the end of the USB cable that matches the microphone’s

connector. The other end of the cable will connect to your computer’s USB

port.

Connecting the Microphone to Your Computer (Windows)

The MXL USB.006 microphone will operate with both USB 2.0 (high speed USB)

and USB 1.1 data buses. We recommend you connect your microphone directly

to the computer’s USB port as opposed to using a USB hub. USB hubs have been

known to interfere with the performance of various USB devices.

PLEASE NOTE: Audio and video recording can be very taxing to a com-

puter’s resources. For this reason, you should close any and all running

applications that are non essential.

Please take the following steps to get connected:

1. If open, close your audio recording application. You will open it after the

microphone is connected and operational.

2. Connect the remaining end of the USB cable to the computer’s USB port.

Windows will display the New Hardware Found dialog message and your

system may make a sound if your computer uses Window’s system sounds.

3. Allow Windows time to identify the device.

4. In approximately one minute, Windows should display a dialog message stat-

ing that Your New Hardware is Installed and Ready for Use. After this ﬁrst con-

nection, Windows will require just a few moments to identify the microphone.

Congratulations! You are ready to begin recording.

Initial Setup with Windows XP:

1. To select the MXL USB.006 microphone as the default audio input device go to

the Start Menu and select Control Panel.

MXL USB.006

2. Select Sounds and Audio Devices.

3. Click on the Audio tab and select USB audio CODEC as the default device for

sound Recording. Note the Volume button is grayed out. To adjust the gain

of the MXL USB.006 microphone use the three position gain switch located on

the back of the microphone. Click Apply for these changes to take effect.

IMPORTANT NOTE ABOUT SOUND PLAYBACK:

Some computer systems may change the default sound playback device to be the

USB Audio Codec when your MXL Microphone is attached to the computer. By

doing this it will seem as though your computer no longer has any audio output. To

ﬁx this use the drop down menu under Sound Playback to select your standard

soundcard/audio device used for audio playback. Be sure to click the Apply button

after making any changes.

Setup

10 11

MXL USB.006

Initial Setup with Windows Vista and Windows 7:

1. To select the MXL USB.006 as the default audio input device, go to the Start

Menu and select Control Panel.

Your Windows XP computer is now set up to use the MXL USB.006. Some

recording applications will require additional settings to be changed within the

program. Please see your recording software manual for proper setup.

2. Double click the Sound icon.

3. Select the Recording tab, highlight the microphone icon labeled USB Audio

Device and click Set Default.

Setup

12 13

MXL USB.006 Setup

Connecting the Microphone to Your MAC

As is the case with a Windows PC, the MXL USB.006 microphone will operate with

both USB 2.0 (high speed USB) and USB 1.1 data buses. All current Macs operate

with USB 2.0. We recommend you connect your microphone directly to the com-

puter’s USB port as opposed to using a USB hub. USB hubs have been known to

interfere with the performance of various USB devices.

PLEASE NOTE: Audio and video recording can be very taxing to a com-

puter’s resources. For this reason, you should close any and all running

applications that are non essential.

Please take the following steps to get connected:

1. Make certain that any audio applications are closed.

2. Connect the remaining end of the USB cable to the computer’s USB port.

3. To set the USB microphone as the default audio input for audio, click on the

4. To make further adjustments to the recording settings, double-click on the

microphone icon labeled USB Audio Device. Click on the tab labeled

Advanced. From the drop-down menu you can change the sample rate and

bit-depth for audio recording. Please note that you should verify that these

settings match the settings in your recording application.

IMPORTANT NOTE ABOUT SOUND PLAYBACK:

Some computer systems may change the default sound playback device to be the

USB Audio Codec when your MXL Microphone is attached to the computer. By

doing this it will seem as though your computer no longer has any audio output. To

ﬁx this select the Playback tab. Highlight your standard soundcard/audio device

used for audio playback and click the Set Default button.

Your Windows Vista/Windows 7 computer is now set up to use the MXL USB.006.

Some recording applications will require additional settings to be changed within the

program. Please see your recording software manual for proper setup.

14 15

MXL USB.006

Apple icon in the upper left hand of the screen and select System Preferences

as shown the ﬁgure below.

4. Next, click on the Sound icon in the Hardware group as shown in the ﬁgure

below.

Setup

5. After opening the Sound dialog screen, there will be three tabs at the top of the

window, select the Input tab by clicking on it.

6. Then select the USB Audio Codec as the device for sound input as shown in

7. By watching the movements of the Input level meter in this window, you can

now see that the MXL USB microphone is working as you speak into it. This

setting will be saved as the default input whenever the microphone is plugged

in.

16 17

MXL USB.006

Setting the MXL USB mic to record in Garage Band

1. Open Garage Band. This application will be found in either the Dock Bar or by

opening the Apple Finder, clicking on Applications and/or opening Garage

Band.

2. Garage Band opens with the default project “My Song”. Refer to Garage

Band’s user manual to change the default project.

3. “My Song” opens with one software instrument track. To record through the

USB microphone, click on Track on the top of the window bar and select New

Track as shown in the ﬁgure below.

4. Select the tab in the window that opens that says Real Instrument. Then select

the source you will be recording through the microphone, such as vocals or

guitar, as shown in the ﬁgure below (See next page).

5. Click OK.

Setup

6. To select an audio input source for Garage Band, click on Garage Band from

the top menu bar and select Preferences as shown in the ﬁgure below.

18 19

MXL USB.006

7. Then select the Audio/MIDI icon in the top row. From the drop down menu

under Audio Input, select the USB Audio Codec as shown in the ﬁgure below.

8. You will then be asked if you really want to change the driver. Select Yes. The

computer will then say it is initializing the audio driver. Wait until this is done,

then close the window.

9. At this point, you should see the meter move when you speak into the micro-

phone. You can now click on the Record button and record your vocal or

dialog using your microphone.

Warranty

PLEASE NOTE: As long as the microphone is plugged in when Garage

Band is started, the audio input source settings in Garage Band will be

saved until you change them again, even if you close the program or start

a new project.

For More Information:

For additional information about your MXL USB microphone, how to contact techni-

cal support, as well as information on other products manufactured by MXL, please

visit us online at www.mxlmics.com.

Windows is a registered trademark of Microsoft Corporation in the United States and other countries.

WARRANTY: Marshall Microphones are guaranteed against defects in

material and workmanship for one year from date of purchase. Should you

encounter any problem with this unit, promptly contact the company you

purchased it from for assistance. The original dated sales receipt will be

necessary for any warranty claim. Do not send any unit directly to us with-

out prior authorization from our service department! Warranty coverage

is limited to repair or replacement (at our option) of the microphone, and

does not cover incidental damages due to use of this unit, nor damage

caused by accidental misuse of this product.

Dieses Handbuch passt für folgende Modelle

Inhaltsverzeichnis

Andere MXL Mikrofon Handbücher

Beliebte Mikrofon Handbücher anderer Marken

IK Multimedia

IK Multimedia iRig Stream MIC PRO Bedienungsanleitung

DAPAudio

DAPAudio RM-101 Bedienungsanleitung

AKG

AKG CHM 21 Bedienungsanleitung

Sennheiser

Sennheiser evolution wireless series EM 100 Bedienungsanleitung

Sony

Sony C-48 Bedienungsanleitung

GIGAMEDIA

GIGAMEDIA GGM PAMICUHFG Bedienungsanleitung

Shure

Shure WH30TQG Bedienungsanleitung

auna PRO

auna PRO MIC-900 Bedienungsanleitung

AKG

AKG D 3800 Bedienungsanleitung

Shure

Shure KSM141 Bedienungsanleitung

MAIIN SOUND

MAIIN SOUND IIN style Bedienungsanleitung

Earthworks

Earthworks TC25 Bedienungsanleitung

Sennheiser

Sennheiser evolution D1 Bedienungsanleitung

Alesis

Alesis MicLink Wireless Bedienungsanleitung

DSPPA

DSPPA D6234 Bedienungsanleitung

Monacor

Monacor IMG STAGELINE ECM-300B Bedienungsanleitung

Ansr Audio

Ansr Audio Scan16 Bedienungsanleitung

Shure

Shure MXA710 Series Bedienungsanleitung
