Nibe F1145 series Kurzanleitung

F1145 for heating systems, any accessories as well as additional heaters

NIBE AB - Energy systems Box 14, SE-285 21 Markaryd www.nibe.eu

ODM GB 1010-1

M10788

PAGE 1 (5)

Application

Houses with water-borne heating systems.

Function

F1145 prioritises hot water charging. The

heat pump is controlled by the outdoor

sensor (BT1) in combination with the in-

ternal ow sensor. The internal immersion

heater is connected automatically when the

energy requirement exceeds the capacity of

the heat pump.

Heating system 2

The external circulation pump (EP21-GP20)

is dimensioned for the under oor heat-

ing system’s demand. The ow through

the heat pump is adjusted using the heat

medium pump and any applicable control

valve.

NOTE!! In cases where the system volume

in the heating system is below 20 l/kW

(compressor output) and/or heating me-

dium ow is choked uncontrolled, a UKV

tank is installed as a volume increaser. For

only under oor heating systems and UKV,

3 connections on the UKV tank must be

used according to its installation instruc-

tions.

Note! This is an outline diagram. Actual

installations must be planned according to

applicable standards.

See the appropriate “Installer manual” for

more information.

Outline diagram

-QM31

-QM32

-FL3

-QM42

-QM12

-CM2

-HQ1

Lables according to IEC 61346-2

-QM34

-XL15

-BT1

-EB100

F1145

-FL2

-CM1

-EP12

Designations according to standard IEC 61346-2

Ground water collector

FLM

Passive cooling

Heating system 2

Pool

UKV

Extra hot water

Hot water circulation

Hot tap water

Ext. electr. heating add.

Ext. oil heating add.

Ext. district heating add.

F1145 for heating systems, any accessories as well as additional heaters

NIBE AB - Energy systems Box 14, SE-285 21 Markaryd www.nibe.eu

ODM GB 1010-1

M10788

PAGE 2 (5)

Pos Name Specication Manufacturer Art no. Remarks

BP6 Manometer, Brine

BT1 Temp.sensor, Outdoor NIBE Included in F1145

BT6 Temp. sensor, HW charging NIBE Included in F1145

CM1 Expansion vessel, closed, HM

CM2 Level vessel Brine Level vessel at open system. Level vessel included in

F1145.

CM3 Expansion vessel Brine Expansion vessel at closed system.

CP1 Hot water heater VPB 200 NIBE 088 515

EB100 Heat pump F1145 NIBE

EP12 Collector, Brine

FL2 Valve, Safety, HM

FL3 Valve, Safety, Brine NIBE Included in F1145

HQ1 Particle filter HM NIBE Included in F1145

QM12 Valve, Filling, Brine

QM21 Valve, Bleeding, Brine

QM31 Valve, Shut-off, HM-f

QM32 Valve, Shut-off, HM-r

QM34 Valve, Shut-off, Brine-r

QM42 Valve, Shut-off, Brine-r

XL 15 Filling set, Brine Brine R25/G32 NIBE 089 368/089 971 KB R25 (max 12 kW), KB G32 (max 30 kW)

Hot water circulation

AA5 Accessory card AXC 40 NIBE 067 060 Required if the ground water pump or hot water

circulation is to be connected to F1145 at the same

time as the buzzer alarm. The relay outputs on the

accessory card can have a max load of 2A (230V) in

total.

EB2 Water heater

GP11 Pump, Circulation, HW

QN12 Valve, 4 way

QN3 Valve, Regulator

List of Components

F1145 for heating systems, any accessories as well as additional heaters

NIBE AB - Energy systems Box 14, SE-285 21 Markaryd www.nibe.eu

ODM GB 1010-1

M10788

PAGE 3 (5)

Pos Name Specication Manufacturer Art no. Remarks

QN4 Valve, Regulator

RM3 Valve, Non-return

RM4 Valve, Non-return

Extra Hot Water

EB2 Hot water heater COMPACT NIBE

Ground water collector

AA5 Accessory card AXC 40 NIBE 067 060 Required if the ground water pump or hot water

circulation is to be connected to F1145 at the same

time as the buzzer alarm. The relay outputs on the

accessory card can have a max load of 2A (230V) in

total.

EP4 Heat exchanger, groundwater

EP12 Collector, Brine

HQ2 Particle filter Brine

UKV

CP5 Buffer vessel (UKV) UKV 100/200/300/500 NIBE Size varies depending on heat pump and system

volume.

Passive cooling

AA5 Accessory card NIBE Included in PCS 44

BT64 Temp. sensor, Cooling flow line NIBE Included in PCS 44

BT65 Temp. sensor, Cooling return line NIBE Included in PCS 44

EP13 Supply air coil/Fan convector

EQ1 Passive cooling system PCS 44 NIBE 067 063

GP13 Pump, Circulation, cooling NIBE Included in PCS 44

QN18 Valve, Mixing, cooling NIBE Included in PCS 44

RM5 Valve, Non-return NIBE Included in PCS 44

Heating system 2

AA5 Accessory card NIBE Included in ECS 40

BT2 Temp.sensor, HM, Flow NIBE Included in ECS 40

BT3 Temp.sensor, HM, Return NIBE Included in ECS 40

List of Components cont’d

F1145 for heating systems, any accessories as well as additional heaters

NIBE AB - Energy systems Box 14, SE-285 21 Markaryd www.nibe.eu

ODM GB 1010-1

M10788

PAGE 4 (5)

List of Components cont’d

Pos Name Specication Manufacturer Art no. Remarks

EP21 Climate system 2 ECS40 NIBE 067 061

GP20 Pump, Circulation, HM Lower shunt NIBE Included in ECS 40

QN11 Valve, Mixing, addition NIBE Included in ECS 40

FLM

AZ1 Air unit NIBE FLM NIBE 067 011

RM6 Valve, Non-return NIBE Included in NIBE FLM

RN11 Valve, Adjusting NIBE Included in NIBE FLM

Pool

AA5 Accessory card NIBE Included in POOL 40

BT25 Temp.sensor, HM, Flow, External NIBE Included in POOL 40

BT51 Temp.sensor, Pool NIBE Included in POOL 40

CL11 Pool kit POOL 40 NIBE 067 062

EP5 Exchanger pool

GP9 Pool, pump

GP10 Pump, Circulation, HM

HQ4 Particle filter Pool

QN19 Valve, Three-way NIBE Included in POOL 40

RM2 Valve, Non-return

RN10 Valve, Regulator

External Electricity/Oil/District heating addition

AA5 Accessory card AXC 40 NIBE 067 060

BT25 Temp.sensor, HM, Flow, External

BT52 Temp.sensor, Boiler

CM4 Expansion vessel, closed, HM

EB1 Immersion heater ELK 15, ELK 213 NIBE 069 022/069 500

EM1 Oil, gas, pellets or wood boiler

EP7 Exchanger, District heating

FL2 Valve, Safety, HM

F1145 for heating systems, any accessories as well as additional heaters

NIBE AB - Energy systems Box 14, SE-285 21 Markaryd www.nibe.eu

ODM GB 1010-1

M10788

PAGE 5 (5)

List of Components cont’d

Pos Name Specication Manufacturer Art no. Remarks

GP10 Pump, Circulation, HM

KA1 Auxiliary relay HR10 NIBE 089 423

QM40 Valve, shut-off

QM41 Valve, shut-off

QN11 Valve, Mixing valve, addition

RM1 Valve, Reversing

RM5 Valve, Reversing

RN11 Valve, Adjusting, external
