NEC Express5800/120Ri-2 Bedienungsanleitung

NEC

Express5800

120Ri-2

The NEC Express5800/120Ri-2 supports up to two Quad-

Core Intel®Xeon®5300 series processors or up to two

Dual-Core Intel®Xeon®5100 series processors. Powered by

the multi-core Intel®Xeon®processors that enable data-

intensive processing, the 120Ri-2 delivers improved application

performance while achieving energy-efficient operation within

the same physical space.

Delivering up to 48GB (4GB x12) of memory capacity, the

120Ri-2 employs DDR2-667 Fully-Buffered DIMM memory

with ECC, ChipkillTM, mirroring, and on-line sparing

capabilities.

To provide high-performance internal storage, the 120Ri-2

supports Serial Attached SCSI (SAS), with a maximum

capacity of 1.8TB (300GB x6), and enables RAID 0 and 1 as

standard and RAID 5 as option.

In addition to the Low Profile PCI slots (one PCI EXPRESSTM x8

slot and two x4 slots), the 120Ri-2 supports a wide variety of

option boards to further customize the slot mix and to meet

particular needs.By replacing the standard riser card (one PCI

EXPRESSTM x8 slot and two 64bit/100MHz PCI-X slots, Full

Height) with an optional riser card*, one of the following slot

options becomes available:

- Two 64bit/133MHz PCI-X slots and one 64bit/100MHz PCI-X

slot

- Three 64bit/33MHz PCI (5V) slots

* Two different optional riser cards are available for 120Ri-2.

To ensure continuous system operation, hot-swap redundant

power supplies and fans are supported as option.

To enhance RAS (Reliability, Availability and Serviceability)

functionality, the 120Ri-2 comes standard with the

EXPRESSSCOPE Engine.This feature allows the user to

monitor the status of a managed server and operate its KVM

(Keyboard, Video, and Mouse) devices from a remote console

via LAN.

Bundled for easy system management, NEC ESMPRO

monitors and controls system operation from the remote

console, and assists the administrator in troubleshooting the

system.For simple system installation, NEC EXPRESSBUILDER

is attached as an installation support tool.

Product Highlights

www.necam.com/servers

■

Delivers utmost performance for

medium to large businesses, along with

high expandability, reliability, and

availability in a space-saving 2U rack

form factor

■

Supports Multi-Core Intel

Xeon

processors for powerful processing

■

EXPRESSSCOPE Engine provides

enhanced RAS functionality while

optimizing your management cost

NEC

Express5800

120Ri-2

Hardware Specification

www.necam.com/servers

•

Microsoft and Windows Server are either registered trademarks or trademarks of Microsoft Corporation in the United States

and/or other countries.

•

Intel and Intel Xeon are registered trademarks of Intel Corporation or its subsidiaries in the United States and other countries.

•

Linux is a trademark of Linus Torvalds.

•

Red Hat is a registered trademark of Red Hat, Inc. in the U.S.

•

All other products, brands, or trade names used in this document are trademarks or registered trademarks of their respective holders.

•

Specifications are subject to change without notice.

Cat.No. E07BS4

NEC

EXPRESS5800

For further information, please contact:

External Interface

Dimensions (mm)

Weight

Support OS

Power Supply

Cooling Fan

1[1]

6[6]

Total: 6 slots

Full Height:

Standard : PCI EXPRESSTM x8 : 1

64bit/100MHz PCI-X: 2

Option 1

: 64bit/133MHz PCI-X: 2

64bit/100MHz PCI-X: 1

Option 2

: 64bit/33MHz PCI (5V): 3

Low Profile

Standard : PCI EXPRESSTM x8: 1

PCI EXPRESSTM x4: 2

Display x1, Keyboard / Mouse x1

USB2.0 x4, Serial x2

LAN x2, Management LAN x1

445W x 722D x 88H

, 2U rack

21kg (standard), 31kg (max)

Windows Server™2003,

Standard Edition

*6 *7

/ Enterprise Edition

Windows Server™ 2003 R2,

Standard Edition

/ Enterprise Edition

Windows Server™ 2003 R2,

Standard x64 Edition / Enterprise

64 Edition

Red Hat

Linux™

900VA/890W

Standard: 1, Not redundant

Option :Up to 2, redundant, hot-swap

Standard: Not redundant

Option : Redundant, hot-swap

Device Bays [Free]

Disk Drive Bays [Free]

Expansion Slots

Graphics

Maximum

Power Consumption

Server Management Controller

integrated (2MB)

Option: ATI ES1000 (16MB)

Quad-Core Intel®Xeon®Processor

X5355

(2.66GHz/1333MHz FSB/2x4MB L2 Cache)

E5345

(2.33GHz/1333MHz FSB/2x4MB L2 Cache)

Dual-Core Intel®Xeon®Processor

5160

(3GHz/1333MHz FSB/4MB L2 Cache)

5140

(2.33GHz/1333MHz FSB/4MB L2 Cache)

5130

(2GHz/1333MHz FSB/4MB L2 Cache)

5110

(1.60GHz/1066MHz FSB/4MB L2 Cache)

Supported

Intel®5000P

1-2

2GB (1GB x2)

48GB (4GB x12)

(when standard DIMMs are removed.)

CD-RW/DVD combo drive

*10

1000BASE-T x2

(100BASE-TX and 10BASE-T are supported.)

Intel®64

Chipset

CPU

No. of CPU

ODD

Network

Standard

Max

I/F

Memory

Internal

HDD

DDR2-667 FB-DIMM

ECC, Chipkill, mirroring, on-line sparing

Serial Attached SCSI

Supported

1.8TB (300GB x6)

On-board RAID 0, 1

RAID 5 (option)

Hot-Plug

RAID

Requires an optional Disk Array Controller (SAS) [N8103-91, -99, or -105].

Requires an optional Riser Card (PCI-X) [N8116-07].

Requires an optional Riser Card (5V) [N8116-08].

Use a Y-cable provided with the system.

The front bezel and protruding objects are not included.

When included: 485W x 822D x 88H

Supports up to 4GB memory.

SP1 or later.

Contact your local NEC sales company for RAID configurations on Linux.

Go to "NEC Express5800 on Linux" at:

http://www.nec.co.jp/express/linux/index.html

*10

Writing software is not provided for this combo drive.
