National Cycle N20331 Bedienungsanleitung

National Cycle, Inc. O Box 158 Maywood, IL 60153-0158 USA

708-343-0400 / Fax: 708-343-0625 / www.nationalcycle.com / [email protected]

Thank you for purchasing a National Cycle product. Read these instructions carefully and thoroughly before beginning work. Dealers, if installing this wind-

screen for a custo er, please give the this anual upon co pletion. It contains infor ation needed to properly aintain and use this product.

Note:

Tips for facilitation of operation, control and

adjustment, as well as maintenance work.

Attention:

Special notes and cautionary measures which can

prevent damage to the accessory or motorcycle.

CONTENT OF KIT

Quantum® Hardcoated Polycarbonate

V tream® Windscreen for:

Yamaha 900 Tracer GT

N20331, Low Dark Tint

N20332, Mid Light Tint

N20333, Tall Clear

TOOL REQUIRED

5mm Hex Wrench

Figure 1

Figure 2

PREPARATION

1.osition motorcycle securely on its stand.

Remove the OEM windscreen. Hardware will not be

re-used.(5mm Hex Wrench) Figure 1

IN TALLATION

1. Make four screw assemblies using one each:

M5 Screw (2)

Washer (3)

2. Install VStream Windshield onto Motorcycle using

the four screw assemblies. (5mm Hex Wrench)

Figure 2

Tighten screws firmly. Do not overtighten. Do not

use threadlocker.

Item Description Part No. Qty.

(1) VStream® Windscreen 1

BAG#1310

(2) Screw, SS, M5 x 20 51-516220-000 4

(3) Washer, Flat 49-490124-000 4

(2) x 4

(3) x 4

(2)

(3)

(1)

National Cycle, Inc. O Box 158 Maywood, IL 60153-0158 USA

708-343-0400 / Fax: 708-343-0625 / www.nationalcycle.com / [email protected]

CLEANING AND MAINTENANCE

To clean the screen, wash with a clean soft cloth and plenty of warm water and, if

necessary, a non-abrasive soap such as dishwashing liquid. Flannel or soft cham-

ois make good cleaning cloths. Paint, glue residue or grease removal: Moisten

cotton wad with naphtha or turpentine followed by a wash as above.

National Cycle hield Wash™ (N1401-01) makes a good daily cleaner and comes

with a handy travel-size bottle. Shield Wash is safe for all windshields and helmet

visors.

Do not clean polycarbonate in hot sun or high temperatures. Do not clean the

screen with household glass cleaners.

Do not allow brake fluid, alcohol, or strong solvents to contact the screen.

RAIN REPELLENT

Do not use rain protective products made for glass. We recommend National

Cycle’s RainZip® (N1410-01) to keep your windscreen clear in rainy weather.

National Cycle 3-Year Limited Warranty

National Cycle hereby warrants to the original registered owner of a National Cycle polycarbonate windshield for a period of

three years from the date of purchase against breakage. This limited warranty is expressly limited to the replacement of the

polycarbonate windscreen. This limited warranty does not include scratches, coating failure, cosmetic wear and tear, replace-

ment of hardware, or any consequential damages or expenses including labor cost of installation, removal and/or replace-

ment, inconvenience, inbound freight expenses or damage to any other component of the motorcycle or any other acces-

sories. Certain chemicals, generally known as acidic hydrocarbons, are known to cause polycarbonate damage and will not be

covered under this limited warranty. lease refer to the cleaning instructions supplied with all National Cycle windshields.

Visit www.nationalcycle.com for further details or call or write National Cycle

Never ride your motorcycle with loose accessory mounting hardware. Check the hardware for tightness regularly.

Today's motorcycles are built with enough frame rigidity to withstand the moderate loads imposed on them by the foreseeable addition of an

accessory(ies). If an accessory(ies) adversely affects your motorcycle's stability, immediately remove the accessory(ies). Do not ride a motorcycle

that exhibits unsafe handling traits.

Have experienced service personnel correct any problem before riding with the accessory(ies) installed. For further questions concerning handling

problems associated with an accessory(ies), contact your dealer, motorcycle manufacturer, or accessory manufacturer.

unlight reflected off the inside curvature of the windscreen can, at certain times of the day, cause extreme heat buildup on the motor-

cycle’s instruments and possibly even melt them. Exercise care in parking to avoid this. Park your motorcycle facing the sun, or place

an opaque object over the instruments and dash panel.

VStrea ® Windscreen Patent no. 7,387,328

Ask for Shield Wash™ and RainZip® at your local dealer

or visit www.nationalcycle.co .

WARNING
