NETGEAR ReadyDATA 5200 Bedienungsanleitung
350 East Plumeria Drive
San Jose, CA 95134
USA
May 2012
201-15135-02
ReadyDATA 5200
Installation Guide
2
ReadyDATA 5200
© NETGEAR, Inc. All rights reserved.
No part of this publication may be reproduced, transmitted, transcribed, stored in a retrieval system, or translated
into any language in any form or by any means without the written permission of NETGEAR, Inc.
NETGEAR, the NETGEAR logo, and Connect with Innovation are trademarks and/or registered trademarks of
NETGEAR, Inc. and/or its subsidiaries in the United States and/or other countries. Information is subject to
change without notice. Other brand and product names are registered trademarks or trademarks of their
respective holders. © NETGEAR, Inc. All rights reserved.
Technical Support
Thank you for choosing NETGEAR. To register your product, get the latest product updates, get support online, or
for more information about the topics covered in this manual, visit the Support website at
http://support.netgear.com.
Phone (US & Canada only): 1-888-NETGEAR
Phone (Other Countries): Check the list of phone numbers at
http://support.netgear.com/app/answers/detail/a_id/984.
Statement of Conditions
To improve internal design, operational function, and/or reliability, NETGEAR reserves the right to make changes
to the products described in this document without notice. NETGEAR does not assume any liability that may
occur due to the use, or application of, the product(s) or circuit layout(s) described herein.
Declaration of Conformity
For complete DoC, visit the NETGEAR EU Declarations of Conformity website at
http://support.netgear.com/app/answers/detail/a_id/11621/.
GNU General Public License (GPL)
For GNU General Public License (GPL) related information, visit
http://support.netgear.com/app/answers/detail/a_id/2649.
This symbol was placed in accordance with the European Union Directive 2002/96 on the Waste
Electrical and Electronic Equipment (the WEEE Directive). If disposed of within the European
Union, this product should be treated and recycled in accordance with the laws of your jurisdiction
implementing the WEEE Directive.
3
2. Installation Overview
Thank you for purchasing the NETGEAR ReadyDATA™ 5200. This installation guide includes
the following topics:
• Review the Package Contents
• Prepare the Installation Site
• Install Optional NICs
• Install the System in a Rack
• Attach Cables
• Power Up the System
• Register Your Product
For more information about the ReadyDATA 5200, see the following resources:
• ReadyDATA 5200 Hardware Manual and ReadyDATA OS Software Manual.Available
on the Resource CD that came with your product. You can also obtain these manuals by
clicking the ?icon in the 5200’s Dashboard user interface.
• Support web site. Visit www.netgear.com.
Installation Overview
4
ReadyDATA 5200
Review the Package Contents
Your ReadyDATA 5200 package includes the following items:
• 5200 chassis
• Power cables
• Rack-mount hardware
• Resource CD
If you purchased an optional expansion disk array, the separate package contains the
following items:
• Expansion disk array chassis
• SAS cascading cable
• Rack-mount hardware
You can purchase other accessories for your 5200, including these:
• Single-drive pack (SATA, SAS, or SSD)
• Six-drive pack (SATA or NL-SAS)
• 1 GbE or 10 GbE (SFP+) network interface card
If you purchased any of these accessories, they are in separate boxes from the 5200.
Prepare the Installation Site
Keep the following considerations in mind as you install your unit:
• Ambient operating temperature. If the unit is installed in a closed or multi-unit rack
assembly, the ambient operating temperature of the rack environment might be greater
than the ambient temperature of the room. Therefore, consideration should be given to
installing the equipment in an environment compatible with the maximum rated ambient
temperature.
• Reduced airflow. Mount the equipment into a rack so that the amount of airflow required
for safe operation is not compromised.
• Mechanical loading. Mount the equipment into a rack so that a hazardous condition
does not arise due to uneven mechanical loading.
• Circuit overloading. Consider the equipment’s connection to the power supply circuitry
and the effect that any possible overloading of circuits might have on overcurrent
protection and power supply wiring. Consider equipment nameplate ratings when
addressing this concern.
Installation Overview
5
ReadyDATA 5200
• Reliable ground. This product requires that a reliable ground be maintained at all times.
To ensure this, ground the rack itself. Pay particular attention to power supply
connections other than the direct connections to the branch circuit (for example, the use
of power strips).
• Setup location. This product is intended for installation in a restricted access location
(dedicated equipment rooms, service closets, and the like) only.
• Clearance. Leave enough clearance in front of the rack (about 25 inches) to enable you
to open the front door completely and in the back of the rack (about 30 inches) to allow for
sufficient airflow and ease in servicing.
Install Optional NICs
The ReadyDATA 5200 comes with two 1 GbE NICs and one 10 GbE SFP+ NIC installed on
the motherboard, so it can connect to your LAN or the Internet without optional additional
NICs.
If you purchased one or more 1 GbE or 10 GbE NICs (the ReadyDATA supports up to two
additional NICs), follow these steps to install them before you rack-mount your 5200.
To install optional NICs:
1. Ensure that the 5200 is powered down.
2. Remove the cover from your 5200.
3. If you are installing one NIC, use the J5 PCI Express slot.
4. If you are installing a second NIC, use the J8 PCI Express slot.
5. Replace the cover.
Installation Overview
6
ReadyDATA 5200
Install the System in a Rack
Use the rack-mount hardware included with your ReadyDATA 5200 or your expansion disk
array to install it in a rack.
Note that the left and right rails are not identical. The left rail is marked with a sticker bearing
the letter L, and the right rail is marked with a sticker bearing the letter R. Each rail has an
outer rail, a middle rail, and an inner rail. Do not exchange the inner rails of the left and right
rails.
While installing the system into a rack, keep the ball bearing shuttle locked at the front of the
middle rail during installation.
A minimum of two people are required for safe installation of the system.
DANGER:
A unit with installed drives can weigh more than 75 pounds. To avoid
injury or damage to the equipment, perform the rack-mount installation
with appropriate assistance.
Precautions
Follow these rack-mount precautions:
• Ensure that the leveling jacks on the bottom of the rack are fully extended to the floor with
the full weight of the rack resting on them.
• In single-rack installations, stabilizers should be attached to the rack. In multiple-rack
installations, the racks should be coupled together.
• Always make sure the rack is stable before extending a component from the rack.
• You should extend only one component at a time; extending two or more simultaneously
might cause the rack to become unstable.
• Review the electrical and general safety precautions that came with the components you
are adding to your chassis.
• Determine the placement of each component in the rack before you install the rails.
• Install the heaviest components on the bottom of the rack first, and then work up.
• Use a regulating uninterruptible power supply (UPS) to protect the ReadyDATA 5200
from power surges and voltage spikes and to keep your system operating in case of a
power failure.
• Allow any hot-plug drives and power supply modules to cool before touching them.
• Always keep the rack’s front door and all panels and components on the servers closed
when not servicing them to maintain proper cooling.
Installation Overview
7
ReadyDATA 5200
Rack Installation
Read these instructions in their entirety before you begin.
To install the system into a rack:
1. Using the left rail, pull the inner rail out of the outer rail until it is fully extended.
2. Press the locking tab down to release the inner rail and separate it from the outer and
middle rails.
PULL
Installation Overview
8
ReadyDATA 5200
3. Place the inner rail firmly against the side of the system chassis, ensuring that the hooks on
the chassis are straight and aligned with the holes in the inner rail.
4. Slide the inner rail forward until it clicks into the locked position.
5. (Optional) Secure the inner rail to the chassis with a screw.
6. Repeat Step 1 through Step 5 with the right rail.
7. Using the left rail, Press the locking tab and push the middle rail back into the outer rail.
Installation Overview
9
ReadyDATA 5200
8. Hang the hooks on the front of the left rail on the rack holes, and if necessary, secure with
screws.
9. Repeat with the back of the left rail, extending as necessary.
10. Repeat Step 7 through Step 9 with the right rail.
Installation Overview
10
ReadyDATA 5200
11. Using the left rail, pull the middle rail out of the front of the outer rail, ensuring that the ball
bearing shuttle is locked at the front of the middle rail.
12. Repeat Step 11 with the right rail.
