NEC Express 5800 Bedienungsanleitung

N8800-048F/049F

)

NEC Express5800/320Lb/320Lb-R

User's Guide (Setup

2nd Edition

Updated 04-2005

856-123741-001-B

PROPRIETARY NOTICE AND LIABILITY DISCLAIMER

The information disclosed in this document, including all designs and related materials, is the

valuable property of NEC Corporation (NEC) and /or its licensors. NEC and/or its licensors, as

appropriate, reserve all patent, copyright and other proprietary rights to this document, including all

design, manufacturing, reproduction, use, and sales rights thereto, except to the extent said rights are

expressly granted to others.

The NEC product(s) discussed in this document are warranted in accordance with the terms of the

Warranty Statement accompanying each product. However, actual performance of each such

product is dependent upon factors such as system configuration, customer data, and operator control.

Since implementation by customers of each product may vary, the suitability of specific product

configurations and applications must be determined by the customer and is not warranted by NEC.

To allow for design and specification improvements, the information in this document is subject to

change at any time, without notice. Reproduction of this document or portions thereof without prior

written approval of NEC is prohibited.

Second Printing, January 2004

NEC Corporation

7-1 Shiba 5-Chome, Minato-Ku

Tokyo 108-8001, Japan

Printed in Japan

Keep this User's Guide handy for quick reference when necessary.

SAFETY INDICATIONS

To use NEC Express5800 Series safely, follow the instructions in this User's Guide.

This guide explains components that pose a danger, types of dangers caused by failing to follow the

instructions, and actions taken to prevent them; such components are labeled warning.

This guide and warning labels use “WARNING” and “CAUTION” to indicate a danger depending on

the degree. These terms are defined as follows:

WARNING Indicates a danger that could lead to a death or serious injury.

CAUTION Indicates a danger that could lead to a burn, other injuries or damage to

physical assets.

This guide uses the following three types of symbols to give indications and precautions against a

danger. They are defined as follows:

Indicates that a failure to follow the instructions could cause a danger. Each image

symbolizes a particular type of danger. (Attention)

Indicates what you must not do. Each image symbolizes a particular type of

prohibition. (Prohibited actions)

Indicates what you must do. Each image symbolizes a particular type of action

necessary to avoid a danger. (Mandatory actions)

(Example) Symbol to draw attention

Term indicating a degree of danger

CAUTION

High temperature.

Immediately after the power-off, system components such as hard disk are

very hot. Wait the server to cool down completely before adding/removing

some component.

Symbol indicating a prohibited

action (may not always be

indicated)

Description of a danger

Symbols and its descriptions used in this User’s Guide and warning labels are as follows:

Attention

Indicates a risk of an electric shock.

Indicates a risk of an injury due to heat.

Indicates a risk of catching your fingers.

Indicates a risk of a fire or smoke.

Indicates a general precaution or warning that are not defined herein.

Indicates a risk of losing eyesight due to laser beam.

Indicates a risk of an injury or damage to physical assets due to a hazardous material.

Prohibited actions

Indicates a general prohibition that is not defined herein.

Do not disassemble, repair, or modify the equipment. Otherwise, there is a risk of an

electric shock or fire.

Mandatory actions

Unplug the server. Otherwise, there is a risk of an electric shock or fire.

Indicates a general action to take that is not defined herein. Make sure to follow the

instructions.

For detailed notes to set up the machine safely, refer to “NOTES FOR SAFE HANDLING” on page

1-2.

NOTE: This equipment has been tested and found to comply with the limits for a Class Adigital

device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable

protection against harmful interference when the equipment is operated in a commercial

environment. This equipment generates, uses, and can radiate radio frequency energy and, if not

installed and used in accordance with the instruction manual, may cause harmful interference to

radio communications. Operation of this equipment in a residential area is likely to cause harmful

interference in which case the user will be required to correct the interference at his own expense.

This class A digital apparatus meets all requirements of the Canadian Interference-Causing

Equipment Regulations.

Cet appareil numériqeu de la classeA respecte toutes les exigences du Règlement sur le matériel

brouilleur du Canada.

CE Statement

Warning: This is a Class A product. In residential environment, this product may cause radio

interference, in which case the user may be required to take adequate measures (EN55022).

NOTE: This product provides resistance against hardware faults with its redundant hardware

modules. However, this does not mean complete fault-tolerance is assured. For example,

there is a risk of system down when:

– A fatal fault occurs in software.

– Both modules within a redundant hardware pair break down.

– A fatal fault occurs in a non-redundant component, such as the clock generator circuitry

or the interconnect backplane.

– The entire system is cut off from AC power.

Trademarks

NEC EXPRESSBUILDER, NEC ESMPRO, and NEC Express5800/ft series are trademarks of NEC

Corporation.

Stratus is a registered trademark of Stratus Technologies Bermuda Ltd.

Microsoft, Windows, Windows Server, Windows NT, and MS-DOS are registered trademarks of

Microsoft Corporation in the United States and other countries.

Intel and Pentium are registered trademarks of Intel Corporation.

AT is a registered trademark of International Business Machines Corporation in the United States

and other countries.

VERITAS is a registered trademark of VERITAS Software Corporation in the U.S. and other

countries.

The VERITAS logo and VERITAS Volume Manager are trademarks of VERITAS Software

Corporation.

Adobe, the Adobe logo, Acrobat, and the Acrobat logo are trademarks ofAdobe Systems

Incorporated.

Datalight is a registered trademark of Datalight, Inc. ROM-DOS is a trademark of Datalight, Inc.

Xeon is a trademark of Intel Corporation in the United States. DLT and DLTtape are trademarks of

Quantum Corporation in the United States. QLogic and its logo are trademarks of QLogic

Corporation in the United States. Fast!UTIL is a trademark of QLogic Corporation in the United

States.

All other product, brand, or trade names used in this publication are the trademarks or registered

trademarks of their respective trademark owners.

Microsoft Windows Server 2003 Standard Edition operating system and Microsoft Windows Server

2003 Enterprise Edition operating system are called Windows Server 2003 for short. Microsoft

Windows 2000 Server operating system, Microsoft Windows 2000 Advanced Server operating

system and Microsoft Windows 2000 Professional operating system are called Windows 2000 for

short. Microsoft Windows NT Server network operating system version 3.51/4.0 and Microsoft

Windows NT Workstation operating system version 3.51/4.0 are called Windows NT for short.

Microsoft Windows Millennium Edition Operating System is called Windows Me for short.

Microsoft Windows 98 operating system is called Windows 98 for short. Microsoft Windows 95

operating system is called Windows 95 for short.

Names used with sample applications are all fictitious. They are unrelated to any existing product

names, names of organizations, or individual names.

Notes:

(1) No part of this manual may be reproduced in any form without prior written permission of

NEC Corporation.

(2) The contents of this manual are subject to change without prior notice.

(3) The contents of this manual shall not be copied or altered without prior written permission of

NEC Corporation.

(4) All efforts have been made to ensure the accuracy of all information in this manual. If you find

any part unclear, incorrect, or omitted in this manual, contact the sales agent where you

purchased this product.

(5) NEC assumes no liability arising from the use of this product, nor any liability for incidental or

consequential damage arising from the use of this manual regardless of (4) above.

PREFACE

Welcome to the NEC Express5800/ft series.

NEC Express5800/ft series is a “fault-tolerant (ft)” server focusing on “high reliability” in terms of

fault-tolerance, in addition to “high performance,” “scalability,” and “general versatility” provided

by NEC Express5800 series. In the event of trouble, its dual configuration will allow the system to

instantaneously isolate the failed parts to assure non-stop running; operation will be moved

smoothly from one module to the other, minimizing damage to it. You can use this ft series in a

mission-critical system where high availability is required. By the use of Windows 2003 operating

system, it also provides outstanding openness for general-purpose applications, etc.

To make the best use of these features, read this User's Guide thoroughly to understand how to

operate NEC Express5800/ft series.

ABOUT THIS USER'S GUIDE

This User's Guide helps a user to properly setup and use the product. Consult this guide when you

set up the product.

Keep this manual and the separate volume of User’s guide handy.

This User's Guide is intended for users who have a good knowledge on the basic use of Windows

operating systems and general I/O devices such as a keyboard and mouse.

How to Use This User's Guide

This guide explains the procedures you should perform before you begin system operation after you

purchased the product. Read the guide in order from Chapter 1. If you perform procedures

according to this guide, you will set up the product properly.

Chapter 3 describes how to install the operating system. Chapter 4 describes post-installation

procedures. Chapter 5 explains how to troubleshoot if you cannot set up the product properly. Refer

to “SYSTEM REPAIR” on page 5-2 for details about system configurations and repairs of this

product. Refer to “TROUBLESHOOTING” on page 5-21 if you feel you failed to set up the

product.

See this User’s Guide for details of this product’s operation, and functions and operations of the

hardware and system.

iii

Additional symbols

The following symbols are used throughout this User's Guide in addition to the caution symbols

describe at the beginning.

IMPORTANT: Important points or instructions to keep in mind when using the

server or software

CHECK: Something you need to make sure when using the server of

software

TIPS: Helpful information, something useful to know
