Nauticam NA-D7200 Bedienungsanleitung

Thank you for your purchase of a NAUTICAM digital camera housing.

At NAUTICAM, we pride ourselves in the a ility to recognise the requirements of

professional as well as amateur underwater photographers and fulfill them

through the innovative designs of our products. We strive to achieve a high level

of user-friendliness y allowing stress-free installation and easy operation of all

important functions of the camera.

Each housing is individually inspected and water pressure tested to ensure

optimum quality.

Please read this manual carefully efore using the housing, this will maximise its

performance as well as its lifetime.

All NAUTICAM Products are warranted against any material and

manufacturing defects for two years from the date of purchase for consumer

use. Please fill in the warranty cards shipped with our housings and

viewfinders at the time of sale and return them to your point of purchase

within a month. If we do not receive the completed warranty card for a

particular product, the warranty period would e assumed to egin from the

day that the product is shipped from our facility. This warranty only applies to

products purchased from authorised NAUTICAM dealers and does not extend

eyond the original retail purchaser.

To return your product for service, please contact your regional authorized

service centre(s). Please note that this warranty only applies when the

product is purchased in the territory where the service centre is located.

NAUTICAM accepts no lia ility for any damage to and defects in the housing

caused y improper use and/or poor maintenance; it is the responsi ility of

the owner to carefully follow the instructions in our manuals.

NAUTICAM does not hold responsi ility for damage, of any nature, to any

equipment used with and/or placed within our products.

NAUTICAM accepts no lia ility for any loss of captured images or the ina ility

to capture images even if it is due to the malfunctioning of our products.

Unauthorised modifications and/or repairs of our products will automatically

invalidate the warranty.

1. NA-D7200 housing

2. Instruction manual

3. Spare silicone ru er main o-ring

4. O-ring remover

5. CR2032 attery (for moisture alarm)

6. Lu ricant

7. Set of Allen keys

8. M10 plastic plug removal tool (for removal of M10 plastic insert)

Spare silicone ru er o-ring

Lu ricant M10 plastic plug removal

tool

CR2032 attery

O-ring remover

1. A water-tight test without the camera inside the housing is highly

recommended when using the system for the first time and after the changing

of port and O-ring(s).

2. Do not use lu ricants from other rands with the silicone ru er O-ring on this

housing, only use the lu ricant provided y NAUTICAM.

3. Discontinue use immediately should you notice any leakage.

4. Store the housing in a ro ust, shock-proof container during transportation;

avoid transporting with any equipment, such as a camera, inside the housing.

5. When travelling y air, do not close the housing if the port is installed, as this

may lead to a pressure difference etween the atmosphere and inside the

housing.

6. Care must e taken when opening the housing, as pressure may uild up inside

the housing which increases the opening force.

7. Do not open the product in a wet or sandy environment. Protect the interior

from moisture and de ris in order to prevent malfunction or leakage.

8. Do not store the product in an environment of high humidity.

9. Do not leave the housing and the camera in direct sunlight for prolonged

periods.

10. Keep out of reach of children, failure to do so could result in injury.

11. Defective products should e shipped to our distri utors for service,

unauthorized disassem ling and/or modifications could result in malfunction

or leakage.

Specifications 6

Identification of Parts 7

Opening and Closing the Housing 11

Preparation of the Housing 12

Installing the Camera 17

Mounting the Port 19

Changing the Vie finder 21

Care and Maintenance 22

Construction

Housing ody: Aluminium alloy

Surface treatment: Hard anodised

Display window: A rasion resistant polycar onate

Grip handles: Polycar onate and ru er

Dimensions

(with handles)

Width: 343 mm

Height: 186 mm

Depth: 132 mm

Weight 2.74kg (without all mounts)

Buoyancy Slightly negative

Depth rating 100 metres

Features

Moisture alarm: Blinking LED and audi le alarm

Viewfinder: 0.66X viewfinder

TTL capa ility:

Nikonos 5-pin ulkheads (optional)

2 optical ulkheads utilising on camera

pop-up flash as commmander

Port mount: Patented port locking lever for easy port

installation.

Multi selector: Allows diagonal movement in addition to

the up/ down/ left/ right functions.

ISO sensitivity

lever:

Allows easy ISO adjustments from the left

handle.

Fn key lever: Allows easy access from the right handle.

1 On/Off control kno 4 Optical ulkhead for stro e

connections x 2

2 Grip handle x 2 5 Port alignment index

3 Port lock/release lever

6 M16 accessory port 12 Mode utton

7 Main command dial 13 M14 accessory port

8 Movie record lever 14 M10 plastic plug (M5 on top, M10

on housing)

9 AF-ON lever 15 Shutter release lever

10 Exposure compensation lever 16 Su -command dial

11 Info lever 17 Fn lever

19 Delete utton 28 Housing lock (R)

20 Menu utton 29 Housing lock safety utton (R)

21 Help/ Protect/ White alance

utton 30 Live view selector lever

22 Housing lock (L) 31 Multi selector

23 Housing lock safety utton (L) 32 Up selection utton

24 Play ack zoom in/ Image quality

utton 33 Left selection utton

25 i utton 34 OK utton

26 Moisture alarm window 35 Right selection utton

27 LV utton 36 Down selection utton
