Tools Needed

Helpline

If you have any problems with this product or require

any replacement fittings please contact Customer

Services Tel: 0333 777 8999

ASSEMBLY INSTRUCTIONS.

Regrettably self assembly items cannot be returned once assembly is part or fully completed unless the item is found

to be faulty. Should you need to return the unassembled product, please repack in the original packaging.

IMPORTANT

• Carefully check that you have all parts before beginning assembly.

• We suggest you spend a short time reading through this leaflet and then follow the simple step-by-step

instructions.

• Keep fittings out of children's reach and keep children well away from the construction area.

IMPORTANT - RETAIN FOR FUTURE REFERENCE - READ CAREFULLY.

801708 / 488034 MILANO GLOSS SMALL WALL

801708 / 488034 MILANO GLOSS SMALL WALL 801708 / 488034 MILANO GLOSS SMALL WALL

801708 / 488034 MILANO GLOSS SMALL WALL

• All assembly fixings should always be tightened properly and periodically check all fixings and tighten if necessary.

PRODUCT INFORMATION

• Keep fittings out of children's reach and keep children well away from the construction area.

• We recommend that the packaging is used to protect the surfaces during assembly.

• A minimum of two persons is required to assemble this product.

• The maximum weight this unit can hold safely is 20 kg.

• Made from partical board & MDF with a pvc finish.

CARE INSTRUCTIONS

• Never drag pieces of furniture across the floor as this will cause damage to the joints.

• Avoid keeping furniture in direct sunlight or close to any heat sources as this can cause cracking, discolouration or

warping.

• Do not put hot dishes directly on the surfaces of the item.

• Made in China.

• Ensure the product is protected with mats and coasters when items are placed on the surfaces, to prevent

scratching or damage.

• Any spills should be removed immediately with a soft clean damp cloth and dried immediately.

• Do not rub or scrub the surface when cleaning.

•Gloss finishes are prone to light surface scratch and it is therefore very important

that you care for this item correctly.

• For general cleaning, periodically dust with a soft clean lint-free cloth or a soft micro fibre cloth. Please note soft

cloths (including yellow dusters) contain abrasive fibres which can lightly scratch the surface, if in doubt please try

your cloth in an inconspicuous area of the furniture first to assess its suitability. A sample of a suitable cloth for

cleaning is included within the hardware pack

• Do not use furniture polish.

Page 1 of 7

FITTINGS

PARTS

right left

DX16CX2BX10AX8 EX16 FX12

(6*30mm)

LX1

(8*30mm)

GX8 HX2 IX8 JX1 KX1

(25mm)

Please note: Remove the protective film after assembly of this product unless it is stated in

the steps to do so - this will prevent accidental scratches during assembly

1. Insert 16 x cambolts (E) into panels 1, 2, 5 & 6 and

tighten with a screwdriver.

STEP ONE

Page 2 of 7

1. Glue and insert 2 x wooden dowels (A) into panel 1

and attach panels 7(x2) to panel 1.

2. Insert 2 x camlocks (D) into panels 7(x2) and tighten

with a screwdriver.

Ensure the arrow indicator is pointing towards the

panel edge and ensure the assembly bolt locates

properly into the camlock before turning

1. Glue and insert 3 x wooden dowels (B) into panel 4

and attach panel 4 to panel 1.

2. Insert 2 x camlocks (D) into panel 4 and tighten with

a screwdriver.

Ensure the arrow indicator is pointing towards the

panel edge and ensure the assembly bolt locates

properly into the camlock before turning

STEP TWO

STEP THREE

1. Glue and insert 2 x wooden dowels (A) into panels

7(x2) .

2. Glue and insert 3 x wooden dowels (B) into panel 4

and attach panel 2 to panels 4 & 7(x2).

3. Insert 4 x camlocks (D) into panels 7(x2) & 4 and

tighten with a screwdriver.

Ensure the arrow indicator is pointing towards the

panel edge and ensure the assembly bolt locates

properly into the camlock before turning

STEP FOUR

Page 3 of 7

1. Glue and insert 2 x wooden dowels (A) into panel 5

2. Glue and insert 2 x wooden dowels (B) into panel 5

and attach panel 5 to panels 1, 2 & 4.

3. Insert 4 x camlocks (D) into panels 1 & 2 and tighten

with a screwdriver.

Ensure the arrow indicator is pointing towards the

panel edge and ensure the assembly bolt locates

properly into the camlock before turning

1. Glue and insert 2 x wooden dowels (A) into panel 6

2. Glue and insert 2 x wooden dowels (B) into panel 6

and attach panel 6 to panels 1, 2 & 4.

3. Insert 4 x camlocks (D) into panels 1 & 2 and tighten

with a screwdriver.

Ensure the arrow indicator is pointing towards the

panel edge and ensure the assembly bolt locates

STEP FIVE

STEP SIX

properly into the camlock before turning

1. Use 12 x stickers (F) to cover the camholes .

STEP SEVEN

Page 4 of 7

1. Attach 2 x hinges (H) to panel 3 with 4 × screws (G)

by using a screwdriver until tight.

2. Attach panel 3 to panel 2 with 4 × screws (G)

through 2 x hinges (H) by a screwdriver.

To align doors use the adjustment diagram

below.

LATERAL

VERTICAL

FRONT- TO-BACK

STEP EIGHT

1. Attach hinge (J) to panels 3 & 6 with 4 × screws (I)

by using a screwdriver until tight.

2. Attach hinge (K) to panels 3 & 5 with 4 × screws (I)

by using a screwdriver until tight.

STEP NINE

Page 5 of 7

1. Use the template (L) provided to mark on the wall

the position of the fixings.

NB: Place the template over the back of the wall unit to

ensure that the holes match the position of the hooks

before drilling into your wall

2. Use a spirit level to check that the fixings are level .

3. Drill three holes and insert an appropriate wall plug

into each. Insert the screws and tighten,leaving the

screw head exposed by about 1/4 inch(6mm)

Warning:

Always ensure intended wall area to be drilled is

free from hidden electrical wires, water and gas

pipes.

NB: Wall fixings are not included - please source

suitable fixings for your wall type. If in doubt

please consult a qualified trades person.

STEP TEN

PLEASE SELECT WHICH ORIENTATION YOU WANT THE UNIT TO BE HANG ON THE WALL.

STEP ELEVEN

1. Lift the wall cupboard into position ensuring that

the fixing clips attached to the wall are firmly hooked

over the screw heads. Check the wall unit periodically

to see that no fitting has loosened and needs

attention.

PLEASE SELECT WHICH ORIENTATION YOU WANT THE UNIT TO BE HANG ON THE WALL.

Page 6 of 7

1. Use the template (L) provided to mark on the wall

the position of the fixings.

NB: Place the template over the back of the wall unit to

ensure that the holes match the position of the hooks

before drilling into your wall

2. Use a spirit level to check that the fixings are level .

3. Drill four holes and insert an appropriate wall plug

into each. Insert the screws and tighten,leaving the

screw head exposed by about 1/4 inch(6mm)

Warning:

Always ensure intended wall area to be drilled is

free from hidden electrical wires, water and gas

pipes.

NB: Wall fixings are not included - please source

suitable fixings for your wall type. If in doubt

please consult a qualified trades person.

STEP THIRTEEN

STEP FOURTEEN

PLEASE SELECT WHICH ORIENTATION YOU WANT THE UNIT TO BE HANG ON THE WALL.

1. Lift the wall cupboard into position ensuring that

the fixing clips attached to the wall are firmly hooked

over the screw heads. Check the wall unit periodically

to see that no fitting has loosened and needs

attention.

Next Retail Ltd, Desford Road, Leicester, LE19 4AT

PLEASE SELECT WHICH ORIENTATION YOU WANT THE UNIT TO BE HANG ON THE WALL.

Next Retail Ltd, Desford Road, Leicester, LE19 4AT

Page 7 of 7
