NCR 7403-K325 Bedienungsanleitung
7403‐K325
NoHingeBaseCover
KitInstructions
IssueA
ii
Revision Record
Issue Date Remarks
ANov2008Firstissue
1
Introduction
ThiskitprovidesareplacementRearBaseCoverforthe7403thatsealsthehingearea
foramorepleasingcosmeticappearanceoftheunitwhenusingtheDisplayWall
Mountkit(7403‐K321)tolocatetheDisplayHeadremotely.
7403-K325 Components
26913
7403-K325
2
7403-K321 Components
26908
Wall Mount Bracket Strain Relief
497-0462353
Screw, 6-32 x 5/16, Phillips, Flat Hd
006-8611269
Wall Mount Bracket
497-0462352
Remote Display Cable (2.5 m)
497-0462914
Remote Display Base
497-0462754
Hole Plug, 1.75"
006-8614720
3
Installation Procedure
1. RemovetheFrontCover.
a. Insert the Security Key and turn it 90 degrees clockwise.
26124a
Security Key
Front Base Cover
b. Pivot the top of the Front Base Cover toward the front of the unit and remove it from
the terminal.
26032a
4
2. RemovetheDisplayHeadfromtheBase.
a. ReleasetheDisplayCablefromtheCableGuides.
b. DisconnecttheDisplayCable(squeezethesidesoftheconnector).
c. LoosentheDisplaythumbscrews(2).
26464a
Display Cable
Thumbscrews
Cable Guides
5
d. DepresstheDisplayReleaseLatches(2)andslidetheDisplayHeadtowardthe
rearoftheterminaltodisengageitfromthechassis.
26151b
Display Latches
6
3. InstalltheWallMountBracketStrainReliefonthebackofthe7403(2screws).
26731
Wall Mount Bracket Strain Relief
Screw, 6-32 x 5/16, Phillips, Flat Hd
4. ConnecttheRemoteDisplayCabletothe7403andsecureitwiththeCableStrain
Relief.AftertighteningtheStrainReliefinserttheendofthestrapintotheslotin
thebracketsoitwillnotinterferewhentheterminalismountedontheWall
Bracket.
26734
Strain Relief
Insert the end of the Strain Relief strap into slot.
7
5. SecuretheWallMountBrackettoaverticalsurfaceusinglagscrews(4).Usethe
bracketasatemplatetomarkthelocationoftheholesorusethedimensions
shownbelow.
Note: Makesureyouinstallthescrewsintothestudsorthatyouusehardwareof
similarstrength.
26411
45 mm
(1.8 in.)
204 mm
(8.0 in.)
258 mm
(10.2 in.)
102 mm
(4.0 in.)
178 mm
(7.0 in.)
7.1 mm
(0.28 in.)
Use 6.4 mm
(0.25 in) bolts.
Note: TheWallMountBracketalsohasstandardVESAmountingholesthatcanbe
usedtomountthe7403onvariousVESAmounts,suchasswingarms.
8
Note: TheWallMountBrackethasthesameholepatternasolderUniversal
MountBrackets(7402‐K562,7402‐K522,and7401‐K533).Thereforeifyouare
replacingaterminalthatismountedonaUniversalMountBracketthensimply
removethebracketandinstalltheWallMountBracketusingthesamescrewsand
mountingholes.
Note: Therecommendedviewingheightfortheterminalis1.2m(48in.)from
thefloor.
26408a
Remove the older Universal Mount Bracket
and use mount 7403-K321 using same screws
and holes.
7403-K321 Wall Mount Bracket
