NETGEAR GA621 Bedienungsanleitung

GA 621

MODEL

Fiber Gigabit Ethernet Card

Reference Guide

Trademarks

NETGEAR® is a registered trademark of NETGEAR,INC.in the United States and other countries.

Microsoft®,Windows® and Windows NT® are registered trademarks of Microsoft Corporation. Other

brand and product names are trademarks or registered trademarks of their respective holders.

Information is subject to change without notice.

Statement of Conditions

In the interest of improving internal design, operational function, and/or reliability,NETGEAR reserves

the right to make changes to the products described in this document without notice.

NETGEAR does not assume any liability that may occur due to the use or application of the product(s)

or circuit layout(s) described herein.

Certificate of the Manufacturer/Importer

It is hereby certified that the NETGEAR Model GA621 Gigabit Ethernet Cards have been suppressed in

accordance with the conditions set out in the BMPT-AmtsblVfg 243/1991 andVfg 46/1992.The opera-

tion of some equipment (for example, test transmitters) in accordance with the regulations may,however,

be subject to certain restrictions.Please refer to the notes in the operating instructions.

Federal Office forTelecommunications Approvals has been notified of the placing of this equipment on

the market and has been granted the right to test the series for compliance with the regulations.

VCCI Statement

This equipment is in the Class B category (information equipment to be used in a residential area

or an adjacent area thereto) and conforms to the standards set by theVoluntary Control Council for

Interference by Data Processing Equipment and Electronic Office Machines aimed at preventing radio

interference in such residential areas.

When used near a radio orTV receiver,it may become the cause of radio interference.

Read instructions for correct handling.

Federal Communications Commission (FCC) Compliance Notice:Radio Frequency Notice

Note: Modifications to this device change it from the original state it was in when tested and

may alter the device so that it no longer complies with FCC testing limitations for Class B digital

devices.According to FCC regulations, the user could be prohibited from operating this equipment

if it is modified.

iii

This device complies with Part 15 of the FCC Rules.Operation is subject to the following two conditions:

1. This device may not cause harmful interference.

2. This device must accept any interference received,including interference that may cause undesired

operation.

Note:This equipment has been tested and found to comply with the limits for a Class B digital

device,pursuant to Part 15 of the FCC Rules.These limits are designed to provide reasonable pro-

tection against harmful interference in a residential installation.This equipment generates,uses,and

can radiate radio frequency energy and, if not installed and used in accordance with the instruc-

tions, may cause harmful interference to radio communications.However,there is no guarantee that

interference will not occur in a particular installation.If this equipment does cause harmful interfer-

ence to radio or television reception, which can be determined by turning the equipment off and on,

the user is encouraged to try to correct the interference by one or more of the following measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and receiver.

• Connect the equipment into an outlet on a circuit different from that to which the receiver is

connected.

• Consult the dealer or an experienced radio/TV technician for help.

EN 55 022 Statement

This is to certify that the NETGEAR Model GA621 Gigabit Ethernet Card are shielded against the

generation of radio interference in accordance with the application of Council Directive 89/336/EEC,

Article 4a.Conformity is declared by the application of EN 55 022 Class B (CISPR 22).

Compliance is dependent upon the use of shielded data cables.

Canadian Department of Communications Radio Interference Regulations

These digital apparatus (NETGEAR Model GA621 Gigabit Ethernet Card) do not exceed the Class B

limits for radio-noise emissions from digital apparatus as set out in the Radio Interference Regulations of

the Canadian Department of Communications.

Règlement sur le brouillage radioélectrique du ministère des Communications

Ces appareils numériques (NETGEAR Model GA621 Gigabit Ethernet Card) respectent les limites de

bruits radioélectriques visant les appareils numériques de classe B prescrites dans le Règlement sur le

brouillage radioélectrique du ministère des Communications du Canada.

Customer Support

For assistance with installing and configuring your NETGEAR system or with questions or problems

following installation:

• Check the NETGEAR Web page at http://www.NETGEAR.com.

• CallTechnical Support at the phone number listed on the Support Information Card that shipped

with your switch.

• EmailTechnical Support at support@NETGEAR.com.

Defective or damaged merchandise can be returned to your point-of-purchase representative.

Internet/World Wide Web

NETGEAR maintains a World Wide Web home page that you can access at the universal resource locator

(URL) http://www.NETGEAR.com. A connection to the Internet and aWeb browser such as Internet

Explorer or Netscape are required.

contents v

CONTENTS

CHAPTER 1

Introduction

Benefits 1-1

Features 1-1

CHAPTER 2

HARDWARE INSTALLATION

Package Contents 2-1

Requirements 2-2

Hardware Description 2-5

Preparing to InstallYour GA621 Fiber Gigabit Ethernet Card 2-6

InstallingYour GA621 Fiber Gigabit Ethernet Card 2-7

Connecting the Network Cables 2-8

CHAPTER 3

Windows 95 OSR2/98/Me DRIVER SOFTWARE

Installing the Driver Software 3-1

Moving the Network Card to a Different Slot 3-6

CHAPTER 4

WINDOWS NT DRIVER SOFTWARE

Installing the Driver Software 4-1

Updating the Driver Software 4-7

Moving the Network Card to a Different Slot 4-8

CHAPTER 5

WINDOWS 2000 DRIVER SOFTWARE

Installing the Driver Software 5-1

Moving the Network Card to a Different Slot 5-6

Removing the Driver Software 5-7

contents vi

CHAPTER 6

NETWARE DRIVER SOFTWARE

Pre-Installation Requirements 6-2

Installing the Driver Software 6-2

Modifying Driver Properties 6-5

InstallationTroubleshooting 6-6

CHAPTER 7

LINUX DRIVER SOFTWARE

File Listing 7-1

Installing the Driver Software 7-2

Testing the Driver Software 7-3

Configurable Parameters 7-4

CHAPTER 8

TROUBLESHOOTING

Checking the Port LEDs 8-1

Using aTroubleshooting Checklist 8-2

APPENDIX A

SPECIFICATIONS

Cable Specifications GA621 (1000BASE-SX) A-1

Technical Specifications A-1

INDEX

contents vii

FIGURE

Figure 2-1. Front Panel of Model GA621 Gigabit Ethernet Card 2-5

TABLES

Table 2-1. Software and Hardware Requirements 2-2

Table 2-2. GA621 LEDs 2-6

Table 2-3. GA621 (1000BASE-SX) Cable Characteristics 2-8

Table 3-1. Parameter Descriptions 3-6

Table 4-1. Parameter Descriptions 4-6

Table 6-1. NetWare Device Installation Methods 6-1

Table 6-2. NetWare Support Files 6-2

Table 6-3. Parameter Descriptions 6-5

Table 7-1. Linux files 7-1

Table 8-1. GA621 (1000BASE-SX) Port LED Activity 8-1

Table 8-2. PCI BIOS Parameters 8-2

introduction 1-1

CHAPTER 1: INTRODUCTION

Congratulations on your purchase of the NETGEAR®GA621 Fiber Gigabit Ethernet

Card.Designed especially for high-performance systems,such as servers and high-end

workstations,it offers 2 gigabits per second (Gbps) of aggregate bandwidth and opti-

mized performance while minimizing network overhead on the host system.This guide

describes the installation and use of the GA621 for operation within a Microsoft®

Windows®95OSR2,Windows®98,Windows®NT,Windows®2000,Windows®Me,

Novell®NetWare,or Red Hat®Linux environment.

This chapter provides information about the features of the GA621.It connects

your PCI-compliant server or workstation to a Gigabit Ethernet network, incorporat-

ing a new technology that transfers data at a rate of 1 Gbps or 1000 megabits per

second (Mbps) over 62.5/125 or 50/125 Micron multimode fiber with SC

connectors.

Benefits

Performance is optimized and network overhead on the host system is minimized

with the use of the GA621 Fiber Gigabit Ethernet Card.

The GA621 has demonstrated interoperability with all major Gigabit Ethernet equip-

ment on the market that is compliant with IEEE 802.3z standards. In addition,

because the GA621 uses standard Ethernet frame and Media Access Control (MAC)

formats,

it provides full compatibility with Fast Ethernet network equipment through network

switches from a variety of vendors,including NETGEAR.

Features

The key features of the GA621 Fiber Gigabit Ethernet Card are:

• Full-duplex operation (2,000 Mbps:1,000 Mbps each way) with DMA (Direct

Memory Access) Gigabit Ethernet interface (IEEE 802.3z)

introduction 1-2

• Duplex SC fiber connector for 62.5-micron or 50-micron multimode fiber cable

• Interoperability with existing Fast Ethernet equipment compliance with the

following standards and protocols:

– IEEE 802.3z 1000BASE-SX Gigabit Ethernet

– IEEE 802.3u Fast Ethernet

• Standard Ethernet frame size (up to 1,518 bytes)

• Jumbo frames support

• 33/66 MHz,32/64-bit PCI bus master (Local Bus Revision 2.2 compliant)

with adaptive DMA channels

• Two independent DMA channels for simultaneous read and write operations;

as a bus master,the network card requests access to the PCI bus instead of

waiting to be polled

• Software driver support for Windows 95 OSR2,Windows 98,Windows NT,

Windows 2000,Windows Me,NetWare 4.2, 5.0,5.1, and Red Hat Linux 6.0, 6.1,

6.2,7.0 and 7.1.

• Universal dual-voltage signaling (3.3 V and 5 V)

CHAPTER 2: HARDWARE INSTALLATION

This chapter provides information about the package contents,system requirements,

and installation of the NETGEAR GA621 Fiber Gigabit Ethernet Card.

Package Contents

The product package contains:

• GA621 Fiber Gigabit Ethernet Card

•

GA621 Fiber Gigabit Ethernet Card Driver and Documentation CD

•

GA621 Fiber Gigabit Ethernet Card Installation Guide

• Warranty & Registration Card

• Support Information Card

Call your reseller or customer support in your area if there are any wrong, missing,

or damaged parts.Refer to the Support Information Card for the telephone number

of customer support in your area.

Keep the Support Information Card, along with the original packing materials.

Use the packing materials to repack the GA621 Fiber Gigabit Ethernet Card

if you need to return it for repair.

To qualify for product updates and product warranty registrations,fill out the

registration information within 30 days of purchase.For priority service, register

online on the NETGEAR Web page at:

http://www.NETGEAR.com

You can also fill out and return the Warranty & Registration Card that is included in

your product package.

hardware installation 2-1
