NetComm Wireless NWL-25 Kurzanleitung

4G LTE Light Industrial M2M Router

NWL-25

Firmware Upgrade Instructions

NWL-25 Firmware Upgrade Guide

www.netcommwireless.com

v1.4

The information contained herein is proprietary to NetComm Wireless. No part of this document may be translated, transcribed,

reproduced, in any form, or by any means without prior written consent of NetComm Wireless.

Trademarks and registered trademarks are the property of NetComm Wireless Limited or their respective owners. Specifications are

subject to change without notice. Images shown may vary slightly from the actual product.

Note: This document is subject to change without notice.

This document covers the following products:

NetComm Wireless NWL-25-02

DOCUMENT VERSION

DATE

1.0 –Initial document release

16 February 2015

1.1 –Updated for v2.0.29.1 firmware

3 July 2015

1.2 –Updated for v2.0.29.6 firmware

18 December 2015

1.3 –Updated instructions for two separate module upgrade files

18 February 2016

1.4 –Updated for v2.0.29.11 firmware and LR3.3.2.0-21821 module firmware

18 April 2017

www.netcommwireless.com

NWL-25 Firmware Upgrade Guide

v1.4

Requirements

You will need the following equipment to complete the firmware upgrade procedure:

1 x PC with Ethernet port

1 x Ethernet cable

1 x 12VDC 1.5A power adapter

In addition to this, the following files are required:

FILE

SIZE

MD5

SQN3120-NWL25_ECM-ACM-ECM-VERIZON_BOOTROM_LR3.3.2.0-

19816.sfp

9.31

619ef09a5c4207566325f3419852e564

SQN3120-NWL25_ECM-ACM-ECM-VERIZON_LR3.3.2.0-21821.sfp

9.27

c54c1ef2690353e665710cc9f2eee8ce

ntc_nwl25_2.0.29.11.cdi

50.1

69ce0e60c85e42ef2ec280911aed2351

Firmware Upgrade Procedure

The firmware update process must be completed in the order described below. Please follow the instructions carefully.

Note: In order to perform a firmware update, you must be logged into the router with the root manager account. Refer to

the “Advanced configuration” section of the User Guide for details.

To upgrade your router’s firmware:

Connect one end of the RJ45 (Ethernet cable) to the Ethernet port of the NWL-25 router (labelled “LAN”) and the other end

to the Ethernet port of your computer.

Connect the power adapter to the DC power jack of the NWL-25 router and plug it into an available wall socket. Wait

approximately 1 minute for the router to start up.

Ensure that you have the files in the table above on the computer that is connected to the router.

Open a web browser and navigate to http://192.168.1.1

In the Username field, enter root and in the Password field, enter admin then click the Log in button. If you have changed

the root password, enter the configured password.

Select the System item from the top menu bar, select the System configuration item from the menu on the left and then

select the Upload menu item.

Under the File Uploads section, click the Choose a File button. Locate the u-boot image file on your computer named

SQN3120-NWL25_ECM-ACM-ECM-VERIZON_BOOTROM_LR3.3.2.0-19816.sfp and click Open.

NWL-25 Firmware Upgrade Guide

www.netcommwireless.com

v1.4

Click the Upload button. The file is uploaded to the router.

Next to the SQN3120-NWL25_ECM-ACM-ECM-VERIZON_BOOTROM_LR3.3.2.0-19816.sfp file, click the Install link and

then click OK on the confirmation pop-up window. The phone module bootloader is updated and when it is complete the

router displays “Done” and then returns to the list of uploaded files.

Repeat steps 7 and 8 for the router firmware file (ntc_nwl25_2.0.29.11.cdi)

Note: The router may appear not to respond for approximately 3-4 minutes. Do not interrupt the router, disconnect the

power or navigate to other pages of the user interface.

www.netcommwireless.com

NWL-25 Firmware Upgrade Guide

v1.4

When complete, the router reboots and displays the Status page.

the menu on the left and then select the Upload menu item.

Repeat steps 7 and 8 for the module firmware file (SQN3120-NWL25_ECM-ACM-ECM-VERIZON_LR3.3.2.0-21821.sfp)

Next to the module firmware file (SQN3120-NWL25_ECM-ACM-ECM-VERIZON_LR3.3.2.0-21821.sfp), click the Install link

and then click OK on the confirmation pop-up window. The module firmware image is updated and when it is complete

the router displays “Done” and reboots.

After the upgrade has completed, we recommend that you restore the factory default settings of the router. To do this, use

a paperclip or another similarly shaped object to hold down the reset button on the router for 15-20 seconds. The router

reboots with the factory default settings.

Confirm that the upgrade completed successfully by ensuring that the Model, Module firmware and Firmware version fields

on the Status page match those shown below.

NWL-25 Firmware Upgrade Guide

www.netcommwireless.com

v1.4

If they do not match, refresh the page in the browser by pressing CTRL and F5.If the Model and Module firmware

versions do not match, perform step 10 once more.

When all versions appear as in the screenshot above, the firmware upgrade is complete.
