NetComm NB16WV Bedienungsanleitung

NETCOMM LIBERTY™ SERIES

ADSL2+ Wireless N Modem

Router with VoIP

Quick Start Guide

NB16WV

Hardware Installation

The router has been designed to be placed on a desktop. All of the cables exit from the

rear for better organization. The LED indicator display is visible on the front of the router to

provide you with information about network activity and the device status. See below for an

explanation of each of the indication lights.

FRONT PANEL ICON COLOUR STATE DESCRIPTION

Power Blue Off The NB16 is powered off

Flashing The NB16 is currently starting up

On The NB16 is powered on

ADSL Sync Blue Off A connection via an ADSL service is not currently congured

Flashing Connecting to an ADSL service

On Connected via an ADSL service

3G Signal Blue Off A connection via 3G is not currently congured or no 3G dongle found

Flashing Connecting to a 3G service

On Connected via a 3G service

Red Flashing 3G connection failed, attempting to connect again

On SIM Error

Internet Connection N/A Off An Internet connection is not currently congured

Blue Flashing Trafc via the ADSL connection

On Connected via an ADSL service

Red Flashing Trafc via the 3G connection

On Connected via a 3G service

Purple Flashing Trafc via the WAN connection

On Connected via an internet service supplied via the WAN port

ETH 1, 2, 3, 4 - Blue Off No device is connected via the LAN port

Flashing Trafc on LAN port

On Device connected via the LAN port

WAN Blue Off No device connected via the WAN port

On Device connected via the WAN port

WiFi Blue Off WiFi is disabled

Flashing WPS PBC connection available

On WiFi is enabled

VoIP Blue Off VoIP is not congured

Flashing Connecting to VoIP service

On VoIP connection registered

** Please note that all lights will ash simultaneously if a rmware upgrade takes place.

POWER POWER CONNECTOR, CONNECTS TO A DC 12V 1.5A POWER ADAPTER

On/Off Turn the NB16 on or off

USB Attach an external USB storage device to share content with connected computers

3G Dongle Attach a 3G dongle with an active SIM card to utilise a 3G based internet connection

WPS / Reset Hold this button down for over 10 seconds to reset to factory defaults.

Hold and release this button in 3 seconds to enable the WPS push-button connect function.

ETH 1 Connect Ethernet based clients here

ETH 2 Connect Ethernet based clients here

ETH 3 Connect Ethernet based clients here

ETH 4 Connect Ethernet based clients here

WWW Connect an Ethernet based WAN device here

ADSL Connect a telephone line with an active ADSL service here

Telephone Connect a telephone handset here to utilise with a VoIP service

For an ADSL based connection:

Plug one end of the supplied RJ-11 (telephone) cable into the port marked ADSL on the rear of

the NB16 and plug the other end of the cable into the telephone wall socket.

For a 3G based connection:

Insert your 3G dongle (with an active SIM card) into the 3G dongle USB slot on the rear of the NB16.

1. Connect the power adapter to the power socket on the back of the NetComm router.

2. Plug the power adapter into the wall socket and switch on the power.

Wait approximately 60 seconds for the NetComm router to power up.

1. Connect the yellow Ethernet cable provided to one of the yellow LAN ports on the back

of the NB16.

2. Connect the other end of the yellow Ethernet cable to your computer or to another

Ethernet enabled device like a gaming console, a TV or a home cinema system.

Wait approximately 30 seconds for the connection to establish.

Connecting to the router via an

Ethernet Cable

Computer

1. After establishing a wired connection using the previous steps, open your Web browser

and type http://192.168.1.1 into the address bar at the top of the web browser window

and press enter.

2. Enter “admin” into both the username and password elds and click “Login”.

3. The “First-Time Setup Wizard” should then be displayed. Click on the “Yes, Let’s get

started with the wizard” button to congure your NetComm Router.

4. Select your chosen connection type. You can select from:

- ADSL

- 3G

Connecting the Router to

the Internet

ADSL:

Select the ADSL connection type and enter the username/password as supplied by your

ADSL provider

Please note: To enable a backup connection via 3G, tick the checkbox and then enter the appropriate 3G connection

information. This information should be supplied by your 3G provider. You will also need to enter a high availability

website (e.g. – www.google.com) in order to verify if your ADSL based internet connection is currently active.

3G:

Select the APN from the dropdown box (enter your username/password if required) as

supplied by your 3G provider. After selecting the appropriate connection type and entering the

required details, click “Next”.

Telephone

Exchange

5. Select to enable or disable your wireless network, show or hide your wireless network (Hide

SSID) or change the wireless network name (SSID). After making the appropriate changes,

click “Next”. (If you do not want to change the default settings, simply click “Next”)

6. Select the wireless security and wireless security key you would like to use on your

wireless network and click “Next”.

(If you do not want to change the default settings, simply click “Next”)

7. Enter the username and password you would like to use when logging into the web based

user interface. Conrm the new password by entering it a second time in the “Retype

Password” eld and click “Next”.

(If you do not want to change the default settings, simply click “Next”)

8. Review your selected settings and click “Finish”. If you would like to change any of

the settings, click “Back” until you reach the required page and adjust your settings

accordingly. Click “Next” until you reach the summary page again.

The NetComm Router will now attempt to connect using the details you have entered. This

can take up to 2 minutes.

If the connection attempt was successful, the Internet Connection LED on the front of

the unit will then be lit.

1. Ensure WiFi is enabled on your device (computer/laptop/smart phone/gaming console).

2. Scan for wireless networks in your area and connect to the network name that matches

the Wireless network name found on the Wireless Security Card (included in the box).

3. When prompted for your wireless security settings, enter the Wireless security key listed

on your Wireless Security Card (included in the box).

Wait approximately 30 seconds for the connection to establish.

Connecting to the Router via

Wireless (WiFi)

List of Mobile Broadband Service Providers

MOBILE SERVICE APN

Australia

Telstra Telstra.internet

Telstra.pcpack

Telstra.datapack

Telstra.extranet

Optus – Postpaid connect

Optus – Prepaid preconnect

Three – Postpaid 3netaccess

Three – Prepaid 3services

Vodafone – Postpaid vnternet.au

Vodafone – Prepaid vfprepaymbb

Crazy John’s purtona.net

DoDo dodolns1

Blink splns888a1

Internode Internode

Primus primuslns1

TPG internet

Exetel Exetel1

Westnet Splns555a1

iiNet iiNet

New Zealand

Vodafone NZ www.vodafone.net.nz

CallPlus www.callplus.net.nz

Slingshot www.slingshot.net.nz

Telstra Clear www.telstraclear.net.nz

Telecom NZ XT internet.telecom.co.nz
