Netvox RA08D Series Bedienungsanleitung

RA08D Series

Wireless Multifunction CO2 Sensor

RA08D Series

User Manual

This document contains proprietary technical information which is the property of NETVOX Technology. It shall be

maintained in strict confidence and shall not be disclosed to other parties, in whole or in part, without written

permission of NETVOX Technology. The specifications are subject to change without prior notice.

Table of Contents

1. Introduction......................................................2

2. Appearance.......................................................2

3. Features ............................................................3

4. Setup Instruction ..............................................3

4.1 On/Off.........................................................3

4.2 Network Joining .........................................3

4.3 Function Key ..............................................4

4.4 Sleeping Mode............................................4

5. Data Report ......................................................5

5.1 Example of ReportDataCmd ......................6

5.2 Example of ConfigureCmd.........................9

5.3 ReadBackUpData ..................................... 11

5.4 Example of GlobalCalibrateCmd .............12

5.5 Set/GetSensorAlarmThresholdCmd.........13

6. RA08D Series and Sensors Configuration.....15

7. Important Maintenance Instructions ..............16

1. Introduction

RA08D series is a Class A device based on LoRaWAN open protocol. It could be used for temperature, humidity, CO2, PIR, air

pressure, illuminance, TVOC, PM2.5, CH2O, O3, and CO detection. Data collected by sensors would be shown on the E-ink

display. Users are able to know the data through one quick peek.

Note:

For more information of RA08D series and its sensors, please refer to 6. RA08D and Sensor Configuration.

2. Appearance

PIR

Light Sensor

E-ink Display

Indicator

Function Key

Mounting Bracket

3. Features

SX1262 wireless communication module.

Powered by DC 12V adapter.

Compatible with LoRaWANTM Class A device.

Frequency hopping spread spectrum.

Support third-party platforms: Actility/ThingPark, TTN, MyDevices/Cayenne.

4. Setup Instruction

4.1 On/Off

Power on Connect to power supply

Turn on

The green indicator flashes once.

Reboot

Press and hold the function key for 5 seconds until green indicator flashes once.

Then release the function key. The device will automatically shut down after the indicator flashes

10 times.

Reset to factory setting

Press and hold the function key for 10 seconds until green indicator flashes fast for 20 times.

The device will reset to factory setting and automatically shut down.

Power off Disconnect the power supply

Note

1. 5 seconds after power on, the device will be in engineering test mode

. On/off interval is suggested to be about 10 seconds to avoid the interference of capacitor

inductance and other energy storage components.

4.2 Network Joining

Never joined the network

Turn on the device to search the network to join.

The green indicator stays on for 5 seconds: Success

The green indicator remains off: Fail

Had joined the network

(without factory resetting)

Turn on the device to search the previous network to join.

The green indicator stays on for 5 seconds: Success

The green indicator remains off: Fail

Fail to join the network User is recommended to check the device verification information on the gateway or consult your

platform server provider.

4.3 Function Key

Press and hold for 5 seconds

Turn off and Restart

Long press the function key for 5 seconds and the green indicator flashes 10 times.

Release the function key and the green indicator flashes 10 times.

The green indicator remains off: Fail

Press and hold for 10 seconds

Reset to factory setting / Turn off

The green indicator flashes 20 times: Success

The green indicator remains off: Fail

Short press The device is in the network: green indicator flashes once, screen refreshes once, and send a data

report.

The device is not in the network: screen refreshes once and the green indicator remains off

4.4 Sleeping Mode

The device is on and

in the network

Sleeping period: Min Interval.

When the reportchange exceeds the setting value or the state changes, the device will send a data

report based on the Min Interval.

The device is on but

not in the network

Note:

1. Users should disconnect the power supply when the device is not in use.

2. Users are recommended to check the device verification information on the gateway

5. Data Report

After powering on, the device would refresh the information on the screen and send a version packet report along with an uplink

packet.

The device sends data based on the default configuration before any configuration is done. Please do not send commands without

turning on the device.

CO2:

Fluctuation of CO2data caused by delivery and storage time could be calibrated.

Please refer to 5.2 Example of ConfigureCmd for detailed information.

TVOC:

(1)Two hours after powering on, the data sent by devices with TVOC sensors are for reference only.

(2) If the data is way higher or below the setting, the device should be placed in an environment with fresh air for 24 to 48 hours

until the data is back to normal value.

(3) TVOC level:

Very good

< 150 ppm

Good

150-500 ppm

Medium

500-1500 ppm

Poor

1500-5000 ppm

Bad

> 5000 ppm

The information shown on the E-ink display:

The information shown on the screen is based on user’s choice of sensor. It would be refreshed by pressing the function key,

triggering

the PIR, or refreshed based on the report interval.

// FFFF of reported data and “—” on the screen means the sensors are turning on or disconnection and errors of sensors.

Default Setting:

Max Interval: 0x0384 (900s)

Min Interval: 0x0384 (900s)

// The Max and Min Intervals shall not be less than 5 minutes for devices with CH2O and O3 sensors.

// The Max and Min Intervals shall not be less than 3 minutes for the rest of the devices.

IRDisableTime: 0x001E (30s)

IRDectionTime: 0x012C (300s)

Data collecting and transmission:

(1)Join the network:

Press the function key (indicator flashes once) / trigger PIR, read data, refresh screen, report detected data (based on the report

interval)

(2)Without joining the network:

Press the function key / trigger PIR to get data and refresh the information on the screen.

// The interval of data packets would be 10 seconds by default.

// When the ack = 0x01, the intervals would be 30 seconds.

Note:

Please refer Netvox LoRaWAN Application Command document and Netvox Lora Command Resolver

http://www.netvox.com.cn:8888/cmddoc to resolve uplink data.

Data report configuration and sending period are as follows:

Min. Interval

(Unit: second)

Max. Interval

(Unit: second) Detection Interval Report Interval

180 to 65535 180 to 65535 MinTime Exceed the setting value: report based on the

MinTime or the MaxTime interval

5.1 Example of ReportDataCmd

FPort: 0x06

Bytes 1 Byte 1 Byte 1 Byte Var (Fix = 8 Bytes)

Version DevieType ReportType NetvoxPayLoadData

Version– 1 bytes –0x01——the Version of NetvoxLoRaWAN Application Command Version

DeviceType– 1 byte – Device Type of Device

ReportType –1 byte–the Presentation of the NetvoxPayLoadData，according the devicetype

NetvoxPayLoadData– Fixed bytes (Fixed =8bytes)

Tips

1. Battery Voltage:

If the battery is equal to 0x00, it means that the device is powered by a DC power supply.

2. Version Packet:

When Report Type=0x00 is the version packet, such as 01A0000A01202307030000, the firmware version is 2023.07.03.

3. Data Packet:

When Report Type=0x01 is data packet.

(If the device data exceeds 11 bytes or there are shared data packets, the Report Type will have different values.)

4. Signed Value:

When the temperature is negative, 2's complement should be calculated.

Device

Type

Report

Type NetvoxPayLoadData

RA08D 0xA0

0x01

Battery

(1Byte)

unit:0.1V

Temperature

(Signed 2Bytes)

unit:0.01°C

Humidity

(2Bytes)

unit:0.01%

CO2

(2Bytes)

Unit:1ppm

Occupy

(1Byte)

0:Un Occupy

1: Occupy

0x02

Battery

(1Byte)

unit:0.1V

AirPressure

(4Bytes)

unit:0.01hPa

Illuminance

(3Bytes)

unit:1Lux

0x03

Battery

(1Byte)

unit:0.1V

PM2.5

(2Bytes)

Unit:1 ug/m3

PM10

(2Bytes)

Unit: 1ug/m3

TVOC

(3Bytes)

Unit:1ppb

0x04

Battery

(1Byte)

unit:0.1V

HCHO

(2Bytes)

unit:1ppb

(2Bytes)

unit:0.1ppm

(2Bytes)

unit:0.1ppm

Reserved

(1Byte)

fixed 0x00

0x05

Battery

(1Byte)

unit:0.1V

ThresholdAlarm (4Bytes)

Bit0:TemperatureHighThresholdAlarm,

Bit1: TemperatureLowThresholdAlarm,

Bit2:HumidityHighThresholdAlarm,

Bit3: HumidityLowThresholdAlarm,

Bit4:CO2HighThresholdAlarm,

Bit5:CO2LowThresholdAlarm,

Bit6: AirPressure HighThresholdAlarm,

Bit7: AirPressure LowThresholdAlarm,

Bit8: illuminanceHighThresholdAlarm,

Bit9: illuminanceLowThresholdAlarm,

Bit10: PM2.5HighThresholdAlarm,

Bit11: PM2.5LowThresholdAlarm,

Bit12: PM10HighThresholdAlarm,

Reserved

(3Byte)

fixed 0x00

Uplink:

Data #1 01A00100097A151F020C01

1st byte (01): Version

2nd byte (A0): DeviceType 0xA0 －RA08D Series

3rd byte (01): ReportType

4th byte (00): Battery－DC power supply

5th 6th byte (097A): Temperature－24.26℃, 97A (Hex)= 2426 (Dec), 2426*0.01℃ = 24.26℃

7th 8th byte (151F): Humidity－54.07%, 151F (Hex) = 5407 (Dec), 5407*0.01% = 54.07%

9th 10th byte (020C): CO2－524ppm , 020C (Hex) = 524 (Dec), 524*1ppm = 524ppm

11th byte (01): Occupy－1

Data #2 01A002000001870F000032

1st byte (01): Version

2nd byte (A0): DeviceType 0xA0 －RA08D Series

3rd byte (02): ReportType

4th byte (00): Battery－DC power supply

5th - 8th byte (0001870F): Air Pressure－1001.11hPa, 0001870F (Hex) = 100111 (Dec), 100111 * 0.01 hPa = 1001.11 hPa

9th - 11th byt e(000032): illuminance－50Lux, 000032 (Hex) = 50 (Dec), 50 * 1Lux = 50Lux

Data #3 01A00300FFFFFFFF000007

1st byte (01): Version

2nd byte (A0): DeviceType 0xA0 －RA08D Series

3rd byte (03): ReportType

4th byte (00): Battery－DC power supply

5th-6th (FFFF): PM2.5 －FFFF (N/A)

7th-8th byte (FFFF): PM10－FFFF (N/A)

9th-11th byte (000007): TVOC/VOC－7ppb, 000007 (Hex) = 7 (Dec), 7*1ppb = 7ppb

Bit13: PM10LowThresholdAlarm,

Bit14: TVOCHighThresholdAlarm,

Bit15: TVOCLowThresholdAlarm,

Bit16: HCHOHighThresholdAlarm,

Bit17: HCHOLowThresholdAlarm,

Bit18:O3HighThresholdAlarm,

Bit19: O3LowThresholdAlarm,

Bit20:COHighThresholdAlarm,

Bit21: COLowThresholdAlarm,

Bit22-31:Reserved

Data #4 01A00400000AFFFFFFFF00

1st byte (01): Version

2nd byte (A0): DeviceType 0xA0 －RA08D Series

3rd byte (04): ReportType

4th byte (00): Battery－DC power supply

5th-6th (000A): HCHO－10ppb, 000A (Hex) = 10 (Dec), 10 * 1ppb = 10ppb

7th-8th byte (FFFF): O3－FFFF (N/A)

9th-10th byte (FFFF): CO－FFFF (N/A)

11th byte (00): Reserved

Data #5 01A0050000000001000000

1st byte (01): Version

2nd byte (A0): DeviceType 0xA0 －RA08D Series

3rd byte (05): ReportType

4th byte(00): Battery－DC power supply

5th-8th (00000001): ThresholdAlarm－1 = 00000001(binary), bit0 = 1 (TemperatureHighThresholdAlarm)

9th-11th byte (000000): Reserved

5.2 Example of ConfigureCmd

FPort: 0x07

Bytes 1 1 Var (Fix = 9 Bytes)

CmdID DeviceType NetvoxPayloadData

CmdID– 1 byte

DeviceType– 1 byte – Device Type of Device

The devicetype is listed in Netvox LoRaWAN Application Devicetype.doc

NetvoxPayLoadData– var bytes (Max=9bytes)

Description Device Cmd

Device

Type NetvoxPayloadData

ConfigReport

Req

RA08D

0x01

0xA0

MinTime

(2bytes Unit:s)

MaxTime

(2bytes Unit:s)

Reserved

(2Bytes,Fixed 0x00)

ConfigReport

Rsp 0x81

Status

(0x00_suA0ess)

Reserved

(8Bytes,Fixed 0x00)

ReadConfig

ReportReq 0x02 Reserved

(9Bytes,Fixed 0x00)

ReadConfig

ReportRsp 0x82 MinTime

(2bytes Unit:s)

MaxTime

(2bytes Unit:s)

Reserved

(2Bytes,Fixed 0x00)

Andere Handbücher für RA08D Series

Dieses Handbuch passt für folgende Modelle

Inhaltsverzeichnis

Andere netvox Sicherheitssensor Handbücher

netvox

netvox RA02A Bedienungsanleitung

netvox

netvox R718WB2 Bedienungsanleitung

netvox

netvox R313LA Bedienungsanleitung

netvox

netvox S31502 Bedienungsanleitung

netvox

netvox R718WBA Bedienungsanleitung

netvox

netvox ZB11D Bedienungsanleitung

netvox

netvox R718WB Bedienungsanleitung

netvox

netvox R313CB Bedienungsanleitung

netvox

netvox Z801TXB Bedienungsanleitung

netvox

netvox R311A Bedienungsanleitung

netvox

netvox R718PA9 Bedienungsanleitung

netvox

netvox R718WB2 Bedienungsanleitung

netvox

netvox R718B Bedienungsanleitung

netvox

netvox RA02C Bedienungsanleitung

netvox

netvox R313W Bedienungsanleitung

netvox

netvox R718WA2 Bedienungsanleitung

netvox

netvox R311W Bedienungsanleitung

netvox

netvox R718WB Bedienungsanleitung

netvox

netvox R718WAA Bedienungsanleitung

netvox

netvox R718B2 Bedienungsanleitung

netvox

netvox R313CC Bedienungsanleitung

netvox

netvox R313WA Bedienungsanleitung

netvox

netvox R313WA Bedienungsanleitung

netvox

netvox S31501 Bedienungsanleitung

Beliebte Sicherheitssensor Handbücher anderer Marken

THORLABS

THORLABS PDA10JT Bedienungsanleitung

Waeco

Waeco UV-DETECT Bedienungsanleitung

Intermatic

Intermatic IOS-DSIMF Bedienungsanleitung

urmet domus

urmet domus 1083 Bedienungsanleitung

Siemens

Siemens AZL66 Series Bedienungsanleitung

BTI

BTI Profiline Multi Finder Bedienungsanleitung

Challenger

Challenger SL01 Bedienungsanleitung

DMP Electronics

DMP Electronics 1122INT Bedienungsanleitung

Rielta

Rielta Ladoga MK-RK Bedienungsanleitung

Mirion Technologies

Mirion Technologies ACCURAD PRD Bedienungsanleitung

Bosch

Bosch DS835 Bedienungsanleitung

DBI SALA

DBI SALA EZ Stop Bedienerhandbuch

Lamptime

Lamptime ST05C Bedienungsanleitung

Ubiquiti

Ubiquiti MFI-MSC Bedienungsanleitung

Subsite

Subsite 910R Montageanleitung

Satel

Satel OPAL Pro Bedienungsanleitung

Aleph

Aleph XC-1XTEU Bedienungsanleitung

Pima

Pima LARIS QUAD Bedienungsanleitung

netvox RA08D Series Bedienungsanleitung

Beliebte Sicherheitssensor Handbücher anderer Marken
